St. Pancras And Leicester Via Corby

This OpenRailwayMap shows the route between Kettering and Leicester via Corby.

Note.

  1. Kettering station is in the bottom right corner of the map.
  2. Kettering is on the Midland Main Line from St. Pancras.
  3. North of Kettering the route splits into two.
  4. The Midland Main Line goes North-West through Market Harborough to Wigston junction and Leicester.
  5. The Midland Main Line is electrified to Wigston junction.
  6. The Corby branch goes North-East to Corby, which is indicated by a blue arrow.
  7. The Corby branch is electrified to Corby.

On Saturday, I went to Leicester and because there were engineering works at Market Harborough, the train went via Corby.

Over The Welland Viaduct

After Corby, the train went over the Welland Viaduct and I took these pictures.

It is an impressive viaduct and is the longest viaduct across a valley in the United Kingdom.

I have some further thoughts.

Could The Corby Service Be Extended to Leicester?

Consider.

  • Between Corby and Leicester is 40.8 miles of track without electrification.
  • Trains could call at Oakham, Melton Mowbray and Syston stations.
  • Oakham, Melton Mowbray and Syston stations, could be given an appropriate number of trains every day to Leicester, Corby, Kettering, Wellingborough, Bedford, Luton, Luton Airport Parkway and London St. Pancras International stations.
  • No new infrastrructure would be needed.
  • I suspect an hourly service would be sufficient.

I am fairly sure that a Class 810 train fitted with batteries could work the route.

Leicester, Oakham, Melton Mowbray And Syston Stations Would Get A Direct Connection To Luton Airport

Some travellers might find this very useful.

Leicester Station Would Have A Neat Passenger Drop-Off For Luton Airport

I wrote about this in Busiest UK Airports Raise Kiss-and-Fly Fees, Says RAC.

Every rail station needs a passenger drop-off as good and affordable as the one at Leicester station.



July 21, 2025 Posted by | Transport/Travel | , , , , , , , , , , , , , | Leave a comment

‘Rollercoasters In My Back Yard’: Welcome To Universal Studios Bedford

The title of this post, is the same as that of this article on The Times.

This is the sub-heading.

Britain’s answer to Orlando could be a 480-acre world boasting big rides, bigger films and 7m visitors a year. Some locals are far from enchanted

These three paragraphs introduce the story.

Picture the scene: It’s a snowy Christmas Eve, 2030, at King’s Cross station. Dozens of families from across the UK and Europe gather as the station speakers announce: “The train now leaving platform 9¾ is the Hogwarts Express, calling at the Wizarding World of Harry Potter. And Bedford.”

The stuff of JK Rowling’s fiction? Perhaps not.

For, if all goes to plan, a featureless 480 acres of industrial and agricultural land a short broomstick’s ride from downtown Bedford will, by the end of the decade, become one of the world’s most spectacular theme parks.

I have a few thoughts.

Eden Project Morecambe

Eden Project Morecambe will be the first of a new generation of theme parks in the UK.

The new Eden Project is to be developed at Morecambe, which is close to Lancaster. As Lancaster will be an High Speed Two  terminus, Eden Project North could be connected to HS2 by a high tech shuttle like the Luton DART. So the Eden Project North will also attract day trippers from a large proportion of England and the South of Scotland.

I believe increasingly we will see theme parks, bringing in their visitors on futuristic public transport systems.

The Location Of Universal Studios Bedford

This map from Universal Destinations & Experiences shows the location of the site of the proposed Universal Studios Bedford.

Note.

  1. The site is shown by yellow shading.
  2. The blue lines are major roads.
  3. The pink lines are railways.
  4. The rail link running to the West of the site is currently the Marston Vale Line, which is being developed into the East West Railway between Oxford and Cambridge via Milton Keynes.
  5. The East West Railway will also connect to Ipswich, Norwich and Reading.
  6. The rail link running to the East of the site is the Midland Main Line, which links St. Pancras station with Derby, Nottingham and Sheffield.

The site certainly has excellent transport connections.

Expanding Rail Connections At Universal Studios Bedford

I believe that in these days of climate change, that theme parks and other attractions like sports stadia and shopping centres will develop their rail connections.

Universal Studios Bedford could have two stations.

  •  Kempston Hardwick on the East West Railway.
  • Their own station on the Midland Main Line.

Note.

  1. Both stations could be connected by a futuristic people mover transporting visitors around the site.
  2. Using current train times, trains would take thirty minutes between the theme park and St. Pancras for Eurostar to and from Europe.
  3. Thameslink’s trains could shuttle visitors to and from Luton Airport.

