The Shape Of Train Services To Come

Today, I went to Lincoln, which as I reported in LNER To Put Lincoln On The Rail Map, is now a city, that has five trains per day to and from London.

It actually appears that from the timetable change on December 15th, 2019, the LNER timetable will be as follows.

  • On Mondays to Saturdays, there will be six trains per day (tpd) in both directions.
  • On Sundays, there will be five tpd in both directions.
  • Services stop at Stevenage, Peterborough, Grantham and Newark Northgate.
  • All direct services are under two hours, by at least a couple of minutes.
  • Indirect services with a change at Newark are generally no more than ten minutes over two hours, with some under two hours.
  • All direct trains would appear to be five-car Class 800 trains.

I can’t see any cause for passenger complaint.

On The 10:06 To Lincoln

Today is a Friday and I had expected more people on this direct service to Lincoln Central station.

As this was the first direct Friday service at this time to Lincoln, perhaps the word has been slow to get around?

The train arrived on time in Lincoln, although it had been a few minutes late at Grantham.

I asked several people, including a knowledgeable journalist, if Lincoln had ever had a two-hourly service from London and all said the answer was never!

On The 13:23 From Lincoln

This train was very close to maximum capacity with only a few empty seats.

The only problem was a young Lady, although I hasten to add she didn’t behave like a lady, who was sitting on the other side of the carriage.

She was constantly shouting into her phone and using the F-word to boot.

An elderly gentleman politely asked her to calm it down and it made no difference.

I did say to the very large guy, who looked like a prop forward opposite me, that will you ram her phone down her throat or shall I? All it got was a few laughs all round.

Perhaps her mother, didn’t wash her mouth out with soap often enough?

Catering

The train had a buffet and we had a visit from the trolley on the way to Lincoln.

Coming back, there was no trolley, but the train might have been too busy to get it through.

First Class

Five-car Class 800 trains have forty-five First Class and two hundred and seventy Standard Class seats.

Given that some train companies are reducing the number of First Class seats, I wonder if LNER will follow suit on the service to and from Lincoln and perhaps replace them with Second Class seats.

Performance And Train Times

The journey is effectively in two parts.

  • 120 miles between Kings Cross and Newark, which is electrified.
  • 16 miles between Newark and Lincoln, which is not electrified.

A two hour trip between Kings Cross and Lincoln is an average of around sixty-eight mph.

The current two hour schedule is not a convenient time for an operator running a service. Something more under two hours would make timetabling easier.

Suppose, the train took an hour and forty minutes to do the trip and that twenty minutes were to be allowed for turnround and any short delays of a few minutes. This would enable a two-hourly clockface timetable, with a train both ways every two hours.

This would need an overall average speed of 81 mph, including all the stops.

Would this average speed be possible?

In the next few aub-sections, I’ll discuss various factors.

The Class 800 Trains

Consider.

  • The Class 800 trains have fast acceleration and deceleration.
  • Each stop currently takes about two minutes and probably with better systems and staff training could be improved.
  • Most of the time on the electrified East Coast Main Line, the trains are running at speeds in excess of 110 mph and at times up to 125 mph.
  • The trains can run at 140 mph with in-cab digital signalling, as their cousins; the Class 395 trains do on High Speed One.
  • Between Newark and Lincoln, the trains will be slowed by the maximum linespeed.
  • The trains will be running on diesel between Newark and Lincoln.
  • The next generation of AT300 trains are being designed for the Midland Main Line.

These trains will only get better.

In Thoughts On The Next Generation Of Hitachi High Speed Trains, I laid out my thoughts about how they will develop.

One development will be battery-electric trains and these will use battery power between Newark and Lincoln. This will mean that the trains would only need one diesel engine for emergencies like overhead line failure.

The 140 mph East Coast Main Line

Digital in-cab signalling is planed to be installed on the East Coast Main Line between London and Doncaster.

This will allow the following.

  • Closer control of the trains.
  • 140 mph running, where track and traffic allow.
  • More trains per hour (tph)

It was originally planned to be operational by 2020.

It should be noted that High Speed Two is planned to run at eighteen tph. Surely, the slower East Coast Main Line could allow an increase in frequency.

I estimate that this higher speed running could save upwards of ten minutes between Kings Cross and Newark.

Improvements Between Newark And Lincoln

Wikipedia says this about the line between Newark and Lincoln.

The line between Newark and Lincoln is currently only cleared for 50–70-mile-per-hour (80–100 km/h) speeds. Nottinghamshire County Council has paid for a study into 90-mile-per-hour (140 km/h) running.

From my helicopter, the line looks to be all double-track, fairly straight, in good condition, with signs of recent improvements. But there are also up to a dozen level crossings.

With improvements, I suspect that a 90 mph linespeed will be possible.

Summing Up Performance

My mathematical nous, feels that with the digital signalling and other improvements, that the required four hour round trip would be possible.

If this can be achieved, then just two trains would be needed to run a one train every two hours and between Kings Cross and Lincoln.

Other Services

The Wikipedia entry for LNER, says this about the services to Lincoln and other new destinations in the North.

