The Cambridge Re-signalling, Relock and Recontrol Project

This project is Network Rail’s big signalling project in the Cambridge area and it is fully described in this document on the Network Rail web site.

The project is called the C3R Project for short and its scope is described in this Network Rail infographic.

Note.

  1. 125 miles of track are to be resignalled.
  2. Seventeen stations are likely to be resignalled.
  3. Eight level-crossings are to be upgraded.

Network Rail’s document splits the project into five sections.

  • Cambridge Power Signal Box – This will be upgraded.
  • Safety Interlocking Equipment – This will be upgraded with a computer-based system.
  • Closure Of Three Signal Boxes – Control will be relocated to Cambridge Power Signal Box.
  • Seven Level Crossing Upgrades – These will be upgraded to full barrier crossings.
  • Land Acquisition – As necessary to complete the works.

Upon completion the project will have replaced around 690 signalling assets.

Network Rail also say that the outline design contract to Alstom and it is expected to be completed in the last quarter of 2021.

Network Rail also says this about completion.

Subject to obtaining the necessary consents and design approvals, the detailed design and delivery of the signalling upgrade could begin by end of 2021 and be complete around the end of 2024.

My experience of project management and the railways of East Anglia, says that subject to one caveat, that this is a reasonable timescale.

The Level Crossing Problem

The problem could be the level crossings, as local interests are very protective of their supposed right to cross unhindered.

I particularly remember the Little Cornard Derailment, because a solicitor, who regularly instructed my late wife, was seriously injured in the derailment.

This is the first paragraph of the Wikipedia entry.

The Little Cornard derailment occurred on 17 August 2010 when a passenger train collided with a road vehicle on a level crossing on the Gainsborough Line near Little Cornard, Suffolk, and partly derailed. The vehicle, a tanker lorry, had begun crossing over the track when the Class 156 train from Sudbury destined for Marks Tey struck it whilst travelling at a speed of approximately 40 miles per hour (64 km/h)

Note.

Although, my late wife had died in 2007, one of her barrister colleagues told me of the link.

East Anglia and other rural parts of the UK suffer regularly from this type of accident.

This Google Map shows a 3D visualization of the site of the derailment.

It appears to be rather remote.

I am totally appalled that there was such primitive safety equipment on this crossing.

  • I have worked in seriously dangerous chemical plants, where Health and Safety rules forbade anyone entering the plant without full training.
  • As a sixteen-year-old in 1963, I was designing and installing systems on industrial guillotines, so that workers didn’t lose their hands.
  • A proportion of work, I did whilst working for ICI was about Health and Safety.
  • I have travelled extensively in tour buses in Eastern Europe and seen some appealing driving at level crossings.
  • According to a Hungarian friend, if you want to see bad driving at level crossings try Russia. He put it down to the local firewater.

This experience leeds me to believe that one of two things should be done with all level crossings on the railway.

  1. There should be a strong safety system on the crossing.
  2. The level crossing should be closed.

Will Network Rail be allowed by local interests to upgrade all the crossings they need?

The Level Crossings Network Rail Propose To Upgrade

These are the crossings Network Rail propose to upgrade.

Meldreth Road Level Crossing

This Google Map shows the Meldreth Road level crossing.

Note.

  1. Meldreth Road is the A10 between Cambridge and Royston.
  2. The double-track rail is the Cambridge Line between Cambridge and the East Coast Main Line.
  3. The line has a maximum speed of 90 mph.
  4. In every hour there are up to 10-12 passenger trains per hour (tph) through the level crossing.
  5. There are perhaps ten other trains per day, or less than one tph.

The ABC Railway Guide gives a line speed of 90 mph and adds these risk factors.

  • Sun Glare
  • Frequent Trains

It is very much a classic case of a busy railway crossing a busy road.

I also think that Network Rail has another problem here.

Pressure from train operators and passengers, could lead to more and faster trains through this level crossing.

In my view, the best solution to that problem would be to drop the railway into a cutting and put the road on a bridge over the top.

But this would be a very expensive and disruptive solution, which might mean that the road and/or railway were to be closed for several months.

The only other solution would be to run all trains between Royston and Cambridge under the control of digital signalling and Automatic Train Operation.

Trains would be timed so, that trains in opposite directions crossed on the level crossing, when the full barriers were down to stop traffic.

If this could be done, it could have various effects.

  • This would halve the number of level crossing closures in every hour.
  • The timekeeping might even impress drivers.
  • It might even train drivers to expect two trains, so if one was a minute or so late, they might be more prepared to wait.

This technique would give whole new meaning to a double cross.

This page on the My Councillor web site, gives details of opposition to the project by Councillor Susan van der Ven.

Six Mile Bottom Level Crossing

This Google Map shows the Six Mile Bottom level crossing.

Note.

  1. The road is the A1304 which is the main link between Newmarket and the South.
  2. The road can get very busy, when there is a big race meeting.
  3. The rail track is only single track.
  4. The line has a maximum speed of up to 75 mph.
  5. In every hour there are no more than one passenger tph in both directions.
  6. There are some occasional freight trains over the crossing.

The ABC Railway Guide gives a line speed of 60 mph and adds these risk factors.

