Cardiff Queen Street Station

Cardiff Queen Street station is the first station to be refurbished for the proposed South Wales Metro.

Note.

  1. The station is fully step-free.
  2. The platforms are wide, which helps interchange or waiting for your destination. See Canada Water on the Overground and St. Pancras on Thameslink.
  3. Currently, to get to Cardiff Bay station, you need to catch a five trains per hour (tph) shuttle train from Platform 1.

The service pattern is fairly-straight-forward, with the following lines passing though the station from South to North.

It is said, that to build anything, you need good foundations.

These services through Cardiff Queen Street station, seem to be a good foundation for the South Wales Metro.

The current proposed services through the station after the Metro is completed are.

  • 2 tph – Coryton Line between Penarth and Coryton stations via Cardiff Central – Tri-Mode Stadler Flirts
  • 2 tph – Cynon Line between The Flourish and Aberdare stations.. – Stadler Citylink Metro Vehicles
  • 2 tph – Rhondda Line between Cardiff Queen Street and Treherbert stations – Stadler Citylink Metro Vehicles
  • 2 tph – Rhondda Line between The Flourish and Treherbert stations – Stadler Citylink Metro Vehicles
  • 2 tph – Rhymney Line between Barry Island and Rhymney stations via Cardiff Central – Tri-Mode Stadler Floirts
  • 2 tph – Rhymney Line between Bridgend and Rhymney stations via Cardiff Central – Tri-Mode Stadler Flirts
  • 2 tph – Rhymney Line between Penarth and Caerphilly stations via Cardiff Central – Tri-Mode Stadler Flirts
  • 2 tph – Taff Line between The Flourish and Merthyr Tydfil stations – Stadler Citylink Metro Vehicles
  • 2 tph – Cynon and Taff Lines between Aberdate and Merthyr Tydfil stations via the City Line and Cardiff Central – Stadler Citylink Metro Vehicles.

Summarising services gives these figures.

  • 6 tph – To and from The Flourish – Stadler Citylink Metro Vehicles
  • 10 tph – To and from Cardiff Central – Tri-Mode Stadler Flirts
  • 2 tph – To and from Cardiff Central – Stadler Citylink Metro Vehicles

This Google Map shows Cardiff Queen Street station.

Note.

  1. The bay platform, which is numbered 1, is in the South East corner of the station. is used for services to Cardiff Bay station.
  2. There is no North-facing bay platform.
  3. Northbound trains for Aberdare, Merthyr Tydfil and Treherbert share Platform 5.
  4. Northbound trains for Bargoed, Coryton and Rhymney share Platform 4.
  5. Sounthbound trains use Platforms 2 and 3.

I believe that this layout will be changed  in the creation of the South Wales Metro.

In an ideal world passengers should have a same-platform or cross-platform interchange between services going in the same direction.

If services going in the same direction shared the same platform, this would meet sixteen tph using two platforms, as two tph will terminate at Cardiff Queen Street station.

Canada Water station on the East London Line of the London Underground in a couple of years will be handling twenty tph.

  • The platforms are wide with escalators, lifts and stairs.
  • Four Southern destinations and Two Northern destinations are served.
  • All services are run by Class 378 trains.
  • Access between train and platform is step free and wheel-chairs and buggies can be pushed across.
  • The East London Line has modern signalling.

If Crossrail and Thameslink will be able to handle twenty-four tph with digital signalling, I believe a solution can be found so that sixteen tph can pass through Cardiff Queen Street station.

Having seen wide platforms in operation at stations like Canonbury, London Bridge and Whitechapel, I feel an ideal layout at Queen Street station would be to use Platform 3 for all Southbound services and Platform 4 for all Northbound services, with as  wide a platform as possible in between.

Consider.

  • Passengers from Rymney and Coryton needing to go to The Flourish, would get off the train and get a Citylink for The Flourish.
  • Passengers between The Flourish and Cardiff Central would just have to walk across the platform at Queen Street station to change trains.
  • Passengers needing a train to Rhoose Airport could choose to change at Queen Street station.

