Is The Eastern Leg Of High Speed Two Under Threat?

This page on the High Speed Two web site is entitled HS2 Phase 2b Eastern Leg.

These are the opening three paragraphs.

Earlier this year the government made clear in its response to the Oakervee Review its commitment to Phase 2b of HS2, ensuring we boost capacity, improve connectivity between our regions and share prosperity.

As part of this, the government plans to present an Integrated Rail Plan for the North and Midlands by the end of the year, informed by an assessment from the National Infrastructure Commission, which will look at how to deliver HS2 Phase 2b, Northern Powerhouse Rail, Midlands Rail Hub and other rail programmes better and more effectively.

In the meantime, the government has asked HS2 Ltd to pause work on the Eastern Leg. We recognise that this causes uncertainty and our Eastern Leg community engagement teams remain in place to support you.

The page then says that the work on the Western Leg should proceed, with the aim of a Western Leg Bill in early 2022.

In Northern Powerhouse Rail – Significant Upgrades Of The East Coast Main Line From Leeds To Newcastle (Via York And Darlington) And Restoration Of The Leamside Line, I showed that the current and future upgrades to the East Coast Main Line, required by the East Coast Main Line, Northern Powerhouse Rail and High Speed Two, will greatly reduce the times on services from London Kings Cross to Doncaster, Yorkshire, the North East and Scotland.

I said this on timings on the East Coast Main Line.

  • London Kings Cross and Doncaster could be around an hour.
  • London Kings Cross and Leeds could be around one hour and thirty minutes, using the current Doncaster and Leeds time, as against the one hour and twenty-one minutes for High Speed Two.
  • London Kings Cross and York could be around one hour and twenty-three minutes, using the current Doncaster and York time, as against the one hour and twenty-four minutes for High Speed Two.
  • Timings between York and Newcastle would be the same fifty-two minutes as High Speed Two, as the track will be the limitation for both services.
  • High Speed Two’s timing for York and Newcastle is given as fifty-two minutes, with York and Darlington as twenty-five minutes.
  • London Kings Cross and Darlington could be around one hour and forty-nine minutes
  • London Kings Cross and Newcastle could be around two hours and sixteen minutes.
  • London Kings Cross and Edinburgh would be under three-and-a-half hours, as against the proposed three hours and forty-eight minutes for High Speed Two.

LNER’s Azuma cavalry will hold the fort for as long as is needed.

I’ll now look at how various stations, will be affected if the Eastern Leg of High Speed Two is not built, until a couple of decades in the future.

Leeds

Current Long Distance Services At Leeds Station

Leeds station has the following long distance services in trains per hour (tph)

  • CrossCountry – 1
  • LNER – 2
  • TransPennine Express – 5

It is a bit thin compared to say Birmingham or Manchester.

Northern Powerhouse Rail And Leeds

Northern Powerhouse Rail has plans for Leeds with these services to other Northern cities.

  • Hull – two tph in 38 minutes
  • Manchester – six tph in 25 minutes
  • Newcastle – four tph in 58 minutes
  • Sheffield – four tph in 28 minutes.

From what they have written, the following could also be possible.

  • Bradford – six tph in a few minutes
  • Liverpool – four or more tph in 51 minutes
  • Manchester Airport – four or more tph in 35 minutes

It is an ambitious plan.

High Speed Two And Leeds

High Speed Two is planning to run the following trains to Leeds in every hour.

  • Birmingham Curzon Street and Leeds – 200 metre train
  • Birmingham Curzon Street and Leeds via East Midlands Hub – 200 metre train
  • London Euston and Leeds via Old Oak Common and East Midlands Hub – 200 metre train
  • London Euston and Leeds via Old Oak Common and East Midlands Hub – 400 metre train
  • London Euston and Leeds via Old Oak Common, Birmingham Interchange and East Midlands Hub – 400 metre train

Timings will be as follows.

  • Birmingham Curzon Street and Leeds – 49 minutes.
  • London Euston and Leeds – One hour and 21 minutes.

There will be about 1000 seats per hour between Birmingham Curzon Street and Leeds and 2500 seats per hour Between London Euston and Leeds.

High Speed Two And Leeds Via Manchester

This report on the Transport for the North web site, is entitled At A Glance – Northern Powerhouse Rail.

This map shows Transport for the North’s ideas for connections in the West linking Crewe, Liverpool, Manchester, Manchester Airport, Warrington and Wigan.

A black line goes East from Manchester to link it to Leeds via Huddersfield and Bradford.

  • This is proposed as a route shared between High Speed Two and Northern Powerhouse Rail.
  • High Speed Two are promising that London Euston and Manchester will be timed at one hour and eleven minutes.
  • London Euston and Manchester will have a frequency of three tph and will all be 400 metre High Speed Two Full Size trains, with about a thousand seats.
  • Northern Powerhouse Rail have an objective of a twenty-five minute journey time between Manchester and Leeds.

I would also build the Manchester and Leeds route with the following characteristics.

  • As a full-size tunnel capable of taking High Speed Two Full Size trains and the largest freight trains.
  • Intermediate and underground stations at Huddersfield and Bradford.
  • It could be built as a base tunnel, like the similarly-sized Gotthard base tunnel in Switzerland.
  • The Swiss tunnel has a maximum operating speed for passenger trains of 125 mph.

If it can be built for a reasonable cost and in a reasonable time-scale, it could be a way of doing the following.

  • Creating a straight 150 mph plus route across the Pennines, with a capacity of 18 tph.
  • Running high-capacity fast trains between London Euston and Leeds via Manchester Airport and Manchester.
  • Running freight trains between the two sides of the Pennines.
  • Creating a high frequency route between Liverpool and Hull via Manchester Airport, Manchester, Huddersfield and Bradford and Leeds.

The passenger service between Liverpool and Hull could be the world’s first high speed metro.

If the London Euston and Manchester trains, were to be extended to Leeds, London Euston and Leeds would take one hour and thirty-six minutes, which would only be fifteen minutes slower, than is promised for the route going via the Eastern Leg of High Speed Two.