It should also be noted that several of Southern England’s most visited sites are just a train ride away.

Easy Places To Visit

These attractions would be easy to visit.

  • Bicester Village – Direct train from Kempston Hardwick after 2024.
  • Cambridge – Direct train from Kempston Hardwick after 2030.
  • London – Direct train from the new station after it’s built.
  • Oxford – Direct train from Kempston Hardwick after 2024.
  • Woburn Safari Park – Direct train from Kempston Hardwick after 2024.

Note.

All trains would be electric or battery-electric powered.

I have assumed that rail services between Oxford and Bedford open in 2024.

I have assumed that rail services between Oxford and Cambridge open in 2030.

Conclusion

This is an interesting idea, which is at an excellent location. But will the locals like it?





December 24, 2023 Posted by | Transport/Travel, World | , , , , , , , , , , , , | 3 Comments

Gatwick Airport – 23rd November 2023

I went to Gatwick Airport to see the new railway station.

Note.

  1. As at Reading and Leeds stations, space has been created by building a wide concourse over the tracks.
  2. The experience certainly seemed better.
  3. Most platforms have up and down escalators and lifts.
  4. There were still a few things  that needed to be finished.

But for me, as a man with a Freedom Pass and a Senior Railcard, the ticketing to Gatwick is still a pain.

  • If I go to Heathrow or London City, I use my Freedom Pass to get to the Airport.
  • If I go to Eurostar, I use my Freedom Pass to get to St. Pancras station.
  • If I go to Stansted, I use my Freedom Pass to get to Liverpool Street station and buy a ticket for Stanstead Express.

If I go to Gatwick, Luton or Southend airports, I use my Freedom Pass to get to a station with a Booking Office and then buy an extension ticket from the Zone 6 boundary to the airport.

I believe there are three solutions.

Make It Possible To Link A Bank Card To A Freedom Pass

It should be possible to do something like the following.

  • Touch in at Moorgate.
  • Take the Elizabeth Line to Farringdon.
  • Take Thames to Gatwick Airport.
  • Check out at Gatwick Airport.

The credit card associated with the Freedom Pass would then be charged the fee for between the Zone 6 boundary and Gatwick Airport.

The credit card would be entered through the Freedom Pass web site.

On a related matter I believe that the Freedom Pass web site could be a nice little earner for Transport for London, by doing the following.

  • Selling rail tickets on a best-priced basis. Savings are to be had by selling tickets for Freedom Pass holders from the Zone 6 boundary.
  • Managing Railcards.
  • Selling Transport for London merchandise.

Nobody would pay more than they do now, but Transport for London would pick up some commission from selling tickets.

Develop A Flexible App That Works With A Freedom Pass And Phone Payments

Similar to the first option, but the app charges accordingly.

Put Gatwick Airport In Zone 6

The management of Gatwick Airport might like to attract more travellers, so they would pay from the Zone 6 boundary for Freedom Farm users.

Conclusion

I would find the first two options acceptable, providing the charges were no more than now!

November 24, 2023 Posted by | Transport/Travel | , , , , , , , , | 1 Comment

Thoughts On The East Midlands Railway Timetable After Class 810 Trains Enter Service

East Midlands Railway will soon be replacing their diesel Class 222 trains with new bi-mode Class 810 trains.

  • 32 trains will be replaced by 33 trains.
  • 167 cars will be replaced by 165 cars.
  • The current trains come in four, five and seven cars.
  • The new trains come in five-cars only.
  • The platforms at St. Pancras station can accept a pair of the new trains.
  • Both Class 222 and Class 810 trains are genuine 125 mph trains.
  • St. Pancras and Corby takes one hour and fifteen minutes
  • St. Pancras and Nottingham takes hour and forty-five minutes
  • St. Pancras and Sheffield takes two hours

The current services are as follows.

  • St. Pancras and Corby via Luton Airport Parkway, Luton, Bedford, Wellingborough and Kettering
  • St. Pancras and Nottingham via Kettering, Market Harborough, Leicester, Loughborough (1 tph), East Midlands Parkway (1 tph) and Beeston (1 tph).
  • St. Pancras and Sheffield via Leicester, Loughborough (1 tph), East Midlands Parkway (1 tph), Long Eaton (1 tph), Derby and Chesterfield.

Note.

All services are two trains per hour (tph)

If all services were run by single trains, the following number of trains would be needed for each service.

  • St. Pancras and Corby – 6 trains
  • St. Pancras and Nottingham – 8 trains
  • St. Pancras and Sheffield – 9 trains

Note.

