Existing Stations Where High Speed Two Trains Will Call

The June 2020 Edition Of Modern Railways has an article called HS2 Minister Backs 18 tph Frequency, which gives a detailed diagram of the route structure of High Speed Two and it is possible to summarise the stations, where High Speed Two trains will call.

• Carlisle – 3 tph – 400 metres – Split/Join
• Chesterfield – 1 tph – 200 metres
• Crewe – 2 tph – 400 metres – Split/Join
• Darlington – 2 tph – 200 metres
• Durham – 1 tph – 200 metres
• East Midlands Hub HS2 – 7 tph – 400 metres – Split/Join
• Edinburgh Haymarket – 2.5 tph – 200 metres
• Edinburgh Waverley – 2.5 tph – 200 metres – Terminal
• Glasgow Central – 2.5 tph – 200 metres – Terminal
• Lancaster – 2 tph – 200 metres – Terminal
• Leeds HS2 – 5 tph – 400 metres
• Liverpool Lime Street – 2 tph – 200 metres – Terminal
• Lockerbie – 1 tph – 200 metres
• Macclesfield – 1 tph – 200 metres – Terminal
• Manchester Airport HS2 – 5 tph – 400 metres
• Manchester Piccadilly HS2 – 5 tph – 400 metres
• Motherwell – 0.5 tph – 200 metres
• Newcastle – 3 tph – 200 metres – Terminal
• Oxenholme – 0.5 tph – 200 metres
• Penrith – 0.5n tph – 200 metres
• Preston – 4 tph – 400 metres
• Runcorn – 2 tph – 200 metres
• Sheffield – 2 tph – 200 metres
• Stafford – 1 tph – 200 metres
• Stoke-on-Trent – 1 tph – 200 metres
• Warrington Bank  Quay – 1 tph – 200 metres
• Wigan North Western – 1 tph – 200 metres
• York – 4 tph – 200 metres

Note.

1. HS2 after the station name indicates a new station for High Speed Two
2. tph is trains per hour
3. 0.5 tph is one train per two hours (tp2h).
4. 200/400 metres is the maximum length of trains that will call.
5. Terminal indicates that trains will terminate at these stations.
6. Split/Join indicates that trains will split and join at these stations.

These are more detailed thoughts on how existing stations will need to be modified.

Train Lengths

Before, I look at the individual stations, I’ll look at the train lengths.

• High Speed Two train – Single – 200 metres
• High Speed Two train – Pair – 400 metres
• Class 390 train – 11-car – 265.3 metres
• Class 390 train – 9-car – 217.5 metres
• Class 807 train – 7-car – 182 metres
• Class 810 train – 5-car – 120 metres
• Class 810 train – Pair of 5-car – 240 metres
• InterCity 125 – 2+8 – 220 metres
• InterCity 225 – 9-car – 245 metres
• Class 222 train – 4-car – 93.34 metres
• Class 222 train – 5-car – 116.16 metres
• Class 222 train – 7-car – 161.8 metres
• Class 222 train – 4-car+5-car – 209.5 metres
• Class 222 train – 5-car+5-car – 232.32 metres

These are the thoughts on the individual stations.

Carlisle

Carlisle station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.

I estimate the platforms are about 380 metres, but it looks like, they could be lengthened, without too much difficulty.

As High Speed Two trains to the North of Carlisle will be 200 metres long, there would probably be no need for platform lengthening North of Carlisle, as these trains are shorter than the Class 390 trains, that currently work the routes to Edinburgh and Glasgow.

Carlisle station is step-free, has good secondary rail connections and is within walking distance of the city centre.

The only thing it needs, is a connection to Edinburgh on a rebuilt Borders Railway.

Chesterfield

Consider.

• Chesterfield station will need to handle 200 metre trains.
• Chesterfield station may be rebuilt for High Speed Two.
• Chesterfield station can handle an InterCity 125, which is 220 metres.
• It will need to handle a pair of Class 810 trains, which would be 240 metres.

This Google Map shows Chesterfield station.

Note.

1. The slow lines passing the station on the Eastern side.
2. There are two long through platforms and a third bi-directional platform on the down slow line.

There is space to build two long platforms for High Speed Two, but is it worth it, when one one tph will stop?

• According to High Speed Two’s Journey Time Calculator, trains will take just twelve minutes between Sheffield and Chesterfield stations.
• This compares with 12-15 minutes for the current diesel trains.
• The distance between the two stations is 14 miles, which means that a twelve minute trip has an average speed of 70 mph.
• If there are still two tph to St. Pancras, there will be four tph, that run fast between the Sheffield and Chesterfield stations, of which three will stop at Chesterfield.