London Kings Cross And Leeds

When the in-cab digital signalling is complete between London Kings Cross and Leeds, I am fairly confident that with a few other improvements and more zoom from the Azumas, that a London Kings Cross and Leeds time of one hour and fifty minutes will be possible.

But will two nine-car or pairs of five-car trains per hour (tph), be enough capacity? Especially, as pairs of five-car trains will split and join to serve a wider catchment area, which will harvest more passengers.

LNER will in a couple of years have an extra path every hour into Kings Cross.

I would feel that best use of this path would be to run between London Kings Cross and Edinburgh via Leeds and Newcastle.

  • Leeds and Newcastle could be the only intermediate stops.
  • Leeds would be the ideal place to change to Northern Powerhouse Rail for anywhere in the North of England.
  • My estimates, say it could run between London Kings Cross and Edinburgh in around three-and-a-half hours.
  • It would run non-stop between London Kings Cross and Leeds, Leeds and Newcastle and Newcastle and Edinburgh.

It would increase capacity, between the four major destinations on the route; London Kings Cross, Leeds, Newcastle and Edinburgh.

It could start running, once the digital signalling and current improvements to the East Coast Main Line are complete.

London St. Pancras And Leeds

I discussed, Northern Powerhouse Rail’s plan for Sheffield and Leeds in Northern Powerhouse Rail – Connecting Sheffield To HS2 And On To Leeds.

This could see the following new infrastructure.

  • Electrification between Clay Cross North Junction and Sheffield station of the route shared by the Midland Main Line and High Speed Two.
  • Electrification through Sheffield and on to Leeds, via the Wakefield Line
  • New stations for High Speed trains at Rotherham and Barnsley Dearne Valley.

I could see East Midlands Railway taking advantage of this route, with their new Class 810 trains and running a regular Leeds and St. Pancras service.

  • It would call at Wakefield Westgate, Barnsley Dearne Valley, Rotherham and Meadowhall. between Leeds and Sheffield stations.
  • It would take twenty-eight minutes between Leeds and Sheffield, if it met Northern Powerhouse Rail’s objective.
  • Perhaps one of the two tph between London St. Pancras and Sheffield could be extended to Leeds.

As the current time between London St. Pancras and Sheffield, is a few minutes under two hours, I can see a time of comfortably under two-and-a-half hours between London St. Pancras and Leeds.

A Summary Of Journey Times Between London And Leeds

I can summarise my estimates, between London and Leeds.

  • High Speed Two – Direct via Eastern Leg – One hour and twenty-one minutes.
  • High Speed Two – via Manchester – One hour and thirty-six minutes.
  • East Coast Main Line – via Doncaster – One hour and thirty minutes.
  • Midland Main Line – via Derby and Sheffield – Two hours and twenty minutes.

The direct High Speed Two route is the fastest., but others could be viable alternatives for some passengers.

Bradford

Consider.

  • Under current plans Bradford won’t be getting any high speed service from High Speed Two.
  • The best it can get under current plans is several direct services per day, between Bradford Forster Square and London Kings Cross in perhaps two hours.
  • The layout of the city and its two stations doesn’t give good connectivity.

Bradford, Harrogate, Huddersfield and Skipton could probably be served by trains to and from London Kings Cross that join and split at Leeds.

But if Northern Powerhouse Rail goes for a tunnel between Manchester and Leeds with Bradford as an underground station, it could be served by High Speed Two services going between London Euston and Leeds via Manchester.

I would estimate that if London Euston and Leeds via Manchester took around one hour and thirty-six minutes, London Euston and Bradford could take around an hour-and-a-half.

Darlington

I can summarise my estimates, between London and Darlington.

  • High Speed Two – Direct via Eastern Leg – One hour and forty-nine minutes.
  • High Speed Two – via Manchester and Leeds – Two hours and six minutes.
  • East Coast Main Line – via Doncaster – One hour and forty-nine minutes.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle; will speed up East Coast Main Line services to Darlington.

Edinburgh

I can summarise my estimates, between London and Edinburgh.

  • High Speed Two – Direct via Western Leg – Three hours and Forty minutes.
  • High Speed Two – via Manchester and Leeds – Three hours and forty-eight minutes.
  • East Coast Main Line – via Doncaster – Three hours and thirty minutes.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle; will speed up East Coast Main Line services to Newcastle.

Harrogate

Consider.

  • Under current plans Harrogate won’t be getting any high speed service from High Speed Two.
  • The best it can get under current plans is several direct services per day, between Harrogate and London Kings Cross in perhaps two hours.

Bradford, Harrogate, Huddersfield and Skipton could possibly  be served by trains to and from London Kings Cross that join and split at Leeds.

Huddersfield

  • If Huddersfield is served by underground platforms beneath the current Huddersfield station, a lot of what I said for Bradford would apply to Huddersfield.
  • The timings would probably be around an-hour-and-a-half from London Euston.

Bradford, Harrogate, Huddersfield and Skipton could possibly be served by trains to and from London Kings Cross that join and split at Leeds.

Hull

Hull is an interesting destination.

  • Reaching Hull from the current High Speed Two network will need a change at Leeds or another station.
  • Using Northern Powerhouse Rail’s objectives on timings, London Euston and Hull via Manchester on High Speed Two, would be a few minutes under two-and-a-half hours.
  • I strongly feel, that London Kings Cross and Hull via Selby could be reduced to below two hours.

Hull would also make a superb Eastern terminal station for both Northern Powerhouse Rail and a High Speed Two service from London via Manchester and Leeds.

You pays your money and takes your choice.

Middlesbrough

Reaching Middlesbrough from the proposed High Speed Two network will need a change at York or another station.

But a time of two hours and twenty minutes, should be possible using the East Coast Main Line via Doncaster.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle, will speed up East Coast Main Line services to Middlesbrough.

Newcastle

I can summarise my estimates, between London and Newcastle.