  1. This means a total of twenty-three trains.
  2. I am assuming, that trains can turn round in fifteen minutes at each end of the journey.
  3. If pairs of trains run, then the numbers can be doubled to forty-six trains.

These are my thoughts.

Do The Luton Airport Express Services Need Pairs Of Trains?

The Corby service is now branded as the Luton Airport Express.

This picture shows a packed Luton Airport Express at Luton Airport Parkway station.

After seeing this, I believe that a pair of trains must run to Corby to pick up passengers, who want a fast service to and from Luton Airport.

Will The Class 810 Trains Replace The Class 360 Trains To Corby?

If all services are run by single Class 810 trains, the following would apply.

  • The current service pattern would need 23 trains.
  • All stations would get the same number of trains to and from St. Pancras.
  • All East Midlands Railway out of St. Pancras would use the same 125 mph electric trains and services could probably be speeded up.
  • The Class 810 train has 2.94 MW on diesel and the Class 360 train has 1.55 MW on electric, so I suspect that the Class 810 train has the faster acceleration.
  • Bedford, Kettering, Luton, Luton Airport Parkway, Market Harborough and Wellingborough would have 125 mph electric commuter services to and from London.
  • Corby and Luton Airport Parkway services would have marginally more seats, if Corby services were pairs of trains.

There would be ten spare trains, if the Class 360 trains were replaced or four spare trains, if pairs of trains ran to Corby.

Would Class 810 Trains Running On Electric Execute Stops Faster?

This document on Rail Engineer gives these figures for total power on electric of Class 802 trains.

  • Five-car – 2712 kW
  • Nine-car – 4520 kW

Note.

  1. These figures are based on a Hitachi figure of 226 kW for the power of a traction motor.
  2. The five-car train has twelve motors and the nine-car has twenty.
  3. As a five-car train has three powered cars and a nine-car train has five, it looks like each powered car has four traction motors.
  4. The document also says that the power to weight ratio on electric is thirty percent more than on diesel.

This  document on the Hitachi web site provides this schematic of the traction system.

Note that four traction motors are confirmed.

Consider the power of the various trains, that run or will run on the Midland Main Line.

  • Four-car Class 180 train has one 559 kW diesel engine per car.
  • Four, five and seven-car Class 222 train has one 559 kW diesel engine per car.
  • Four-car Class 360 train has 1.55 MW on electric – 387 kW per car.
  • Five-car Class 810 train has 2.94 MW on diesel – 588 kW per car.
  • Five-car Class 810 train has 2.94 MW on electric – 588 kW per car.

Note.

  1. The Class 810 train will out-accelerate the Class 360 train as it has at least 40 percent more power on electric.
  2. The Class 810 train has pantographs on both driving cars.
  3. The Class 810 train has two powered cars; numbers 2 and 4.
  4. I have assumed that if the Class 810 train can handle 2.94 MW on both diesel and electric.
  5. With eight traction motors, they would need to be 367.5 kW.
  6. The Class 810 train should out-accelerate the Class 180 train and Class 222 train as it has at five percent more power on both diesel and electric.

I think it is also relevant that the order for the Class 810 trains was placed in August 2019 and Hitachi announced their collaboration with Eversholt Rail Group to develop the battery-electric versions of the Class 802 trains only sixteen months later. As the Class 810 appears to be an revolution of the Class 802 train, I suspect that Hitachi were working hard on battery design, as this train’s design evolved.

These are the five cars of the Class 810 train.

  • 1 – DPTS – Driver-Pantograph-Trailer-Standard with Generator Unit
  • 2 – MS – Motored-Standard with Generator Unit
  • 3 – TS – Trailer-Standard with Transformer
  • 4 – MC – Motored-Composite with Generator Unit
  • 5 – DPTF – Driver-Pantograph-Trailer-First with Generator Unit

Note.

  1. Generator Unit is a diesel generator.
  2. Motored means the car has four traction motors.
  3. Composite means a car with both First and Standard accommodation.
  4. Cars 1-2, and 4-5, form two power units with two generator units, four traction motors and a pantograph, at each end of the train. Cables would connect them to the transformer in car 3.

It looks a neat solution, which probably has high reliability.

I can envisage the  two generator units under cars 2 and 4 could be replaced by battery packs.

  • The battery packs would mimic the function of the generator units.
  • Noise in cars 2 and 4 would be reduced.
  • Carbon emissions would be reduced.
  • The battery packs would be charged, when running under the wires or possibly from chargers or short length of overhead wires at terminal stations.
  • The battery packs would handle regenerative braking.
  • Adding battery packs would allow the trains to jump gaps left in the electrification.