An expanded service to Lincoln began on 21 October 2019 when four terminating services at Newark Northgate were extended into Lincoln. This is in addition to the sole one train per day service, which in all, now provides five out and back workings to and from London King’s Cross. LNER also plans for December 2019 timetable change that a sixth return service to London from Lincoln will be introduced and 5 extra services on a Saturday will begin from 7 December 2019. From December 2019, LNER will introduce a Harrogate to London service 6 times a day. LNER expects to introduce two-hourly services to Bradford and a daily service to Huddersfield in May 2020 when more Azuma trains have been introduced. The Middlesbrough service is expected to begin in December 2021 after infrastructure work required to run the service is completed.

That looks like a comprehensive increase in service to Bradford, Harrogate, Huddersfield and Middlesbrough

Conclusion

LNER seem to have made a good start on the increased service levels to Lincoln.

Harrogate would appear to be next!

It will be interesting to follow both places, to see if they benefit from an improved train service.

But I can certainly see a day in the not too distant future, when LNER’s or other operator’s Azumas and other 140 mph trains are running to multiple destinations via the East Coast Main Line.





October 25, 2019 Posted by | Transport | , , , , , , , | 2 Comments

More Frequent Trains And A New Station For The London Overground

The title of this post, is the same as that of this article on IanVisits.

This is said.

In a statement, the government agreed to requests for £80.8 million from the GLA to support transport upgrades so that 14,000 homes can be built along the East London Line.

Upgrades include

  • New Bermondsey station, which was originally to be called Surrey Canal Road, will be built.
  • A second entrance will be built at Surrey Quays station.
  • Frequency between Dalston Junction and Clapham Junction stations will be increased from four trains per hour (tph) to six tph.
  • Frequency between Highbury & Islington and Crystal Palace stations will be increased from four tph to six tph.

The frequency upgrades will mean twenty tph between Dalston Junction and Surrey Quays stations, or a tyrain every three minutes as opposed to the  current three minutes and forty-five seconds.

A few thoughts follow.

Surrey Quays Station Upgrade

Ian’s article says this about the new entrance at Surrey Quays station.

The very cramped Surrey Quays station gets a second entrance, which will run under the main road and be based on the north side, where the shopping centre car park is today. That avoids crossing two busy roads, which can take some time if you’re waiting for the lights to change.

This Google Map shows the station and the car park of the Shopping Centre.

These are my pictures, taken at and around the station.

Traffic is bad and the subway suggested by Ian’s wording will be very welcome.

Collateral Benefits At New Cross Gate

New Cross Gate station will be one of several stations along the East London Line to see benefits in service frequency and quality.

The train frequency on East London Line services will rise from eight tph to ten tph.

But this is not all that should or could happen.

  • The service between Highbury & Islington and West Croydon stations could rise from four tph to six tph.
  • This would mean that New Cross Gate would have a twelve tph service to and from Whitechapel, which in a year or so, will have Crossrail connections to Canary Wharf, Bond Street, Paddington and Heathrow.
  • Southeastern should be getting new higher-capacity, higher-performance and possibly longer trains to replace their elderly trains into London Bridge.
  • Charing Cross station is redeveloped into a higher-capacity, cross-river station, to allow more trains.
  • Digital signalling, as used on Thameslink will be extended to cover all trains through New Cross and New Cross Gate.
  • The Docklands Light Railway to Lewisham will get new and higher-capacity trains.
  • Southeastern Metro services could go to the London Overground.

Could this all mean that the East London Line, Southeastern and Crossrail will more than hold the fort until it is decided to build the Bakerloo Line Extension?

The Bakerloo Line Extension

This map shows the route of the Bakerloo Line Extension.

If and when the Bakerloo Line Extension is built, New Cross Gate will surely become a major transport hub.

If you look at the current and proposed stations on the Southern section of an extended Bakerloo Line, you can say the following.

  • Paddington will get a step-free pedestrian link between Crossrail and the Bakerloo Line.
  • Charing Cross will benefit from more Southeastern Metro services into the main line station.
  • Waterloo will benefit from more Southeastern Metro services through the attached Waterloo East station.
  • Elephant & Castle station will benefit from more Thameslink services through the attached main line station.
  • New Cross Gate will benefit from more Southeastern Metro and East London Line services through the station.
  • Lewisham will benefit from more Southeastern Metro services through the station.



But there are no interim benefits for the blue-mauve area, that will be served by the proposed Old Kent Road 1 and Old Kent Road 2 stations.

In addition, is there a need to add capacity between  the New Cross area and Lewishan? Spiutheastern improvements will help, but the Bakerloo Line Extension will do a lot more!

Except for these two stations, is there a reason to build an extension to the Bakerloo Line, as train services between Charing Cross, Waterloo East and New Cross Gate and Lewisham will be significantly increased in frequency, reach and quality?

A Bakerloo Line Extension Redesign

Whatever happens to the Bakerloo Line, the following should be done.

  • New walk-through trains running at a higher-frequency on the current route.
  • Major access improvements and better connection to main line services at Elrphant & Castle, Wterloo East, Charing Cross and Willesden Junction stations.
  • A radical reorganisation North of Queen’s Park station, in conjunction with the Watford DC Line and the proposed West London Orbital Railway.

This would improve the current line, but it would do nothing for those living where the extension will go!

So why not do what is happening to the Northern Line at Battersea and create a short extension to the Bakerloo Line that serves the areas that need it and one that can be extended in the future?