  • High Speed Two – Direct via Eastern Leg – Two hours and seventeen minutes.
  • High Speed Two – via Manchester and Leeds – Two hours and thirty-four minutes.
  • East Coast Main Line – via Doncaster – Two hours and sixteen minutes.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle; will speed up East Coast Main Line services to Newcastle.

Nottingham

I will compare average speeds on the Midland Main Line between London St. Pancras and Nottingham and on the East Coast Main Line, between London Kings Cross and Leeds.

Currently.

  • London St. Pancras and Nottingham services, over the 126 mile route, take one hour and fifty minutes. which is an average speed of 69 mph.
  • London Kings Cross and Leeds services, over the 186 mile route, take two hours and thirteen minutes, which is an average speed of 94 mph.

Note.

  1. The two routes are of similar character and are fairly straight with large sections of 125 mph running and quadruple tracks.
  2. The East Coast Main Line to Leeds  is fully electrified, whereas the Midland Main Line is only partially electrified.
  3. Both routes have a small number of stops.
  4. In a few years time, services on both routes will be run by different members of the Hitachi AT-300 train family.

I don’t feel it would be unreasonable to assume that a London St. Pancras and Nottingham service could be run at an average speed of 94 mph, if the Midland Main Line were upgraded to the same standard as the East Coast Main Line.

This could mean a time of around one hour and twenty-one minutes between London St. Pancras and Nottingham, or a saving of twenty-nine minutes.

Is that possible?

  • The new Class 810 trains, will have four engines instead of the normal three for a five-car AT-300 train. Will they be able to be closer to the 125 mph line-speed on diesel power, where it is available on the Midland Main Line.
  • The trains will be able to use electrification between London St. Pancras and Market Harborough.
  • There have been hints, that more electrification may be installed on the Midland Main Line.
  • Hitachi have announced a battery electric version of the AT-300 train called a Regional Battery Train, where one or more of the diesel engines are replaced by battery packs.
  • The new trains will be ready to accept in-cab ERTMS digital signalling, so they could be able to run at up to 140 mph, if the track were to be upgraded.

I certainly feel, that substantial time savings could be possible between London St. Pancras and Nottingham.

Eighty-one minutes would be very convenient, as it would comfortably allow a three hour round trip, which would mean just six trains or more likely pairs of trains would be needed for the current two tph service.

Eighty-one minutes would not be the fifty-two minute service promised by High Speed Two!

But!

  • The new trains are planned to be introduced from 2023.
  • Who knows, when High Speed Two will arrive at the East Midlands Hub station?
  • They won’t need any new substantial infrastructure to replace the current trains.

I also suspect the new trains will have more seats, but, the capacity of the Class 810 train, has not been published.

Nottingham could also be served by a high speed service from London Kings Cross via Grantham, which I estimate would take about one hour and twenty minutes.

Sheffield

A lot of what I said for Nottingham can be applied to Sheffield.

  • Currently, London St. Pancras and Sheffield services, over the 165 mile route, take two hours, which is an average speed of 82.5 mph.
  • High Speed Two is promising a journey time of one hour and twenty-seven minutes.
  • An average speed of 90 mph, would mean a journey time of one hour and fifty minutes.
  • This would allow a four hour round trip, which would mean just eight trains or more likely pairs of trains would be needed for the current two tph service.

It would be very convenient for the operator.

It looks like if pairs of trains were to be run on both the Nottingham and Sheffield routes, that twenty-eight trains would be needed to run both services.

This fits well with a fleet size of thirty-three trains.

The only caveat, is that to get the required journey times, it might be necessary to rebuild and electrify the tracks, between Sheffield and Clay Cross North Junction.

  • These tracks will be shared with the future Sheffield Branch of High Speed Two.
  • It would only be 15.5 miles of double-track to rebuild and electrify.
  • It could be rebuilt to allow 140 mph running. Several minutes could be saved!

The electrification could allow Hitachi’s Regional Battery trains to be able to run the Sheffield service.

These trains would certainly be a way of avoiding the tricky electrification of the Derby and Clay Cross section of the route, which goes through the World Heritage Site of the Derwent Valley Mills.

Sheffield could also be served by a high speed service from London Kings Cross via Doncaster, which I estimate would take about one hour and thirty minutes.

Skipton

Consider.

  • Under current plans Skipton won’t be getting any high speed service from High Speed Two.
  • The best it can get under current plans is several direct services per day, between Skipton and London Kings Cross in perhaps two hours.

Bradford, Harrogate, Huddersfield and Skipton could possibly  be served by trains to and from London Kings Cross that join and split at Leeds.

Sunderland

Reaching Sunderland from the proposed High Speed Two network will need a change at York or another station.

But a time of two hours and thirty minutes, should be possible using the East Coast Main Line via Doncaster.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle, will speed up East Coast Main Line services to Sunderland.

York

I can summarise my estimates, between London and York.

  • High Speed Two – Direct via Eastern Leg – One hour and twenty-four minutes.
  • High Speed Two – via Manchester and Leeds – One hour and forty-two minutes.
  • East Coast Main Line – via Doncaster – One hour and twenty-four minutes.

Improvements on the East Coast Main Line, needed to enable and speed-up High Speed Two services to York, Darlington and Newcastle; will speed up East Coast Main Line services to York.

I believe strongly, that York would be about as fast from London, by either of the direct routes, but both would serve different intermediate destinations.

Conclusion

My first conclusion is a surprising one, but the promised timings from High Speed Two and the current timings in the timetable make it clear.

To achieve the required timings for High Speed Two, major improvements must be made to existing track and these improvements will mean that existing services will be competitive with High Speed Two on time.

These improvements fall into this category.

  • Improving the East Coast Main Line between York and Newcastle, will make East Coast Main Line services to York, Darlington, Durham and Newcastle competitive with High Speed Two services.
  • Improving the East Coast Main Line between York and Newcastle, may also mean that London Kings Cross and Edinburgh will be faster than the High Speed Two service between London Euston and Edinburgh.
  • Electrifying the route shared between Sheffield and Clay Cross North Junction, will speed up London St. Pancras and Sheffield services and make them more competitive with High Speed Two.

