High Speed Two To Build Stabling Facility In Scotland

High Speed Two has announced the intension to build a stabling facility for trains at Annandale in Dumfries and Galloway.

This document on the Government web site is entitled HS2 Phase 2b Western Leg Design Refinement Consultation.

Details of the Annandale Depot, start on Page 43.

This is the introductory paragraph.

Phase 2b will provide an increased number of services to Scotland and North West England compared to Phase 2a or Phase One of HS2, with two 400m trains running from Euston each hour and splitting at Carlisle into two 200m trains to serve Glasgow and Edinburgh. HS2 trains will also serve Scotland from Birmingham. New HS2 trains serving Scotland and the north west of England will need overnight stabling and light maintenance in this area, near to where trains finish and start service. It would not be operationally efficient for these trains to run empty to the next closest HS2 depot north of Crewe, approximately 150 miles away.

Note the services are as laid out in the June 2020 Edition of Modern Railways, which was obviously the thinking at the time on High Speed Two.

If you ignore the splitting and joining and assume that they are two separate trains, the Anglo-Scottish services on High Speed Two are as follows.

  • One train per hour (tph) – London Euston and Edinburgh Waverley via Old Oak Common, Preston, Carlisle and Edinburgh Haymarket.
  • One tph – London Euston and Edinburgh Waverley via Old Oak Common, Birmingham Interchange, Preston, Carlisle and Edinburgh Haymarket.
  • One tph – London Euston and Glasgow Central via Old Oak Common, Preston and Carlisle.
  • One tph – London Euston and Glasgow Central via Old Oak Common, Birmingham Interchange, Preston and Carlisle.
  • One train per two hours (tp2h) – Birmingham Curzon Street and Edinburgh Waverley via Wigan North Western, Preston, Lancaster, Oxenholme, Penrith, Carlisle. Lockerbie and Edinburgh Haymarket
  • One tp2h – Birmingham Curzon Street and Glasgow Central via Wigan North Western, Preston, Lancaster, Oxenholme, Penrith, Carlisle. Lockerbie and Motherwell

Note.

  1. Oxenholme and Penrith might not be served by both Birmingham trains.
  2. All services would be run by High Speed Two’s Classic-Compatible trains.
  3. The two Birmingham services effectively provide a one tph service between Birmingham and Scotland.
  4. All services will be single  200 metre long trains to the North of Carlisle, as pairs will split and join at Carlisle station.
  5. There would appear to be a fairly consistent five tph between Carlisle and Carstairs, where the Glasgow and Edinburgh routes divide.
  6. Edinburgh Waverley and Glasgow Central will both have three tph to and from Carlisle and Preston.

These were factors in the choice of location of the depot, stated in the report.

  • Be close to the existing railway.
  • Be a relatively large, flat site.
  • Preferably a brownfield rather than greenfield site.
  • Located as close as feasible to where HS2 services will terminate or begin to minimise empty train movements.
  • Be accessible to the workforce and local transport network.
  • Be suitable for 24-hour working.
  • Have enough space to accommodate equipment for light maintenance activities.
  • Have enough space to accommodate the expected number of trains.

The site is also close to the M74.

A few of my thoughts.

The Location Of The Proposed Depot

This Google Map shows the area mentioned in the report.

Note.

  1. The red arrow indicates Cranberry Farm, which will be just to the North of the site.
  2. The West Coast Main Line passing just South of Cranberry Farm, going across the map.
  3. The B 7076 and M74 will be to the South of the site.

It looks to meet many of the factors, I stated earlier. But it does appear to be a greenfield, rather than a brownfield site.

Distances And Times From The Depot

These are distances to places, where services will or might start.

  • Carlisle – 9 miles – 6 minutes
  • Edinburgh – 93 miles – 68 minutes
  • Glasgow – 94 miles – 59 minutes

I have used distances from Gretna Green Junction, which is just to the South of the proposed depot.

Will The Depot Be Only For Classic-Compatible Trains?

Consider.

  • All services North of Wigan North Western will be run by High Speed Two’s Classic-Compatible trains.
  • A simpler depot would surely be possible if it only handled High Speed Two’s Classic-Compatible trains.
  • With the possible exception of the occasional demonstration or test run High Speed Two;s full-size fleet will never be seen North of the Border.

The only thing this depot might have to do with the full-size fleet is turn-back a test train, which would only need a 400 metre long siding. A siding this length would probably be needed to turn a pair of High Speed Two’s Classic-Compatible trains.

Could The Depot Serve A Possible Irish Extension?

I believe that eventually High Speed Two will be extended across Southern Scotland and a bridge will connect it to Northern Ireland

In A Glimpse Of 2035, I gave a fictionalised version of the first journey from London Euston to Dublin, by high speed train.

I have just calculated the length of a high speed rail link between the proposed Annandale . Depot and a Belfast Parkway station. It is around 120 miles and the route would probably branch off between Lockerbie and Annandale Depot.

I feel that Annandale Depot could serve trains for Belfast, but there would probably need to be another depot in Dublin.



Extra HS2 Services To Scotland

Currently, TransPennine Express run services Between Liverpool and Manchester in England and Edinburgh and Glasgow in Scotland.

I can see High Speed Two replacing these services with a similar service to the one they are planning for Birmingham.

The current service is as follows,

  • One tp2h – Manchester Airport and Edinburgh Waverley via Manchester Piccadilly, Preston, Lancaster, Carlisle and Haymarket
  • One tp2h – Manchester Airport and Glasgow Central via Manchester Piccadilly, Preston, Lancaster, Carlisle and Motherwell
  • Four trains per day (tpd) – Liverpool Lime Street and Glasgow Central via Wigan North Western, Preston, Lancaster, Carlisle and Motherwell

Note.

  1. They call at smaller stations like Wigan North Western, Lancaster, Oxenholme, Penrith and Lockerbie as appropriate, to even up the service.
  2. These services probably share one path between Preston and Carstairs.
  3. The Liverpool services are diverted Manchester services.

Could they be replaced by High Speed Two services?

The Manchester services could become.

  • One tp2h – Manchester Piccadilly and Edinburgh Waverley via Manchester Airport, Preston, Lancaster, Carlisle and Haymarket
  • One tp2h – Manchester Piccadilly and Glasgow Central via Manchester Airport, Preston, Lancaster, Carlisle and Motherwell.

Blackpool, Liverpool and other parts of the North West may be better served with high speed commuter services linking them to Preston.

Serving Scotland’s Seven Cities

Scotland has seven cities that are connected by Inter7City trains.

  • Aberdeen – Not Electrified
  • Dundee – Not Electrified
  • Edinburgh – Will be served by High Speed Two
  • Glasgow – Will be served by High Speed Two
  • Inverness – Not Electrified
  • Perth – Not Electrified
  • Stirling – Fully Electrified

Can we forget about serving Aberdeen, Dundee, Inverness and Perth until they are dulling electrified?

But Stirling must be a possibility.

There is a fully electrified route via Motherwell, Whifflet, Greenfaulds and Larbert

I estimate, that coming up from London will take four hours and five minutes, as against the current time of five hours and eighteen minutes.

Increasing Capacity On The West Coast Main Line In Scotland

Over the years, there have been several plans to run more and faster trains between England and Glasgow on the West Coast Main Line.

So would an High Speed Two go to Sirling?

At present the maximum operating speed on the route is 125 mph. Trains like Avanti West Coast’s Class 390 trains and Hitachi’s AT-300 trains, could run at 140 mph, if digital in-cab signalling were rolled out on the route.

It is absolutely essential before High Speed Two trains run to Scotland, that the West Coast Main Line is digitally signalled.

In addition to faster running, trains can be closer together, so more trains can be run in an hour.

There are also other things, that could be done to help.

  • Ensure, that all the many freight trains on the route are electrically-hauled and capable of operating at 100 mph or more.
  • Make sure that local trains sharing the routes into Glasgow and Edinburgh are fast enough to keep out of the way of the expresses.
  • Selectively, add extra tracks, so that fast trains can overtake slow ones.
  • Ideally, a line like the West Coast Main Line, needs to be quadruple track all the way.

There also must be scope for flighting.

Consider.

  • Class 390 trains take about 30 minutes between Edinburgh Waverley and Carstairs South Junction
  • Class 390 trains take about 30 minutes between Glasgow Central and Carstairs South Junction
  • Carstairs South Junction is where the two routes join.

Suppose the two trains were to leave Edinburgh and Glasgow at similar times and run South from Carstairs South Junction, a safe distance apart.

  • The lead train would be travelling at 140 mph perhaps three to five minutes in front of the second train.
  • In-cab digital signalling would enforce the safe distance.

When the trains arrived in Carlisle, they would take a couple of minutes to join up physically for the high speed dash to London.

This Google Map shows Carstairs station and the splitting of the Glasgow and Edinburgh routes.

Note.

  1. The tracks going North-West to Glasgow.
  2. The tracks going North-East to Edinburgh.
  3. The tracks going South-East to Glasgow
  4. All tracks in the picture are electrified.

There might be a need for a passing loop to increase the efficiency of this junction.

It’s not just high speed passenger trains, that can use this technique, but it can be applied to trains with the same performance. So freight trains could form a convoy!

Flighting can decrease the number of train paths needed for a particular number of services and as digital in-cab signalling extends its reach across the UK, we’ll see more applications of the technique.

Effectively, by pathing the two London and Edinburgh/Glasgow trains and adding in one Birmingham and Manchester service, High Speed Two services would only need four paths between Carlisle and Carstairs.

But there would be.

  • Four tph between Preston/Carlisle and Scotland. So capacity would be good.
  • Three tph Between Carlisle and Edinburgh.
  • Three tph Between Carlisle and Glasgow.

As Birmingham Curzon Street, Manchester Piccadilly and Manchester Airport all can handle a pair of High Speed Two’s Classic-Compatible trains, it might be possible in the future to serve both Edinburgh and Glasgow with the Birmingham and Manchester services, splitting the trains at Carlisle. This would mean.

  • Four tph between Preston/Carlisle and Scotland.
  • Four tph Between Preston/Carlisle and Edinburgh.
  • Four tph Between Preston/Carlisle and Glasgow.

That looks strange mathematics, but that’s what you get when a train can serve two places by splitting.

What About The Glasgow And South Western Line?

The Glasgow And South Western Line, runs between Glasgow and Carlisle via Dumfries.

Consider.

  • It is not electrified
  • It can be used as a diversion, when the West Coast Main Line is blocked.
  • It has always puzzled me, why this line wasn’t electrified, when the West Coast Main Line was electrified in the 1970s.
  • High Speed Two’s need for more paths and higher speeds on the West Coast Main Line, may chase some of the freight on that route on to the Glasgow and South Western, as an alternative.

Perhaps, a small part of the High Speed Two budget could be used to electrify the route.

It certainly could be used to take some freight traffic from the West Coast Main Line and to ease diversions, if High Speed Two needed to close the West Coast Main Line for improvements to track, electrification or signalling.

It is also a line, where alternative methods of powering the trains could be used.

  • It has electrification at both ends and with some electrification in the middle, battery electric passenger trains might be able to use the route.
  • The City of Glasgow is majoring on hydrogen and the route, which is 115 miles long, could be ideal for a hydrogen train.

On the other hand full electrification could enable the electric services to be run at times, when the West Coast Main Line was blocked.

It is certainly a route, that could benefit from improvement.

Extension Of The Borders Railway To Carlisle

It is looking increasingly likely that the Borders Railway will be extended to Carlisle.

This report from the High Speed Rail Group is entitled Cross-Border High-Speed Rail And The Borders Railway Project.

The first paragraph is firm about why the Edinburgh and Glasgow services should split and join at Carlisle.

It has taken a while for HS2 service plans to focus on Carlisle as the right place to divide and join Glasgow/Edinburgh high-speed train portions. Earlier plans used Carstairs – and left Carlisle with no HS2 London service.

I also think it will be considerably more affordable  and less disruptive to extend Carlisle’s already long platforms, than to build a massive new station at Carstairs capable of handling 400 metre long trains.

This paragraph puts its case for extending the Borders Railway to Carlisle.

To get best use out of the enhanced services that will then be possible, and to fully utilise the additional line capacity along the West Coast Main Line, onward rail connectivity is crucial. That’s why we flagged the compatibility with the Borders Railways re-opening from Tweedbank via Hawick to Carlisle in our report. With Carlisle-London journey times reduced to a little over 2 hours, and the Borders Railway fully re-instated, journey times from the Borders towns could be dramatically shortened – to London as well as to other major cities in England. Inward travel for tourists to the Borders region would be dramatically enhanced too.

They also add that a Borders Railway could be an useful diversion route, during the increasing number of problems on UK rail networks caused by the weather.

I believe that the Borders Railway should be extended to Carlisle and it should also be electrified.

  • It would be a useful diversion route.
  • It could handle some freight trains.
  • It might be useful to move empty stock between Edinburgh and Annandale Depot, as the Borders Railway joins the West Coast Main Line not far from the depot.

We mustn’t underestimate how many passengers to and from the Borders will use the Borders Railway to catch High Speed Two at Carlisle.