  • You could argue, that the extension to Lewisham is short and it could be extended to Hayes and other places.
  • I also think, that the route goes via New Cross Gate, as that is one of the few sites in the area, from where a large tunnel could be built.

Ideally, what could be needed is a high-capacity public transport link from Elephant & Castle and Greenwich and/or Lewisham via the Old Kent Road, New Cross Gate and New Cross.

The Germans, the Dutch and others wouldn’t mess about and would run trams along the road, but that would go down with the locals like a lead West London Tram.

So it looks like some form of extension of the Bakerloo Line is the only way to go.

Consider.

  • Two-platform terminal stations at Brixton and Walthamstow Central handle up to thirty-six tph on the Victoria Line.
  • New Cross Gate and New Cross stations are about five hundred metres apart.
  • Double-ended stations like Knightsbridge on the Piccadilly Line and Kings Cross on the Victoria Line work very well.

I would look at building a doublr-ended Bakerloo Line station deep underneath New Cross Road.

  • It would be connected by escalators and lifts to the existing stations at New Cross Gate in the West and New Cross in the East.
  • Provision would be made to extend the line further to either Greenwich or Lewisham.
  • New Cross and Lewisham already have a high-frequency connection around four tph.
  • The whole extension could be built from the single tunnelling location on the Sainsbury’s site at New Cross Gate.
  • There would be no necessity for any works at Lewisham station.

It would probably need more services to be run between New Cross and Lewisham.

Extending The East London Line Service South From New Cross

New Cross is served by the only short service on the London Overground; the four tph between Dalston Junction and New Cross stations.

So could this Rast London Line service be extended South to serve Lewisham to increase services between New Cross and Lewisham?

This map from carto.metro.free.fr shows the lines at New Cross station.

Note how the double-track East London Line, shown in orange, arrives from Surrey Quays station arrives in the North-Western corner of the map, becomes a single-track and then goes under the main lines before going into the bay platform D.

This Google Map shows the same area.

The London Overground track is clearly visible.

Could extra track be added, to enable the following?

  • Southbound trains could join the main line and stop in Platform C
  • Northbound trains could leave the main line after stopping in Platform A and go towards Surrey Quays station.

If this is possible, then  it would give a four tph service between Dalston Junction and Lewisham, with an important stop at Whitechapel to connect to Crossrail.

Lewisham doesn’t have the space for a terminal, but there would appear two possible terminals South of Lewisham.

  • Hayes – Journey time to and from Dalston Junction would take around 53 minutes.
  • Orpington – Journey time to and from Dalston Junction would take around 50 minutes.

Both stations would make ideal terminals.

  • They have bay platforms for terminating the trains.
  • Round trips would be a convenient two hours.
  • Eight trains would be needed for the service.
  • New Cross will have the same four tph to and from Dalston Junction as it does now!
  • Lewisham and Dalston Junction would have a four tph service that would take 27 minutes.

The service could even be split with two tph to each terminal.

Will the Extended Services Need To Replace Other Services?

Currently Hayes has these current Off Peak services.

  • Two tph to Cannon Street via London Bridge
  • Two tph to Charing Cross via London Bridge

I would expect that if digital signalling is applied through the area, that the extra services could be added to Hayes and Orpington as decided.

An Improved Hayes Line

Transport for London and various commentators always assume that the Bakerloo Line will eventually take over the Hayes Line.

This will or could mean the following.

  • Passengers used to a full-size train looking out on the countryside and back gardens through big windows, will have to get used to a more restricted view.
  • Platforms on the Hayes Line will need to be rebuilt, so that two different size of train will be step-free between train and platform.
  • The service could be slower.
  • The ability to walk through an increasingly pedestrianised Central London to and from Cannon Street, Charing Cross and London Bridge will be lost.
  • Loss of First Class seats. which will happen anyway!

I think that passengers will want to stick with the current service.

The only reason to allow the Bakerloo Line Extension to take over the Hayes Line, is that it would allow another four tph to run between Lewisham and London Bridge. But digital signalling could give the same benefit!

But what if the Overground muscled in?

The Hayes Line could take up to four tph between Dalston Junction and Hayes, via Lewisham and New Cross, which would give these benefits.

  • Increased capacity on the Hayes Line.
  • An excellent connection to Crossrail, which would give a better connection to the West End, Liverpool Street and Heathrow.
  • Better connection to the Eastern side of the City of London and Canary Wharf.

There would be no mahor changes to the infrastructure, except for the installation of digital signalling, which will happen anyway.

Times To And From Crossrail

Times to and from Whitechapel, with its Crossrail connection are.

  • Lewisham – 17 minutes
  • Hayes – 44 minutes
  • Orpington – 41 minutes

The current service between Orpington and Farrington, which also will connect to Crossrail, takes 52 minutes.

Penge Interchange

Although, this has not been funded, I think that this new interchange could be very much in Transport for London’s plans.

I discuss the possible Penge Interchnge station in Penge Interchange.

It’s certainly something to watch out for, as it could improve connectivity by a large amount.

The View From The Dalston Omnibus

For decades, Dalston had a terrible reputation and then came the Overground, which changed everything.

There are now these combined devices from the two Dalston stations.