I suspect there may be similar mutual improvements on the Western leg of High Speed Two.

Other smaller conclusions from my analysis of the improvements include.

  • These improvements will create some extra capacity on the East Coast and Midland Main Lines, by removing bottlenecks and improving line speeds.
  • Electrification, even if it is only partial or discontinuous, will improve services on the Midland Main Line.
  • Some places like Harrogate, Middlesbrough and Skipton will never be served directly by High Speed Two, but are easily served by East Coast Main Line services from London Kings Cross.
  • Northern Powerhouse Rail is very much part of the North-South capacity for England.
  • In-cab ERTMS signalling will play a large part in increasing capacity and line speeds.

Perhaps in our planning of High Speed Two, we should plan all the routes in the North and Midlands in a much more holistic way.

If we look at the capacity between London and the North, I feel that with the addition of Phase 1 of High Speed Two to Birmingham in 2029-2033 and hopefully Phase 2a soon afterwards, that Phase 2b will not be needed for reasons of speed and capacity until years later.

So, I would pause most construction of the Eastern Leg of High Speed Two until Phase 1 and Phase 2a are complete.

I would make exceptions for the following.

  • Improvements to the shared section of the East Coast Main Line and High Speed Two, between York and Newcastle.
  • Building a high speed connection between Leeds and York for the use of Northern Powerhouse Rail and the East Coast Main Line.
  • Rebuilding and electrification of the shared section of the Midland Main Line and High Speed Two, between Clay Cross North Junction and Sheffield.
  • Improve and electrify the route between Sheffield and Leeds.

But I would continue with the design, as I feel that East of Leeds is very much sub-optimal at the present time.

The route of the Eastern leg of High Speed Two would be safeguarded.









December 7, 2020 Posted by | Transport | , , , , , , , , , , , , , , , , , | Leave a comment

Direct London-Bordeaux Service By 2022 – SNCF

The title of this post is the same as that of this article on Rail Magazine.

Diego Diaz, who is International President of SNCF is quoted as saying this.

With the view to opening up to the international scene, SNCF Gares & Connexions and HS1 Ltd, the owner of St Pancras station, have decided to twin the two stations and the operating teams.

I hope I can be on the first service, when it happens.

March 9, 2020 Posted by | Transport | , , , , | 2 Comments

The Missing Link At St. Pancras Station

This picture was taken inside St. Pancras station.

I was standing in front of the glass security wall, towards the East (Kings Cross) side of the station.

On the British Library side of the station it is possible to walk along to the four platforms for East Midlands Railway trains.

I wonder why, there isn’t a link down the Kings Cross side of the station, so that it would be possible to walk from the front of the station to the Souyjeastern HighSpeed commuter routes.

October 7, 2019 Posted by | Transport | , , | 2 Comments

How Will Abellio East Midlands Railway Maximise Capacity On The Midland Main Line?

In this post, I will try and get a feel to how Abellio East Midlands Railway, will maximise capacity on the Midland Main Line.

The Current Service

There are currently two trains per hour (tph) to both Nottingham and Sheffield and one tph to Corby from London.

Ignoring the Corby service, which will be using electric trains, intermediate calls have these frequencies, from South to North.

  • Bedford – One tph
  • Wellingborough – One tph
  • Kettering – One tph
  • Market Harborough – Two tph
  • Leicester – Four tph
  • Loughborough – Two tph
  • East Midlands Parkway – Two tph
  • Long Eaton – One tph
  • Beeston – One tph
  • Derby – Two tph
  • Chesterfield – Two tph

As the new bi-mode trains will be more modern, with probably shorter dwell times at each station, I suspect that when Abellio East Midlands Railway implement their ultimate timetable, there will be more stops, without degrading journey times.

These are fastest times.

  • London and Nottingham is one hour forty minutes
  • London and Sheffield is two hours

I feel that round trips to both destinations will be four hours with some speed increases and shorter station dwell times.

  • The current two tph to Nottingham and Sheffield needs eight trains to each destination.
  • This is a total of sixteen trains.

As each train could be two five-car trains working as a ten-car train, train numbers for the current service could be as high as thirty-two trains.

A first look seems to indicate that there .will be no overall increase in train frequency, although, as I said earlier, the performance of the new trains should allow extra station stops.

It also indicates to me, that any increases in frequency between London and Nottingham/Sheffield will need extra trains.

The Electrified High Speed Line South Of Kettering

Midland Main Line services South of Kettering are as follows.

  • Two tph to London and Nottingham
  • Two tph between London and Sheffield
  • One tph between London and Corby.

From December 2021, there will be two tph between London and Corby.

The maximum number of services between London and Kettering on the electrified section currently envisaged is only six tph or one train every ten minutes.

As the Class 700 trains on Thameslink are capable of using digital signalling and all the new trains will also be similarly equipped, I wouldn’t be surprised that the theoretical capacity of the electrified fast lines could be higher than the proposed six tph. |Especially, when digital signalling is installed.

The number of trains in the fleet, is much more of a limit on services, than the capacity of the Midland Main Line.

If all trains were ten cars, the following numbers of trains would be needed.

  • Current two tph – 32 trains
  • Increase to three tph – 48 trains
  • Increase to three tph – 64 trains

Are there enough passengers to fill all these trains?

Does St. Pancras Have Enough Capacity?

St. Pancras station has four platforms for Midland Main Line services.

  • The platforms are long enough to take two five-car Class 222 trains,.
  • They would surely accommodate a ten-car formation of the new Hitachi trains.
  • Each platform can probably handle three or four tph, giving a total capacity of 12-16 tph.

As four tph to Nottingham and Sheffield and two tph to Corby is only a total of ten tph, there is enough platform capacity for several years to come.