Conclusion

Moving the depot to Annandale, may look to some like a way of giving the Scots a higher profile in High Speed Two.

But I do think it gives options to make a High Speed Network easier to run North of the border.

  • High Speed Two have total control of their depot.
  • It is well placed for Carlisle, Edinburgh and Glasgow.

It is also extremely well placed for the rail network of South Scotland.

October 11, 2020 Posted by | Transport | , , , , , , , , | Leave a comment

It’s A Privilege To Work Here!

I was speaking to a young station assistant at Liverpool Lime Street station, who I suspect could have been a trainee or an apprentice, when he came out with the title of this post.

These pictures show the platforms at the station, since the recent remodelling.

Note.

  1. The platforms are wide and can take an eleven-car Class 390 train.
  2. TransPennine Express’s five-car Class 802 trains are easily handles in the shorter platforms of the Western train shed.
  3. I suspect Avanti West Coast’s new Class 807 trains, which are fifty-two metres longer than the Class 802 trains, could fit into the Western train shed, if needed.

It is certainly a station with a large capacity and I believe, with a few tweaks the station will be able to handle High Speed Two and Northern Powerhouse Rail.

Train Lengths Into Liverpool Lime Street

These are the lengths of the various trains that will be terminating at the station.

  • Class 350 train – eight cars – 160 metres
  • Class 350 train – twelve cars – 240 metres
  • Class 390 train – nine cars – 217.5 metres
  • Class 390 train – eleven cars – 265.3 metres
  • Class 730 train – five cars – 120 metres
  • Class 730 train – ten cars – 240 metres
  • Class 802 train – five cars – 130 metres
  • Class 802 train – ten cars – 260 metres
  • Class 807 train – seven cars – 182 metres
  • High Speed Two Classic-Compatible train – 200 metres

That looks like future-proofing to me!



An Almost Absence Of Red

I have looked at arrivals into Liverpool Lime Street over the last couple of days on Real Time Trains and nearly all trains seemed to be on time.

So has all the work to improve the track and signalling on the approaches to the station,  over the last couple of years, resulted in better time keeping?

Certainly, train and passenger flows seemed to be smooth.

Conclusion

Wikipedia says this about Liverpool Lime Street station.

Opened in August 1836, it is the oldest still-operating grand terminus mainline station in the world.

I’ve used Lime Street station for fifty-five years and finally, it is the station, the city needs and deserves.

I’ve been to grand termini all over the world and Lime Street may be the oldest, but now it is one of the best.

August 21, 2020 Posted by | Transport | , , , , , | Leave a comment

Should High Speed Two’s Macclesfield And London Service Call At Birmingham Interchange?

Connecting Manchester City Centre to the High Speed Two network will be a major undertaking.

  • It looks increasingly likely that High Speed Two and Northern Powerhouse Rail will have a shared line running from the main High Speed Two route through Crewe to Manchester Piccadilly via Manchester Airport.
  • Between Manchester Airport and Manchester Piccadilly will be in a high speed tunnel.
  • Northern Powerhouse Rail will connect Liverpool Lime Street and Warrington to Manchester Airport and Manchester Piccadilly.
  • There will be a major problem keeping train services running between Manchester and Birmingham, London and the South.

But just at Project Rio kept Manchester connected during the rebuilding of the West Coast Main Line in the early years of this century, I believe that a similar creditable alternative route may be starting to evolve.

Avanti’s Additional Class 807 Trains Will Be Delivered

These trains will allow additional services and release some Class 390 trains to reinforce other services.

Avanti West Coast’s Future West Coast Main Line Service

The small fleet of Class 807 trains are needed to provide extra services on the West Coast Main Line.

  • But if these trains are successful, will more be used as replacements for the nearly twenty-years-old Class 390 trains?
  • Will they also be given more traction power to double as the classic-compatible trains for High Speed Two.
  • Other operators might also like to purchase a high capacity 200 metre long high speed train, which would share routes used by High Speed Two.

In Thoughts On Class 807 Trains And High Speed Two’s Classic-Compatible Trains, I discuss the design of extra trains for High Speed Two and the West Coast Main Line.

Surely, though having similar trains handling both roles on the West Coast Main Line and High Speed Two, would be an advantage to Avanti West Coast?

London And Manchester Services

Currently, there are these services between London Euston and Manchester Piccadilly stations.

  • Via Milton Keynes Central, Stoke-on-Trent and Stockport
  • Via Stoke-on-Trent, Macclesfield and Stockport
  • Via Stafford, Crewe, Wilmslow and Stockport

All services have a frequency of one train per hour (tph)

High Speed Two plans to run these services between the South and the Manchester area.

  • 1 tph – 200 metres – London Euston and Wigan North Western via Old Oak Common, Crewe and Warrington Bank Quay
  • 1 tph – 200 metres – London Euston and Macclesfield via Old Oak Common, Stafford and Stoke.
  • 1 tph – 400 metres – London Euston and Manchester Piccadilly via Old Oak Common, Birmingham Interchange and Manchester Airport
  • 2 tph – 400 metres – London Euston and Manchester Piccadilly via Old Oak Common and Manchester Airport
  • 2 tph – 200 metres – Birmingham Curzon Street and Manchester Piccadilly via Manchester Airport
  • 1 tph – 200 metres – Birmingham Curzon Street and Wigan North |Western

Note.

  1. I have included Wigan North Western, as it has good connections to North Manchester.
  2. Services can’t go via Manchester Airport until the tunnel is completed.
  3. The 400 metre services will need to use dedicated High Speed Two tracks, so will need to use the tunnel via Manchester Airport.

Wigan and Macclesfield stations will not be requiring major rebuilding, during the construction of High Speed Two. That should mean the stations will not need to be closed for long periods.

  • Macclesfield station could probably handle up to three tph from the South.
  • Wigan North Western station could probably handle two tph from the South.
  • Work in the Manchester Piccadilly area, may well close the station at times.

I suspect Macclesfield and Wigan North Western could be very useful alternative stations for travelling to and from the South.

Manchester And Birmingham Via Macclesfield

I can see that there could be difficulties for some passengers, if they found themselves at Macclesfield wanting to go to the Birmingham area.

A solution would be for the Macclesfield and London service to stop at Birmingham Interchange, which will be extremely well-connected.

Birmingham Interchange

This map from High Speed Two, shows Birmingham Interchange and Birmingham International stations.

Note.

  • Birmingham Interchange station is marked by the blue dot.
  • Birmingham International station is to the West of the M42.

The two stations will be connected by an automatic people mover.

Destinations and their frequencies available from Birmingham Interchange, when High Speed Two is complete will include.

  • 2 tph – Birmingham Curzon Street
  • 1 tph – Carlisle
  • 1 tph – East Midlands Hub
  • 1 tph – Edinburgh Haymarket
  • 1 tph – Edinburgh Waverley
  • 1 tph – Glasgow Central
  • 1 tph – Leeds
  • 5 tph – London Euston
  • 1 tph – Manchester Airport
  • 1 tph – Manchester Piccadilly
  • 5 tph – Old Oak Common
  • 1 tph – Preston

It looks like if you miss your train to many important cities at Birmingham Interchange, it will be an hour to wait for the next train.

Destinations and their frequencies available from Birmingham International are currently.

  • 8 tph – Birmingham New Street
  • 1 tph – Bournemouth
  • 1 tph – Crewe
  • 0.5 tph to Edinburgh Waverley
  • 0.5 tph to Glasgow Central
  • 7 tph – London Euston
  • 1 tph – Macclesfield
  • 1 tph – Manchester Piccadilly
  • 1 tph – Reading
  • 1 tph – Shrewsbury
  • 1 tph – Southampton
  • 1 tph – Stafford
  • 1 tph – Stoke-on-Trent
  • 2 tph – Wolverhampton

Note that 0.5 tph is one train per two hours.

These two lists can be combined.

  • 10 tph – Birmingham Curzon Street/New Street
  • 1 tph – Bournemouth
  • 2 tph – Carlisle
  • 1 tph – Crewe
  • 1 tph – East Midlands Hub
  • 1.5 tph – Edinburgh Haymarket
  • 1.5 tph – Edinburgh Waverley
  • 1.5 tph – Glasgow Central
  • 1 tph – Leeds
  • 12 tph – London Euston
  • 1 tph – Macclesfield
  • 1 tph – Manchester Airport
  • 2 tph – Manchester Piccadilly
  • 5 tph – Old Oak Common
  • 1 tph – Preston
  • 1 tph – Reading
  • 1 tph – Shrewsbury
  • 1 tph – Southampton
  • 1 tph – Stafford
  • 1 tph – Stoke-on-Trent
  • 2 tph – Wolverhampton

This list is surely missing Bristol, Cardiff, Liverpool, Sheffield and Newcastle.

Conclusion

We should not underestimate the importance of Macclesfield and Wigan North Western stations in getting to and from Manchester during the building of High Speed Two.

July 15, 2020 Posted by | Transport | , , , , , , , , , , | Leave a comment

Thoughts On Class 807 Trains And High Speed Two’s Classic-Compatible Trains

Avanti West Coast’s New Class 807 Trains

Avanti West Coast have ordered a small fleet of Class 807 trains.

This article on Railnews, gives this short description.

There will be more seats, because a seven-car train will have 453 and five-car sets will have 301. First said the seven-car version will have about the same number of seats as a nine-car Pendolino, because each IET vehicle is longer, at 26m.

Adding standard details of other Hitachi trains in the family, the following seems to be known.

  • They are seven-car trains.
  • The cars are the standard twenty-six metres, so a seven-car train will be 182 metres.
  • Ten trains have been ordered.
  • I suspect that like all the other trains in the family, they will be 125 mph trains, that are capable of 140 mph, when the signalling and track allows.
  • They are pencilled in for services between London Euston and Birmingham New Street, Blackpool North and Liverpool Lime Street stations
  • They will not have batteries or diesel engines for emergency or hotel power. Could this mean, that the trains have been designed for high performance, by removing excess weight?
  • The trains don’t have a tilting capability. Does this save weight and increase acceleration?
  • The trains have 453 seats, as opposed to the nine-car Class 390 trains, which have 469 seats.

Could these trains be designed, to be able to better the Class 390 train schedules on the West Coast Main Line?

  • They have no tilting capability.
  • They can only work on electric power, like the Class 390 trains.
  • They could have very fast acceleration, due to the weight loss.
  • They only reduce capacity by 3.5 %, when compared to a nine-car Class 390 train.

In Will Avanti West Coast’s New Trains Be Able To Achieve London Euston and Liverpool Lime Street In Two Hours?, this was my conclusion.

I believe the following will be possible.

    • A two hour service between London Euston and Liverpool Lime Street will be possible with Avanti West Coast’s new Class 807 trains.
    • The current Class 390 trains could go a bit faster.
    • I estimate that a Class 807 train could save as much as two-and-a-half-minutes at each stop.
    • Blackpool North and London times will be comfortably under three hours.
    • Coventry and London times will be comfortably under an hour.

The performance of these Class 807 trains will improve the West Coast Main Line.

What will London in two hours, do for Liverpool?

Class 807 Trains With Different Car Lengths

It is possible to create a table showing car length, train length and capacity for Class 807 trains

  • 26 metres – 182 metres – 453 seats
  • 26.5 metres – 185.5 metres – 462 seats
  • 27 metres – 189 metres – 470 seats
  • 27.5 metres – 192.5 metres – 479 seats
  • 28 metres – 196 metres – 488 seats
  • 28.5 metres – 199.5 metres – 497 seats

It seems that by lengthening all cars by half a metre, just adds nine seats.

Does this point to the fact, that twenty-six metres was a carefully-chosen optimal car length?

Class 807 Trains With Different Numbers Of Cars

A similar table can also be created for different numbers of twenty-six metre cars.

  • 7 cars – 182 metres – 453 seats
  • 8 cars – 208 metres – 518 seats
  • 9 cars – 234 metres – 582 seats
  • 10 cars – 260 metres – 647 seats

Note that as an eleven-car Class 390 train is 265.3 metres, a ten-car Class 807 train will fit all platforms, currently used by eleven-car Class 390 trains.

Replacement Of Eleven-Car Class 390 Trains With Class 807 Trains

The eleven-car Class 390 trains are 265.3 metres long and seat 589 passengers.

Looking at the two tables, nine-car Class 807 trains would be almost direct replacements for an eleven-car Class 390 trains.

  • The performance of the Class 807 trains would be as good if not better.
  • The passenger capacity of both trains would be similar, with just seven seats less in the new trains.
  • The Class 807 trains would also be shorter and could fit any platform currently served by an eleven-car Class 390 train.

It should also be noted, that the Class 807 trains would have to run as singles, as platforms on the West Coast Main Line can’t handle a four hundred metre train.

I believe it is highly likely that the classic-compatible trains for High Speed Two and the trains that replace the Class 390 trains will be the same and based on the Class 807 trains, that are now being assembled at Hitachi’s factory at Newton Aycliffe.

Could A Class 807 Train Be Stretched To Become A High Speed Two Classic-Compatible Train?

The Classic-Compatible trains are described in this section in Wikipedia, by this sentence.