  • Eoght tph to Stratford
  • Four tph to Richmond via Willesden Junction
  • Four tph to Clapham Junction via Willesden Junction
  • Four tph to Clapham Junction via Surrey Quays
  • Four tph to Creystal Palace via Surrey Quays
  • Four tph to New Cross via Surrey Quays
  • Four tph to West Croydon via Surrey Quays

There is also a useful eight tph connecting service between Dalston Junction and Highbury & Islington.

In the next couple of years, these developments should happen.

  • Services on the East London Line will be increased with an extra two tph to Clapham Junction and Crystal Palace.
  • Services on the North London Line will be increased to cope with overcrowding. As the Dalston Junction and Highbury & Islington connecting service will be going to ten tph, it would seem logical that the North London Line service should match this frequency.
  • Crossrail will open and Dalston will have a twenty tph connection to its services at Whitechapel.

Dalston needs better connections to either main line terminal stations or their interchanges a  few miles out.

Currently, Dalston has very useful connections to the following main interchanges.

  • Stratford for the Great Eastern Main Line.
  • Clapham Junction for the South Western Railway and Southern services.
  • Richmond for Windsor and Reading services.
  • Whjitechapel will provide a link to Crossrail.
  • In addition the planned update at Norwood Junction will give better connection to services to Gatwick, Brighton and other services to the South of Croydon.

Better interchanges are needed with services to the North and the South East of London.

Extending the Dalston Junction and New Cross service to Hayes or Orpington via Lewisham could greater improve the train service from Dalston, by providing interchange to services fanning out into and beyond South East London.

Conclusion

I am drawn to these two conclusions.

  • The Bakerloo Line should be extended via two new Old Kent Road stations to a double-ended terminal station in New Cross with interchange to both New Cross Gate and New Cross stations.
  • The New Cross branch of the London Overground should be extended through Lewisham to Orpington and/or Hayes.

Coupled with planned increases in frequency, reach and quality of existing services, this would surely help serve the housing development planned for South East London.

September 12, 2019 Posted by | Transport | , , , , , , , , , | Leave a comment

Alstom Digital Train Control System Enters Service On Wuppertal Suspension Railway

The title of thiis post is the same as that of this article on Railways Africa.

It describes how Alstom have fitted digital signalling with ETCS to Wuppertal’s Schwebebahn.



Surely, if you can fit digital signalling to the city’s weird and wonderful railway, it can be applied to any other railway.



September 7, 2019 Posted by | Transport | , , , | Leave a comment

Is There Going To Be Full Electrification Between Leeds And Huddersfield?

This article on Rail Technology Magazine is dated 23/08/19 and is entitled Network Rail Reveals Detailed £2.9bn Upgrade Plans For TransPennine Route and it prompted me to write this post of the same name.

The Rail Technology Magazine article talks about a comprehensive upgrade to the Huddersfield Line is planned that includes.

  • Improvement between Huddersfield and Westtown
  • Grade separation or a tunnel at Ravensthorpe
  • Rebuilding and electrification of eight miles of track.
  • Possible doubling the number of tracks from two to four.
  • Improved stations at Huddersfield, Deighton, Mirfield and Ravensthorpe.

I have now found this document on the Network Rail web site, which is entitled Huddersfield to Westtown (Dewsbury).

This statement is included under proposals.

Electrification of the railway from Huddersfield to Ravensthorpe – and right through to Leeds.

Because there is a dash in the words, has electrification to Leeds, been a recent addition?

It certainly doesn’t fit with the Rail Technology Magazine article.

It also doesn’t fit with this article on the BBC, which is dated 20/08/19 and is entitled Detailed TransPennine £2.9bn Rail Upgrade Plans Unveiled.

Electrification is mentioned in the second paragraph.

Network Rail has also announced it intends to electrify the line between Huddersfield and Dewsbury and double the number of tracks from two to four.

And in the sixth paragraph.

Network Rail said the proposed major overhaul and electrification work would be carried out on an 8-mile (13km) section of the route, with the “first round” of consultations starting with those living closest to the railway.

The two news sites seem to have used the same source.

The BBC also uses this map, that I have copied from the Network Rail document

Note the railway lines shown in red. Are these the ones to be electrified? As they go from Huddersfield to Westtown, I think the answer is probably in the affirmative.

I seems to me, that Rail Technology Magazine and the BBC are using a common source and could it be an earlier version of the Network Rail document.

But the map, I have shown, shows the electrification only going as far as Westtown, despite coming from a document, that states twice that the electrification is going as far as Leeds.

It is certainly sloppy documentation.

Track Layouts

This document on the Digital Railway web site is dated 16/08/18 and is entitled Transpennine Route Upgrade SDO1 ETCS – Analysis.

Significantly, it is written by the Digital Railway – Joint Development Group (JDG), which consists of representatives of Siemens, Hitachi, ARUP and Network Rail.

It is mainly about using digital signalling called ETCS on the Transpennine Route, but it does give these track layouts between Huddersfield and Dewsbury.

This is the current layout.

There is also this full four-track layout, which I assume was the original plan.

It is more complicated and involved the building of bridges in the area of Ravensthorpe station.

There is also a reduced four-track layout, which I assume was developed as the track analysis progressed.

It is not a massive upgrade from the current layout.

As I see it, if the reduced layout can handle the required number of services, it has major advantages over the full scheme.