Most waits at Queen Street station would be in a few minutes.

Although, passengers would wait longer for Barry Island, Bridgend and Rhoose Airport.

There is still the problem about what to do with the two tph that from Treherbert that terminate at Queen Street station.

  1. They could use Platform 2 or 5.
  2. They could use a new bay platform in the North end of Pltform 3/4.
  3. They could go through Queen Street station to terminate at The Flourish
  4. They could go through Queen Street and Central stations to terminate elsewhere.

Option 1 would have problems.

  • Every thirty minutes a Citylink would have to cross the busy lines to the North of Queen Street station.
  • Passengers wouldn’t always use the same platform for the Rhondda Line.
  • Passengers wouldn’t have an easy interchange at Queen Street station.

Option 2 would be better.

  • The track layout would be similar.
  • Rhondda Line passengers would only have the inconvenience of sometimes walking along the platform.

.Even if this option was not used to turn trains, I suspect it could be built, as it would also be useful for service recovery purposes.

I like Option 3, although it will have the following consequences.

  • ,The Flourish would need to be able to handle eight tph on the two proposed platforms.
  • Queen Street station would need to be able to handle eighteen tph in both directions.

I suspect that both problems are solvable.

The problem with Option 4 is where do you turn the two extra trains?

I suspect that the Citylink vehicles can only use the City Line after Cardiff Central.

Would it be a good idea or not to run four tph on this route?

I don’t know! But a personable young station man at Queen Street station, said that handling the football can be a problem.

So perhaps more trains going to Ninian Park station might be a good idea.

I write about it in detail in The South Wales Metro and Big Events.

Conclusion

Cardiff Queen Street station has the possibility to be a World Class Metro interchange.







June 10, 2018 Posted by | Travel | , , , , , , , , , , , | Leave a comment

How Can Discontinuous Electrification Be Handled?

On the proposed South Wales Metro, it is proposed to use discontinuous electrification to avoid rebuilding a lot of bridges and other structures.

This document on the KeolisAmey web site details their plans for the new Wales and Borders Franchise.

The document states this about the electrification.

Discontinuous overhead line electrification to 25 KVAC with permanently earthed sections around restricted structures, saving 55 interventions e.g. rebuilding bridges/no need for wire in Caerphilly tunnel.

So how are these interventions avoided?

The Karlsruhe Solution

On the Karlsruhe Stadbahn, similar Citylink vehicles to those proposed for Cardiff need to work on both the main line 15 KVAC used in Germany and the 750 VDC used by Karlsruhe trams.

To isolate the two voltages, a ceramic rod is placed in the catenary. The vehicle’s pantograph just rides across the voltage boundary and the vehicle’s electrical system uses whatever voltage is present.

Bridges On The South Wales Metro

These pictures show some of the types of bridges on the Cardiff Valleys Lines.

They are a real assortment.

  • Some station footbridges from the Victorian era with nice castings and decoration, but no much-needed step-free access.
  • Some quality brick and stone arch bridges.
  • British Rail-era steel bridges, with no architectural merit
  • Some modern road bridges in steel and concrete.

I also saw sizeable pipelines over the railway, which would need to be raised.

The greatest number were simple steel bridges like the one at Caerphilly station, designed to get pedestrians and cyclists, who were not using the railway, from one side of the tracks to the other.

I suspect the simplest way would be to erect two standard gantries at a safe distance of a few metres either side of the structure.

Between the two gantries would be an conductor, like this one. that I photographed in the Berlin Hauphtbahnhof.

It would be earthed, so that it offered no danger to life. There could even be extra supports under the bridge.

At each end, it would be connected to the 25 KVAC using a ceramic rod or other insulating device.

The vehicle’s pantograph would then ride from one side of the bridge to the other on its own track without being lowered.

Anything electrified at 25 KVAC would be kept at a very safe distance from the bridge.