  • Large Numbers Of Users
  • Sun Glare

I used to drive across this level crossing regularly, when I lived in the area and the trouble is that it is on a straight road, that encourages high speed.

Legend has it, that this was one of public roads used by Vincent to test their high performance motorcycles.

In the time I lived near the crossing, I can remember a serious accident between a car and a train, at the crossing.

It would appear that a partial solution has been applied.

This video shows how much brighter LED lights have been fitted to the crossing.



Let’s hope this encourages drivers to slow down, when the crossing is closed.

How many other level crossings would be improved with bright LED lights like these?

Dullingham Level Crossing

This Google Map shows the Dullingham level crossing.

Note.

  1. The current barriers are operated manually by the signalman in Dullingham signal box.
  2. The road is a local road and the small amount of traffic could probably be easily handled by an automatic crossing with full barriers.
  3. The rail line is the same at that at Six Mile Bottom, but is double-track.

The ABC Railway Guide gives a line speed of 60 mph and adds these risk factors.

  • Poor Visibility for Approaching Road Vehicles
  • Crossing is Near a Station
  • Crossing Approach
  • Sun Glare

From my local experience, I suspect that an automatic crossing with full barriers might even cause less delay to road traffic.

Milton Fen Level Crossing

This Google Map shows the Milton Fen level crossing.

Note.

  1. The road is a local road and the small amount of traffic could probably be easily handled by an automatic crossing with full barriers.
  2. The railway is the Fen Line between Cambridge and Ely.
  3. It looks like there are three passenger tph and the occasional freight trains through this crossing.
  4. The line speed of the rail line is 75 mph.

The ABC Railway Guide gives a line speed of 75 mph and adds these risk factors.

  • Sun Glare
  • Frequent Trains

It should also be noted that I can find reports of serious accidents and deaths on this crossing.

It looks to me, that an automatic crossing with full barriers could work well on this level crossing.

Waterbeach Level Crossing

This Google Map shows the Waterbeach level crossing.

Note.

  1. The road is a local road, but could the traffic be easily handled by an automatic crossing with full barriers?
  2. The railway is the Fen Line between Cambridge and Ely.
  3. It looks like there are three passenger tph and the occasional freight trains through this crossing.
  4. The line speed of the rail line is 75 mph.
  5. Waterbeach station is split with one platform either side of the level crossing, which is used by passengers to cross the line.

The ABC Railway Guide gives a line speed of 75 mph and adds these risk factors.

  • Poor Visibility for Approaching Road Vehicles
  • Crossing is Near a Station
  • Crossing Approach
  • Large Numbers of Users
  • Blocking Back
  • Frequent Trains

It should also be noted that Network Rail rate this crossing as high risk.

There is probably a long-term solution for this level crossing

Under Future Plans in the Wikipedia entry for Waterbeach station, this is said.

Plans to develop a New Town of 8,000 to 9,000 homes on the former Waterbeach Barracks site have been outlined by South Cambridgeshire District Council. As part of the proposal, there are plans to relocate the station to a new site and extend the platforms to accommodate 12 car trains.

Surely, a well-designed transport network to serve all these houses would see the level crossing closed and a new station built at a convenient location.

Dimmocks Cote Level Crossing

This Google Map shows the Dimmocks Cote level crossing.

Note.

  1. The road is the A1123, so could the traffic be easily handled by an automatic crossing with full barriers?
  2. The railway is the Fen Line between Cambridge and Ely.
  3. It looks like there are three passenger tph and the occasional freight trains through this crossing.
  4. The line speed of the rail line is 75 mph.

The ABC Railway Guide gives a line speed of 75 mph and adds these risk factors.

  • Infrequent Trains
  • Deliberate Misuse or User Error

It should also be noted that Network Rail rate this crossing as high risk.

Croxton Level Crossing

This Google Map shows the Croxton level crossing.

Note.

  1. The road is the A1075, so could the traffic be easily handled by an automatic crossing with full barriers?
  2. The railway is the Breckland Line between Norwich and Ely.
  3. It looks like there are two passenger tph and the occasional freight trains through this crossing.
  4. The line speed of the rail line is 75-90 mph.

It should also be noted that Network Rail rate this crossing as high risk.

The ABC Railway Guide gives the line speed as 40 mph and adds these risk factors.

  • Poor Visibility for Approaching Road Vehicles
  • Crossing Approach
  • Large Numbers of Users
  • Sun Glare
  • Deliberate Misuse or User Error

This crossing sounds like it could be an accident waiting to happen.

Although, I would feel that installing similar lights to those at Six Mile Bottom could be a big help!

Summarising The Proposed Level Crossing Upgrades

I can split these by topic.

Full Barrier installation

It would appear that all barriers can probably be replaced with the latest full barrier technology.

Improved Lighting

The video from Six Mile Bottom was impressive and probably shows how fairly simple improvements can increase safety.

Local Opposition

On this brief summary of all the level crossings, that Network Rail propose to upgrade to automatic crossing with full barriers, it would appear that only the Meldreth Road crossing is seeing opposition from local interests. Although, I do have doubts, that the development of all those houses at Waterbeach will ever happen because of local opposition.

Major Construction Works

It would appear that only two upgrades could require major works.

Meldreth Road – But only if it was felt that a substantial solution was needed.