  • There are no changes to track  layout between Ravensthorpe and Dewsbury stations.
  • Rebuilding Ravensthorpe station should be a smaller project.
  • The current and reduced layout have three tracks between Mirfield and Ravensthorpe stations.
  • There are no expensive new bridges to be built.

To make the scheme work there is a small amount of bi-directional running on the centre track, which is made possible by using digital signalling on the route.

Track Usage

By using bi-directional running on the centre track between Ravensthorpe and Mirfield stations, which is controlled by ETCS, the track layout is simplified, with three tracks instead of four.

  • Slow trains from Huddersfield to Dewsbury will dive under the Brighouse lines and call in/pass Platform 1 at Mirfield station before going straight on to Ravensthorpe and Dewsbury. This is as trains do now.
  • Slow trains from Dewsbury to Huddersfield will use the centre track from East to West and call in/pass Platform 2 at Mirfield station before turning South-West  on to Huddersfield. This is as trains do now.
  • Fast trains from Huddersfield to Dewsbury will call in/pass Platform 3 at Mirfield station and then cross over to the top track and go straight on to Ravensthorpe and Dewsbury.
  • Fast trains from Dewsbury to Huddersfield will use the centre track from East to West and call in/pass Platform 4 at Mirfield station before turning South-West  on to Huddersfield.
  • Trains from Brighouse  to Wakefield will call in/pass Platform 1 at Mirfield station and then cross to the centre track and go straight on to Wakefield. This is as trains do now.
  • Trains from Wakefield to Brighouse will use the centre track from East to West and call in/pass Platform 2 at Mirfield station and go straight on to Brighouse.

Note.

  1. Platforms at Mirfield station are numbered 1 to 4 from the North
  2. The slow lines between Mirfield and Huddersfield are shown in black.
  3. The fast lines between Mirfield and Huddersfield are shown in blue.
  4. Passengers can use Platforms 1/2 as a cross-platform interchange between slow Huddersfield-Leeds and Brighouse-Wakefield services.

I also think it likely, that the proposed layout will improve the timetable.

Does The Reduced Layout Produce A Cost Saving?

In one of the first jobs I did at ICI Plastics Division, I simulated a chemical process on an analogue computer. My mathematics showed they could use much smaller vessels, which meant the height of the plant could be reduced by a few  metres. I remember the engineer in charge of the project being very pleased, when he told me, that height costs money.

  • The reduced layout removes three bridges, which must mean a cost saving.
  • There is probably less track to lay

The negative is that digital signalling with ETCS must be installed through the area. This is going to be installed on the UK network, so it probably needs little more than shuffling the installation order.

On balance, when all things are considered, I suspect if the reduced layout can be used, there will be substantial cost savings on the project.

Problems At Morley Station

Morley station is two stations after Dewsbury station on the route towards Leeds.

Unusually for Wikipedia, the entry for Morley station has a large section entitled Current Problems.

This is the first two paragraphs.

The increase in demand, combined with growth elsewhere on the line, means that overcrowding in the morning peak, particularly for commuters heading towards Leeds, is becoming more of an issue.

Despite this commuter growth little has been done to bring this station into the 21st century. For example, only one platform is accessible for disabled passengers, there is insufficient parking, access routes to and from the station are often overgrown with weeds, and there are frequent drainage problems which all combine to make the station not as pleasant as other stations in West Yorkshire. In 2012 a “Friends of Morley station” group was formed, and is addressing some of these issues. Work to improve the car park and drainage commenced in February 2013.

To make matters worse, the station is 10-15 minutes walk from the centre of Morley with poor bus and taxi connections.

Would the following help the Friends of Morley Station?

  • Longer trains.
  • More frequent trains.
  • Faster trains to Leeds
  • Better bus services.

Electric trains would help solve the first three.

White Rose Station

There are plans to build a new White Rose station in the next couple of years at the White Rose Centre..

This would be between Morley and Cottingley stations.

This station will surely increase the passenger numbers on the Huddersfield Line.

Have Network Rail Designed The Electrification Between Dewsbury And Leeds?

This electrification has been off and on more times, than the lights in an average kitchen, so I suspect there is a workable plan dating from the last century amongst many others.

Would Extending Electrification To Leeds Provide The Power?

Electrification needs a good connection to the National Grid to provide the power needed to run the trains.

The short eight-mile electrification, as originally proposed could probably have been fed from one end; Huddersfield or Dewsbury.

Both locations would need new sub-stations, with Huddersfield possibly needed in the future to power the wires all the way to Manchester.

Leeds is already fully-electrified with electric expresses to Doncaster and London and several electric local services.

So is the easiest and most affordable way to power the eight-mile electrification between Huddersfield and Westtown to run an extension cable between Leeds and Dewsbury?

Network Rail had a similar problem on the Midland Main Line, which I wrote about in Welcome For Extension Of Midland Electrification.

National Grid had provided a power connection near Market Harborough for the Midland Main Line electrification, which was then cancelled North of Kettering North Junction, leaving the electrification to Corby without a power supply.

The problem is being solved, by extending the electrification to Market Harborough and connecting the wires to the power there.

I do wonder, that the most affordable way to power the Huddersfield and Westtown electrified line is to electrify all the way to Leeds and connect to the power there.