In the earthed section, when the vehicle would be receiving no power, the vehicle would automatically switch to battery power. There would be no driver action required, except to monitor it was all working as it should.

As on the South Wales Metro, it appears that all vehicles using the lines proposed to be electrified will have their own onboard batteries, there shouldn’t be any problem.

In some ways, this discontinuous operation is a bit like using your laptop connected to the mains. When say the cleaner pulls out the plug to put in the vacuum cleaner, your laptop switches automatically to the battery.

The Caerphilly Tunnel

The Caerphilly tunnel is over a mile long. This picture shows the tunnel entrance.

It would probably be possible to electrify using a rail in the roof, but why bother if the trains running through the tunnel could go from one end to the other on their own battery power?

Trains could lower the pantograph before entry and then raise it again, when under the electrification at the other end.

This could be performed automatically using a GPS-based system.

I have also had an e-mail, which said this.

As I understand Caerphilly will have a natural bar in it but be much closer to the train roof than would be allowed with a live one.

Now there’s an idea!

A composite or earthed metal rail would be fixed to the roof of the tunnel, so that the pantograph could run smoothly from one electrified section on one side of the tunnel to the electrification on the other side, using battery power all the way.

Cost Savings

In Novel Solution Cuts Cardiff Bridge Wiring Cost, I talked about another method applied in South Wales to avoid rebuilding a bridge.

At this bridge, traditional electrification methods were used, but the need to demolish the bridge was avoided by using advanced insulation and protection measures.

This was my final statement.

Network Rail reckon that the solution will save about £10 million on this bridge alone, as it avoids the need for an expensive rebuild of the bridge.

The savings on this bridge will be higher as it is a large bridge over several tracks, but even saving a million on each bridge in the South Wales Metro is £55 million, which will probably be enough to build much of the infrastructure to extend to The Flourish, which would appear to not need expensive viaducts or electrification.

Should Downhill Tracks Be Left Without Electrification?

I think this may be possible on the South Wales Metro, as vehicles coming down the hills could use gravity and small amounts of battery power.

Regenerative braking would also be continuously charging the batteries.

It would certainly be simpler, than having to constantly swap between overhead and battery power on the descent, where the electrification was discontinuous.

As the lines are going to have a more intensive service, there will be additions of a second track in places to allow trains to pass.

Any electrification that could be removed from the project would be beneficial in terms of building and operational costs.

Other Routes

This post has used the South Wales Metro as an example, but I don’t see any reason, why the discontinous method and that used on the Cardiff Bridge can’t be applied to other bridges and structures over the lines on other routes in the country.

I suspect, that if they’d been used on the Gospel Oak to Barking Line, electric trains would have been running months ago!

Conclusion

Look what you get with thinking, when you have a Bonfire of the Boxes!



June 7, 2018 Posted by | Travel | , , , , , , | 3 Comments

A Reason Why The UK Is Fertile Territory For Tram Trains

The UK has several modern tram systems. If you look at the cross section of trams you get the following figures.

I wonder why Nottingham is twenty-five centimetres narrower!

If you look at the Class 399 tram-train, it has a width of 2.65 metres and a height of 3.67 metres.

So no wonder, there has been no problems with Class 399 tram-trains running on the Sheffield Supertram as trams!

Various trains that run local rail networks include.

  • Class 142 – Width 2..8 metres – Height 3.86 metres
  • Class 150 – Width 2.8 metres – Height 3.8 metres
  • Class 222 – Width 2.73 metres
  • Class 319 – Width 2.82 metres – Height – 3.58 metres
  • Class 345 – Width 2.78 metres – Height N/A
  • Class 378 – Width 2.80 metres – Height 3.78 metres
  • Class 700 – Width 2.80 metres – Height N/A
  • Class 769 – Width 2.82 metres – Height 3.58 metres
  • Mark 4 Coach – Width 2.73 metres – Height 2.79 metres

These are some figures from German trains.