The classic-compatible trains, capable of high speed but built to a British loading gauge, permitting them to leave the high speed track to join conventional routes such as the West Coast Main Line, Midland Main Line and East Coast Main Line. Such trains would allow running of HS2 services to the north of England and Scotland, although these non-tilting trains would run slower than existing tilting trains on conventional track. HS2 Ltd has stated that, because these trains must be specifically designed for the British network and cannot be bought “off-the-shelf”, these conventional trains were expected to be around 50% more expensive, costing around £40 million per train rather than £27 million for the captive stock.

The trains will have the same characteristics as the full-size trains.

  • Maximum speed of 225 mph.
  • Cruising speed of 205 mph on High Speed Two.
  • Length of 200 metres.
  • Ability to work in pairs.
  • A passenger capacity around 500-600 passengers.

A seven-car Class 807 train with twenty-six metre long cars would appear to be a partial match and tick all the boxes, except for the following.

  • The train’s maximum and cruising speeds are well below what is needed.
  • The train is only 182 metres long.
  • The train has a passenger capacity of 453.

Would a train with eight twenty-five metre long cars be a better fit?

  •  The train length would be 200 metres.
  • I doubt twenty-five metre cars would cause a problem!
  • I estimate the passenger capacity would be 498 seats.

The trains or members of the same family have already shown.

  • They can run on the East Coast, Great Western, Midland and West Coast Main Lines.
  • They can run on High Speed One.
  • They can split and join automatically.
  • When needed they can run on local lines.

If I was Avanti West Coast’s train-Czar, I would be seriously interested in a Classic-Compatible High Speed Two train, that was very similar to one, that I already had in service. Provided, of course it did what it promised in the specification.

In Wikipedia, the car lengths for Class 800, Class 801, Class 802, Class 805 and Class 810 trains are all given and have been reported in the media.

But the car lengths of the Class 803 and Class 807 trains are not given. Is it just an omission or is it deliberate?

Both these trains are designed for demanding routes.

  • The Class 803 trains are designed for London and Edinburgh in four hours.
  • I believe that the Class 807 trains are designed for London and Liverpool in two hours.

To get these demanding times, have Hitachi changed the car lengths?

  • Trains with shorter cars might accelerate better.
  • A redesigned interior might get more passengers in the shorter length.

I shall await the launch of both these lightweight speedsters with interest!

Conclusion

I wouldn’t be surprised that Hitachi’s offering for more trains on the West Coast Main Line and the Classic-Compatible trains for High Speed Two are very similar to the Class 807 trains.

  • The classic-compatible trains for High Speed Two could be eight-car trains with twenty-five metre cars.
  • The replacements for the eleven-car Class 390 trains could be nine-car trains with twenty-six metre cars.

Both would be based on the Class 807 train.













July 15, 2020 Posted by | Transport | , , , , | 5 Comments

Macclesfield Station And High Speed Two

Today, I went to Macclesfield station.

In the latest iteration of High Speed Two, two new destinations were added to the High Speed Two Network; Macclesfield and Lancaster.

These pictures show Macclesfield station.

It is a modern station, with three through platforms, two bridges and some Modernist architecture from the 1970s, that could be improved.

This Google Map shows the layout of the station.

Note.

  1. Platform 1 is in the West and is used by trains to Stockport and Manchester Piccadilly.
  2. Platform 2 is in the middle and is used by trains going to Stoke, London and the South.
  3. Platform 3 is in the East and appears to be used a couple of times per day.
  4. It also appears there might have been a fourth platform.

All platforms appear capable of handling an eleven-car Class 390 train, which are over two hundred and sixty metres in length.



Is the plan to use Macclesfield as a High Speed Two terminal feasible?

Which Trains Will High Speed Two Use On Macclesfield Services?

It appears that High Speed Two will have two types of trains.

  1. Trains built to the European loading gauge, that will only be able to work on high lines like High Speed One and High Speed Two. Examples would be Eurostar’s Class 373 and Class 374 trains.
  2. Trains built to the UK loading gauge, that could also work on existing UK 125 mph routes like the East Coast, Great Western, Midland and West Coast Main Lines. Examples would be Class 800. Class 801, Class 802, Class 390 and Class 745 trains.

The second type, which are referred to, as class-compatible trains will be used to Macclesfield, as these services will share track with Class 390 and other trains, that have been or will be built to the smaller UK loading gauge.

Will Classic-Compatible High Speed Two Trains Fit Into Macclesfield Station?

Currently, every hour, one eleven-car Class 390 train calls in Macclesfield station in both directions, as they provide one of Avanti \west Coast’s three trains per hour (tph) between London Euston and Manchester Piccadilly stations.

The current trains are sixty metres longer than the proposed classic-compatible High Speed Two trains, that could be terminating in Macclesfield station.

How Would Passengers Who Started And Finished Their Journeys In Macclesfield, Connect to Manchester?

Currently, these hourly services connect Manchester Piccadilly and Stoke stations.

  • Avanti West Cost – Manchester Piccadilly and London Euston.
  • CrossCountry – Manchester Piccadilly and Bournemouth
  • CrossCountry – Manchester Piccadilly and Bristol
  • Northern – Manchester Piccadilly and Stoke, which stops at all stations.

The characteristics would be common to all these four trains.

  • Services call at Stockport, Macclesfield and Stoke stations.
  • As services share tracks with a High Speed Two service, they must be reasonably fast.
  • All except the Northern service are 125 mph trains.
  • The Northern service is run by a 90 mph Class 323 electric train.
  • As Manchester Piccadilly and Stoke via Stockport is a fully-electrified route, the trains should probably be able to take advantage.

In an ideal world should the frequency be six tph or one train every ten minutes in each direction?

Which Platforms Would Be Used To Terminate High Speed Two Services?

Trains built to the UK loading gauge could probably terminate in any of the three platforms.

But it might be advantageous to terminate all services in the same platform.

Platform 3 would be the obvious choice.

  • It shares an island platform with classic services going South between Manchester Piccadilly and Stoke.
  • Passengers starting their journeys in Manchester Piccadilly or Stockport could just walk across from their connecting train to the High Speed Two train.

It must surely be a possibility to make Platform 2 able to operate bi-directionally, so that all trains between Manchester Piccadilly and Stoke stations in both directions, stop in Platform 2, alongside the High Speed Two train for London and the South, that is waiting in Platform 3. The combined frequency would be eight tph. All passengers would just walk across the island platform to change trains.

Could A North-Facing Bay Platform Be Fitted Into The Northern End Of The Island Platform 2/3?

If you are going to provide a High Speed Two service to and from Macclesfield station, it needs to have superb and comprehensive connections to as many places as possible.

The station currently has four tph to Manchester Piccadilly, Stockport and Stoke, but would a North-facing bay platform with level access to the High Speed Two platform make any of the following feasible?

  • Run a second local stopping service between Manchester Piccadilly and Macclesfield to give all intermediate stations two tph to High Speed Two.
  • Run hourly services to places that don’t have good connections to high speed services to London and the South.
  • The Stockport and Stalybridge Line could be used to connect Stalybridge and Huddersfield to High Speed Two.
  • There might even be a way of creating a link between Macclesfield and Manchester Airport.

Note.

  1. Looking at the platform layout at Macclesfield station, fitting in a bay platform would appear to be feasible.
  2. The important Stockport station, which seems to have been forgotten by High Speed Two would probably have at least six tph to High Speed Two at Macclesfield station.
  3. The local train could be timed to arrive at Macclesfield station, a convenient time before the High Speed Two train is scheduled to depart.

The bay platform could even be part of Platform 3, if it was decided that trains stopping in Platform 3, never used the platform as a through platform. It would be Macclesfield’s version of the Clapham Kiss.

I suspect more space could be found, by moving the signal box at the end of the station.

\remember that these days most signalling is controlled from centralised Rail Operation Centres.

Could High Speed Two Trains Run Between Macclesfield And Manchester Piccadilly?

As I said earlier, High Speed Two’s classic-compatible trains will be the same cross-section and shorter, than an eleven-car Class 390 train.

So the answer to my question must be yes!

  • This would enable a stop at Stockport station.
  • No platform lengthening would be required at Manchester Piccadilly and Stockport stations.

High Speed Two must have good reasons for using Macclesfield as a terminal.

  • There are capacity issues between Macclesfield and Manchester Piccadilly stations.
  • Macclesfield offers opportunities to connect to places, that are difficult to reach from Manchester Piccadilly station.

But these problems could probably be overcome by digital signalling or extension of the Manchester Metrolink.

Could More High Speed Two Services Run Between Macclesfield Station and The South?

Consider.

  • I believe that Macclesfield station could handle more than an hourly High Speed Two train.
  • It is a general principle, that on a metro like the London Overground or Merseyrail, that a single platform can handle up to four or even six tph.
  • Four tph would surely be too high, but Macclesfield could easily handle a second classic-compatible train to and from Birmingham Curzon Street via Stoke and Stafford.
  • During the inevitable works at Manchester Piccadilly station to sccomodate High Speed Two, Macclesfield could offer an alternative route, between London and Manchester.

Using Macclesfield station, as an alternative terminal for Manchester Piccadilly, builds in extra capacity for the future and offers a valuable alternative route during construction and upgrade works.

Rationalisation Between Cross Country And High Speed Two

Consider.

  • In a lot of locations North of Birmingham, CrossCountry and High Speed Two seem to provide similar services between the same stations.
  • Using currently proposed connections between High Speed Two and the classic network, CrossCountry’s services could run faster.
  • CrossCountry’s new fleet of trains will probably be multi-mode trains, that will be very similar to the classic-compatible High Speed Two trains.
  • Some of the routes used by CrossCountry’s services will have a substantial upgrade to allow higher speeds and more trains, to speed up High Speed Two services.

There must be a case for rationalisation of services.

Conclusion

The more I look at High Speed Two terminating at Macclesfield station, the more I like it.

I can see these services running from the station in the future.

  • High Speed Two – Macclesfield and London Euston – One tph – This service would additionally call at Birmingham Interchange to link up with CrossCountry to the South.
  • High Speed Two – Macclesfield and Birmingham Curzon Street – One tph
  • CrossCountry – Macclesfield and Bournemouth, Plymouth or Reading – One tph.
  • Northern and others – Macclesfield and Manchester Piccadilly via Stockport – Four-six tph
  • Northern – Macclesfield and Huddersfield via Stockport and Stalybridge – Two tph
  • Northern – Macclesfield and Manchester Airport – Two tph.

Obviously, this is all speculation, but Macclesfield will develop into an important rail hub to the South-East of Manchester.



July 14, 2020 Posted by | Transport | , , , , , , , , | 2 Comments

High Speed Two To The North West Of England

This map clipped from the High Speed Two web site, shows High Speed Two routes in the North West of England.

Note.

  1. When shown in orange, High Speed Two will use new tracks.
  2. When shown in blue, High Speed Two will use existing tracks.
  3. New stations are shown as large blue dots.
  4. High Speed Two and the West Coast Main Line appear to share a corridor through Crewe, before dividing near Walley’s Green.
  5. High Speed Two loops to the East of the West Coast Main Line and rejoins it South of Wigan between Bryn Gates and Abram Brow.

The route will or might serve the following stations in North West England.

Blackpool North

Blackpool North station is not planned to be served by High Speed Two.

But the station has been recently rebuilt.

  • It has a number of platforms, that are capable of handling 200 metre long classic-compatible High Speed Two trains.
  • The route to High Speed Two at Preston is fully electrified.
  • In a couple of years, it will be connected to Blackpool’s expanding tramway.
  • Blackpool would welcome High Speed Two with open arms.

Blackpool North  would be an ideal extra destination, if more trains were to be split and joined at Crewe.

But whatever happens, I believe that high speed commuter trains will run from Blackpool North.

  • Blackpool and Manchester Piccadilly via Preston, Wigan North Western, Warrington Bank Quay and Manchester Airport.
  • Blackpool and Derby via Preston, Wigan North Western, Warrington Bank Quay, Crewe and Stoke-on-Trent.

Blackpool North has the platforms and electrification and it will be used.

Carlisle

Carlisle station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

But two tph will be 400 metre London Euston and Edinburgh/Glasgow trains, so platform lengthening will probably be required.

There will be the following trains.

  • Birmingham Curzon Street and Carlisle – I tph – 118 minutes
  • London Euston and Carlisle – 2 tph – 154 minutes.

After any necessary platform lengthening, Carlisle will be ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

The High Speed Two web site, says Carlisle will be reached in Phase 2b, but as Edinburgh and Glasgow are part of Phase 1, this must be a mistake.

Crewe

Crewe station is at the bottom of the map, just to the right of centre.

The station gets this introduction on this page of the High Speed Two web site.

HS2 services will call at Crewe, where passengers will be able to access the high speed network heading south. Journey times to London will be cut to under an hour. Macclesfield, Stafford and Stoke-on-Trent will also receive HS2 services, spreading the benefits of better connectivity.

The page also says that between five and seven trains per hour (tph) will call at Crewe.