I think this could result in a simple and efficient design for the tracks between Sheffield and South of Clay Cross, where High Speed Two joins the Erewash Valley Line.

Chesterfield station is step-free.

Crewe

Crewe station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.

There have been references to rebuilding of Crewe stations, but it does appear that some platforms are over 300 metres long.

Darlington

Darlington station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Durham

Durham station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Edinburgh Haymarket

Edinburgh Haymarket station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Edinburgh Waverley

Edinburgh Waverley station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Glasgow Central

Glasgow Central station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Currently, Avanti West Coast runs the following services to Glasgow Central.

• One tph from London Euston calling at Warrington Bank Quay, Wigan North Western, Preston, Lancaster, Oxenholme Lake District (1tp2h), Penrith (1tp2h) and Carlisle.
• One tp2h from London Euston calling at Milton Keynes Central, Coventry, Birmingham International, Birmingham New Street, Sandwell and Dudley, Wolverhampton, Crewe, Warrington Bank Quay, Wigan North Western, Preston, Lancaster, Oxenholme Lake District (1tp2h), Penrith (1tp2h) and Carlisle.

High Speed Two is proposing to run the following trains to Glasgow Central.

• Two tph from London Euston calling at Old Oak Common, Preston and Carlisle.
• One tp2h from Birmingham Curzon Street calling at Wigan North Western, Preston, Lancaster, Oxenholme (1tp2h), Penrith (1tp2h), Carlisle, Lockerbie and Motherwell (1tp2h)

If the current services to Glasgow Central  were to be replaced by the High Speed Two services, most travellers would get a similar or better service.

But if Avanti West Coast decide to drop their classic services to Glasgow via Birmingham, will travellers starting between Milton Keynes and Crewe, be a bit miffed to lose their direct services to Glasgow?

Glasgow Central station would appear to be ready for High Speed Two.

Lancaster

I was initially surprised, that on High Speed Two, one tph would terminate at Lancaster station.

This Google Map shows the station.

Note.

1. There are two bypass lines without any platforms on the Western side of the tracks, where trains can speed through.
2. The station has five platforms.
3. Some Avanti West Coast services terminate at Lancaster station.
4. 265 metre, eleven-car Class 390 trains, stop in Lancaster station.

As High Speed Two services will use 200 metre trains, which are shorter than all Class 390 trains, I would suspect that High Speed Two services will be able to be turned at Lancaster station, without too much difficulty.

Liverpool Lime Street

Liverpool Lime Street station will need to be able to turn two 200 metre High Speed Two tph.

• The remodelling of the station in 2018, probably allowed for two tph between London Euston and Liverpool Lime Street station.
• From 2022-2023, it will be turning two Class 807 trains per hour, which will probably be 182 metres long.

Liverpool Lime Street station may well be ready for Phase One of High Speed Two. It’s also very much step-free.

There are also alternative plans for a new High Speed station in Liverpool.

• It would be alongside the current Liverpool Lime Street station.
• The station would have a route to High Speed Two at Crewe via Warrington and a junction at High Legh.
• Northern Powerhouse Rail would start in the station and go to Manchester via Warrington, High Legh and Manchester Airport.
• It would enable six tph between Liverpool and Manchester, in a time of just 26 minutes.

I talked about this plan in Changes Signalled For HS2 Route In North, where I included this map.

High Legh Junction is numbered 5 and 6.

Nothing published about High Speed Two, would appear to rule this plan out.

Lockerbie

Lockerbie station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Macclesfield

I was initially surprised, that on High Speed Two, one tph would terminal at Macclesfield station.

This Google Map shows the station.

Wikipedia says this about the platforms in the station.

There are three platforms but only two are in regular use, the up platform for services to Manchester and the down platform to Stoke-on-Trent and Birmingham. Platform 3 sees a small number of services. Evidence of a fourth platform can be seen, on which a Network Rail building now exists.

As the station has a regular Avanti West Coast service every hour, the platforms must be over 200 metres long and they will be long enough for the 200 metre High Speed Two trains.

So why would High Speed Two want to terminate a train at Macclesfield, rather than at Manchester Piccadilly as they do now?

Currently, Avanti West Coast runs these services between London Euston and Manchester Piccadilly.

• One tph via Milton Keynes Central, Stoke-on-Trent and Stockport.
• One tph via Stoke-on-Trent, Macclesfield and Stockport
• One tph via Stafford, Crewe, Wilmslow and Stockport

The diagram in the Modern Railways article shows these High Speed Two services to Manchester Piccadilly.