Waterbeach – If a new station were to be built to cater for future housing development.

The others would only need barrier replacement and other appropriate improvements.

I would also feel that most of the work could be carried out without major disruption to train services or road traffic.

Modern Digital Signalling With Automatic Train Operation

Modern digital signalling with in-cab displays and a measure of automatic train operation offers three main gains to train operators and passengers.

  • More services can be squeezed safely into the existing network, without building controversial and expensive new lines.
  • Trains can run at higher average speeds.
  • Trains can run to timetable easier.

It should be noted that South of Doncaster the East Coast Main Line is being converted to this type of signalling and this will allow the Azumas and other trains to run at 140 mph, where the track allows, to speed up services between King’s Cross and the North.

Services Between King’s Cross and Cambridge

South of Hitchin, some services between King’s Cross and Cambridge share the lines with the expresses to and from the North.

For that reason the 100 mph Class 700 trains and the 110 mph Class 387 trains, would be out of their speed range like Morris Minors on the M1.

In 2018, I wrote Call For ETCS On King’s Lynn Route, based on an article in Rail Magazine, which called for 125 mph trains to Cambridge and King’s Lynn, so they wouldn’t slow the expresses.

It does appear to me that the digital signalling part of the C3R Project will enable 125 mph trains to run between King’s Cross and King’s Lynn via Cambridge.

  • Oxford has 125 mph non-stop local trains to London, so why not Cambridge?
  • A nine-car Class 800 train has a similar seating capacity to a twelve-car Class 700 train, but the seats are better and the train can travel at 125 mph.
  • These trains would significantly reduce the fifty minute journey time between King’s Cross and Cambridge.

This would be a real Cambridge Express.

Developing Services Around Cambridge

Just as full digital signalling is helping London to expand its railways with Crossrail and Thameslink. I believe that the C3R Project will help to squeeze more trains through Cambridge.

In a few years time, I believe Cambridge will have a core route consisting of Cambridge North, Cambridge and Cambridge South stations with much expanded services to Bury St. Edmunds, Ely, Ipswich, Kings Lynn, London, Norwich, Peterborough, Stansted Airport, Stevenage and Wisbech.

Ten years ago, I was told by one of Cambridge’s eminent thinkers, that Cambridge needed the connectivity to bring in the people that the economy needs.

The pandemic has changed things, but not Cambridge’s desire to create more businesses expand.

A Connection To Peterborough

Peterborough is the other half of Cambridgeshire’s area and shares the Cambridgeshire & Peterborough Combined Authority with Cambridge.

Peterborough station is well connected to the North and Midlands.

  • LNER’s connect the station to most stations  on the East Coast Main Line.
  • It has hourly services to Birmingham, Leicester, Liverpool, Manchester and Nottingham.

But the connection between Cambridge and Peterborough is not of the quality and frequency that the two cities need.

A Connection To Stevenage

Stevenage is an important manufacturing and technology centre, with a strong presence in aerospace.

Stevenage station is well connected to the North and South.

  • LNER and other services connect the station to most stations South of Leeds and York on the East Coast Main Line.
  • The new service from East Coast Trains will provide a direct service to Newcastle and Edinburgh with a frequency of seven trains per day (tpd).
  • It has a direct suburban line to King’s Cross.
  • It has a direct suburban line to Moorgate.

Stevenage seems to be acquiring more long distance services as time progresses.

But the connection between Cambridge and Stevenage is currently poor, at just two tph, which stop everywhere.

Improve the connection between Cambridge and Stevenage and have more calls of services to and from the North at Stevenage and Cambridge and \stevenage would benefit.

Currently, the fast Cambridge services take 27 minutes to do the 30.3 miles between Cambridge and Stevenage, which is an average speed of 67.3 mph.

A Connection To Wisbech

Progress seems to be being made on a service between Cambridge and Wisbech, which I wrote about in Hope For Wisbech Line Revival.

This was the conclusion of that post.

I very much feel that the Cambridgeshire & Peterborough Combined Authority and Network Rail can create a very useful branch line to Wisbech.

There is not much infrastructure to be built and upgraded.

    • A new station will be built at Wisbech, which I feel is likely to be a Park-and-Ride on the A47.
    • A bay platform will probably need to be reopened at March station.
    • March station will need to be step-free.
    • There may be a station and a passing loop at Coldham.
    • Track and signalling will need to be replaced.

But the big project needed is the remodelling at Ely, which will have to be done to increase capacity, through the bottleneck.

Greater Anglia’s Class 755 trains would appear to be ideal for the branch and could operate on battery power.

This connection could be a very valuable connection.

It certainly looks like there are better plans to connect Wisbech to Cambridge, than there are to improve the connections between Cambridge and Peterborough and Stevenage.

Conclusion

The C3R Project will give the Cambridge compatible signalling with the East Coast Main Line and I feel increasingly Cambridge could be treated as a series of stations just off the East Coast Main Line and we might see some services develop, that seem strange to today’s travellers.

A simple example could be a Regional Metro running between Peterborough and Stevenage.

  • It would call at March, Ely, Waterbeach, Cambridge North, Cambridge, Cambridge South, Royston and Hitchin.
  • It would run at a frequency upwards of two tph.
  • It could even connect to Lincoln.