Lancaster

Lancaster station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

Lancaster will also be a terminus of 200 metre long classic-compatible High peed Two train from London Euston, so there may need to be refurbishment to handle the larger, if not longer train.

The use of Lancaster as a terminus, would appear to have the following advantages.

  • The platform is already there.
  • Using Lancaster as a terminal, may reduce the scope of works at Carlisle and Preston.
  • The one tph service from London Euston is effectively a High Speed Northern stopper between Lancaster and Crewe, with calls at Warrington Bank Quay, Wigan North Western and Preston stations.
  • Lancaster has connections to Barrow-in-Furness, Heysham Port and Morecambe and the scenic Cumbrian Coast and Settle-Carlisle Lines.
  • Paces like Barrow-in-Furness. Morecambe and a host of other stations, should save forty-three minutes on journeys to and from London.

I think that Lancaster, is a good place to terminate a service in the North-West of England.

There will be the following trains.

  • Birmingham Curzon Street and Lancaster – I tph – 65 minutes
  • London Euston and Lancaster – 1 tph – 101 minutes.

After the necessary refurbishment, Lancaster will be ready  and waiting for High Speed Two and will be reached in Phase 2b of the project.

But I do feel that Lancaster could be reached in Phase 1 of the project, if necessary works North of Preston and at Lancaster station were planned as an independent project.

Liverpool Lime Street

Liverpool Lime Street station is at the Western edge of the map, at the end of the Liverpool Branch of the West Coast Main Line.

Liverpool gets this headline and brief description on this page of the High Speed Two web site.

The City Region Wants To Deliver a World Class Transport Network

Its ambitious plans would integrate the existing HS2 route and builds on the Northern Powerhouse Rail proposals for high speed, east-west links directly into Liverpool City Centre.

Liverpool has made a good start to prepare for High Speed Two.

  • The Grade II Listed; Lime Street station now has lengthened platforms and an improved layout so that it can handle two 200 metre long High Speed Two trains per hour.
  • Merseyrail is taking delivery of a fleet of new Class 777 trains to update their suburban network.
  • By the time High Speed Two arrives in the city, the suburban network will be larger.

Liverpool is ready and waiting for High Speed Two and will be reached in Phase 1 of the project.

Macclesfield

Macclesfield station is at the Eastern edge of the map, at the end of its own leg of High Speed Two.

The station was the surprise destination added, during the last iteration of High Speed Two.

  • The late, great Brian Redhead, who lived in the town would be very pleased.
  • The station was rebuilt in 1960 and has three platforms.
  • It is planned to have one tph to London Euston via Stoke-on-Trent, Stafford and Old Oak Common.
  • The visualisation on this page of the High Speed Two web site, also shows three platforms, but I wouldn’t be surprised to see a fourth added, as the extra platform would add flexibility.

The second surprise for Macclesfield, is that like Liverpool, it will be reached in Phase 1 of the project.

Manchester Airport

Manchester Airport station is the Southern large blue dot at the top of the map.

This page on the High Speed Two web site is rather sparse on information about Manchester Airport station.

I have combined train times given on the web page, with frequencies from an article in the June 2020 Edition of Modern Railways to create this table, which should be valid after the completion of High Speed Two.

  • Birmingham Curzon Street and Manchester Airport – 2 tph – 32 minutes
  • Birmingham Interchange and Manchester Airport – 1 tph – 29 minutes
  • London Euston and Manchester Airport – 3 tph – 63 minutes
  • London Old Oak Common and Manchester Airport – 3 tph – 56 minutes
  • Manchester Piccadilly and Manchester Airport – 5 tph – 6 minutes

In Changes Signalled For HS2 Route In North, I stated that Northern Powerhouse Rail were proposing the following Liverpool and Manchester service.

Manchester Airport station will be reached in Phase 2b of the project.

  • Six tph
  • Stops at Manchester Airport and Warrington.
  • An end-to-end journey time of 26 minutes.

This would do the following.

  • Add a Liverpool and Manchester Airport service with a frequency of 6 tph, that will take 20 minutes.
  • Add a Warrington Parkway and Manchester Airport service with a frequency of 6 tph that will take around 10 minutes.
  • Increase the frequency between Manchester Piccadilly and Manchester Airport to 11 tph. Or more likely 12 tph.

How many cities have an airport connection running every five minutes using trains running at 125 mph?

As these Liverpool and Manchester services would probably start in places like Hull and Newcastle and come via varied routes that included a selection of Bradford, Doncaster Huddersfield, Leeds and Sheffield, all of the North, that lies to the East of the Pennines will be connected to Manchester Piccadilly, Manchester Airport and Liverpool by high speed trains.

Manchester Piccadilly

Manchester Piccadilly station is the Northern large blue dot at the top of the map.

This page on the High Speed Two web site is rather sparse on information about Manchester Piccadilly station.

Using the same data as before I can create a table of services from Manchester Piccadilly station, where I have included Liverpool and Manchester services, that will be run by Northern Powerhouse Rail.

  • Birmingham Curzon Street – 2 tph – 40 minutes
  • Birmingham Interchange – 1 tph – 37 minutes
  • London Euston – 3 tph – 67 minutes
  • London Old Oak Common – 3 tph – 60 minutes
  • Manchester Airport – 12 tph – 6 minutes
  • Liverpool – 6 tph – 26 minutes

Manchester Piccadilly station will be reached in Phase 2b of the project.

Oxenholme Lake District

Oxenholme Lake District station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be the following trains.

  • Birmingham Curzon Street and Oxenholm Lake District – I tph – 79 minutes
  • London Euston and Oxenholme Lake District – 115 minutes – Change at Preston

Oxenholme Lake District is ready  and waiting for High Speed Two and will be reached in Phase 2b of the project.

But I do feel that Oxenholme Lake Districtcould be reached in Phase 1 of the project, if necessary works North of Preston and at Lancaster station were planned as an independent project

Penrith North Lakes

Penrith North Lakes station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be the following trains.

  • Birmingham Curzon Street and Penrith North Lakes – I tph – 102 minutes
  • London Euston and Penrith North Lakes – 138 minutes – Change at Preston

Penrith North Lakes is ready  and waiting for High Speed Two and will be reached in Phase 2b of the project.

But I do feel that Penrith North Lakes could be reached in Phase 1 of the project, if necessary works North of Preston and at Lancaster station were planned as an independent project

Preston

Preston station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

But two tph will be 400 metre London Euston and Edinburgh/Glasgow trains, so platform lengthening will probably be required.

There will be the following trains.

  • Birmingham Curzon Street and Preston – I tph – 50 minutes
  • London Euston and Preston – 3 tph – 78 minutes.

After any necessary platform lengthening, Preston will be ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

Runcorn

Runcorn station is a through station on the Liverpool service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be two tph between London Euston and Runcorn and trains will take 74 minutes.

Runcorn is ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

Stafford

Stafford station is a through station on the Macclesfield service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be one tph between London Euston and Stafford and trains will take 54 minutes.

Sfafford is ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

Stoke

Stoke station is a through station on the Macclesfield service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be one tph between London Euston and Stoke and trains will take 71 minutes.

Stoke is ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

Warrington

Warrington Bank Quay station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be the following trains.

  • Birmingham Curzon Street and Warrington Bank Quay – I tph – 25 minutes
  • London Euston and Warrington Bank Quay – 1 tph – 73 minutes.

Warrington Bank Quay is ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.

Wigan

Wigan North Western station is a through station on the current Glasgow service and can handle a nine-car Class 390 train which is over 210 metres long, which means they can handle a 200 metre long, classic-compatible High Speed Two train.

There will be the following trains.

  • Birmingham Curzon Street and Wigan North Western – I tph – 36 minutes
  • London Euston and Wigan North Western – 1 tph – 84 minutes.

Wigan North Western is ready  and waiting for High Speed Two and will be reached in Phase 1 of the project.



June 25, 2020 Posted by | Transport | , , , , , , , , , , , , , , | 3 Comments

Existing Stations Where High Speed Two Trains Will Call

The June 2020 Edition Of Modern Railways has an article called HS2 Minister Backs 18 tph Frequency, which gives a detailed diagram of the route structure of High Speed Two and it is possible to summarise the stations, where High Speed Two trains will call.

  • Carlisle – 3 tph – 400 metres – Split/Join
  • Chesterfield – 1 tph – 200 metres
  • Crewe – 2 tph – 400 metres – Split/Join
  • Darlington – 2 tph – 200 metres
  • Durham – 1 tph – 200 metres
  • East Midlands Hub HS2 – 7 tph – 400 metres – Split/Join
  • Edinburgh Haymarket – 2.5 tph – 200 metres
  • Edinburgh Waverley – 2.5 tph – 200 metres – Terminal
  • Glasgow Central – 2.5 tph – 200 metres – Terminal
  • Lancaster – 2 tph – 200 metres – Terminal
  • Leeds HS2 – 5 tph – 400 metres
  • Liverpool Lime Street – 2 tph – 200 metres – Terminal
  • Lockerbie – 1 tph – 200 metres
  • Macclesfield – 1 tph – 200 metres – Terminal
  • Manchester Airport HS2 – 5 tph – 400 metres
  • Manchester Piccadilly HS2 – 5 tph – 400 metres
  • Motherwell – 0.5 tph – 200 metres
  • Newcastle – 3 tph – 200 metres – Terminal
  • Oxenholme – 0.5 tph – 200 metres
  • Penrith – 0.5n tph – 200 metres
  • Preston – 4 tph – 400 metres
  • Runcorn – 2 tph – 200 metres
  • Sheffield – 2 tph – 200 metres
  • Stafford – 1 tph – 200 metres
  • Stoke-on-Trent – 1 tph – 200 metres
  • Warrington Bank  Quay – 1 tph – 200 metres
  • Wigan North Western – 1 tph – 200 metres
  • York – 4 tph – 200 metres

Note.

  1. HS2 after the station name indicates a new station for High Speed Two
  2. tph is trains per hour
  3. 0.5 tph is one train per two hours (tp2h).
  4. 200/400 metres is the maximum length of trains that will call.
  5. Terminal indicates that trains will terminate at these stations.
  6. Split/Join indicates that trains will split and join at these stations.

These are more detailed thoughts on how existing stations will need to be modified.

Train Lengths

Before, I look at the individual stations, I’ll look at the train lengths.

  • High Speed Two train – Single – 200 metres
  • High Speed Two train – Pair – 400 metres
  • Class 390 train – 11-car – 265.3 metres
  • Class 390 train – 9-car – 217.5 metres
  • Class 807 train – 7-car – 182 metres
  • Class 810 train – 5-car – 120 metres
  • Class 810 train – Pair of 5-car – 240 metres
  • InterCity 125 – 2+8 – 220 metres
  • InterCity 225 – 9-car – 245 metres
  • Class 222 train – 4-car – 93.34 metres
  • Class 222 train – 5-car – 116.16 metres
  • Class 222 train – 7-car – 161.8 metres
  • Class 222 train – 4-car+5-car – 209.5 metres
  • Class 222 train – 5-car+5-car – 232.32 metres

These are the thoughts on the individual stations.

Carlisle

Carlisle station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.



I estimate the platforms are about 380 metres, but it looks like, they could be lengthened, without too much difficulty.

As High Speed Two trains to the North of Carlisle will be 200 metres long, there would probably be no need for platform lengthening North of Carlisle, as these trains are shorter than the Class 390 trains, that currently work the routes to Edinburgh and Glasgow.

Carlisle station is step-free, has good secondary rail connections and is within walking distance of the city centre.

The only thing it needs, is a connection to Edinburgh on a rebuilt Borders Railway.

Chesterfield

Consider.

  • Chesterfield station will need to handle 200 metre trains.
  • Chesterfield station may be rebuilt for High Speed Two.
  • Chesterfield station can handle an InterCity 125, which is 220 metres.
  • It will need to handle a pair of Class 810 trains, which would be 240 metres.

This Google Map shows Chesterfield station.

Note.

  1. The slow lines passing the station on the Eastern side.
  2. There are two long through platforms and a third bi-directional platform on the down slow line.

There is space to build two long platforms for High Speed Two, but is it worth it, when one one tph will stop?

  • According to High Speed Two’s Journey Time Calculator, trains will take just twelve minutes between Sheffield and Chesterfield stations.
  • This compares with 12-15 minutes for the current diesel trains.
  • The distance between the two stations is 14 miles, which means that a twelve minute trip has an average speed of 70 mph.
  • If there are still two tph to St. Pancras, there will be four tph, that run fast between the Sheffield and Chesterfield stations, of which three will stop at Chesterfield.

I think this could result in a simple and efficient design for the tracks between Sheffield and South of Clay Cross, where High Speed Two joins the Erewash Valley Line.

Chesterfield station is step-free.

Crewe

Crewe station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.

There have been references to rebuilding of Crewe stations, but it does appear that some platforms are over 300 metres long.

Darlington

Darlington station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Durham

Durham station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Edinburgh Haymarket

Edinburgh Haymarket station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Edinburgh Waverley

Edinburgh Waverley station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Glasgow Central

Glasgow Central station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Currently, Avanti West Coast runs the following services to Glasgow Central.