• One tph from London Euston via Old Oak Common, Birmingham Interchange and Manchester Airport
• Two tph from London Euston via Old Oak Common and Manchester Airport
• Two tph from Birmingham Curzon Street via Manchester Airport.

Note.

1. None of these five tph serve Macclesfield, Milton Keynes Central, Stockport, Stoke-on-Trent or Wilmslow.
2. All five proposed services are shown to call at Manchester Airport.
3. It is likely, that a tunnel will be bored between Manchester Airport and Manchester Piccadilly stations.
4. The High Speed Two station at Manchester Piccadilly might even be in a tunnel under the current Manchester Piccadilly station or central Manchester.
5. A below-ground High Speed Two station for Manchester could also serve Northern Powerhouse Rail services to Leeds and the East.
6. According to the plans, I talked about under Liverpool Lime Street earlier, there could also be up to six tph running between Liverpool and Manchester via Manchester Airport, as part of Northern Powerhouse Rail.

Plans need to be developed to serve the towns and cities, that will not be served by High Speed Two’s current proposals.

• It appears Stafford, Stoke-on-Trent and Macclesfield will be served by an independent High Speed Two service from London Euston.
• Terminating one tph at Macclesfield station doesn’t appear to be challenging.
• A rail route between Macclesfield and Manchester Airport to link up with the proposed tunnel could be very difficult.
• Manchester Piccadilly and Macclesfield stations have a frequent rail connection, with most trains calling at Stockport station.
• Perhaps during construction work for High Speed Two in the centre of Manchester, Macclesfield station can be used as an alternative route into the city, using the existing Manchester Piccadilly station.

The London Euston and Macclesfield service via Stafford and Stoke-on-Trent could be a pragmatic solution to part of the problem, but what about Milton Keynes, Wilmslow and Stockport?

According to the title of the Modern Railways article, High Speed Two will have a maximum frequency of 18 tph.

When fully-developed, the current proposed timetable shows the following.

• A frequency of 17 tph between London Euston and Birmingham Interchange stations.
• A frequency of 11 tph between Birmingham and Crewe.
• A frequency of 9 tph through East Midlands Hub station.

It would appear that if there is a capacity bottleneck, it is between London and Birmingham.

However if classic services to Manchester Piccadilly are replaced by the High Speed Two services to the city via the new tunnel from Manchester Airport to a new station in the City Centre, there will be spare capacity on the Crewe and Manchester Piccadilly route via Wilmslow and Stockport stations.

This could lead to a number of solutions.

• A direct High Speed Two service runs using the spare path, between London and the current Manchester Piccadilly station.
• Similar to the previous service, but the service splits and joins at Crewe, with one individual train going to Manchester Piccadilly and the other somewhere else. Blackpool?
• One service between London and Liverpool is planned to split and join at Crewe with individual trains going to Lancaster and Liverpool. The other Liverpool service could split at Crewe with individual trains going to Liverpool and Manchester Piccadilly.
• The service between London and Macclesfield is run by a pair of trains, that split at Birmingham Interchange, with individual trains going to Macclesfield and Manchester Piccadilly. The advantage of this service, is that if you got into the wrong train, you’d still be going to roughly the same destination.
• Wikipedia says “At peak times, the current Avanti West Coast services may additionally call at one or more of: Watford Junction, Rugby, Nuneaton, Tamworth, Lichfield Trent Valley.” So why not run classic services on the West Coast Main Line between Euston and Manchester Piccadilly via Milton Keynes using suitably fast trains. Perhaps, the new Class 807 trains would be ideal.

Note.

1. All services serving the current Manchester Piccadilly station would call at Crewe, Wilmslow and Stockport stations.
2. Passengers going to or from Manchester Airport would change at Crewe.

The more I look at Macclesfield, the more I like using it as a High Speed Two destination.

Motherwell

Motherwell station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Newcastle

Newcastle station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Oxenholme

Oxenholme station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Penrith

Penrith station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Preston

Preston station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.

I estimate that the main through platforms aren’t much short of the required 400 metres.

But something must be done to make the station step-free.

Runcorn

Runcorn station will need to accommodate 200 metre trains.

As it already accommodates 217 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Sheffield

Sheffield station will need to accommodate 200 metre trains.

This Google Map shows the station.

As the station can already handle a 220 metre InterCity 125, there shouldn’t be too much of a problem. The station is also substantially step-free.

Stafford

Stafford station will need to accommodate 200 metre trains.