At some point in the future, the other two generator units could be removed or replaced with battery packs, depending on whether full electrification happens on the Midland Main Line.

These meanderings convince me that the Class 810 trains will be able to save time in the stops on the Midland Main Line.

Because of these savings, I can see East Midlands Railway, reorganising stops on the electrified section of the route, as although the stop will add a minute or two, this lost time will be picked up on savings at existing stops and by more 125 mph running.

Could The Nottingham And Sheffield Services Be Combined?

These are the current services to Nottingham and Sheffield.

  • St. Pancras and Nottingham via Kettering, Market Harborough, Leicester, Loughborough (1 tph), East Midlands Parkway (1 tph) and Beeston (1 tph).
  • St. Pancras and Sheffield via Leicester, Loughborough (1 tph), East Midlands Parkway (1 tph), Long Eaton (1 tph), Derby and Chesterfield.

Note.

  1. Both services call at Leicester , Loughborough and East Midlands Parkway.
  2. Some trains call at Luton Airport Parkway, Luton, Bedford, Wellingborough, Kettering and Market Harborough on the section of the Midland Main Line, which is currently being electrified between Kettering and Wigston.
  3. A lot of money has been spent on the Luton DART and it only has two fast trains from St. Pancras. Four tph would be ideal.

Suppose the Sheffield and Nottingham trains operated like this.

  • A pair of Class 810 trains would leave St. Pancras.
  • South of Leicester, they would call at one or two stations, as defined in the timetable.
  • They would then call at Leicester , Loughborough and East Midlands Parkway.
  • At East Midlands Parkway, the two trains would split.
  • One train would go to Sheffield and the other would go to Nottingham, stopping as defined in the timetable.

Note.

  1. Because of the trains superior performance, they would be doing quicker calls at stations, which should allow the existing timetable to be maintained or even improved.
  2. Hitachi trains can split and join in around two minutes.
  3. These trains would call at Luton Airport Parkway, to give that station four tph from St. Pancras, Luton and Bedford.

I calculated earlier that a 2 tph Sheffield service would need nine trains. So if it served both Nottingham and Sheffield it would need another nine trains. This would give a total of eighteen trains.

  • If the St.Pancras and Corby service were to be run by pairs of Class 810 trains, this would require twelve trains.
  • Adding the two services together would require thirty trains. Would three trains be enough for backup and in maintenance?

I suspect splitting and joining at East Midlands Parkway could be beneficial.

Could Four tph Be Run To Nottingham And Sheffield?

Consider.

  • Bristol, Cardiff, Edinburgh, Leeds, Liverpool, Manchester, Newcastle, Norwich, Southampton and York all get two tph from London.
  • Some closer stations like Birmingham, Cambridge, Ipswich, Leicester, Oxford and Reading get more.
  • Most of these routes are electrified and run modern trains.

I wouldn’t say never, but adding two tph to both Nottingham and Sheffield services would require.

  • Two more hourly train paths on both between St. Pancras and Nottingham, and St. Pancras and Sheffield.
  • Eighteen extra trains.

But as a sub-two hour service would be running on both routes, it would probably be possible to accurately predict, when more trains were needed.

Electrification Through Leicester

As more electrification is added, this should result in faster journeys, that reduce carbon emissions.

OpenRailwayMap is now showing the electrification as dotted lines on the Midland Main Line.

This map shows the electrification scheme through Leicester.

Note.

  1. Only the two main lines in the centre of the station seem to be going to be electrified.
  2. These lines are used by East Midlands Railway’s through trains and surprisingly some freight trains.
  3. Terminating services from places like Birmingham, Grimsby and Lincoln seem to stop in the outer platforms.

This picture shows the platforms from the Northern footbridge.

This picture shows the platforms from the Northern footbridge.

At the Southern end of the station, the tracks go under the London Road bridge. This map shows the tracks there.

Note.

  • The two main tracks of the Midland Main Line appear that they will be electrified.
  • But the lines at each side are not electrified.

Some years ago I came back to London from Leicester with a group of drivers. At one point, the conversation turned to electrification and they said that they had met a Network Rail engineer, who had told them, that the bridge was rather low for electrification and the track couldn’t be lowered because Leicester’s main sewer was underneath the railway.

It looks like Network Rail have found a way to squeeze two electrified tracks through the middle of the bridge and then use diesel, battery or other self-powered trains on lines without electrification on either side.

