If there is a problem, it is that the large numbers of passengers would overwhelm the stairs and escalators between the ground level of the station and the platforms.

I am certain, that just like the Eurostar platforms at St. Pancras, the Midland Main Line platforms will need better passenger access and facilities.

Will it even be enough, when up to six tph, all of which could be 240 metres long, start to arrive in December 2021?

What could be done to help solve the capacity problem at St. Pancras station in the future?

Better Access To The Midland Main Line Platforms

Consider.

  • Space is limited to add extra escalators, lifts and places to wait
  • St. Pancras is a Grade I Listed Building.
  • As I don’t travel through the station in the Peak, the escalators seem to always be going the wrong way.

Improving the current access will be very difficult.

This Google Map shows the Northern End of the station.

Note.

  1. The Midland Main Line platforms are the two island platforms on the left.
  2. The Southeastern HighSpeed platforms are the two island platforms on the right.
  3. The Eurostar platforms are the three island platforms in the middle.

Could a second entrance to some of the platforms be built here?

It would be very difficult, unless the extension was future-proofed when it was built.

Underground Improvements

Getting between the Midland Main Line platforms and the Underground is an obstable course.

As a Londoner, who’s had the operation to have the Underground Map implanted in my brain, I generally go to the Midland Main Line platforms at St. Pancras by taking one of the following.

A bus from close to my house to outside the station.

  • A Metropolitan Line train from Moorgate
  • A Northern Line train from Angel.
  • A Piccadilly Line train from Manor House
  • A Victoria Line train from Highbury & Islington

The last four need a bus to get to the Underground.

I usually come back home, by spending just over a tenner on a black cab!

Crossrail 2

Crossrail 2 should improve matters, but will it ever be built?

Will The New Brent Cross Thameslink Station Allow Cross Platform Interchange Between Midland Main Line and Thameslink Services?

Consider.

  • The proposed Brent Cross Thameslink will be just North of Cricklewood station.
  • Midland Main Line services through the station would be six tph.
  • Thameslink services through the station would be fourteen tph
  • The West London Orbital Railway could be built to connect the station to High Speed Two and Heathrow

Would it take the pressure off St. Pancras?

It might do, if a cross-platform interchange could be arranged.

Could Some Midland Main Line Services Use Thameslink?

Consider.

  • The obvious service to go through Thameslink would be the two tph service between Corby and St. Pancras.
  • Thameslink is currently setup to handle 24 tph, but it has been designed for 30 tph.
  • The Corby service will stop at Kettering, Luton and Luton Airport Parkway, to the North of London.
  • It could perhaps terminate at the soon-to-be-rebuilt Gatwick Airport station in the South.

It might work!

Especially, if Kettering station were to be rebuilt to have cross-platform interchange between Corby sewrvices and the bi-mode ones going further North.

Splitting And Joining Trains

In Rock Rail Wins Again!, I gave this simple example of how the splitting and joining capability of Hitachi AT-300 trains can be used.

A ten-car train might leave St. Pancras as two five-car units running as a pair. It could split at East Midlands Parkway station and one train could go to Nottingham and the other to Derby. Coming South the two trains would join at East Midlands Parkway.

I feel that Derby, East Midlands Parkway and Leicester are ideal stations on the Midland Main Line, where services could be split and joined.

  • They have at least four platforms.
  • The platforms are long and straight.

The two terminals at Nottingham and Sheffield could also probably be used to enable services to serve more destinations.

Shorter trains must have advantages on some routes.

  • Capacity is better matched to demand.
  • Platforms may not need to be extended.
  • Services can be run by a driver and a conductor.

Will Abellio East Midlands Railway use splitting and joining to increase the coverage of their services?

Great Western Railway’s Class 800, 801 and 802 trains have the capability to split and join and the operator doesn’t seem to use it. Although, they do split and join Class 387 trains.

Extended Services To And From The North And East

The ability to split and join, that could be used to extend services to the North And East.

Serving Barnsley, South Yorkshire And Leeds

Consider.

I wonder if there are paths and need for a London and Sheffield service to split at Sheffield with, the two five-car trains going to different destinations.

  • Leeds via Rotherham, Barnsley Dearne Valley and Wakefield Westgate, is one possibility.
  • Could a service go to Huddersfield?
  • Hull is probably too far.

One tph could terminate at Sheffield and one splitting and one tph could split and serve other destinations.

Advantages could include.

  • Barnsley and Rotherham get a direct hourly service to London.
  • South Yorkshire and Leeds have a direct hourly service to the East Midlands.
  • Sheffield and Leeds have an hourly fast service.

I’m sure Abellio have a very workable plan to improve services North of Sheffield.

Serving Lincolnshire And Nottinghamshire

Consider.

  • Splitting and joining at Nottingham may allow an increase in direct services to and from Lincoln.
  • Perhaps parts of North Lincolnshire could be well-served by a fast train from Nottingham.
  • Would Mansfield and Worksop benefit from a direct service from London on the Robin Hood Line, after a reverse at Nottingham.

The five-car trains give the flexibility to do the previously unthinkable.

Conclusion

There is a lot of developments that can or will happen with Midland Main Line services.

August 1, 2019 Posted by | Transport | , , , , , , | 4 Comments

Could London Get A New Tube Line Between Canary Wharf And Euston?

The title of this post is the same as that as this article on CityMetric.

The article makes some interesting points.

  • The line has been proposed by the owners of Canary Wharf.
  • Getting to Canary Wharf from Euston, Kings Cross and St. Pancras is difficult.
  • Property developers have always decided where London’s railways go.
  • The plan would seem to have just one intermediate stop at Blackfriars station.

These new or improved services will be happening in the next ten years.

  • More and faster services to/from the Midlands and the North West at Euston.
  • High Speed Two services at Euston
  • More and faster services to/from the East Midlands and Sheffield at St. Pancras.
  • More Continental services at St. Pancras
  • More and faster services to/from Yorkshire, the North East and Scotland at Kings Cross.