Conclusion

Improving services on the Huddersfield Line between Huddersfield and Leeds is going to be very necessary in the next few years, as passenger numbers will surely grow, due to new housing, increased commuting and the opening of White Rose station.

  • New or refurbished four-car electric trains would provide more capacity, increased frequencies and faster services,
  • Digital signalling with ETCS would allow more trains to run smoothly.

It appears to me, that to electrify all of the Huddersfield Line between Huddersfield and Leeds would be a good idea, if the money can be found.

Has that money been found by developing a more affordable track layout for the proposed TransPennine Upgrade between Huddersfield and Westtown?

But also using the power at Leeds and electrifying all the way between Huddersfield and Leeds, seems to be a bloody great tail, that is wagging the dog of electrification.

Further Electrification

Providing a fully-electrified route between Huddersfield and Leeds, would leave just two sections of the main TransPennine route without electrification.

I don’t know about the planning and difficulty of the first route, but from my helicopter the engineering shouldn’t be too difficult, with the exception of the elecxtrification of the Standedge Tunnels, although Wikipedia seems optimistic about the electrifying the main twin-bore tunnel.

During the 2000s, Network Rail proposed reinstating rail traffic through the 1848 and 1871 tunnels to increase capacity on the Leeds-Manchester trans-Pennine route, but after a re-appraisal after the decision to electrify the trans-Pennine line, it was reported in 2012 that reinstatement was unnecessary.

In addition, could it be, that Manchester with lots of electric trains can provide enough power at Stalybridge, where an updated power connection has been recently installed, to power electric trains between Manchester and Huddersfield?

, The second has been planned for years and has a string of advantages.

  • Speed up services between Leeds and Newcastle and Scotland.
  • Allow LNER to run electric trains between London and Scotland via Leeds.
  • Create an electrified route between Neville Hill Depot and York.
  • Create an electrified diversion through Leeds for the East Coast Main Line

This section should be electrified for operational reasons on the East Coast Main Line.

A Final Conclusion

Network Rail’s plans seem to have evolved under analysis to be as follows.

  • Limited four-tracking and updated track between Huddersfield and Westtown.
  • Digital signalling with ETCS between Huddersfield and Leeds.
  • Full electrification between Huddersfield and Leeds
  • Power for the electrification from Leeds.

Could it even cost less than the allocated £2.9billion?







August 31, 2019 Posted by | Transport | , , , , , , | 2 Comments

Will HS2 And Northern Powerhouse Rail Go For The Big Bore?

It looks to me that there will be increasing links and merging between High Speed Two (HS2) and Northern Powerhouse Rail (NPR).

This report on the Transport for the North web site, is entitled At A Glance – Northern Powerhouse Rail.

Proposals and possibilities include.

  • NPR will have a Western terminal at a new station in Liverpool City Centre.
  • HS2 trains would access Liverpool and Manchester via a junction between HS2 and NPR at High Legh.
  • There will be six trains per hour (tph) between Liverpool and Manchester via Manchester Airport.
  • The route between Manchester and Manchester Airport is planned to be in tunnel.
  • There will be six tph between Manchester and Leeds.

In addition, Boris has made positive noises about a high speed line between Manchester and Leeds being of a high priority.

So will the planners go for the logical solution of a High Speed tunnel between Manchester Airport and Leeds?

  • There could be a theoretical capacity of perhaps 15 tph, which is the design capacity of High Speed Two.
  • Speeds of up to 140 mph should be possible.
  • Stations could be at Manchester Airport, Manchester Piccadilly/Piccadilly Gardens, Huddersfield, Bradford and Leeds.
  • West of Manchester Airport, the route appears easier and the tunnel would emerge close to the airport.
  • East of Leeds the tunnel would join up with existing routes to Doncaster, Hull, Newcastle and York.

I believe such a tunnel could be built without disrupting existing rail services and passengers. Remember building Crossrail’s tunnels was an almost invisible process.

It would result in two rail systems across Northern England.

  • Upgraded Classic Rail Routes
  • The Big Bore

My thoughts on the two systems follow.

Upgraded Classic Rail Routes

This could include improvements such as these,

  • Extra passing loops.
  • Selective electrification
  • Improved stations
  • Comprehensive in-cab digital signalling
  • More paths for passenger and freight trains.

Which could be applied to routes, such as these.

In addition, there could be the reopening of some closed or freight routes to passenger trains.

This article on Rail Technology Magazine is entitled Network Rail Reveals Detailed £2.9bn Upgrade Plans For TransPennine Route.

It is a comprehensive upgrade that includes.

  • Improvement between Huddersfield and Westtown
  • Grade separation or a tunnel at Ravensthorpe
  • Rebuilding and electrification of eight miles of track.
  • Possible doubling the number of tracks from two to four.
  • Improved stations at Huddersfield, Deighton, Mirfield and Ravensthorpe.

This project would be a major improvement to the Huddersfield Line.

In Sheffield Region Transport Plan 2019 – Hope Valley Line Improvements, I talked about planned improvements to the Hope Valley Line, which should begin in the next couple of years.

These improvements are given in detail under Plans in the Wikipedia entry for the Hope Valley Line.

The Hope Valley Improvements will cost in the region of tens of millions of pounds and Wikipedeia sums up the benefits like this.