  • DBAG 641 – Width 2.90 metres – Height 3.7 metres
  • BD Class 420 – With 3.08 metres
  • ICE 3 – Width 2.95 metres – Height 3.89 metres

I’ll look at various issues.

Tram And Train Height

I think this is not a big issue.

If a tram or electric train can run on a particular track, then there should be no height problems running a tram-train over the route, providing overhead wires can be erected.

UK Tram And Train Width

It would appear that the maximum width of UK trains is 2.82 metres. In some stations, where there is only one class of train, level access is possible.

The picture shows a Class 378 train on the London Overground.

This is not one of the best I’ve seen, but there is no reason, why someone in a wheelchair shouldn’t be able to wheel themselves into every train at every station.

This is in the train operating company’s interest, as one of the things that delays trains, is getting someone in a wheelchair on and off the train with a portable ramp.

If we take the UK train width of 2.82 metres and compare that to the width of a Class 399 tram-train, which is 2.65 metres, that means that there is seventeen  centimetres difference or eight and a half centimetres on each side of the train.

If the platform can be arranged to be level, that is not a large gap. It’s probably about the same size as this gap in this picture.

Shown is a Class 399 tram-train at a tram stop on the Sheffield Supertram.

Continental Tram And Train Width

But on the Continent, where the trains are wider and the loading gauge is bigger, the gap will be larger.

Trains on the Continent also often have a significant step up as this picture shows.

Shown is an Italian High Speed train.

If the EU wanted to improve train travel for the disabled, those in wheelchairs, those with buggies and the elderly, they should make it compulsory for all trains to have level access from the platform.

It’s very rare to find level access on the Continent and not that easy in parts of the UK.

Gap Fillers

But things are getting better, as this picture shows.

Shown is a Stadler Flirt with a rather nifty automatic gap filler.

Merseyrail’s New Class 777 Trains

Gap fillers will be fitted to Merseyrail‘s new Class 777 trains, which are being built by Stadler.

The Class 777 trains and the current Class 507 trains have the same width of 2.82 metres, but the new Stadler trains have an eighteen centimetre lower floor.

The picture shows a Class 507 train at one of Liverpool’s underground stations.

Eighteen centimetres wouldn’t be far away from the height of the step in the picture.

The design must also allow both classes of trains to be in service at the same time, to ease introduction of the new Class 777 trains.

Talk about Swiss precision!

South Wales Metro

This document on the KeolisAmey web site details their plans for the new Wales and Borders Franchise.

For services around Cardiff and on the Cardiff Valley Lines, KeolisAmey Wales intend to acquire the following fleet.

  • 11 – four-car Stadler Flirt DEMU
  • 7 – three-car Stadler Flirt Tri-mode MU
  • 17 – four-car Stadler Flirt Tri-mode MU
  • 36 – three-car Stadler Citylink Metro Vehicles

Note.

  1. The Stadler Flirts look very similar to Greater Anglia‘s Class 755 trains, that by the time of delivery of these trains for Wales, will have proven themselves on the mountains of East Anglia.
  2. The tri-mode multiple units will be able to run on electric, diesel or battery power.
  3. The Stadler Citylink Metro Vehicles look very similar to Sheffield Supertram‘s Class 399 tram-trains, that are providing a tram service in Sheffield and will soon be running on the rail network to Rotherham.
  4. It is an all-Stadler fleet.

This is a clip from the KeolisAmey document.

This looks like a visualisation of one of the Flirts, as the Citylink tram-trains have flat sides.

I will be very surprised if Stadler don’t provide the Cardiff area, with one of the best step-free networks in the world.

Conclusion

The UK’s standard tram width of 2.65 metres and our small loading gauge must make it easier to design tram-train systems for the UK.









.

June 6, 2018 Posted by | Travel | , , , , , , , , | Leave a comment

Abbey Wood Station – 21st May 2018

Abbey Wood station has been progressing and I took these pictures.

The layout of the connecting bridges between the Crossrail and North Kent Line platforms is now clear.