This Google Map shows the station.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Wikipedia says this about Stafford station and High Speed Two.

Under current proposals, Stafford will be a part of the High Speed 2 network, via a ‘Classic Compatible’ junction, which will allow HS2 trains to operate to Stafford, and further on towards Liverpool. This would shorten journey time from Stafford to London, to an estimated 53 minutes. Under current proposals it is expected that an hourly services will operate in both directions, however it is currently unclear if these services will terminate at Stafford, or Liverpool.

This does appear to be rather out of date with High Speed Two’s latest proposals as disclosed in the Modern Railways article, which say that Stafford is served by the following service.

• One tph between London Euston and Macclesfield.
• Calls at Old Oak Common, Stafford and Stoke-on-Trent.
• A 200 metre train.

One possibility must surely be to run a pair of 200 metre trains to and from Stafford, where they would split and join.

• One could go as currently proposed to Stoke-on-Trent and Macclesfield.
• The second train could go to Liverpool via Crewe and Runcorn or Manchester Piccadilly via Crewe, Wilmslow and Stockport.
• The recent works at Norton Bridge Junction will have improved the route for the second train.

There would need to be platform lengthening at Stafford to accommodate the 400 metre pair of trains.

A split and join at Stafford does show the possibilities of the technique.

Another possibility is mentioned for Stafford in Wikipedia.

There is also been proposals to reintroduce services to Stafford to terminate on the Chase Line which was cutback to Rugeley Trent Valley in 2008. The Key Corridors states “Extension of Chase Line services to Stafford”. This is proposed to be in development.

It will surely connect a lot of people to Stafford for High Speed Two.

The extract from Wikipedia, that I used earlier, mentions a Classic Compatible junction, which will allow High Speed Two trains to reach Stafford.

This map clipped from the High Speed Two web site, shows the junction North of Lichfield, where High Speed Two connects to the Trent Valley Line through Stafford.

Note.

1. High Speed Two runs North-South across the map.
2. After the Junction by Fradley South,
3. High Speed Two to Crewe and the North, is the branch to the East.
4. The other branch connects to the Trent Valley Line, which can be picked out North of Lichfield, where it passes through Lichfield Trent Valley station.

The Trent Valley Line is no Victorian double-track slow-speed bottleneck.

• Most of the route between Rugby and Stafford is three or four tracks.
• The speed limit is generally 125 mph.
• I wouldn’t be surprised to see Avanti West Coast’s Class 390 and Class 807 trains running at 140 mph on the route.
• This speed would probably be attained by High Speed Two trains.

London Euston and Stafford would only have under twenty miles of slower line and that could be 140 mph, so High Speed Two  times on the route could be very fast. High Speed Two is quoting 54 minutes on their Journey Time Calculator.

Stoke-on-Trent

Stoke-on-Trent station will need to accommodate 200 metre trains.

This Google Map shows the station.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Warrington Bank Quay

Warrington Bank Quay station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Wigan North Western

Wigan North Western station will need to accommodate 200 metre trains.

In Is Wigan North Western Station Ready For High Speed Two?, I said this.

Wigan North Western station would accept a single-train now, but the platforms would need lengthening to handle a double-train.

As all trains through Wigan North Western station will only be 200 metre single trains and the station is step-free, the station appears to be ready for High Speed Two.

York

York station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Conclusion

I have come to these conclusions.

• Because most of these stations have been rebuilt in the last few decades to accommodate the 200-plus metre InterCity 125s, InterCity 225s and Class 390 trains, all the stations can handle a 200 metre High Speed Two train without significant lengthening.
• Some stations like Carlisle, Crewe, Preston and Stafford may need a small amount of platform lengthening to accommodate a pair of trains, but most of the improvements needed for a world-class High Speed railway will be more refurbishment than a complete rebuild.
• Using existing platforms at Lancaster and Macclesfield stations as terminal platforms is an elegant and a much more affordable solution than building new stations or even platforms.
• Because all five tph into the High Speed Two station at Manchester Piccadilly go via Manchester Airport, I would envisage that this will be in a tunnel, that can be part of a future Northern Powerhouse Rail.

I also think that the plan has been devised with the Project Management and minimising disruption to travellers in mind.

June 13, 2020 Posted by AnonW | Transport/Travel | Avanti West Coast, Class 390 Train, Class 807 Train, High Speed Two, HS3/Northern Powerhouse Rail, InterCity 125, InterCity 225, Lancaster Station, Macclesfield Station, Project Management, Stations, Step-Free, West Coast Main Line | 6 Comments