Other North-South services through Cambridge like Thameslink and Norwich and Stansted would combine to give perhaps six tph through the three main Cambridge stations.

The C3R Project will open up lots of possibilities.











June 3, 2021 Posted by | Transport | , , , , , , , , , , , , | 7 Comments

Is The East-West Rail Link Going For The Freight Market?

I will deal with question in two main sections; West and East.

Freight In The West

In Shapps Supports Beeching Axe Reversals, I talked about the reopening of the Northampton and Marketharborough Line to connect the West Coast and Midland Main Lines..

  • Passenger services could run between Market Harborough or Leicester and Marylebone, Milton Keynes, Oxford or Reading.
  • Multi-modal services could run between freight terminals in the North Midlands and Yorkshire and Southampton Docks.
  • With electrification, it could create the Electric Spine, that was cancelled a few years ago.

Judging by Grant Shapps comments, I do wonder if this scheme is part of the East-West Rail Link.

Look at freight trains between Sheffield or South Yorkshire and Southampton Docks.

  • Currently, they seem to use a route via Chesterfield, Ilkeston, Toton, Burton-on-Trent, Bordesley, Solihull, Warwick Parkway, Banbury, Oxford, Reading and Basingstoke.
  • After the East-West Rail Link and the Northampton and Market Harborough Line are opened, the trains would go via Chesterfield, Ilkeston, East Midland Parkway, Loughborough, Leicester, Market Harborough, Northampton, Milton Keynes, Bletchley, Bicester, Oxford, Reading and Basingstoke.

The advantages of the new second route would appear to be.

  • It doesn’t involve a Grand Tour of Birmingham.
  • It only involves the next phase of the East-West Rail Link.
  • It is partially-electrified.
  • It would be relatively easy to electrify between Didcot and Bletchley.
  • Innovative locomotives like the Class 93 locomotive might be ideal for the route.

I do suspect that the new route will be substantially quicker.

Freight In The East

If the East-West Rail Link will improve freight services in the West, what will it do in the East?

I wrote about freight at the Eastern end of the route in Roaming Around East Anglia – Freight Trains Through Newmarket.

This was the introduction to that article.

The East West Rail Consortium plan to change the route of freight trains to and from Haven Ports; Felixstowe, Harwich and Ipswich to the West of Kennett station.

In this document on the East-West Rail Consortium web site, this is said.

Note that doubling of Warren Hill Tunnel at Newmarket and
redoubling between Coldham Lane Junction and Chippenham Junction is included
in the infrastructure requirements. It is assumed that most freight would operate
via Newmarket, with a new north chord at Coldham Lane Junction, rather than
pursuing further doubling of the route via Soham.

How would these changes affect Newmarket and the horse-racing industry in the town?

I then examined the affects in detail.

My conclusions were that it will be a difficult project to get approved, as Newmarket won’t like a double-track freight railway through the centre.

Summary Of Freight Routes Using The East-West Rail Link

As far as I can see, these will be the major freight routes using the link.

Felixstowe and Birmingham

Ipswich, Newmarket, Cambridge, Bletchley, Nuneaton and Castle Bromwich

Felixstowe and Bristol

Ipswich, Newmarket, Cambridge, Bletchley, Oxford and Swindon

Felixstowe and Cardiff

Ipswich, Newmarket, Cambridge, Bletchley, Oxford, Swindon and Newport

Felixstowe and Glasgow

Ipswich, Newmarket, Cambridge, Bletchley, Stafford, Crewe, Preston and Carlisle

Felixstowe and Liverpool

Ipswich, Newmarket, Cambridge, Bletchley, Stafford, Crewe and Runcorn

Felixstowe and Trafford Park

Ipswich, Newmarket, Cambridge, Bletchley, Stafford Crewe, Manchester Piccadilly and Manchester Oxford Road

Southampton and Birmingham

Basingstoke, Oxford, Bletchley, Nuneaton and Castle Bromwich

Southampton and Glasgow

Basingstoke, Oxford,  Bletchley, Stafford, Crewe, Preston and Carlisle

Southampton and Liverpool

Basingstoke, Oxford, Bletchley, Stafford, Crewe and Runcorn

Southampton and Sheffield

Basingstoke, Oxford, Bletchley, Northampton, Market Harborough, Leicester, East Midlands Parkway, Ilkeston and Chesterfield

Southampton and Trafford Park

Basingstoke, Oxford, Bletchley, Stafford Crewe, Manchester Piccadilly and Manchester Oxford Road

Note, that I have ignored routes like Felixstowe and Leeds or London Gateway and Trafford Park, which will avoid the East-West Rail Link.

Conclusion

The East-West Rail Link is going to be a very important freight route.

Winners And Losers

Will there be objections in places like Cambridge, Market Harborough and Newmarket, which will see a large increase in freight traffic?

On the other hand, some places like Banbury, Birmingham and North London will see a reduction in freight traffic.

Others like Oxford would see little difference in the numbers of trains.

Electrification

The East-West Rail Link connects to five electrified main lines at Oxford, Bletchley, Bedford, Sandy and Cambridge.

For freight’s sake, I think it should be electrified to make the most of new motive power, like the Class 93 locomotive and reduce pollution and carbon emissions.