May 30, 2023 Posted by | Transport/Travel | , , , , , , , , , , , , , | 2 Comments

Moorgate And Luton Airport Parkway

This morning I went by train from Moorgate to Luton Airport Parkway to have a look at the Luton DART.

I used the following route.

  • Elizabeth Line – Moorgate to Farringdon.
  • Thameslink – Farringdon to Luton Airport Parkway.

I came back from Luton Airport Parkway on a Luton Airport Express.

I took these pictures on the route.

Note.

  1. The change at Farringdon station was very easy.
  2. You walk past toilets at the Farringdon change.
  3. There are two bridges, lots of escalators and lifts at Luton Airport Parkway station.
  4. I didn’t take the DART to the airport.

These are some detailed thoughts.

Luton Airport Parkway Station

It is a much improved station, but still has some work to do.

  • There was a problem with one escalator.
  • Some of the signage is not finalised.
  • I had a problem with ticketing, as I was sold the wrong ticket.
  • Staff probably need a bit more training.

But then the station has only been open three weeks.

Luton Airport Express

East Midland Railway’s St. Pancras and Corby service is now branded as Luton Airport Express.

  • It has its own web site.
  • Trains only stop at Luton Airport Parkway, Luton, Bedford, Wellingborough and Kettering.
  • Trains take as little as twenty-two minutes between St. Pancras and Luton Airport Parkway.
  • Class 360 trains are used.
  • Trains run every thirty minutes.

As it serves the local area, I wonder how many airport employees, now use this train to get to work?



April 14, 2023 Posted by | Transport/Travel | , , , , , , , , , | Leave a comment

Silvertown Tunnel Bus Network Proposals

This web page is the Silvertown Tunnel Bus Network Proposals.

These proposals are made.

  • A new high frequency, limited stop service between Grove Park and Canary Wharf referred to in this consultation as route X239
  • To extend route 129 (Lewisham – North Greenwich) north across the river to Great Eastern Quay via the Royal Docks development zone
  • A minor change to route 108 so that it uses the new Millennium Way slip road to exit the Blackwall Tunnel southbound
  • We are also seeking your views on route options for three sections of routes 129 and X239.

It looks like route 108 will continue to use the current stop.

The proposals include this map.

I copied this map from the TfL web site, as they don’t provide one for people who want or need to use it.

These are my observations.

The 108 Bus

The 108 seems to be more or less as now and will be continue to be run by a single-decker bus, as double-decker buses can’t use the Blackwall Tunnel.

North of the Thames, the 108 calls at these stations.

  • Stratford International for DLR and National Rail.
  • Stratford for DLR, Central, Elizabeth and Jubilee Lines, and National Rail.
  • Bow Church for DLR
  • Devons Road for DLR
  • Langdon Park for the DLR
  • Bazely Street (All Saints) for DLR

South of the Thames, the 108 calls at these stations.

  • North Greenwich for the Jubilee Line.
  • Westcombe Park for National Rail
  • Blackheath for National Rail
  • Lewisham for DLR and National Rail

Note.

  1. It is possible to go between Lewisham and Stratford on the DLR with a change at Canary Wharf.
  2. It is possible to go between North Greenwich and Stratford on the Jubilee Line.
  3. Westcombe Park station is on the Greenwich Line.

I would wonder, if many people use this bus route for long distances.

The 129 Bus

Note.

  1. The 129 appears to connect Lewisham and Greenwich to the City Airport and the Becton branch of the DLR.
  2. Many journeys on the 129 bus, might be easier using the DLR, with a change at Westferry or Poplar, which is probably what travellers do now.
  3. The 129 bus is shown on the map with a stop at Silvertown. Does that mean that it could connect with a Silvertown station on the Elizabeth Line?
  4. As the 129 bus will pass through the larger Silvertown Tunnel, it could be a double-decker route, instead of the current single-decker.

North of the Thames, the 129 calls at these stations.

  • Gallions Reach for the DLR
  • Beckton for the DLR
  • Royal Albert for the DLR
  • London City Airport for the DLR
  • Silvertown
  • Pontoon Dock for the DLR
  • West Silvertown for the DLR

South of the Thames, the 129 calls at these stations.

  • North Greenwich for the Jubilee Line.
  • Cutty Sark for DLR
  • Greenwich for DLR and National Rail
  • Lewisham for DLR and National Rail

Would improvements and a frequency increase to the DLR and the building of Silvertown station, mean that changes to the 129 bus route, would not be so important?

The X329 Bus

Note.