These lead me to the conclusion, that a new rail link is needed across London.

A Possible Western Extension To The Docklands Light Railway

In A Connection Between City Thameslink Station And The Docklands Light Railway, I wrote about a possible Western extension of the Docklands Light Railway.

his map from Transport for London, shows this possible Western extension of the DLR.

This was my analysis.

With all the problems of the funding of Crossrail 2, that I wrote about in Crossrail 2 Review Prompts Fresh Delays, could this extension of the DLR, be a good idea?

Consider,

  • Victoria, Euston and St. Pancras are prosposed Crossrail 2 stations.
  • It would link Canary Wharf and the City of London to Eurostar, Northern and Scottish services and High Speed 2.
  • It would give all of the Docklands Light Railway network access to Thameslink.
  • A pair of well-designed termini at Euston and St. Panras would probably increase frequency and capacity on the Bank branch of the system.
  • The DLR is getting new higher capacity trains.
  • Bank station is being upgraded with forty percent more passenger capacity.
  • Holborn station is being upgraded and hopefully will be future-proofed for this extension.
  • One big advantage at City Thameslink, is that Thameslink and the proposed DLR extension will cross at right-angles, thus probably making designing a good step-free interchange easier.
  • The Bank Branch of the DLR currently handles 15 tph, but could probably handle more, if they went on to two terminal stations at St Pancras and Victoria..
  • Waterloo and City Line can run at twenty-four tph.

Cinderella she may be, but then she always delivers, when there is a desperate need, just as she did magnificently at the 2012 Olympics.

The only problem with this extension of the DLR, is that compared to the rest of the system, the views will be terrible.

For myself and all the others living along the East London Line, with a step-free change at Shadwell, we would get excellent access to Euston, Saint Pancras and Victoria

But could the line still be called the Docklands Light Railway, as it spreads its tentacles further?

Will Cinderella come to the help of Canary Wharf for a second time?

I remember, when the Lewisham extension of the DLR was built without fuss, fanfare and cost and time overruns a couple of decades ago.

It was a triumph of sensible engineering.

April 18, 2019 Posted by | Transport | , , , , , | 9 Comments

Google Grabs The Best Site In London For Its Massive Groundscraper

This Google Map the site where the massive groundscraper is being built.

Note.

  1. Kings Cross station, which is on the right of the map, has extensive connections to the North-East of England and Scotland.
  2. St. Pancras station, which is on the left of the map, has extensive connections to the Midlands and Belgium, France and the Netherlands, with more services to come including Germany, Switzerland and Western France.
  3. Thameslink runs North-South beneath St. Pancras station, has extensive connections to Bedfordshire, Herfordshire, Kent, Surrey and Sussex.
  4. There are also six Underground Lines.
  5. Gatwick and Luton Airports have direct connections and City, Heathrow and Southend Airports  only need a step-free change.
  6. Improvements in the next few years could mean that HS2 and all of London’s five airports will have a fast direct connection to the area.

In the middle of all these railway lines, sits Google’s groundscraper, which shows as a white structure towards the top of the map.

These pictures show the area between the two stations, the under-construction groundscraper and the new blocks.

And these pictures show the progress on the site.

There is not much that is visible yet!

More Pictures!

But the building will be more visible soon! For those who can’t wait, this article from the Daily Mail has a lot of visualisations.



November 8, 2018 Posted by | Computing, World | , , , , , , | 1 Comment

Heavyweight Backing Expected For £1.5bn Crossrail Extension

The title of this post, is the same as that of this article on New Civil Engineer.

This is the first paragraph.

Government infrastructure tsar Sir John Armitt is this week expected to throw his weight behind a £1.5bn extension to Ebbsfleet.

The article also says.

  • Circumstances have changed greatly since the 2008 Crossrail Act.
  • Canary Wharf Group, who contributed £150million to the building of Canary Wharf station, may be prepared to contribute, as this will give access from their site to Eurostar.
  • The extension could support the construction of 55,000 new homes and 50,000 jobs.

The extension would take ten years to design and construct.

Eurostar

After my forays to and from Europe recently by Eurostar, I feel that a Crossrail link to Ebbsfleet will be heavily used.

  • As more destinations are served by trains from St. Pancras, more passengers will find Ebbsfleet a more convenient station for the Continent.
  • Ebbsfleet will be linked directly to Canary Wharf, the City of London, the West End and Heathrow.
  • Crossrail will give an easy Undergound-free link between Wales and the West Country and Ebbsfleet stations with a single change at Paddington station.
  • When HS2 opens, there will be an easy Underground-free link between the Midlands and the North and Ebbsfleet stations with a single change at Old Oak Common station.
  • St. Pancras only has four platforms with no space to expand, but it could be relatively easy to add capacity at Ebbsfleet.

If I was in charge of designing and building the Crossrail extension, I’d make sure that Eurostar made a contribution, as they will be big winners from the extension.

The City Of London

The extension may be beneficial to the City of London.

  • The extension would add more stations within easy reach of terminal stations in the City.
  • The extension might give an easier route to and from the City.
  • After Brexit, I suspect the institutions of the City will want more good connections to Amsterdam, Brussels, Frankfurt and Paris.

,Perhaps one of the big City companies might like to finance construction and charge a royalty on each rain?

London City Airport

Should the project to build the extension also include building a Crossrail station at London City Airport?

This would mean that passengers between places like Aberdeen, Belfast, Dublin, Edinburgh, Glasgow, the Isle of Man and Manchester, and Continental destinations served by train would have a more convenient interchange in London.

Ebbsfleet Valley

Ebbsfleet Valley is a proposed new town of 16,000 homes being built on brownfield land close to Ebbsfleet station.

£300million of government money has been pumped into the project. But according to Wikipedia, there has been criticisms of the project.

London Paramount Entertainment Resort

London Paramount Entertainment Resort is described like this in Wikipedia.