  • At the London End, there is a simple footbridge, with steps to each pair of platforms.
  • At the Main Entrance End, there are wide steps and a lift between the station ticket hall and each pair of platforms.
  • The third bridge in the middle is the unusual one with wide steps and a single escalator to each pair of platforms.

I would assume, that the direction of the escalators is as follows.

  • In the Morning Peak, the North Kent Line escalator is set to Up and the Crossrail escalator is set to Down, to speed passengers from the North Kent Line to Crossrail.
  • In the Evening Peak, the Crossrail escalator is set to Up and the North Kent Line escalator is set to Down, to speed passengers from Crossrail to the the North Kent Line.
  • At other times with less traffic, both escalators would be set to Up.

I have seen a lot of station layouts all over the UK and Europe and never one like this.

I doubt, I’ve even seen a pair of platforms connected by three separate bridges too!

Could it be a design of genius to allow thousands of passengers to change between the two pairs of platforms in a short space of time?

Other station layouts that enable this rate of passenger transfer, like the interchange between Crossrail and the Central Line at Stratford station, arrange for a cross-platform interchange, with lines going in the same direction sharing a common platform.

But that arrangement would have been difficult at Abbey Wood, unless perhaps the Crossrail tunnel emerged closer to the station or a flyover or dive-under were to be built.

Both options would have required more space and would have been a lot more expensive.

The design of Abbey Wood station with its three footbridges and wide platforms, would appear to be a more affordable alternative.

Train Length

In some of the pictures, a Class 345 train is shown in one of the Crossrail platforms.

This is a full-length train, which is 205 metres long.

The pictures show just how long these trains are.

LED Lights On The Stairs

Three of the pictures in the bottom row, show the stair handrails with their light underneath.

I Like them.



May 21, 2018 Posted by | Travel | , , , | Leave a comment

No Wires At Salford Crescent Station – 17th April 2018

These pictures show the state of the electrification at Salford Crescent station.

Note that there were no overhead wires through the station and also on the line to Salford Central and Manchester Victoria station. There still appears to be a lot of work to do.

Under Improvements the Wikipedia entry for the station says this.

In 2007, Network Rail recognised that Salford Crescent could not cope with existing passenger levels, leading to platform overcrowding. It suggested expansion of the station with extra platforms, greater use of it as an interchange and use as a terminus for services from east of Manchester. It also raised the possibility of moving the station.

In 2012, improvement work started at the station, including platform extensions, a new rain canopy and the relocation of the ticket office to street level. The works were completed in October 2013 and officially opened by Mayor of Salford, Ian Stewart.

This Google Map shows the station.

I think, it will be a tight fit for extra platforms, as the station is surrounded on all sides by Salford University.

The solution would probably be to build on top of a new station, that was in a strong concrete box.

Changing Trains At Salford Crescent Station

Today, I arrived at Salford Crescent on a train running between Bolton and Manchester Victoria stations.

As I needed to go to Manchester Piccadilly station, I left on a train running between Blackpool North and Manchester Airport stations.

Consider.

  • In the few minutes, I was on the station, I must have heard staff asked, which train do I get to Piccadilly or Victoria, several times.
  • Surrey Quays station handles three routes at the South end of the Thames Tunnel and currently  handles sixteen trains per hour (tph)
  • With high-quality signalling and a measure of automatic train control, I could expect Salford Crescent station to handle at least 12 tph, in both directions.
  • Is the island platform wide enough?
  • Is loading slowed as a lot of trains calling at the station are just two cars, with four doors?
  • Is loading slowed as many of the trains, aren’t step-free from the platform to the train?
  • Are there always staff on the platform.

I believe that operation of the station could be improved.

Reversing Direction At Salford Crescent Station

The current island layout allows passengers to change direction by walking across the platform.

As an example, if you go between Farnworth and Swinton stations, one of the recommended routes is via Salford Cresent.