  1. Canary Wharf must be served and starting at Westferry Circus is probably a good choice.
  2. But is Grove Park station, the ideal Southern terminal?
  3. Not stopping the X329 bus at North Greenwich is probably correct, as North Greenwich station is a large Jubilee Line and bus interchange close to the O2.

North of the Thames, the X329 calls at these stations.

  • Canary Wharf for DLR and Elizabeth and Jubilee Lines

South of the Thames, the X329 calls at these stations.

  • Blackheath for National Rail
  • Lee for National Rail
  • Grove Park for National Rail

Note.

  1. Blackheath station is on the Bexleyheath and North Kent Lines.
  2. Lee station is on the Dartford Loop Line.
  3. Grove Park station is on the South Eastern Man Line.
  4. Grove Park has a bus station, where there could be space for a battery charger for electric buses.

The X329 seems to have been partly designed on the premise, that an express bus should be run through the Silvertown Tunnel. But it does connect four of the rail lines going into London terminals to Canary Wharf.

Silvertown Station For London City Airport

Silvertown station would more than double the number of stations with easy routes to the London City Airport.

The Elizabeth Line would enable the direct connection that is needed to Canary Wharf, the City of London, Heathrow, Liverpool Street and Paddington stations and the West End.

  • A single change at Abbey Wood, would give access to much of Kent.
  • A single change at Farringdon, would give access to Thameslink services and Gatwick and Luton airports.
  • Around 2030, a single change at Old Oak Common, would give access to High Speed Two services.
  • A single change at Paddington, would give access to Wales and West services.
  • A single change at Whitechapel, would give access to the great circle of the London Overground.

I believe the case for a Silvertown station with at least a good walking route to the London City Airport is strong, and the station would be a marvellous asset for Silvertown and the Airport.



January 7, 2023 Posted by | Transport/Travel | , , , , , , , , , , , , , , , , , , , , | 2 Comments

A Trip To Corby

I took these pictures on a trip to Corby this morning.

These are my thoughts.

Trains To And From Corby

I got a Class 222 train to Corby and an eight-car Class 360 train back.

Brent Cross West Station

There was a lot of constructruction activity at the new Brent Cross West station.

Luton Airport Parkway Station

The extensions to Luton Airport Parkway station look to be comprehensive, with several escalators.

The Luton DART connection to Luton Airport appears to be under test, so should open in 2022.

But will there be any air passengers to use it?

I last used it in 2008, when I went to see England play in Belarus.

Electrification North Of Bedford

The electrification North of Bedford station is obviously complete on the slow lines, but on the fast lines, as the pictures show, the gantries are all erected, but there are still wires to be installed.

But as the Class 810 trains won’t be in service until 2023, there’s still a bit of time.

The gantries certainly look sturdy, as this picture shows.

They’re certainly built for 125 mph, but as the Class 810 trains will be capable of 140 mph with full digital in-cab signalling, I would hope that the electrification has been installed to that standard. Or at least to a standard, that can be easily upgraded!

Corby Station

Corby station has been finished to a single-platform station, which is able to accept a twelve-car Class 360 train.

This should be adequate for the current half-hourly service, as a single platform can handle a least four trains per hour (tph) and several around the country regularly do.

Both tracks through the station are electrified and I suspect with a second platform bridge, both could be used by electric trains to create a two-platform station.

But there would appear to be no need at the moment.

Even, if it were to be decided to extend one tph to Oakham and Melton Mowbray stations, this could probably be accommodated on the single-platform.

Network Rail seem to have already installed a crossover South of Corby station, so that trains can use the single platform.

Serving Oakham And Melton Mowbray

I discussed this extension in detail in Abellio’s Plans For London And Melton Mowbray Via Corby And Oakham.

In the related post, I said this.

This page on the Department for Transport web site is an interactive map of the Abellio’s promises for East Midlands Railway.

These are mentioned for services to Oakham and Melton Mowbray.

    • After electrification of the Corby route there will continue to be direct service each way between London and Oakham and Melton Mowbray once each weekday, via Corby.
    • This will be operated with brand new 125mph trains when these are introduced from April 2022.

This seems to be a very acceptable minimum position.

When my Class 222 train arrived in Corby at 1154, it waited a couple of minutes then took off to the North.

I then took the next train to London, which was an eight-car Class 360 train which formed the 1211 service back to St. Pancras.

Meanwhile the Class 222 train, that I’d arrived on did a reverse in the Corby North Run Around Loop finally arriving back in Corby at 1345. The train had taken one hour and forty-nine minutes to return to Corby.