October 30, 2019 Posted by | Transport | , , , , | Leave a comment

Roaming Around East Anglia – Freight Trains Through Newmarket

The East West Rail Consortium plan to change the route of freight trains to and from Haven Ports; Felixstowe, Harwich and Ipswich to the West of Kennett station.

In this document on the East-West Rail Consortium web site, this is said.

Note that doubling of Warren Hill Tunnel at Newmarket and
redoubling between Coldham Lane Junction and Chippenham Junction is included
in the infrastructure requirements. It is assumed that most freight would operate
via Newmarket, with a new north chord at Coldham Lane Junction, rather than
pursuing further doubling of the route via Soham.

How would these changes affect Newmarket and the horse-racing industry in the town?

How Many Freight Trains Are We Talking About?

This table shows the number of freight trains going through Kennett station on the 1st of March 2019.

  • 00  1  1
  • 01  1  0
  • 02  0  1
  • 03  2  1
  • 04  1  1
  • 05  1  1
  • 06  1  2
  • 07  1  1
  • 08  1  0
  • 09  1  0
  • 10  1  0
  • 11  0  0
  • 12  0  0
  • 13  2  2
  • 14  0  2
  • 15  1  1
  • 16  0  1
  • 17  1  1
  • 18  0  1
  • 19  1  1
  • 20  1  0
  • 21  1  2
  • 22  0  2
  • 23  0  0

In the table the first figure is the hour, the second figure is the number of freight trains going West and the third figure is the number of freight trains going East.

This gives a daily total of eighteen trains going West and twenty-one trains going twenty-one trains going East.

But these figures will increase!

At present, Network Rail are adding a passing loop on the Felixstowe Branch Line. This article on Rail Magazine is entitled £60.4m Felixstowe Branch Upgrade Under Way and says this about the upgrade.

Installing the new line will create capacity for up to ten additional freight trains, each the equivalent of 76 lorries.

Not all will come via Kennett, as some will go via London.

The Port of Felixstowe will get larger and other improvements on the route across Suffolk will increase the number of freight trains passing through Kennett station.

I estimate that it is very likely that in a few years there will be two trains per hour (tph) in both directions for every hour of the day.

Rerouting The Trains Through Newmarket

Currently, these freight trains go via Ely, but the plan of the East West Rail Consortium would be to reroute all these freight trains through the Warren Hill tunnel and Newmarket station.

I suspect the reasons for the change of route could include the following.

Accessing The East West Rail Link From Newmarket Is Easy And Quick

If as expected the East West Rail Link joins the London-Cambridge Line just South of Cambridge South station, then the trains would run through Dullingham, Cambridge and Cambridge South stations, when running between the East West Rail Link and Newmarket station.

The East West Rail Link Will Be An Efficient Railway

Drive on a new motorway and the curves are smooth with relaxed gradients.

A new railway will be like that too and less energy will be used to power trains along its length.

Increasing the Capacity Through Ely Is Difficult

There is a very complicated track layout at Ely and increasing the number of trains might be difficult or very expensive.

Freight Trains Will Use The East West Rail Link To Avoid London

Take going between the Haven Ports and Bristol or South Wales.

Currently, these trains tend to go via London and in a couple of years will have to share tracks with London’s intensive Crossrail network between Acton Main Line and Reading stations.

Using the East West Rail Link, the trains would join the Great Western Main Line at Didcot, a few miles West of Reading.

How many services will use the East West Rail Link to by-pass London?

Freight Trains Will Use The East West Rail Link To Get To The West Coast Main Line

Currently, these trains either go via London or take the slow cross-country route via Peterborough to Nuneaton for the West Coast Main Line.

If they use the East-West Rail Link, they can join the West Coast Main Line at Bletchley.

The East-West Rail Link Will Be An Important Freight Link

I think that as the years pass and more freight terminals are created, we will see more freight trains using the East-West-Rail-Link and many of these trains will go through Newmarket.

What Problems Would The Rerouting Create In Newmarket?

I can see these problems.

Noise And Vibration

Four freight trains per hour will create a lot of noise and vibration as they pass through.

Frightening The Horses

This Google Map shows a corner of the gallops at Newmarket.

Note how the railway from the East splits into two, to the West of the band of trees running down the map.

  • The top branch curves away to the North and goes through Soham to Ely.
  • The bottom branch curves away to the South and goes through Warren Hill Tunnel to Newmarket station and then on to Cambridge.

Alongside, the Southern route is the Al Bahatri all-weather gallop, which is an important facility for training racehorses. It can just be picked out as a sand-coloured line.

Currently, nearly all the freight trains take the Northern route to Ely, keeping them away from the Al Bahatri.

But, if the main freight route was through the town, as planned by the East West Rail Consortium, then at least four freight trains per hour would run alongside the gallop. There could also be four passenger trains per hour.

Railway Electrification

It is unlikely, that the railway through Newmarket will be electrified, but under a different government, this could happen.

It might add another dimension to disturbance through the town, as you get pantograph noise and occasional sparks and flashes. I don’t know how horses will react, but from my own experience years ago, they do react to electrical fields.

The Rail Freight Industry

Look at most freight trains on the UK’s railways and the locomotive on the front, is a noisy, smelly and polluting Class 66 or Class 70 locomotive.