These changes to allow three fast trains, a stopping train and freight trains each hour were also supported in a Transport for the North investment report in 2019, together with “further interventions” for the Northern Powerhouse Rail programme.

It seems like good value to me!

So could we see other Multi-million and billion pound projects created to improve the classic routes across the Pennines?

Projects would be fully planned and the costs and benefits would then be assessed and calculated.

Then it would be up to the Project Managers to devise the optimal structure and order in which to carry out all the projects.

I wouldn’t be surprised to see the following techniques used.

  • Discontinuous electrification to avoid bridge reconstruction.
  • Intelligent, hybrid diesel/electric/battery trains from Bombardier, Hitachi or Stadler, capable of 125 mph running and changing mode at speed.
  • Modular digital signalling
  • Factory built stations and step-free bridges.
  • Removal of all level crossings.
  • All stations updated for step-free access between train and platform.

The objectives would be as follows.

  • More paths, where needed.
  • Faster line speed.
  • Less running on diesel.
  • Fast station stops.

Hopefully, the upgrading could be done without too much disruption.

Remember though, that disruption to existing users during a project, is most likely down to bad project management.

The Big Bore

The Central Core tunnel of Crossrail between Royal Oak and East London, was virtually a separate project before Crossrail’s stations and much of other infrastructure was built.

I believe that digging the tunnel first gave a big advantage, in that it could be constructed as an independent project, provided that the logistics of delivering the components and removing the junk was done efficiently.

But it did mean that travellers wouldn’t see any benefits until the project was almost complete.

HS2 and NPR are different in that they also envisage upgrading these routes.

  • The Huddersfield Line
  • The Chat Moss Line
  • The Calder Valley Line
  • The Hope Valley Line
  • The Dearne Valley Line
  • The Selby Line
  • The Midland Main Line North Of Clay Cross

Only the Huddersfield Line is directly affected by the Big Bore.

Effectively, the Big Bore will provide a by-pass route for passenger trains between Leeds and West of Manchester Airport, to take the fast trains of HS2 and NPR underneath the congested classic lines.

In Changes Signalled For HS2 Route In North I said this about a tunnel between Leeds and Manchester.

To get a twenty-five minute time between Leeds and Manchester with a ten minute frequency, which I believe is the minimum service the two cities deserve, would be like passing a whole herd of camels through the eye of a single needle.

The Swiss, who lets face it have higher hills, than we have in Northern England would create a new route mainly in tunnel between the two cities, with perhaps an underground station beneath the current Grade I Listed; Huddersfield station.

The transport for the North report suggests Bradford Low Moor station, as an intermediate station, so why not Bradford Low Moor and Huddersfield stations?

Note that the Gotthard Base Tunnel, which opened a couple of years ago, deep under the Alps, is about the same length as a Leeds and Manchester tunnel, and cost around eight billion pounds.

It would be expensive, but like Crossrail in London, the tunnel would have big advantages.

  • It could be built without disrupting current rail and road networks.
  • It would have a capacity of up to thirty tph in both directions.
  • Unlike Crossrail, it could handle freight trains.
  • It would unlock and join the railway systems to the East and West.

I believe, it would be a massive leap forward for transport in the North of England.

It would be a very big project and probably one of the longest rail tunnels in the world.

Comparison With The Gotthard Base Tunnel

But surely, if a small and rich nation like Switzerland can build the Gotthard Base Tunnel, then we have the resources to build the Big Bore between Manchester Airport and Leeds.

Consider these facts about the Gotthard Base Tunnel.

  • It is two single track bores.
  • Each bore has a track length of around 57 kilometres or 35 miles.
  • The tunnel may be deep, but it is direct and level.
  • The maximum speed is 250 kph or 160 mph.
  • The operational speed for passenger trains is 200 kph or 125 mph.
  • The operational speed for freight is 100 kph or 62 mph.
  • It can take the largest freight trains.

To make numbers even more impressive it is joined to the shorter Ceneri Base Tunnel, to provide an even longer route.

Manchester Airport And Leeds Direct

Now consider Manchester Airport and Leeds.

  • The current rail distance is 56 miles.
  • There are stops at Manchester Piccadilly, Manchester Oxford Road, Manchester Victoria and Huddersfield stations.
  • Journey time is eighty minutes.

But the direct distance is only 68 kilometres or forty-three miles.

Surely if the Swiss can blast and dig two 57 km. single-track rail tunnels, we can go eleven kilometres further with all the recent experience of tunnelling around the world.

The lengths of the various legs would be as follows.

  • Manchester Airport and Manchester – 14 km.
  • Manchester and Huddersfield – 35 km.
  • Huddersfield and Bradford – 17 km.
  • Bradford and Leeds – 13 km

Trains running on the various legs at 200 kph, which is the cruising speed of a 1970s-built InterCity 125, could take the following times for the various legs.

  • Manchester Airport and Manchester – 4.2 minutes
  • Manchester and Huddersfield – 10.5 minutes
  • Huddersfield and Bradford – 5.1 minutes
  • Bradford and Leeds – 13 km – 3.9 minutes

Leeds and Manchester Airport would be under thirty minutes apart.

Looking at NPR between Liverpool and Hull, times could be as follows.