It might be just coincidence, but are East Midlands Railway doing timing tests to see if services can be extended to Oakham And Melton Mowbray?

It should be noted that service times North of Corby are as follows.

  • Corby and Oakham – 19 mins – 14.3 miles
  • Corby and Melton Mowbray – 31 mins – 25.7 miles
  • Melton Mowbray and Leicester – 17 mins – 12.8 miles (estimate) – CrossCountry service

My logic goes like this.

  • It looks to me that it would not be unreasonable that a Class 222 train could run between Corby and Leicester in forty-eight minutes.
  • Double that and you get one hour and thirty eight minutes, for a journey from Corby to Leicester and back.
  • Subtract that time from the one hour and forty-nine minutes that my train took to reverse and there is eleven minutes for a turnback at Leicester station.
  • Eleven minutes would certainly be long enough to tidy a train and for the crew to change ends.

I also believe that the 35.8 miles would be possible for a Class 810 train fitted with one or more battery power-packs instead of a similar number of the four diesel engines.

So are East Midlands Railway doing tests to find the most efficient way to serve Oakham And Melton Mowbray?

On The Corby Branch

I travelled North on a Class 222 diesel train and South on an electric Class 360 train.

On the Corby branch, I was monitoring the train speed on an app on my phone and both trains travelled at around 90 mph for most of the way.

There were sections at up to 100 mph and the track was generally smooth.

I was left with the impression, that trains might be able to go faster on the branch.

Average speeds for the 2.5 miles of the branch were as follows according to these timings from realtimetrains.

  • Class 222 train – Arriving – 5.25 mins – 28.6 mph
  • Class 222 train – Leaving – 5 mins – 30 mph
  • Class 360 train – Arriving – 7.5 mins – 20 mph
  • Class 360 train – Leaving – 5 mins – 30 mph

It doesn’t appear that there are much difference in the timings, although it might be said, that the electric approach is more cautious.

The Class 360 Trains

The Class 360 trains have not been refurbished yet although as my pictures show, some have been given a new livery.

In Are Class 360 Trains Suitable For St. Pancras And Corby?, I said this about the train refurbishment.

This page on the Department for Transport web site is an interactive map of the Abellio’s promises for East Midlands Railway.

These features are mentioned for Midland Main Line services to Corby.

    • Increased capacity
    • Twelve-car trains in the Peak.
    • More reliable service
    • Improved comfort
    • Passenger information system
    • Free on-board Wi-Fi
    • At-seat power sockets
    • USB points
    • Air conditioning
    • Tables at all seats
    • Increased luggage space
    • On-board cycle storage

What more could passengers want?

It certainly hasn’t happened in full.

I did ask a steward, when the new interiors will be installed and he said they were running late because of the pandemic.

Performance Of The Class 360 Trains

I used my app to follow the speed of the Class 360 train, that brought me back to London.

  • The train hit a maximum speed of about 105 mph.
  • The train arrived in London a minute late.

I feel that as the drivers get used to their new charges, they will match the timetable.

Conclusion

I have a feeling that in a couple of years, these trains will fulfil Abellio’s promises.

May 19, 2021 Posted by | Transport/Travel | , , , , , , , , , , , , | Leave a comment

Thoughts On The Class 360 Trains On The London St. Pancras And Corby Route

In May the Class 360 electric trains will be introduced by East Midlands Railway on the service between St. Pancras and Corby stations.

The Class 360 train is on the left.

The following data has come from Real Time Trains.

  • St. Pancras and Corby are 79.3 miles apart.
  • The current service stops at Kettering, Wellingborough, Bedford and Luton.
  • The new electric service stops at Kettering, Wellingborough, Bedford and Luton and Luton Airport Parkway.
  • Current services take between 67 and 73 minutes
  • The new electric services take between 71 minutes
  • Services leave St. Pancras at XX:15 and XX:45
  • Services leave Corby at XX:11 and XX:40
  • Turnround at St. Pancras appears to be about 23-25 minutes
  • Turnround at Corby appears to be about 12-16 minutes.
  • St. Albans and St. Pancras takes 14 minutes.

Note.

  1. The Class 222 train has a top speed of 125 mph and a maximum acceleration: of 0.80 ms-2
  2. The Class 360 train has a top speed of 110 mph and a maximum acceleration: of 0.98 ms-2

Looks like a case of swings and roundabouts to me!

I can deduce the following.

Average Speed

Consider.