You’ll see these American imports, which don’t meet the latest emission regulations, hauling freight trains, even when there are overhead wires for electric haulage.

Why?

Because rail freight companies are so driven by accountants, that they can’t be bothered to obtain more modern diesel locomotives, that are quieter, more powerful and less polluting.

The picture shows a modern Class 68 locomotive at Stratford. These are quieter and meet most of the noise and emission regulations.

Mitigating The Problems

I’ll deal with various methods, that could be used, starting with the easiest.

A Level Railway Through The Town

It looks like the Victorian engineers, who built the railway through the town, built it as level as possible, so that steam locomotives didn’t have to work so hard in the Warren Hill Tunnel, which I don’t think has a chimney for smoke.

Modern engineers will ensure that the railway is as level as possible, with gentle gradients and curves all the way between Kennett and Dullingham stations.

Passenger Trains With Batteries

Greater Anglia’s new Class 755 trains are powered by both overhead electrification and onboard diesel engines. The latter sit in a power pack in the middle of the train.

Not having seen or heard one of these Swiss-built trains in the metal, I can make no comment as to the noise and vibration of these trains, but they should be quieter than the current three-car Class 170 trains.

It does appear that passenger trains built in the last years are much quieter, as they are much more aerodynamically correct and slippery, so they generate less noise.

The new trains have also been ordered for the South Wales Metro. But the Welsh trains will additionally be fitted with batteries to avoid some difficult electrification in the Valleys.

So if the passenger trains prove to be noisy through the town, which I doubt they will be, there will be the option of adding batteries to avoid the use of diesel power.

It is my belief, that technology will ensure that passenger trains will not be a problem.

More Environmentally-Friendly Freight Locomotives

As I said earlier, smelly, noisy and polluting freight locomotives are a big problem.

This is not just a problem for places like Newmarket with special circumstances, but on railways like the London Overground and those in Central Birmingham, Leeds and Manchester,, where suburban electric railways have to accommodate heavy rail freight.

The railway locomotive manufacturers have designed solutions for the problem in recent years.

Stadler, who are an innovative Swiss company have started to manufacture a Class 93 locomotive, which can run on diesel, electric and/or battery power. I’m fairly sure, that one of the design goals of this locomotive is to be able to haul a heavy freight train between Felixstowe and Peterborough, using electric power where it is available and a mix of diesel and battery at other times.

At Newmarket if the new double-track was well-designed and almost level, I suspect that a Class 93 locomotive could haul a train between Kennett and Dullingham stations on battery power.

Locomotives of this type should be compulsory on all freight routes through sensitive areas.

The government must legislate, as left to themselves the rail freight companies will sit on their hands and wallets.

One of the conditions of a double-track railway through Newmarket, should be that only locomotives that meet the latest noise, vibration and pollution standards, like the Class 93 locomotive should be allowed.

Quieter 100 mph Freight Trains

Karl Watts, who is a disruptive innovator and CEO of the Rail Operations Group, has bought the first ten Class 93 locomotives and intends to use them to haul 100 mph freight trains, where the routes allow.

On the electrified Great Eastern Main Line between Ipswich and London, the operating speed is 100 mph. But freight trains trundle up and down at 75 mph, thus slowing all of the passenger services.

Watts plans to use the Class 93 locomotives with new 100 mph container wagons to run freight trains at 100 mph on this and other routes, which would increase the freight and passenger capacity of the line.

New 100 mph freight wagons will be smoother, quieter and used through Newmarket at an appropriate speed would remove a large proportion of the noise and vibration.

Again, it would need investment from the freight companies.

However, modern freight trains hauled by modern hybrid locomotives like the Class 93 could significantly remove noise and vibration.

Lengthen Warren Hill Tunnel

A second bore will be dug to double-track the kilometre long Warren Hill Tunnel.

Some rail tunnels have been extended with covers and this technique might be possible at the Newmarket station end of the tunnel. The techniques exist, so that housing or other developments can be built on top of the railway.

Techniques like this not only suppress noise and vibration, but create much needed housing.

Acoustic Barriers

You see these a lot in Germany to reduce noise and vibration from railway lines in sensitive area, but rarely in the UK.

Conclusion

It will be difficult to put a double-track railway through Newmarket, but I believe that using modern rolling stock and some advanced construction, that a solution can be found.

Newmarket should dig in its heels and only accept the best to force rail freight companies to get their act together.

Government too, should enforce the current regulations on diesel locomotives, which most of the current locomotives do not meet.

March 4, 2019 Posted by | Sport, Transport | , , , , , , , , , , | 5 Comments

Better East-West Train Services Across Suffolk

The east-west train service across Suffolk is better than it was, but I’ve just read in a Network Rail study entitled Improving Connectivity, about a radical proposal to greatly improve services.

At present at Ipswich station, in addition to the main line services, there are hourly services to Cambridge, Felixstowe and Lowestoft, with a two-hourly service to Peterborough.

From a passenger point of view it is not good at times. In the past I have been irked by.

  • Trying to get between Newmarket and Felixstowe, which often means a not very short wait on Ipswich station.
  • The lack of a late night train back to Newmarket from Ipswich.
  • Bad connectivity between London services and the various branches.

It may be better now and some of the proposals in the latest franchise documents will certainly help.