  • One tph from London Euston calling at Warrington Bank Quay, Wigan North Western, Preston, Lancaster, Oxenholme Lake District (1tp2h), Penrith (1tp2h) and Carlisle.
  • One tp2h from London Euston calling at Milton Keynes Central, Coventry, Birmingham International, Birmingham New Street, Sandwell and Dudley, Wolverhampton, Crewe, Warrington Bank Quay, Wigan North Western, Preston, Lancaster, Oxenholme Lake District (1tp2h), Penrith (1tp2h) and Carlisle.

High Speed Two is proposing to run the following trains to Glasgow Central.

  • Two tph from London Euston calling at Old Oak Common, Preston and Carlisle.
  • One tp2h from Birmingham Curzon Street calling at Wigan North Western, Preston, Lancaster, Oxenholme (1tp2h), Penrith (1tp2h), Carlisle, Lockerbie and Motherwell (1tp2h)

If the current services to Glasgow Central  were to be replaced by the High Speed Two services, most travellers would get a similar or better service.

But if Avanti West Coast decide to drop their classic services to Glasgow via Birmingham, will travellers starting between Milton Keynes and Crewe, be a bit miffed to lose their direct services to Glasgow?

Glasgow Central station would appear to be ready for High Speed Two.

Lancaster

I was initially surprised, that on High Speed Two, one tph would terminate at Lancaster station.

This Google Map shows the station.

Note.

  1. There are two bypass lines without any platforms on the Western side of the tracks, where trains can speed through.
  2. The station has five platforms.
  3. Some Avanti West Coast services terminate at Lancaster station.
  4. 265 metre, eleven-car Class 390 trains, stop in Lancaster station.

As High Speed Two services will use 200 metre trains, which are shorter than all Class 390 trains, I would suspect that High Speed Two services will be able to be turned at Lancaster station, without too much difficulty.

Liverpool Lime Street

Liverpool Lime Street station will need to be able to turn two 200 metre High Speed Two tph.

  • The remodelling of the station in 2018, probably allowed for two tph between London Euston and Liverpool Lime Street station.
  • From 2022-2023, it will be turning two Class 807 trains per hour, which will probably be 182 metres long.

Liverpool Lime Street station may well be ready for Phase One of High Speed Two. It’s also very much step-free.

There are also alternative plans for a new High Speed station in Liverpool.

  • It would be alongside the current Liverpool Lime Street station.
  • The station would have a route to High Speed Two at Crewe via Warrington and a junction at High Legh.
  • Northern Powerhouse Rail would start in the station and go to Manchester via Warrington, High Legh and Manchester Airport.
  • It would enable six tph between Liverpool and Manchester, in a time of just 26 minutes.

I talked about this plan in Changes Signalled For HS2 Route In North, where I included this map.

High Legh Junction is numbered 5 and 6.

Nothing published about High Speed Two, would appear to rule this plan out.

Lockerbie

Lockerbie station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Macclesfield

I was initially surprised, that on High Speed Two, one tph would terminal at Macclesfield station.

This Google Map shows the station.

Wikipedia says this about the platforms in the station.

There are three platforms but only two are in regular use, the up platform for services to Manchester and the down platform to Stoke-on-Trent and Birmingham. Platform 3 sees a small number of services. Evidence of a fourth platform can be seen, on which a Network Rail building now exists.

As the station has a regular Avanti West Coast service every hour, the platforms must be over 200 metres long and they will be long enough for the 200 metre High Speed Two trains.

So why would High Speed Two want to terminate a train at Macclesfield, rather than at Manchester Piccadilly as they do now?

Currently, Avanti West Coast runs these services between London Euston and Manchester Piccadilly.

  • One tph via Milton Keynes Central, Stoke-on-Trent and Stockport.
  • One tph via Stoke-on-Trent, Macclesfield and Stockport
  • One tph via Stafford, Crewe, Wilmslow and Stockport

The diagram in the Modern Railways article shows these High Speed Two services to Manchester Piccadilly.

  • One tph from London Euston via Old Oak Common, Birmingham Interchange and Manchester Airport
  • Two tph from London Euston via Old Oak Common and Manchester Airport
  • Two tph from Birmingham Curzon Street via Manchester Airport.

Note.

  1. None of these five tph serve Macclesfield, Milton Keynes Central, Stockport, Stoke-on-Trent or Wilmslow.
  2. All five proposed services are shown to call at Manchester Airport.
  3. It is likely, that a tunnel will be bored between Manchester Airport and Manchester Piccadilly stations.
  4. The High Speed Two station at Manchester Piccadilly might even be in a tunnel under the current Manchester Piccadilly station or central Manchester.
  5. A below-ground High Speed Two station for Manchester could also serve Northern Powerhouse Rail services to Leeds and the East.
  6. According to the plans, I talked about under Liverpool Lime Street earlier, there could also be up to six tph running between Liverpool and Manchester via Manchester Airport, as part of Northern Powerhouse Rail.

Plans need to be developed to serve the towns and cities, that will not be served by High Speed Two’s current proposals.

  • It appears Stafford, Stoke-on-Trent and Macclesfield will be served by an independent High Speed Two service from London Euston.
  • Terminating one tph at Macclesfield station doesn’t appear to be challenging.
  • A rail route between Macclesfield and Manchester Airport to link up with the proposed tunnel could be very difficult.
  • Manchester Piccadilly and Macclesfield stations have a frequent rail connection, with most trains calling at Stockport station.
  • Perhaps during construction work for High Speed Two in the centre of Manchester, Macclesfield station can be used as an alternative route into the city, using the existing Manchester Piccadilly station.

The London Euston and Macclesfield service via Stafford and Stoke-on-Trent could be a pragmatic solution to part of the problem, but what about Milton Keynes, Wilmslow and Stockport?

According to the title of the Modern Railways article, High Speed Two will have a maximum frequency of 18 tph.

When fully-developed, the current proposed timetable shows the following.

  • A frequency of 17 tph between London Euston and Birmingham Interchange stations.
  • A frequency of 11 tph between Birmingham and Crewe.
  • A frequency of 9 tph through East Midlands Hub station.

It would appear that if there is a capacity bottleneck, it is between London and Birmingham.

However if classic services to Manchester Piccadilly are replaced by the High Speed Two services to the city via the new tunnel from Manchester Airport to a new station in the City Centre, there will be spare capacity on the Crewe and Manchester Piccadilly route via Wilmslow and Stockport stations.

This could lead to a number of solutions.

  • A direct High Speed Two service runs using the spare path, between London and the current Manchester Piccadilly station.
  • Similar to the previous service, but the service splits and joins at Crewe, with one individual train going to Manchester Piccadilly and the other somewhere else. Blackpool?
  • One service between London and Liverpool is planned to split and join at Crewe with individual trains going to Lancaster and Liverpool. The other Liverpool service could split at Crewe with individual trains going to Liverpool and Manchester Piccadilly.
  • The service between London and Macclesfield is run by a pair of trains, that split at Birmingham Interchange, with individual trains going to Macclesfield and Manchester Piccadilly. The advantage of this service, is that if you got into the wrong train, you’d still be going to roughly the same destination.
  • Wikipedia says “At peak times, the current Avanti West Coast services may additionally call at one or more of: Watford Junction, Rugby, Nuneaton, Tamworth, Lichfield Trent Valley.” So why not run classic services on the West Coast Main Line between Euston and Manchester Piccadilly via Milton Keynes using suitably fast trains. Perhaps, the new Class 807 trains would be ideal.

Note.

  1. All services serving the current Manchester Piccadilly station would call at Crewe, Wilmslow and Stockport stations.
  2. Passengers going to or from Manchester Airport would change at Crewe.

The more I look at Macclesfield, the more I like using it as a High Speed Two destination.

Motherwell

Motherwell station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Newcastle

Newcastle station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Oxenholme

Oxenholme station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Penrith

Penrith station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Preston

Preston station will need two 400 metre through platforms, so each can accommodate a pair of 200 metre trains.

This Google Map shows the station.



I estimate that the main through platforms aren’t much short of the required 400 metres.

But something must be done to make the station step-free.

Runcorn

Runcorn station will need to accommodate 200 metre trains.

As it already accommodates 217 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Sheffield

Sheffield station will need to accommodate 200 metre trains.

This Google Map shows the station.

As the station can already handle a 220 metre InterCity 125, there shouldn’t be too much of a problem. The station is also substantially step-free.

Stafford

Stafford station will need to accommodate 200 metre trains.

This Google Map shows the station.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Wikipedia says this about Stafford station and High Speed Two.

Under current proposals, Stafford will be a part of the High Speed 2 network, via a ‘Classic Compatible’ junction, which will allow HS2 trains to operate to Stafford, and further on towards Liverpool. This would shorten journey time from Stafford to London, to an estimated 53 minutes. Under current proposals it is expected that an hourly services will operate in both directions, however it is currently unclear if these services will terminate at Stafford, or Liverpool.

This does appear to be rather out of date with High Speed Two’s latest proposals as disclosed in the Modern Railways article, which say that Stafford is served by the following service.

  • One tph between London Euston and Macclesfield.
  • Calls at Old Oak Common, Stafford and Stoke-on-Trent.
  • A 200 metre train.

One possibility must surely be to run a pair of 200 metre trains to and from Stafford, where they would split and join.

  • One could go as currently proposed to Stoke-on-Trent and Macclesfield.
  • The second train could go to Liverpool via Crewe and Runcorn or Manchester Piccadilly via Crewe, Wilmslow and Stockport.
  • The recent works at Norton Bridge Junction will have improved the route for the second train.

There would need to be platform lengthening at Stafford to accommodate the 400 metre pair of trains.

A split and join at Stafford does show the possibilities of the technique.

Another possibility is mentioned for Stafford in Wikipedia.

There is also been proposals to reintroduce services to Stafford to terminate on the Chase Line which was cutback to Rugeley Trent Valley in 2008. The Key Corridors states “Extension of Chase Line services to Stafford”. This is proposed to be in development.

It will surely connect a lot of people to Stafford for High Speed Two.

The extract from Wikipedia, that I used earlier, mentions a Classic Compatible junction, which will allow High Speed Two trains to reach Stafford.

This map clipped from the High Speed Two web site, shows the junction North of Lichfield, where High Speed Two connects to the Trent Valley Line through Stafford.

Note.

  1. High Speed Two runs North-South across the map.
  2. After the Junction by Fradley South,
  3. High Speed Two to Crewe and the North, is the branch to the East.
  4. The other branch connects to the Trent Valley Line, which can be picked out North of Lichfield, where it passes through Lichfield Trent Valley station.

The Trent Valley Line is no Victorian double-track slow-speed bottleneck.

  • Most of the route between Rugby and Stafford is three or four tracks.
  • The speed limit is generally 125 mph.
  • I wouldn’t be surprised to see Avanti West Coast’s Class 390 and Class 807 trains running at 140 mph on the route.
  • This speed would probably be attained by High Speed Two trains.

London Euston and Stafford would only have under twenty miles of slower line and that could be 140 mph, so High Speed Two  times on the route could be very fast. High Speed Two is quoting 54 minutes on their Journey Time Calculator.

Stoke-on-Trent

Stoke-on-Trent station will need to accommodate 200 metre trains.

This Google Map shows the station.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem. The station is also step-free.

Warrington Bank Quay

Warrington Bank Quay station will need to accommodate 200 metre trains.

As it already accommodates 265 metre Class 390 trains, there shouldn’t be too much of a problem.

Wigan North Western

Wigan North Western station will need to accommodate 200 metre trains.

In Is Wigan North Western Station Ready For High Speed Two?, I said this.

Wigan North Western station would accept a single-train now, but the platforms would need lengthening to handle a double-train.

As all trains through Wigan North Western station will only be 200 metre single trains and the station is step-free, the station appears to be ready for High Speed Two.

York

York station will need to accommodate 200 metre trains.

As it already accommodates 245 metre InterCity 225 trains, there shouldn’t be too much of a problem.

Conclusion

I have come to these conclusions.

  • Because most of these stations have been rebuilt in the last few decades to accommodate the 200-plus metre InterCity 125s, InterCity 225s and Class 390 trains, all the stations can handle a 200 metre High Speed Two train without significant lengthening.
  • Some stations like Carlisle, Crewe, Preston and Stafford may need a small amount of platform lengthening to accommodate a pair of trains, but most of the improvements needed for a world-class High Speed railway will be more refurbishment than a complete rebuild.
  • Using existing platforms at Lancaster and Macclesfield stations as terminal platforms is an elegant and a much more affordable solution than building new stations or even platforms.
  • Because all five tph into the High Speed Two station at Manchester Piccadilly go via Manchester Airport, I would envisage that this will be in a tunnel, that can be part of a future Northern Powerhouse Rail.

I also think that the plan has been devised with the Project Management and minimising disruption to travellers in mind.





June 13, 2020 Posted by | Transport | , , , , , , , , , , , , | 6 Comments

Could Some of Hitachi’s Existing Trains In The UK Be Converted To Battery-Electric Trains?

The last five fleets of AT-300 trains ordered for the UK have been.

Each fleet seems to be tailored to the needs of the individual operator, which is surely as it should be.