London Paramount Entertainment Resort (commonly referred to as London Paramount) is a proposed theme park for the London Resort in Swanscombe, Kent. The project was announced on 8 October 2012 and it was estimated to open by around 2023.. In June 2017, it was announced that Paramount had pulled out of the project[2]. However, London Resort Company Holdings still insist the project is going ahead.

I’ve never been to a theme park, as I prefer the real thing!

But others will like it!

Conclusion

The beneficiaries of extending Crossrail to Ebbsfleet, include a lot of big players with possibly large financial resources.

I would suspect that some could be persuaded to fund particular parts of the project.

After all, if a housing developer invested say £10 million, in a new station for a development and then found it easier to sell the houses, there comes a point, where they make more profit and house buyers get a much better place to live.



June 4, 2018 Posted by | Transport | , , , , , , | 3 Comments

A Connection Between City Thameslink Station And The Docklands Light Railway

In the Wikipedia entry for the Docklands Light Railway, there is a section describing a proposed Euston/St. Pancras Extension.

This is said.

In 2011, strategy documents proposed a DLR extension to Euston and St Pancras. Transport for London have considered driving a line from City Thameslink via Holborn north to the rail termini. The main benefit of such an extension would be to broaden the available direct transport links to the Canary Wharf site. It would create a new artery in central London and help relieve the Northern and Circle lines and provide another metro line to serve the High Speed line into Euston.

This map from Transport for London, shows the possible Western extension of the DLR.

With all the problems of the funding of Crossrail 2, that I wrote about in Crossrail 2 Review Prompts Fresh Delays, could this extension of the DLR, be a good idea?

Consider,

  • Victoria, Euston and St. Pancras are prosposed Crossrail 2 stations.
  • It would link Canary Wharf and the City of London to Eurostar, Northern and Scottish services and High Speed 2.
  • It would give all of the Docklands Light Railway network access to Thameslink.
  • A pair of well-designed termini at Euston and St. Panras would probably increase frequency and capacity on the Bank branch of the system.
  • The DLR is getting new higher capacity trains.
  • Bank station is being upgraded with forty percent more passenger capacity.
  • Holborn station is being upgraded and hopefully will be future-proofed for this extension.
  • One big advantage at City Thameslink, is that Thameslink and the proposed DLR extension will cross at right-angles, thus probably making designing a good step-free interchange easier.
  • The Bank Branch of the DLR currently handles 15 tph, but could probably handle more, if they went on to two terminal stations at St Pancras and Victoria..
  • Waterloo and City Line can run at twenty-four tph.

Cinderella she may be, but then she always delivers, when there is a desperate need, just as she did magnificently at the 2012 Olympics.

The only problem with this extension of the DLR, is that compared to the rest of the system, the views will be terrible.

For myself and all the others living along the East London Line, with a step-free change at Shadwell, we would get excellent access to Euston, Saint Pancras and Victoria

But could the line still be called the Docklands Light Railway, as it spreads its tentacles further?



March 12, 2018 Posted by | Transport | , , , , , , , , , | 16 Comments

The Rigid Overhead Conductor Rails At St. Pancras Thameslink Station

Whilst waiting for a train in St. Pancras Thameslink station, I noticed that the station has been fitted with rigid overhead conductor rails.

I couldn’t remember it being there before. But I don’t often go to the station.

However, I did find this page in Rail Forums, which is entitled Conductor Rail At St. Pancras Thameslink.

Apparently, the change was made at Easter 2013. This is one reply.

Installed over Easter. Known as conductor beam. The contact wire is fixed to the underside. Much more robust than regular OLE, and practically zero maintenance.

It has replaced a tricky tension length of OLE between approx half way along St Pancras LL platforms and the middle of the old KX Thameslink platforms. The curvature, cant and gradient change through this section made the OLE pretty difficult to keep in the right place and had high wear rates.

Likely the conductor beam will be extended north through to Dock Jn and through the new Canal tunnels, not confirmed yet.

Given the robust nature and lower maintenance costs, I think we’ll be seeing lots more of this type of electrification.

November 5, 2017 Posted by | Transport | , , | Comments Off on The Rigid Overhead Conductor Rails At St. Pancras Thameslink Station

Should A Mega-Station Be Created At Kings Cross-St. Pancras-Euston?

The three important stations of Kings Cross, St. Pancras and Euston sit like three isolated islands on Euston Road.

Kings Cross Station

Kings Cross station was extended and refurbished in 2012 and is the most modern of the three, with a well-designed square in front of the station.

Kings Cross serves as a terminus for East Coast Main Line and some Cambridge services.

Underground

Kings Cross has connections to the following Underground lines at Kings Cross St. Pancras tube station.

  • Circle, Hammersmith and City and Metropolitan.
  • Northern
  • Piccadilly
  • Victoria

On the whole, the connections to the Underground are generally good, but crowded.

Buses

If you want to go East connectivity is good, but when taking a bus to the West or South, finding the stop can be difficult.

Taxis

The taxi rank at Kings Cross generally works well, as it was reconfigured when the station was updated.

Summing Up Kings Cross Station

Kings Cross has a lot of space both inside and outside and using the station can be an easy process compared to many.

St. Pancras Station

St. Pancras station was rebuilt and extended for Eurostar and Southeastern Highspeed services in 2007.

I always describe St, Pancras as a Fur-Coat-And-No-Knickers station.

It may look spectacular, but it wasn’t designed for passengers or staff, due to the dreadful connectivity between the various services at the station.

  • Continental
  • Midland Main Line
  • Southeastern Highspeed
  • Thameslink

With all these services set to expand, I have a feeling that St. Pancras faces a capacity problem.

Underground

To further complicate matters, it’s a often a long walk to the Underground line you need, as these were designed to serve Kings Cross.

  • Circle, Hammersmith and City and Metropolitan.
  • Northern
  • Piccadilly
  • Victoria

There is a ticket hall at the front of the station, but it’s often very crowded with large numbers of Eurostar passengers queuing for tickets.

Buses

It’s a walk to Kings Cross in most cases unless you can find a way across the busy Euston Road.