  • Assuming a trip time of seventy minutes for the Class 222 train, gives an average speed of 68 mph including stops.
  • Assuming a trip time of seventy-one minutes for the Class 360 train, gives an average speed of 62 mph including stops.

These speeds don’t seem to be too difficult to achieve. Especially, as the Midland Main Line is a series of straight line between a number of stations., which are ideal for a quick dash in between.

It’s A Three Hour Round Trip

Add up the two 71 minute trips and the turnaround times and it looks to be a comfortable three hour round trip.

So for a two trains per hour (tph) service, you will need six formations of Class 360 trains.

As it looks like each formation will be twelve cars long, that will mean that eighteen of the current twenty-one trains will be needed.

The three spare trains will be very useful, whilst the trains are refurbished with new liveries and interiors.

Route Capacity

This picture shows a five-car Class 222 train at Corby station.

Consider.

  • The current five-car Class 222 trains have a capacity of 50 First Class and 192 Standard Class seats
  • Four-car Class 222 trains have a capacity of 33 First Class and 132 Standard Class seats.
  • A four-car Class 360 train has a capacity of 16 First Class and 264 Standard Class seats.

I can do a simple calculation.

  • The current one tph service, if run by a five-car Class 222 trains would have an hourly capacity of 50 First Class and 192 Standard Class seats.
  • The planned two tph service if run by twelve-car 360 trains has an hourly capacity of 96 First Class and 1584 Standard Class seats.

First Class capacity on the route has doubled and Standard Class accommodation has gone up by a massive 8.25 times.

The latter figure will probably be reduced as some of the seats are to be removed for a more spacious interior with tables.

Serving Luton Airport

It looks like these trains will enable a quick journey to Luton Airport.

  • The St. Pancras and Corby train will take 22 minutes between St. Pancras and Luton Airport Parkway stations.
  • There will be the Luton DART connecting Luton Airport Parkway to the Airport from 2022.
  • I suspect Luton Airport will be aiming for a thirty minute journey between St. Pancras and the Airport.
  • The fast service will have a frequency of two tph.

It will not compare badly with rail times from London to Gatwick of 35 minutes and to Stansted of 50 minutes.

Services To Oakham And Melton Mowbray

Consider.

  • Oakham and Melton Mowbray stations are on the route between Corby station and the Midland Main Line North of Leicester.
  • Oakham and Melton Mowbray stations have a one train per day (tpd) in both directions to London via Corby.
  • In Beeching Reversal – Increased Services To Nottingham And Leicester, via Syston And Loughborough From Melton Mowbray. I wrote about how the local MP wants better services at Melton Mowbray.
  • Oakham is 11.5 miles from Corby.
  • Melton Mowbray is 25.8 miles from Corby.
  • Leicester is just over forty miles from Corby and could be covered in under an hour.
  • A pair of Class 810 trains are the same length as a trio of Class 360 trains, so both trains would fit all platforms.

I think that there are a lot of possibilities for services through Corby.

  • Class 810 trains could use Corby as a diversion, when the Midland Main Line is closed for engineering works.
  • Class 810 trains could run a service between St. Pancras and Leicester via Corby, Oakham and Melton Mowbray.
  • If the Class 360 trains could be fitted with batteries, they should be able to provide a service from St. Pancras to Melton Mowbray and perhaps Leicester.

It could even provide an alternative route to London, if Leicester station has to be substantially rebuilt for electrification..

Conclusion

This not the longest of electric services, but I can see it carrying a lot of passengers.

It will also give a boost to Luton Airport.

April 7, 2021 Posted by | Transport/Travel | , , , , , , | 12 Comments

Luton DART Fly Through

This video does what it says in the title.

It certainly looks like the DART will greatly improve the experience of getting to Luton Airport.

February 24, 2021 Posted by | Health, Transport/Travel | , , , , , | 1 Comment

Construction Of The Luton Direct Air-Rail Transit (DART) Has Started

The Luton DART will connect Luton Airport to Luton Airport Parkway station.

This map from the London Luton Airport web site shows the route.



It is comprehensive with three planned stations.

  • Luton Airport Parkway station.
  • Central Terminal
  • as it is planned to build a stop at the Mid-Stay car park, at a later date.

Note how the DART runs along the Airport side of the Midland Main Line before crossing over into the Airport on the Gateway Bridge, which is shown as an inset on the map.

These pictures show the construction of the DART underway at Luton Airport Parkway station.

It certainly looks substantial.

According to Wikipedia, it will open in 2021.

September 3, 2019 Posted by | Transport/Travel | , , | 1 Comment

« Previous Entries