I can make some observations.

Fast Electric Trains

Both electric fleets on the list, will run on routes, where speed will be important.

  • The Avanti West Coast fleet on the West Coast Main Line, will have to be able to keep up keep with the Class 390 trains, that have the advantage of tilt for more speed.
  • The East Coast Trains fleet on the East Coast Main Line, will have to work hard to maintain a demanding schedule, as I outlined in Thoughts On East Coast Trains.

Any reduction in weight will improve the acceleration.

  • The seven tonne MTU 12V 1600 R80L diesel engines can be removed to reduce the weight.
  • As a five-car Class 800 train with three diesel engine weighs 243 tonnes, this could save nearly 9 % of the train’s weight.
  • East Coast Trains feel they need an appropriately-sized battery for emergency hotel power. Could this be because the catenary is not as good on the East Coast Main Line as on the West?
  • Perhaps, Avanti West Coast feel a battery is not needed, but they could obviously fit one later. Especially, if there was already a ready-wired position underneath the train.

The extra acceleration given by 100% electric operation, must make all the difference in obtaining the required performance for the two routes.

Why Four Diesel Engines In A Class 810 Train?

The Class 810 trains are an update of the current Class 800/Class 802 trains. Wikipedia described the differences like this.

The Class 810 is an evolution of the Class 802s with a revised nose profile and facelifted end headlight clusters, giving the units a slightly different appearance. Additionally, there will be four diesel engines per five-carriage train (versus three on the 800s and 802s), and the carriages will be 2 metres (6.6 ft) shorter due to platform length constraints at London St Pancras.

Additionally, in this article in the October 2019 Edition of Modern Railways, which is entitled EMR Kicks Off New Era, this is said.

The EMR bi-modes will be able to run at 125 mph in diesel mode, matching Meridian performance in a step-up from the capabilities of the existing Class 80x units in service with other franchises.

The four diesel engines would appear to be for more power, so that these trains will be able to run at 125 mph on diesel.

In How Much Power Is Needed To Run A Train At 125 mph?, I calculated that a Class 801 train, which is all-electric, consumes 3.42 kWh per vehicle mile.

  • At 125 mph a train will in an hour travel 125 miles.
  • In that hour the train will need 125 x 5 x 3.42 = 2137.5 kWh
  • This means that the total power of the four diesel engines must be 2137.5,
  • Divide 2137.5 by four and each diesel must be rated at 534.4 kW to provide the power needed.

The MTU 12V 1600 R80L diesel engine is described in this datasheet on the MTU web site.

Note on the datasheet, there is a smaller variant of the same engine called a 12V 1600 R70, which has a power output of 565 kW, as compared to the 700 kW of the 12V 1600 R80L.

The mass of the engines are probably at the limits of the range given on the datasheet.

  • Dry – 4500-6500 Kg
  • Wet – 4700-6750 Kg

It would appear that the less-powerful 12V 100 R70 is about two tonnes lighter.

So where will four engines be placed in a Class 810 train?

  • The five-car Class 800 and Class 802 trains have diesel-engines in cars 2, 3 and 4.
  • The nine-car Class 800 and Class 802 trains have diesel-engines in cars 2,3, 5, 7 and 8.
  • It appears that diesel-engines aren’t placed under the driver cars.
  • Five-car AT-300 trains generally have a formation of DPTS+MS+MS+MC+DPTF.
  • The car length in the Class 810 trains are two metres shorter than those in other trains.

Could it be that the intermediate cars on Class 810 trains will be an MC car, which has both First and Standard Class seating and two identical MS cars both with two smaller diesel engines?

  • The two smaller diesel engines will be about 2.6 tonnes heavier, than a single larger engine.
  • Only one fuel tank and other gubbins will be needed.
  • The shorter car will be lighter in weight.
  • MTU may have designed a special diesel engine to power the train.

I would suspect that a twin-engined MS car is possible.

Could The Battery And The Diesel Engine Be Plug-Compatible?

I found this document on the Hitachi Rail web site, which is entitled Development of Class 800/801 High-Speed Rolling Stock For UK Intercity Express Programme.

The document may date from 2014, but it gives a deep insight into the design of Hitachi’s trains.

I will take a detailed look at the traction system as described in the document.

This schematic of the traction system is shown.

Note BC is described as battery charger.

This is said in the text, where GU is an abbreviation for generator unit.

The system can select the appropriate power source from either the main transformer or the GUs. Also, the size and weight of the system were minimized by designing the power supply converter to be able to work with both power sources. To ensure that the Class 800 and 801 are able to adapt to future changes in operating practices, they both have the same traction system and the rolling stock can be operated as either class by simply adding or removing GUs. On the Class 800, which is intended to run on both electrified and non-electrified track, each traction system has its own GU. On the other hand, the Class 801 is designed only for electrified lines and has one or two GUs depending on the length of the trainset (one GU for trainsets of five to nine cars, two GUs for trainsets of 10 to 12 cars). These GUs supply emergency traction power and auxiliary power in the event of a power outage on the catenary, and as an auxiliary power supply on non-electrified lines where the Class 801 is in service and pulled by a locomotive. This allows the Class 801 to operate on lines it would otherwise not be able to use and provides a backup in the event of a catenary power outage or other problem on the ground systems as well as non-electrified routes in loco-hauled mode.

This is all very comprehensive.

Note that the extract says, that both the Class 800 trains and Class 801 trains have the same traction control system. A section called Operation in the Wikipedia entry for the Class 802 train, outlines the differences between a Class 802 train and a Class 800 train.

The Class 802s are broadly identical to the Class 800 bi-mode trains used in the Intercity Express Programme, and are used in a similar way; they run as electric trains where possible, and are equipped with the same diesel generator engines as the Class 800. However, they utilise higher engine operating power – 700 kW (940 hp) per engine as opposed to 560 kW (750 hp) – and are fitted with larger fuel tanks to cope with the gradients and extended running in diesel mode expected on the long unelectrified stretches they will operate on.

I would assume that the differences are small enough, so that a Class 802 train, can use the same traction control system, as the other two train classes.

The Hitachi document also describes the Train Management and Control System (TCMS), the function of which is described as.

Assists the work of the train crew; a data communication function that aids maintenance work; and a traction drive system that is powered by the overhead lines (catenaries) and GUs.

Several trains have been described as computers on wheels. That could certainly be said about these trains.

There would appear to be a powerful Automatic Train Identification Function.

To simplify the rearrangement and management of train configurations, functions are provided for identifying the train (Class 800/801), for automatically determining the cars in the trainset and its total length, and for coupling and uncoupling up to 12 cars in normal and 24 cars in rescue or emergency mode.

Now that would be a site – One nine-car train rescuing another!

I would assume that this Automatic Train Identification Function has already been updated to add the Class 802 trains and it would appear to me, as a very experienced computer programmer, that in future it could be further updated to cater for the following.

  • New classes of trains like the future Class 803 and Class 810 trains.
  • The fitting of batteries instead of diesel engines.

Could the Function even be future-proofed for hydrogen power?

There are two main ways for trains to operate when the diesel engine in a car has been replaced by a battery.

  1. A plug-compatible battery module is designed, that in terms of function looks exactly like a diesel engine to the TCMS and through that the train crew.
  2. The car with a battery becomes a new type of car and the TCMS is updated to control it, in an appropriate manner.

Both methods are equally valid.

I would favour the first method, as I have come across numerous instances in computer programming, engineering and automation, where the method has been used successfully.

The method used would be Hitachi’s choice.

What Size Of Battery Could Be Fitted In Place Of The Diesel Engine?

Consider.

  • The wet mass of an MTU 16V 1600 R80L diesel engine commonly fitted to AT-300 trains of different types is 6750 Kg or nearly seven tonnes.
  • My engineering knowledge would suggest, that it would be possible to replace the diesel engine with an inert lump of the same mass and not affect the dynamics of the train.

So could it be that a plug-compatible battery module can be fitted, so long as it doesn’t exceed the mass of the diesel engine it replaces?

For an existing Class 800 or Class 802 train, that limit could be seven tonnes.

But for East Coast Train’s Class 803 train, that size would probably be decided by the required train performance.

How much power would a one tonne battery hold?

This page on the Clean Energy institute at the University of Washington is entitled Lithium-Ion Battery.

This is a sentence from the page.

Compared to the other high-quality rechargeable battery technologies (nickel-cadmium or nickel-metal-hydride), Li-ion batteries have a number of advantages. They have one of the highest energy densities of any battery technology today (100-265 Wh/kg or 250-670 Wh/L).

Using these figures, a one-tonne battery would be between 100 and 265 kWh in capacity, depending on the energy density.

This table can be calculated of battery weight, low capacity and high capacity.

  • 1 tonne – 100 kWh – 265 kWh
  • 2 tonne – 200 kWh – 530 kWh
  • 3 tonne – 300 kWh – 895 kWh
  • 4 tonne – 400 kWh – 1060 kWh
  • 5 tonne – 500 kWh – 1325 kWh
  • 6 tonne – 600 kWh – 1590 kWh
  • 7 tonne – 700 kWh – 1855 kWh

As energy densities are only going to improve, the high capacity figures are only going to get larger.

If you look at the design of the Class 810 trains, which could have three positions for diesel engines or batteries, the designers of the train and East Coast Trains can choose the battery size as appropriate for the following.

  • Maximum performance.
  • Power needs when halted in stations.
  • Power needs for emergency power, when the wires come tumbling down.

I suspect, they will fit only one battery, that is as small as possible to minimise mass and increase acceleration, but large enough to provide sufficient power, when needed.

Conversion Of A Five-Car Class 800/Class 802 Train To Battery-Electric Operation

If Hitachi get their design right, this could be as simple as the following.

  • Any of the three MTU 12V 1600 R80L diesel engines is removed, from the train.
  • Will the other diesel related gubbins, like the fuel tank be removed? They might be left in place, in case the reverse conversion should be needed.
  • The new battery-module is put in the diesel engine’s slot.
  • The train’s computer system are updated.
  • The train is tested.

It should be no more difficult than attaching a new device to your personal computer. Except that it’s a lot heavier.

As there are three diesel engines, one, two or three could be replaced with batteries.

Trains would probably be able to have a mixture of diesel engines and battery modules.

A Class 802 train with one diesel engine and two five-tonne batteries would have the following power sources.

  • 25 KVAC overhead electrification.
  • A 700 kW diesel engine.
  • Two five-tonne batteries of between 500 kWh and 1325 kWh.

With intelligent software controlling the various power sources, this train could have a useful range, away from the electrification.

Conversion Of A Five-Car Class 810 Train To Battery-Electric Operation

The process would be similar to that of a Class 800/Class 802 Train, except there would be more possibilities with four engines.

It would also need to have sufficient range to bridge the gaps in the electrification.

Perhaps each train would have the following power sources.

  • 25 KVAC overhead electrification.
  • Two 565 kW diesel engines.
  • Two four-tonne batteries of between 400 kWh and 1060 kWh.
  • Batteries might also be placed under the third intermediate car.

I estimate that with 400 kWh batteries, a train like this would have a battery range of sixty-five miles.

Conclusion

The permutations and combinations would allow trains to be tailored to the best compromise for a train operating company.

June 8, 2020 Posted by | Transport | , , , , , , , | 1 Comment

Will Avanti West Coast’s New Trains Be Able To Achieve London Euston and Liverpool Lime Street In Two Hours?

Note that I have rewritten this post to take account of this information from the January 2020 Edition of Modern Railways, in an article, which is entitled Hitachi Trains For Avanti.

This is said about the ten all-electric AT-300 trains for Birmingham, Blackpool and Liverpool services, which have now been numbered as Class 807 trains.

The electric trains will be fully reliant on the overhead wire, with no diesel auxiliary engines or batteries.

It may go against Hitachi’s original design philosophy, but not carrying excess weight around, must improve train performance, because of better acceleration.

Currently, Avanti West Coast‘s trains between London Euston and Liverpool Lime Street stations are timetabled as follows.

  • The journey takes two hours and thirteen or fourteen minutes.
  • There are three stops at Stafford, Crewe and Runcorn.
  • The stops with the current Class 390 trains seem to take around a minute.
  • There is one train per hour (tph)
  • A second hourly service with a stop at Liverpool South Parkway is planned to be introduced in December 2022.

In 2022, a new fleet of Hitachi AT-300 trains will be introduced on the route. I believe, it would be reasonable to assume, that these Class 807 trains will have similar or better performance, than the current Class 390 trains.

  • Acceleration and braking are likely to be better.
  • Regenerative braking energy may well be handled more efficiently.
  • The trains may well be equipped with in-cab digital signalling and be able to travel in excess of 125 mph in places, where the track allows.

I would expect, that these trains could be running near to or at 125 mph on most of the journey.

London Euston and Liverpool Lime Street are 193.5 miles apart, so if a train could be running at 125 mph all the way, a train would take 93 minutes.

Extra time must be added for the following.

  • Acceleration from a standing start to 125 mph at London Euston, Stafford, Crewe and Runcorn.
  • Deceleration from 125 mph to a stop at Stafford, Crewe, Runcorn and Liverpool Lime Street.
  • Dwell time in the platforms at Stafford, Crewe and Runcorn.