An Improved Design For Salford Crescent Station

Perhaps before deciding to rebuild the station, serious work should be done to see if the station throughput in terms of trains and passengers can be improved.

My ideas would include.

A Wider Platform

This picture shows the island platform at Canonbury station.

It could handle a whole company of Grenadier Guards and all their kit, whereas Salford Crescent would struggle with a platoon.

Canonbury’s wide platform also has the following in the centre.

  • A large covered shelter.
  • A large number of seats.
  • A coffee stall

It also allows passengers to stand well-back when a train goes through the station, without stopping.

Note that Canonbury is a station, where the platforms are uncovered. Would this be a wise idea in Manchester, even with a large central shelter?

Lomger Trains

a lot of trains going through Salford Crescent station are just two cars.

Northern‘s new trains will include, the following electric trains and bi-mode trains.

32 – four-car Class 319 trains

12 – four-car Class 331 trains

31 – three-car Class 331 trains, which will replace the Class 323 trains.

11 – four-car Class 769 bi-mode trsins.

If all trains calling at Salford Crescent were four-cars or more, this would probably mean at least eight doors, which would would speed up loading and unloading.

This would reduce dwell times at the station and increase capacity in terms of the number of trains per hour.

Level Access Between Platform And Trains

If the platforms are widened, I susopect with Harrington Humps, that this could be achieved.

This picture shows two Hsrrington Hump is at Canonbury.

dscn9985

If passengers in wheelchairs, buggy-pushers and those  pulling heavy cases could just walk or push the,selves across.

Again, this would reduce dwell times and increase capacity.

Better Information

Given that I heard passengers asking the same question, I suspect that better informayion, could make the station easier fot  interchang passengers.

Using the displays on Thameslink and at London Bridge station would be a good start.

An Up Escalator

Sal;ford Central station has a long set of stairs and a lift.

Many passengers with movement difficulties would welcome an up escalator.

Conclusion

I believe that a much improved station can be creased , without the expence of adding a new platform.















April 17, 2018 Posted by | Travel | , , , , , , | 1 Comment

Stealing With Pride: Testing Automotive Industry Tech On Swiss Trams

The title of this post, is the same as this article on Global Rail News. This is first two paragraphs.

Swiss public transport operator Baselland Transport (BLT) is testing Bosch Rail Transport’s light rail collision-warning system in collaboration with Stadler.

Should the tests prove successful, BLT plans to equip its entire fleet of Tango trams with the technology – which is already established in the automotive industry.

In my working life, I often stole ideas and especially methods from other industries and obscurer mathematical papers.

This use of an automotive system on a tram is a good way of the application of proven technology in another area.

January 24, 2018 Posted by | Travel | , | Leave a comment

How To Build Railway Stations

With all the troubles caused by the failure of Carillion, it is good to report on a company, that is providing new and improved railway infrastructuresubstantially  on time and on budget.

This article on Rail Engineer is entitled VolkerFitzpatrick: Upgrading Stations.

This is the first two paragraphs.

With Network Rail’s comprehensive Railway Upgrade Plan well underway and the modernisation of Britain’s railways firmly in the spotlight, there is a growing need and expectation for first-class stations and infrastructure to accommodate growing numbers of passengers nationwide.

One business with a huge role in the modernisation programme has developed a reputation as an exceptional multi-disciplinary contractor, with extensive capabilities in civil engineering, building and rail, meeting the demands of a wide range of clients across multiple disciplines. It is this consolidated approach that has helped VolkerFitzpatrick deliver several high-profile UK railway station schemes in the last 10 years.

The article then goes on to describe how the company tackled the following stations.

It then goes on to detail the company’s omvolvement in the Lea Valley Improvement Program, which will deliver new stations at Tottenham Hale, Northumberland Park and Meridian Water.

Read the Rail |Engineer article, as it gives a good insight into design and construction.





January 21, 2018 Posted by | Uncategorized | , , , , , , , , | Leave a comment

Fosteritos

The Bilbao Metro was designed by Foster and Partners.