Taxis

I always walk to Kings Cross, as like most passenger facilities at St. Pnncras, the taxi rank wasn’t well-designed.

Summing Up St. Pancras

St. Pancras doesn’t have the space inside or outside that Kings Cross has and often feels cramped with every seat taken.

With the increase in all services expected in the next few years, passengers should think hard about how they can avoid the station,

Euston Station

Euston station is going to be rebuilt in the next few years for HS2.

Currently, it serves as a terminus for West Coast Main Line and a few suburban services.

Underground

The Underground at Euston is a mess with Euston tube station handling the following lines.

  • Both branches of the Northern
  • Victoria

Round the corner is the cramped Euston Square station which handles the Circle, Hammersmith and City and Metropolitan Lines.

Neither station is fully step-free and the Underground connection will need expansion for HS2.

Buses

Euston has a good bus station if you’re going East, but going West means crossing the busy Euston Road.

Taxis

Euston has an underground taxi rank, that seems to work well.

Summing Up Euston Station

Space is at a premium in Euston station and the Underground connections need urgent improvement.

Crossrail 2

Crossrail 2 is being put forward  as the project that will sort out the problems of the three stations on the Euston Road.

A mega station is to be built called Euston St. Pancras, which will serve all three stations.

But Euston and St. Pancras need extra capacity in connecting services now, not in the early 2030s!

Existing Lines

This map from carto.metro.free.fr shows the current Underground Lines at the three stations.

Can these lines be improved to help solve the capacity problems?

Victoria Line

If you want an example of the quality of the engineers working on the London Underground, you only have to look at the Victoria Line.

Fifty years old next year, the line was built on the cheap, but with superb automatic systems and some clever station layouts and now every year, more trains seem to be squeezed down its pair of tunnels. Currently, the frequency of trains is thirty-six trains per hour (tph) along its whole length.

As the Victoria Line calls at all three stations, any improvements to Dear Old Vicky, like step-free access at Euston, will help.

Northern Line

The Northern Line has three major projects underway.

  • The extension to Battersea
  • The upgrading of Camden Town station.
  • The upgrading of Bank station

When these are complete around 2024, it will be possible to split the line into two separate lines each handling 36 tph.

But more trains will be needed.

Piccadilly Line

The major upgrade for the Piccadilly Line will be new trains, which should arrive from 2022, which will bring a double-digit increase in capacity.

It should also be noted that the frequency in the core is only twenty-one tph, so upwards of thorty tph must be an objectve.

Unlike the Northern And Victoria Lines, the Piccadilly Line doesn’t call at Euston station.

Circle, Hammersmith and City and Metropolitan Lines

The Circle, Hammersmith and City and Metropolitan Lines are being upgraded. This is said on Wikipedia.

Together with the introduction of S Stock trains, the track, electrical supply and signalling systems are being upgraded in a programme planned to increase peak-hour capacity on the Circle and Hammersmith & City lines by 65 per cent by the end of 2018. A single control room for the sub-surface railway is to be established in Hammersmith and an automatic train control (ATC) system will replace signalling equipment installed from the 1940s. The cross-London Crossrail line, planned to open in 2018, is expected to reduce crowding between Paddington and Whitechapel.

This should result in a large increase in capacity between Baker Street and Liverpool Street.



Crossrail

Although Crossrail doesn’t fully open until December 2019, and doesn’t even call at Kings Cross, St.Pancras and Euston stations, the new line will have an effect on passengers travelling to the three stations.

  • In my quote  from Wikipedia, it says that Crossrail is expected to reduce crowding between Paddington and Whitechapel.
  • Crossrail is expected to have a link with HS2 at Old Oak Common station.
  • Crossrail may be extended up the West Coast Main Line.

The latter two points would allow passengers to bypass Euston.

Thameslink

Thameslink when it is running fully at the design frequency of 24 tph will certainly have effects on passenger traffic.

But it is difficult to say what they will be.

Difficult Interchanges

If you look at the interchanges between the various lines, in my opinion, the following are the more difficult interchanges.

  • Euston Square tube station to Euston station.
  • Euston station to St. Pancras station.
  • Victoria Line to Thameslink at St. Pancras station.
  • Circle, Hammersmith and City and Metropolitan Lines ro Thameslink at St. Pancras station.
  • Euston Square tube station to Northern Line at Euston station.

In addition Euston Square and Euston stations are not step-free.

Transport for London probably know the improvements that would offer the most benefit.

Euston Square Station And Euston Station

The poor connectivity between Euston Square tube station and Euston station, is a major problem.

Sort this bad connectivity, when Euston station is rebuilt for HS2 and world’s oldest underground railway, dating from 1863, will be providing a high-frequency service to the UK’s premier high-speed railway.

Euston Road

Euston Road, which can be very busy, is a major problem for passengers needing to cross to perhaps use buses going to the West.

The experience of using the stations could be improved for a proportion of travellers, if crossing the road was easier.

Should A Mega-Station Be Created At Kings Cross-St. Pancras-Euston?

I’ll return to the original question I asked.

  • If Crossrail 2 is built, there will obviously be a mega station at Euston St. Pancras.
  • But I believe that all the other improvements that will happen before HS2 opens may well be enough to cope with the extra capacity needed for a few years.

Obviously though, any improvements must not compromise the building of Crossrail 2’s mega-station.

Conclusion

I believe it is possible to improve connectivity to the three major stations of King Cross, St. Pancras and Euston, by doing the following.

  • Improving the frequency and capacity on the various Underground lines serving the three stations.
  • Splitting the Northern Line into two separate lines.
  • Improving the links between the existing Nation Rail and Underground Lines.
  • Integrating Euston Square station into Euston station, when Euston is rebuilt for HS2.
  • Improving the crossing of Euston Road on foot.

In some ways the last-but-one point is the most important, as it cures the worst interchange.











September 29, 2017 Posted by | Transport | , , , , , , , | 5 Comments