This page on the Eversholt Rail web site, has a data sheet for a Class 802 train, which is a bi-mode AT-300 train with three diesel engines.

The data sheet shows that a five-car train can accelerate to 125 mph and then decelerate to a stop in six minutes in electric mode. As Avanti West Coast’s Class 807 trains will be all-electric seven-car trains with no heavy engine or battery, I doubt they will be slower than a Class 802 train in electric mode. So four accelerations/deceleration cycles  to 125 mph should take no more than twenty-four minutes.

I will assume two minutes for each of the three stops.

I can now give an estimate for the journey.

  • Base journey time – 93 minutes
  • Acceleration from and deceleration to stops – 24 minutes
  • Station dwell time – 6 minutes

This gives a journey time between London Euston and Liverpool Lime Street of two hours and three minutes.

The journey time can probably be improved in the following ways.

  • Take full advantage of the track improvements on the approach to Liverpool Lime Street station and at Norton Bridge Junction.
  • Better train pathing, as has been done on London Liverpool Street and Norwich services to create the fast Norwich-in-Ninety services.
  • Track and signal improvements to pinch a minute here and a minute there.
  • As Runcorn now has an hourly Liverpool Lime Street and Chester service, will the Runcorn stop be dropped to save time?
  • Reduction in station dwell time.
  • Better driver aids.
  • Better staff operating procedures at stops and whilst turning the train.

It should be born in mind, that a two hour journey between London Euston and Liverpool Lime Street would be a start-stop average speed of 97 mph on a 125 mph route. Intriguingly, this means the trains would run at 77 % of the maximum operating speed of the route, which is the same figure for Norwich-in-Ninety services.

Some of these improvements may enable the Class 390 trains to go a bit faster.

It has to be considered, that Avanti West Coast’s Marketing Department would be ecstatic, when told that London and Liverpool were less than two hours apart.

How Many Trains Would Be Needed?

Currently, this is a typical train round trip to Liverpool Lime Street.

  • 07:07 – Leave London Euston
  • 09:20 – Arrive Liverpool Lime Street
  • 09:47 – Leave Liverpool Lime Street
  • 12:02 – Arrive London Euston

The five-hour round-trip would indicate that five trains would be needed for the one tph service.

This train didn’t return to Liverpool, but went off to the Wembley Depot.

After their Liverpool trip, there is no real pattern of where the train will go next, as this table shows.

  • 06:41 – 6 – 33 minutes – Wembley Depot
  • 07:48 – 2 – 36 minutes – Manchester Piccadilly
  • 08:47 – 1 – 40 minutes – Manchester Piccadilly
  • 09:47 – 7 – 30 minutes – Wembley Depot
  • 10:47 – 4 – 42 minutes – Preston
  • 11:47 – 4 – 37 minutes – Preston
  • 12:47 – 1 – 34 minutes – Preston
  • 13:47 – 15 – 13 minutes – Birmingham New Street
  • 16:47 – 6 – 16 minutes – Glasgow Central
  • 17:47 – 1 – 42 minutes – Manchester Piccadilly

Note.

  1. The time is departure time from Liverpool Lime Street, the number is the platform and the minutes are the turnround time in Euston.
  2. I have left out a couple of trains as there was a very late train.
  3. There doesn’t seem to be any regular pattern.
  4. It looks like trains can be turned in under fifteen minutes.
  5. I think there was a time, when Liverpool couldn’t accept eleven-car trains, but the new longer platforms appear to accept them.
  6. Trains appear to be running services to Glasgow Central and Manchester Piccadilly, who seem to usually get eleven-car trains.

I almost think, that they’re allocating trains as they go.

With the new Class 807 trains, I suspect the following is possible.

  • London Euston to Liverpool Lime Street – Two hours
  • Turnround – Fifteen minutes
  • Liverpool Lime Street to London Euston – Two hours
  • Turnround – Fifteen minutes

This means it’s a four-and-a-half hour round trip.

  • Journey times of two hours.
  • Time enough for well-drilled staff to turn the trains.
  • Dedicated platforms at London Euston and Liverpool Lime Street.
  • It would be a very attractive customer-friendly service.

Two tph would need nine trains.

It would be everything the Marketing Department wanted!

Thoughts On The Current Class 390 Timings

As the Class 390 trains are a 125 mph train, their base timing of 93 minutes, between London and Liverpool should still be the same.

As their doors and lobbies are similar in design to those of the Hitachi AT-300 trains, I would allow the same two minutes of dwell time at each station.

Current timings of services on the route vary between 132 and 134 minutes. I’ll take the average of 133 minutes.

So the current services take thirty-four minutes to perform the four accelerate and decelerate sequences on the route.

It would appear that this sequence would take eight-and-a-half minutes in comparison with the six minutes of the new Hitachi AT-300 trains.

An Improved London Euston and Blackpool North Service

The new AT-300 trains will also be running to Blackpool.

  • London Euston and Blackpool North takes between two hours and forty-four minutes and two hours and fifty-nine minutes.
  • Journey times are not very consistent, probably due to timetabling difficulties.
  • Trains stop between four and five times on the West Coast Main Line.

Would the faster stops of the new AT-300 trains mean that Avanti West Coast could run a more regular timetable, with all services under three hours?

It should also be noted, that Grand Central will start a London Euston and Blackpool North service in Spring 2020.

As the rolling stock for this new service will be Class 90 locomotives hauling rakes of Mark 4 coaches, that will be limited to 110 mph, are Avanti West Coast making sure, that they have the fastest trains on the route?

Would AT-300 Trains Save Time To Other Avanti West Coast Destinations?

If we assume that AT-300 trains can save two-and-a-half minutes per accelerate and decelerate sequence times could change as follow.

  • Birmingham New Street – One hour and twenty-two minutes – Three stops – One hour and twelve minutes
  • Coventry – One hour – Two stops – Fifty-five minutes
  • Crewe – One hour and thirty-four minutes – One stop – One hour and thirty minutes
  • Glasgow – As services stop six or thirteen times, there may be substantial savings to be achieved.
  • Manchester – Between two hours and seven minutes and two hours and thirteen minutes – Three stops – Between one hour and fifty-seven minutes and two hours and three minutes.

Note.

  1. The number of accelerate and decelerate sequences is one more than the number of stops.
  2. Coventry services would be under an hour.
  3. Two out of three Manchester services would be under two hours.

This analysis illustrates how fast train performance is important in more customer-friendly services.

Conclusion

I believe the following will be possible.

  • A two hour service between London Euston and Liverpool Lime Street will be possible with Avanti West Coast’s new AT-300 trains.
  • The current Class 390 trains could go a bit faster.
  • I estimate that a Class 807 train could save as much as two-and-a-half-minutes at each stop.
  • Blackpool North and London times will be comfortably under three hours.
  • Coventry and London times will be comfortably under an hour.

The performance of these Class 807 trains will improve the West Coast Main Line.

March 27, 2020 Posted by | Transport | , , , , , , | 3 Comments

Hitachi Trains For Avanti

The title of this post is the same as that of an article in the January 2020 Edition of Modern Railways.

The Bi-Mode Trains

Some more details of the thirteen bi-mode and ten electric Hitachi AT 300 trains are given.

Engine Size and Batteries

This is an extract from the article.

Hitachi told Modern Railways it was unable to confirm the rating of the diesel engines on the bi-modes, but said these would be replaceable by batteries in future if specified.

I do wonder if my speculation in Will Future Hitachi AT-300 Trains Have MTU Hybrid PowerPacks? is possible.

After all, why do all the hard work to develop a hybrid drive system, when your engine supplier has done it for you?

Would Avanti West Coast need a train that will do 125 mph on diesel?

The only place, they will be able to run at 125 mph or even higher will be on the West Coast Main Line, where they will be running under electric power from the pantograph.

If I were designing a bi-mode for 90 mph on diesel and 125 mph on electric, I would have batteries on the train for the following purposes.

  • Handle regenerative braking.
  • Provide hotel power in stations or when stationery.
  • Provide an acceleration boost, if required, when running on diesel.
  • Provide emergency power, if the wires go down in electric mode.

I’m sure MTU could work out a suitable size of diesel engine and batteries in an MTU PowerPack, that would meet the required performance.

Or maybe a smaller diesel could be used. An LNER Class 800 train has 1680 kW of installed power to maintain 125 mph. But the Great Western Railway versions have 2100 kW or twenty-five percent more, as their routes are more challenging with steeper gradients.

For the less challenging routes at a maximum of 90 mph between Crewe, Chester, Shrewsbury and North Wales, I wonder what level of power is needed.

A very rough estimate based on the speed required could put the power requirement as low as 1200-1500 kW.

As the diesel engines are only electrical generators, it would not effect the ability of the train to do 125 mph between Crewe and London.

There looks to be a virtuous circle at work here.

  • Lower maximum speed on diesel means smaller diesel engines.
  • Smaller diesel engines means lighter diesel engines and less fuel to carry.
  • Less weight to accelerate needs less installed power.
  • Less power probably means a more affordable train, that uses less diesel.

It looks to me, that Hitachi have designed a train, that will work Avanti West Coast’s routes efficiently.

The Asymmetric Bi-Mode Train

It looks to me that the bi-mode train  that Avanti West Coast are buying has very different performance depending on the power source and signalling

  • 90 mph or perhaps up to 100 mph on diesel.
  • 125 mph on electric power.with current signalling.
  • Up to 140 mph on electric power with in-cab digital signalling.

This compares with the current Class 221 trains, which can do 125 mph on all tracks, with a high enough operating speed.

The new trains’ different performance on diesel and electric power means they could be called asymmetric bi-modes.

Surely, creating an asymmetric bi-mode train, with on-board power; battery, diesel or hydrogen, sized to the route, means less weight, greater efficiency, less cost and in the case of diesel, higher carbon efficiency.

Carbon Emissions

Does the improvement in powertrain efficiency with smaller engines running the train at slower speeds help to explain this statement from the Modern Railways article?

Significant emissions reduction are promised from the elimination of diesel operation on electrified sections as currently seen with the Voyagers, with an expected reduction in CO2 emissions across the franchise of around two-thirds.

That is a large reduction, which is why I feel, that efficiency and batteries must play a part.

Battery-Electric Conversion

In my quote earlier from the Modern Railways article, I said this.

These (the diesel engines) would be replaceable by batteries in future if specified.

In Thoughts On The Next Generation Of Hitachi High Speed Trains, I looked at routes that could be run by a battery-electric version of Hitachi AT-300 trains.

I first estimated how far an AT-300 train could go on batteries.

How far will an AT-300 train go on battery power?

  • I don’t think it is unreasonable to be able to have 150 kWh of batteries per car, especially if the train only has one diesel engine, rather than the current three in a five-car train.
  • I feel with better aerodynamics and other improvements based on experience with the current trains, that an energy consumption of 2.5 kWh per vehicle mile is possible, as compared to the 3.5 kWh per vehicle mile of the current trains.

Doing the calculation gives a range of sixty miles for an AT-300 train with batteries.

As train efficiency improves and batteries are able to store more energy for a given volume, this range can only get better.

I then said this about routes that will be part of Avanti West Coast’s network.

With a range of sixty miles on batteries, the following is possible.

  • Chester, Gobowen, Shrewsbury And Wrexham Central stations could be reached on battery power from the nearest electrification.
  • Charging would only be needed at Shrewsbury to ensure a return to Crewe.

Gobowen is probably at the limit of battery range, so was it chosen as a destination for this reason.

The original post was based on trains running faster than the 90 mph that is the maximum possible on the lines without electrification, so my sixty mile battery range could be an underestimate.

These distances should be noted.

  • Crewe and Chester – 21 miles
  • Chester and Shrewsbury – 42 miles
  • Chester and Llandudno – 47 miles
  • Chester and Holyhead – 84 miles

Could electrification between Crewe and Chester make it possible for Avanti West Coast’s new trains to go all the way between Chester and Holyhead on battery power in a few years?

I feel that trains with a sixty mile battery range would make operations easier for Avanti West Coast.

Eighty miles would almost get them all the way to Holyhead, where they could recharge!

Rlectrification Between Chester And Crewe

I feel that this twenty-odd miles of electrification could be key to enabling battery-electric trains for the routes to the West of Chester to Shrewsbury, Llandudno and Holyhead.

How difficult would it be to electrify between Chester and Crewe?

  • It is not a long distance to electrify.
  • There doesn’t appear to be difficult viaducts or cuttings.
  • It is electrified at Crewe, so power is not a problem.
  • There are no intermediate stations.

But there does seem to be a very large number of bridges. I counted forty-four overbridges and six underbridges. At least some of the bridges are new and appear to have been built with the correct clearance.

Perhaps it would be simpler to develop fast charging for the trains and install it at Chester station.

Conclusion On The Bi-Mode Trains

It appears to me that Avanti West Coast, Hitachi and Rock Rail, who are financing the trains have done a very good job in devising the specification for a fleet of trains that will offer a good service and gradually move towards being able to deliver that service in a carbon-free manner.