Under Design, Wikipedia says this about access to the Metro.

Access to the metro is provided by ‘fosteritos’, glass structures affectionately named after the architect who designed them, Norman Foster. These modern-looking tunnels stand attractive alongside the modern and innovative interior of the stations.

These pictures show some of the fosteritos.

Crossrail’s Tottenham Court Road station has two square glass structures over the entrances in front of Centre Point.

I wrote about the first in Tottenham Court Road Station Gains A Giant Fosterito. Here’s a picture taken soon after one opened.

It is such a simple idea, I wonder why we don’t see more fosteritos all over the world.





January 17, 2018 Posted by | Travel | , , , , | 7 Comments

Big On The Inside And The Same Size On The Outside

This morning, I took a ride in one of London Overground’s Class 378 trains to Shoreditch High Street station, so that I could have Leon’s version of a Full English Breakfast and a real mug of tea, in their restaurant in Spitalfields. And all for £5.25!

Afterwards, I walked the short distance to Liverpool Street station and took one of Crossrail’s new Class 345 trains to Stratford station.

As the Class 345 train was more or less empty, I was able to take these pictures of the inside.

Several design features are noticeable.

  • The wide flat floor
  • The walk-through design of the train.
  • The wide aisle in the centre.
  • The seats cantilevered from the side of the train.
  • The heating under the seats.
  • The spacious lobbies.
  • The large windows.
  • The way the body sides bulge outwards to create more width at just below shoulder height.

The design seems to create more room for passengers and because of the wide aisle and large windows, the room might even look more spacious than it actually is.

It is certainly a more pleasing train to ride in, than the Class 378 train, I rode ealier, which is very much one of the better trains from the previous generation.

Later I rode on one of Thameslink’s Class 700 trains.

  • The lobbies are wide.
  • Seats obscure the view, as they are not aligned with the windows.
  • The heating takes up space along the side of the train.

But as the sides of the train don’t seem to be so curved, the aisle between the seats seems to be narrower. A lady wheeling a case between the seats would have hit people, if anybody had been sitting in the seats.

I should ride in a full Aventra in the Peak and see if my everybody appears to have more space. I did later!

On the 19th of December, I rode from Romford to Liverpool Street in an Aventra during the morning Peak.

  • The train was perhaps three-quarters full.
  • For some parts of the journey, all seats were taken, but the standees didn’t seem to have too much trouble standing in the smooth-riding train.
  • Only a few were strap-hanging and several were using the backs of seats for support.

It did seem to be a better experuience than other commuter trains.

Others ideas and consequences have emerged in recent months.

Aventras Have Underfloor Heating

The Greater Anglia Class 720 trains have underfloor heating as I detailed in Aventras Have Underfloor Heating.

Underfloor heating would appear to release space for passengers. Especially when it is coupled with seats cantilevered from the sides of the train.

Aventras Have No Doors Between Cars

Tthis article on Global Rail News, which is entitled First look around Greater Anglia’s Bombardier Aventra mock-up, says this.

There will be no doors separating vehicles.

There is just a wide lobby, where the cars are joined together.

This shows the join in a Class 345 train.

Regularly in busy times on London Overground’s Class 378 trains or London Underground’s S Stock, similar areas are full with people.hanging on to the vertical handles or wheelie cases.

It’s a design that seems to work well and again it makes more space available for passengers.

Aventras Can Have 2+3 Seating

This picture shows the inside of Greater Anglia’s Aventra mockup.

Could the 2+3 seating be wider and more comfortable, as Aventras seem to be wider inside at shoulder height, due to the innovative body design?

Note the power sockets in the front of the seats.

Aventra Car Length And Number of Cars Is Flexible

The first two fleets of Aventras ordered had different length cars and different number of cars.

Orders have now been placed for trains with twenty and twenty-two metre length cars and three, four, five, seven, nine and ten cars.

It also seems that it is very simple to change train length by adding and removing cars as required.