One document I’ve read, talked about direct services between London and Lowestoft. When I moved to Suffolk in the 1970s, this route was served a couple of times a day.

But one proposal in the Network Rail study must be taken seriously.

The study proposes creating an island platform at an updated Newmarket station and running a direct service between Newmarket and Peterborough via Ely. The study describes the proposal like this.

To solve this dilemma,  The direct Ipswich to Peterborough service is replaced by a Newmarket to Peterborough service, running via a reinstated Warren Hill Junction – Snailwell Junction chord, as shown in Figure 3.2. A semi-fast Ipswich to Cambridge train connects into this service with a cross-platform connection at a reconstructed Newmarket station.

No services are duplicated and connections at Ipswich are simplified: the East Suffolk line arrival need only connect with the Cambridge train. This method of operation combines two markets on one train, achieving a 35 per cent reduction in train miles and halving the number of passenger train paths required on this busy freight corridor. In addition, Newmarket gains a direct service to Peterborough.

So one new short chord and a reconstructed Newmarket station, dramatically improve the passenger train services across Suffolk, whilst giving more much-needed space in the schedules for freight trains.

This map shows the area between Newmarket station and Warren Hill – Snailwell.

Newmarket's Railways, Racecourses and Training Grounds

Newmarket’s Railways, Racecourses and Training Grounds

Note that the line through Newmarket station goes in a tunnel under the training grounds of Warren Hill before turning to the East to connect to Bury St. Edmunds and Ipswich. The new chord would connect between the Newmarket to Bury Line and the Ely to Bury Line.

Hopefully, Network Rail has safeguarded the route and hasn’t sold the land to some, who would oppose the plan.

If I read Network Rail’s proposal correctly, there would be an hourly Newmarket to Peterborough service, which would provide a cross-platform interchange with an hourly semi-fast Ipswich to Cambridge service.

Given that Abellio Greater Anglia were part of the IPEMU tests between Manningtree and Harwich, I suspect that both the Peterborough to Newmarket and Ipswich to Cambridge services would be run with four-car IPEMUs.

In my view it is a very good starting plan, but it does raise a few questions and interesting possibilities.

  • IPEMUs would be faster than the current diesel trains and would also offer an increase in capacity.
  • Would IPEMUs take over the Cambridge to Norwich, Ipswich to Lowestoft and Ipswich to Felixstowe services?
  • Newmarket racecourse is an incredibly popular venue and the current Newmarket station has inadequate capacity for racegoers. More four-car IPEMU trains from Cambridge, Ipswich, Ely and Peterborough calling at the station can only increase total capacity.
  • As now, I suspect a shuttle bus will be provided, between station and racecourse.
  • A simple one-platform Newmarket Racecourse station could even be built on land owned by the Jockey Club on the single-line section of line to the West of the town, which would be about a kilometre walk from both racecourses.
  • Cambridgeshire County Council have had plans for a long time to reopen Soham station. This would be on the hourly Newmarket to Peterborough service, which would men that with one change you could be in Cambridge or Ipswich.
  • If Soham is worth reopening, why not reopen Fordham station.
  • How would the new station at Cambridge North fit in and affect services in the area?

I think that when and if the full proposals arrive, they will have some extra features.

An uprated service from Cambridge to Ipswich will require some reorganisation at Ipswich.

Over the last few years, freight traffic through Ipswich station has eased due to ther opening of the Bacon Factory Chord which allows diesel-hauled freight trains to go directly between the Felixstowe branch and the Midlands and North via Stowmarket.

The Newmarket reorganisation will also release extra paths through Ely and Peterborough and there could be scope for improving the efficiency of Ipswich station.

Given that services will arrive from and leave to Cambridge, Lowestoft and Felixstowe, every hour. Surely, a platform layout could be found, so that they all used the same part of the station and passengers just walked across.

Imagine the benefits to passengers if say you were going between Beccles and Peterborough and you just walked across between trains at Ipswich and Newmarket.

I suspect that Network Rail and Abellio have an excellent idea for Ipswich station, filed under Cunning Plans.

Would it also be worth improving patterns at Ely?

This Google Map is from Railways in Ely in Wikpedia.

Ely Lines

Ely Lines

It is complicated. These are my thoughts.

  • The layout would appear to work quite well now,but will it cope with Cambridge North station?
  • Cambridge North station will probably generate a lot of traffic and with some reorganisation, passengers might even be able to walk across or just wait for the next train at Cambridge or Ely, to be on their way.
  • But in some cases, changing will mean climbing over the bridge at Cambridge or using the subway at Ely.
  • Ely station should cope with any extra services on the lines to Ely and Norwich.
  • There is also the issue of a possible Wisbech branch at March.

So will we see changes to the track layout at Ely?

I think the answer is yes!

But upgrading Ely does throw up one important question.

When the Cambridge Guided Busway was built, I didn’t think it was the best solution, but I had no real idea what would have been best.

I now wonder, if the ideal transport system for the route of the Cambridge Busway has arrived in the form of the tram-train!

If you look at the route from Huntingdon through Cambridge to Addenbrookes, it’s very much linked to the railway lines through the city. Most of the extensions proposed for the busway could be performed by tram-trains in tram mode. One proposal from Huntingdon to Peterborough, is typical of many systems, I’ve seen in Germany.