  • The initial bi-mode trains will give a big improvement in performance and reduction in emission on the current Voyagers, as they will be able to make use of the existing electrification between Crewe and London.
  • The trains could be designed for 125 mph on electric power and only 90-100 mph on diesel, as no route requires over 100 mph on diesel. This must save operating costs and reduce carbon emissions.
  • They could use MTU Hybrid PowerPacks instead of conventional diesel engines to further reduce emissions and save energy
  • It also appears that Hitachi might be able to convert the trains to battery operation in a few years.
  • The only new infrastructure would be a few charging stations for the batteries and possible electrification between Chester and Crewe.

I don’t think Avanti West Coast’s ambition of a two-thirds reduction in CO2 is unreasonable and feel it could even be exceeded.

Other Routes For Asymetric Bi-Mode Trains

I like the concept of an asymetric bi-mode train, where the train has the following performance.

  • Up to 100 mph on battery, diesel or hydrogen.
  • Up to 100 mph on electrified slower-speed lines.
  • 125 mph on electrified high-speed lines, with current signalling.
  • Up to 140 mph on electrified high-speed lines, with in-cab digital signalling.

I am very sure that Hitachi can now tailor an AT-300 train to a particular company’s needs. Certainly, in the case of Avanti West Coast, this seems to have happened, when Avanti West Coast, Hitachi, Network Rail and Rock Rail had some serious negotiation.

LNER At Leeds

As an example consider the rumoured splitting and joining of trains at Leeds to provide direct services between London and Bradford, Harrogate, Huddersfield, Ilkley, Skipton and other places, that I wrote about in Dancing Azumas At Leeds.

In the related post, I gave some possible destinations.

  • Bradford – 13 miles – 25 minutes – Electrified
  • Harrogate – 18 miles – 30 minutes
  • Huddersfield – 17 miles – 35 minutes
  • Hull – 20 miles – 60 minutes
  • Ilkley – 16 miles – 26 minutes – Electrified
  • Skipton – 26 miles – 43 minutes – Electrified
  • York – 25 miles – 30 minutes

Note, that the extended services would have the following characteristics.

They would be run by one five-car train.

  1. Services to Bradford, Ilkley and Skipton would be electric
  2. Electrification is planned from Leeds to Huddersfield and York, so these services could be electric in a few years.
  3. All other services would need independent power; battery, diesel or hydrogen to and from Leeds.
  4. Two trains would join at Leeds and run fast to London on the electrified line.
  5. Services would probably have a frequency of six trains per day, which works out at a around a train every two hours and makes London and back very possible in a day.
  6. They would stop at most intermediate stations to boost services to and from Leeds and give a direct service to and from London.

As there are thirty trains per day between London and Leeds in each direction, there are a lot of possible services that could be provided.

Currently, LNER are only serving Harrogate via Leeds.

  • LNER are using either a nine-car train or a pair of five-car trains.
  • The trains reverse in Platforms 6 or 8 at Leeds, both of which can handle full-length trains.
  • LNER allow for a generous time for the reverse, which would allow the required splitting and joining.
  • All trains going to Harrogate are Class 800 bi-mode trains.

Note that the Class 800 trains are capable of 125 mph on diesel, whereas the average speed between Harrogate and Leeds is just 35 mph. Obviously, some of this slow speed is due to the route, but surely a train with a maximum speed of 90-100 mph, with an appropriate total amount of diesel power, would be the following.

  • Lighter in weight.
  • More efficient.
  • Emit less pollution.
  • Still capable of high speed on electrified lines.
  • Bi-mode and electric versions could run in pairs between Leeds and London.

LNER would probably save on track access charges and diesel fuel.

LNER To Other Places

Could LNER split and join in a similar way to other places?

  • Doncaster for Hull and Sheffield
  • Edinburgh for Aberdeen and Inverness
  • Newark for Lincoln and Nottingham
  • York for Middlesbrough and Scarborough.

It should be noted that many of the extended routes are quite short, so I suspect some train diagrams will be arranged, so that trains are only filled up with diesel overnight,

GWR

Great Western Railway are another First Group company and I’m sure some of their routes could benefit, from similar planning to that of Avanti West Coast.

Splitting and joining might take place at Reading, Swindon, Bristol and Swansea.

South Western Railway

South Western Railway will need to replace the three-car Class 159 trains to Exeter, that generally work in pairs with a total number of around 400 seats, in the next few years.

These could be replaced with a fleet of third-rail Hitachi trains of appropriate length.

  • Seven cars sating 420 passengers?
  • They would remove diesel trains from Waterloo station.
  • All South Western Railway Trains running between Waterloo and Basingstoke would be 100 mph trains.

I wonder, if in-cab digital signalling on the route, would increase the capacity? It is sorely needed!

Southeastern

Southeastern need bi-mode trains to run the promised service to Hastings.

  • Trains would need a third-rail capability.
  • Trains need to be capable of 140 mph for High Speed One.
  • Trains need to be able to travel the 25 miles between Ashford International and Ore stations.
  • Trains would preferably be battery-electric for working into St. Pancras International station.

Would the trains be made up from six twenty-metre cars, like the Class 395 trains?

The Simple All-Electric Train

The Modern Railways article, also says this about the ten all-electric AT-300 trains for Birmingham, Blackpool and Liverpool services.

The electric trains will be fully reliant on the overhead wire, with no diesel auxiliary engines or batteries.

It strikes me as strange, that Hitachi are throwing out one of their design criteria, which is the ability of the train to rescue itself, when the overhead wires fail.

In Do Class 800/801/802 Trains Use Batteries For Regenerative Braking?, I published this extract from this document on the Hitachi Rail web site.

The system can select the appropriate power source from either the main transformer or the GUs. Also, the size and weight of the system were minimized by designing the power supply converter to be able to work with both power sources. To ensure that the Class 800 and 801 are able to adapt to future changes in operating practices, they both have the same traction system and the rolling stock can be operated as either class by simply adding or removing GUs. On the Class 800, which is intended to run on both electrified and non-electrified track, each traction system has its own GU. On the other hand, the Class 801 is designed only for electrified lines and has one or two GUs depending on the length of the trainset (one GU for trainsets of five to nine cars, two GUs for trainsets of 10 to 12 cars). These GUs supply emergency traction power and auxiliary power in the event of a power outage on the catenary, and as an auxiliary power supply on non-electrified lines where the Class 801 is in service and pulled by a locomotive. This allows the Class 801 to operate on lines it would otherwise not be able to use and provides a backup in the event of a catenary power outage or other problem on the ground systems as well as non-electrified routes in loco-hauled mode.

This is a very comprehensive power system, with a backup in case of power or catenary failure.

So why does it look like Hitachi are throwing that capability out on the trains for Avanti West Coast.

There are several possibilities.

  • The reliability of the trains and the overhead wire is such, that the ability of a train to rescue itself is not needed.
  • The auxiliary generator has never been used for rescuing the train.
  • The West Coast Main Line is well-provided with Thunderbird locomotives for rescuing Pendelinos, as these trains have no auxiliary generator or batteries.
  • Removal of the excess weight of the auxiliary engine and batteries, enables the Hitachi AT-300 trains to match the performance of the Pendelinos, when they are using tilt.

Obviously, Hitachi have a lot of train performance statistics, from the what must be around a hundred trains in service.

It looks like Hitachi are creating a lightweight all-electric train, that has the performance or better of a Pendelino, that it achieves without using tilt.

  • No tilt means less weight and more interior space.
  • No auxiliary generator or batteries means less weight.
  • Wikipedia indicates, that Hitachi coaches are around 41 tonnes and Pendelino coaches are perhaps up to ten tonnes heavier.
  • Less weight means fast acceleration and deceleration.
  • Less weight means less electricity generated under regenerative braking.
  • Pendelinos use regenerative braking, through the catenary.
  • Will the new Hitachi trains do the same instead of the complex system they now use?

If the train fails and needs to be rescued, it uses the same Thunderbird system, that the Pendelinos use when they fail.

Will The New Hitachi Trains Be Less Costly To Run?

These trains will be lighter in weight than the Pendelinos and will not require the track to allow tilting.

Does this mean, that Avanti West Coast will pay lower track access charges for their new trains?

They should also pay less on a particular trip for the electricity, as the lighter trains will need less electricity to accelerate them to line speed.

Are Avanti West Coast Going To Keep The Fleets Apart?

Under a heading of Only South Of Preston, the Modern Railways article says this.

Unlike the current West Coast fleet, the Hitachi trains will not be able to tilt. Bid Director Caroline Donaldson told Modern Railways this will be compensated for by their improved acceleration and deceleration characteristics and that the operator is also working with Network Rail to look at opportunities to improve the linespeed for non-tilting trains.

The routes on which the Hitachi trains will operate have been chosen with the lack of tilt capability in mind, with this having the greatest impact north of Preston, where only Class 390 Pendelinos, which continue to make use of their tilting capability will be used.

Avanti West Coast have said that the Hitachi trains will run from London to Birmingham, Blackpool and Liverpool.

All of these places are on fully-electrified branches running West from the West Coast Main Line, so it looks like there will be separation.

Will The New Hitachi Trains Be Faster To Birmingham, Blackpool And Liverpool?

Using data from Real Time Trains, I find the following data about the current services.

  • Birmingham and Coventry is 19 miles and takes 20 minutes at an average speed of 57 mph
  • Blackpool and Preston is 16.5 miles and takes 21 minutes at an average speed of 47 mph
  • Liverpool and Runcorn is 3.15 miles and takes 15 minutes at an average speed of 52 mph

All the final legs when approaching the terminus seem to be at similar speeds, so I doubt there are much savings to be made away from the West Coast Main Line.

Most savings will be on the West Coast Main Line, where hopefully modern in-cab digital signalling will allow faster running at up to the design speed of both the Hitachi and Pendelino trains of 140 mph.

As an illustration of what might be possible, London to Liverpool takes two hours and thirteen minutes.

The distance is 203 miles, which means that including stops the average speed is 91.6 mph.

If the average speed could be raised to 100 mph, this would mean a journey time of two hours and two minutes.

As much of the journey between London and Liverpool is spent at 125 mph, which is the limit set by the signalling, raising that to 135 mph could bring substantial benefits.

To achieve the journey in two hours would require an overall average speed of 101.5 mph.

As the proportion of track on which faster speeds, than the current 125 mph increase over the next few years, I can see Hitachi’s lightweight all-electric expresses breaking the two hour barrier between London and Liverpool.

What About The Pendelinos And Digital Signalling?

The January 2020 Edition of Modern Railways also has an article entitled Pendolino Refurb Planned.

These improvements are mentioned.

  • Better standard class seats! (Hallelujah!)
  • Refreshed First Class.
  • Revamped shop.

Nothing is mentioned about any preparation for the installation of the equipment to enable faster running using digital in-cab signalling, when it is installed on the West Coast Main Line.

Surely, the trains will be updated to be ready to use digital signalling, as soon as they can.

Just as the new Hitachi trains will be able to take advantage of the digital signalling, when it is installed, the Pendellinos will be able to as well.

Looking at London and Glasgow, the distance is 400 miles and it takes four hours and thirty minutes.

This is an average speed of 89 mph, which compares well with the 91.6 mph between London and Liverpool.

Raise the average speed to 100 mph with the installation of digital in-cab signalling on the route, that will allow running at over 125 mph for long sections and the journey time will be around four hours.

This is a table of average speeds and journey times.

  • 100 mph – four hours
  • 105 mph – three hours and forty-eight minutes
  • 110 mph – three hours and thirty-eight minutes
  • 115 mph – three hours and twenty-eight minutes
  • 120 mph – three hours and twenty minutes
  • 125 mph – three hours and twelve minutes
  • 130 mph – three hours and four minutes

I think that I’m still young enough at 72 to be able to see Pendelinos running regularly between London and Glasgow in three hours twenty minutes.

The paragraph is from the Wikipedia entry for the Advanced Passenger Train.

The APT is acknowledged as a milestone in the development of the current generation of tilting high speed trains. 25 years later on an upgraded infrastructure the Class 390 Pendolinos now match the APT’s scheduled timings. The London to Glasgow route by APT (1980/81 timetable) was 4hrs 10min, the same time as the fastest Pendolino timing (December 2008 timetable). In 2006, on a one off non-stop run for charity, a Pendolino completed the Glasgow to London journey in 3hrs 55min, whereas the APT completed the opposite London to Glasgow journey in 3hrs 52min in 1984.

I think it’s a case of give the Pendelinos the modern digital in-cab signalling they need and let them see what they can do.

It is also possible to give an estimate for a possible time to and from Manchester.

An average speed of 120 mph on the route would deliver a time of under one hour and forty minutes.

Is it possible? I suspect someone is working on it!

Conclusion

I certainly think, that Avanti West Coast, Hitachi and Network Rail, have been seriously thinking how to maximise capacity and speed on the West Coast Main Line.

I also think, that they have an ultimate objective to make Avanti West Coast an operator, that only uses diesel fuel in an emergency.





January 1, 2020 Posted by | Transport | , , , , , , , , , , , , , , , , | 6 Comments