Greater Anglia

Greater Anglia have stated that they are ordering ten-car Aventras with similar train lengths to twelve-car sets of their current rolling stock.

Lengths and passenger capacity are given as follows in Wikipedia.

  • Ten-car Class 720 – 243 metres – 1,145 seats
  • Twelve-car Class 321 – 239.4 metres – 927 seats
  • Twelve-car Class 360 – 244.08 metres – 840 seats

This looks like an over thirty percent increase in seats in a train around the same length, with the following advantages

  • Little if any expensive platform extensions. Especially at Liverpool Street station.
  • Trains will fit existing depots and sidings.
  • Nearly all trains will be fixed formations.

The only disadvantage is that Greater Anglia won’t be providing any First Class seats. Judging by the lack of complaints, few seem to be bothered.

But being less complicated, it would probably be a more affordable train to run and maintain.

In this Greater Anglia example, another factor helps.

The Aventra will only have two cabs, whereas three Class 321 or Class 360 trains will have six.So the length released by four cabs is available for passengers.

c2c

It would appear that the c2c order, where ten-car Aventras replace twelve-car Electrostars, is another application of the same philosophy, that was used by Greater Anglia.

This is an extract from c2c’s Press Release.

The Aventra is one of the fastest-selling trains in the UK rail industry, and these new trains will be manufactured at Bombardier’s factory in Derby. Each new train, which will operate in a fixed set of 10-carriages, will include over 900 seats, plus air-conditioning, wifi, plug sockets and three toilets onboard. Each new carriage is larger and contains more seats than on c2c’s current trains, so each 10-carriage new train provides capacity for 15% more passengers onboard compared to a current 12-carriage c2c train.

So three x four-car trains working as a twelve-car train are replaced by one ten-car train, just as with Greater Anglia. Note the claimed fifteen percent capacity increase!

West Midlands Trains

West Midlands Trains have ordered three sets of Aventras.

  1. 16 x five-car 110 mph trains for long-distance services.
  2. 29 x five-car 110 mph trains for electrified suburban services.
  3. 36 x three car 90 mph trains for Redditch to Lichfield Trent Valley.

Consider.

  • Fleet 1 will probably be used to augment the Class 350 trains in pairs on long distance services.
  • Could these work in pairs that split and join en route to save paths into Euston?
  • Fleet 3 will be direct replacements for the Class 323 trains and will probably work in pairs.
  • Would a five-car train have a similar capacity to two three-car trains working as a pair?
  • Would some of the five-car trains in Fleet 2 be fitted with diesel powere-packs or batteries, so they could run services on lines without electrification?

West Midlands Trains must have a plan, or there will be a large number of trains sitting in sidings.

Conclusion

It looks to me like Bombardier have designed a train, where more passengers can be accommodated, without sacrificing passenger comfort.

December 18, 2017 Posted by | Travel | , , , , | 2 Comments

Crossrail Gets A Convenient Hotel

This article on The Urban Developer is entitled London’s Newest Skyscraper Gets Green Light.

This is the first two paragraphs.

London’s Paddington will soon be home to a new 20-storey hotel tower, dubbed The Gateway Building, after planning permission was granted by Westminster council planners.

The Sheldon Square site will house the 113-metre-high hotel designed by architects Carmody Groarke for developer British Land. The hotel will provide access to the area’s new Crossrail station, with the third basement level expected to provide access to the Elizabeth Line — connecting Reading with London and Heathrow.

As they say, location is everything!

  • Crossrail will whisk you to and from Heathrow.
  • There’s not many hotels with direct access to the station underneath.
  • For the businessman who has everything, Bond Street is only one stop away for the trophy wife to spend your hard-earned money.
  • The City and Canary Wharf are just a few stops further.

I doubt the hotel will be a Premier Inn.

How many other skyscraper hotels will sprout up along Crossrail?

Each one will be another nail in the coffin of Heathrow Express.

November 6, 2017 Posted by | Travel | , , , , , | Leave a comment