But it is too late now to change that decision.

One thing though that surprises me, is the amount of undeveloped land there is on either side of the railway line, where the Cambridge North station is being built. It could be possible to create a a tram line to connect Cambridge North station to the Cambridge to Ipswich Line. Thus tram-trains could go from both Cambridge North and Cambridge stations to Newmarket and then on past Fordham and Soham to Ely, where with a short chord they could turn south to the Cambridge stations.

Obviously, a real route would be based on the proposed developments and passenger traffic, but there are a lot of possibilities to use tram-trains to serve the towns and villages around Cambridge from the existing heavy rail lines.

At the Southern end, how about Shelford to Haverhill and onto Sudbury to then take the Gainsborough Line to Marks Tey?

I suspect that a single-track tram with passing places could handle tram-trains on a route not far removed from the route of the old Stour Valley Railway.

A lot of serious thinking can be done!

October 25, 2015 Posted by | Transport | , , , , , | 4 Comments

Newmarket Sausage Gets European Protected Status

This has just been announced and about time too.

I actually prefer the Musks brand as does the Queen.  It’s just a pity, I find it difficult to get their gluten-free ones in London. Hopefully, now they’ve got the protected status, we might see some promotion by the better food retailers.

I see on the Musks website, that they are offering a gluten-free hamper.

October 29, 2012 Posted by | Food | , , , | 2 Comments

The Man Who Could Have Changed History

I’m half watching a play about Hitler.  But I’m finding it a bit difficult to follow, probably because of the hay fever’s effect on my hearing.

It is set in or about 1930 and I am reminded of another tale. It is in Lord Howard de Walden’s obituary in The Guardian.

He inherited 120 acres of London’s west end and bred and owned the 1985 Derby winner, Slip Anchor. But the story he loved to dine out on was when, as a young Cambridge student fresh out of Eton, he was driving a new car in Munich when a man walked out in front of him and was knocked down. “He was only shaken up,” recalled de Walden. “But had I killed him, it would have changed the history of the world.” The man was Adolf Hitler.

I never actually met him, but I knew a few people who worked for him, who never said any word about him that wasn’t complimentary.  My last vision of him was shortly before he died, sitting in state in a wheel-chair at Newmarket races, immaculately turned out ciomplete with apricot coloured socks; his racing colours as suggested by Augustus John.

August 21, 2011 Posted by | Sport, World | , , , , , | Leave a comment

Hyperion Gets a Few Friends

Newmarket has a lot of statues to horses.  One of the most famous is the one of Hyperion by John Skeaping outside the Jockey Club Rooms.

Hyperion by John Skeaping

 When I was driven through the town yesterday, I noticed that he had a few multi-coloured friends scattered around him. Here’s one outside of the Post Office.

A Multi-Coloured Horse Outside Newmarket Post Office

One of my earliest memories is my father changimg a puncture in probably his Y-Type MG saloon, outside this Post Office or the Jockey Club Rooms.  I also remember driving through the town from Felixstowe to Liverpool in the mid-1960s to get to University.

July 28, 2011 Posted by | Sport | , , | 1 Comment

Boadicea Stands Guard

Standing guard opposite the Houses of Parliament is Boadicea, or as she is more normally spelled these days, Boudica.

Boadicea Stands Guard

She may or may not have defeated the Romans, as whatever happened they remained in Britain.

Her spirit lives on, especially in East Anglia.  She probably came from that region, although no-one is sure quite where!  I have heard several people say, including my father, that if the Germans had landed in Suffolk in the Second World War, they would have got similar treatment to that meted out by Boadicea and her ragbag army of upwards of 100,000 men. When questioned as to the legitimacy of this treatment under the Geneva Convention, a common reply was “What would Boadicea have done?” I don’t know the truth of all these reports, but I know Suffolk people well and they wouldn’t have taken an invasion lightly.

Some also say that her tribe, the Iceni, were the supreme horsemen, who when their horses were suffering from horse sickness, looked for a new and healthier place to raise them. They found this valley in the chalk downs and moved there, calling the place New Horse Market. In time this was corrupted to Newmarket.  The town is the world centre of horse racing and breeding, known amongst racing people as Headquarters.  Every thoroughbred can trace their ancestry back to this small town in Suffolk.

July 2, 2011 Posted by | Sport, World | , , , , , , , | Leave a comment

Do Tinned Artichokes Make You Rich?

I’ve just looked up the richest women in the UK.

I was once in Waitrose in Newmarket and one of the top ten was buying lots of tinned artichokes.

Is there a connection?

May 8, 2011 Posted by | Food, News | , , | 3 Comments

The Battered Stick Together

When you’ve been through what I have, you tend to follow others, who’ve triumped over adversity.

Although, C & I bred racehorses for many years, I don’t follow racing much, these days.

But I was pleased to see a report in The Telegraph that Henry Cecil has the favourite for the flat season’s first  classic, the 2,000 Guineas. Henry has been battling cancer for some years and where lesser men would have crawled into a hole and hid or given up altogther, Henry has just kept going.

I shall be putting a couple of pounds on Frankel.

April 30, 2011 Posted by | Sport | , | Leave a comment