  • Liverpool and Manchester – 26 minutes
  • Manchester and Leeds – 20 minutes
  • Leeds and Hull – 38 minutes

Or a Coast-to-Coast time of under ninety minutes.

Train Frequencies

HS2 is being designed to handle fifteen tph, although slower intensive railways in the UK can handle up to twenty-four tph.

At the current time or certainly in a few years time, the theoretical maximum frequency through the Big Bore should be between these two figures. I will assume at least fifteen tph in this post.

The At A Glance – Northern Powerhouse Rail report talks about the following frequencies.

  • Liverpool and Manchester via Manchester Airport – Six tph.
  • Manchester and Leeds – Six tph
  • Leeds and Hull – Two tph

This is all so lacking in ambition. It is like building a new high capacity road and only allowing those with status to use the road.

If Leeds and Manchester Airport can handle fifteen tph, why not use some of it to create an Express Metro under the Pennines?

To me, if the Big Bore is built, nothing short of twelve tph or a train every five minutes is acceptable, at Liverpool, Manchester Airport, Manchester, Huddersfield, Bradford and Leeds stations.

The extension to Hull could be reduced to perhaps six tph, but with the upgrading of the Hull and Leeds Line to perhaps 140 mph, I’d be bold and create a true TransPennine Express;

Hull and Liverpool every five minutes would be the ultimate Marketing Man’s dream.

The Underground Stations

Manchester Airport, Manchester, Huddersfield, Bradford and Leeds would all be through stations deep underground.

  • They would be connected to the surface by lifts and escalators.
  • Some entrances to the stations would connect to existing stations and others might emerge in City squares like Manchester’s P:iccadilly Gardens.
  • Most stations would be just two platforms, as all trains would pass through on either side of a large underground concourse.;
  • All stations would have platform edge doors.
  • Passengers would be able to reverse direction by just walking across the concourse.

Stations would build on the lessons learned from Crossrail. But then NPR is closer to Crossrail than a Classic High Speed Line.

The Terminal Stations

The two main terminal stations for NPR and trains running through the Big Bore would be the proposed High Speed station at Liverpool and the existing Hull station.

But one other terminal station is being created; Edinburgh.

I have been going to Edinburgh station to and from England for perhaps thirty years and the capacity of the station has constantly increased.

Recent developments are extended Platforms 5 and 6, that can take the longest LNER trains.

I wouldn’t be surprised to find out that with the application of digital signalling, that there is capacity for at least eight tph between Edinburgh and Newcastle.

There would certainly be capacity for at least two tph between Liverpool and Edinburgh via Manchester Airport, Manchester, Huddersfield, Bradford, Leeds, York and Newcastle.

In the East the other possibilities for terminals are Doncaster, Newcastle and York.

  • I would discount Newcastle, as it lacks capacity and its location would make it difficult to add more.
  • Doncaster has good connectivity and space, but do Leeds and Hull offer similar connectivity?

So that leaves Hull, Edinburgh and York, as the only Eastern terminals.

In the West, there is probably a need to connect to the Northern section of the West Coast Main Line (WCML).

Glasgow Central is probably the obvious terminal, but it would need an extra connection at the junction of HS2, NPR and WCML at High Legh.

If necessary Preston could be used, as it has space and lots of connectivity.

Integration Of HS2 and NPR

The At A Glance – Northern Powerhouse Rail report is proposing this and it looks that the following HS2 services could be possible between Euston and Manchester.

  • Two tph – Euston and Hull via Old Oak Common, Manchester Airport, Manchester, Huddersfield, Bradford and Leeds
  • Two tph – Euston and Edinburgh via Old Oak Common, Manchester Airport, Manchester, Huddersfield, Bradford, Leeds, York and Newcastle.

Note.

  1. Manchester Airport, Manchester, Huddersfield, Bradford and Leeds would all have four tph to and from London, by the Western arm of HS2’s Y.
  2. If in addition there were two tph between Liverpool and Hull and Liverpool and Edinburgh, this would mean four tph from the Big Bore of NPR to both Hull and Edinburgh.
  3. None of these core services need to terminate in the Big Bore.

I very much feel that integrating HS2 and NPR is the way to go.

Could We See A High Speed Northern Metro?

If we assume that the Big Bore could handle the HS2 frequency of at least fifteen tph, then it would be possible to create a service across the Pennines with the following frequencies.

  • Liverpool and Hull – 4 tph
  • Liverpool and Edinburgh – 2 tph
  • Glasgow and Hull – 2 tph
  • London Euston and Hull – 2 tph
  • London Euston and Edinburgh – 2 tph

This would result in the following frequencies

  • Liverpool – 6 tph
  • Glasgow – 2 tph
  • London Euston – 4 tph
  • Manchester Airport – 12 tph
  • Manchester – 12 tph
  • Huddersfield – 12 tph
  • Bradford – 12 tph
  • Leeds – 12 tph
  • Hull – 8 tph
  • York – 4 tph
  • Newcastle – 4 tph
  • Edinburgh – 4 tph

What would these frequencies do for train travel in the North of England?

Freight

The Gotthard Base Tunnel has been designed so that both freight and passenger trains can use the route.

There is a need for extra freight capacity across the country and I wonder if freight trains could use the Big Bore.

I estimate that the Big Bore would be 68 kilometres if bored straight and level between West of Manchester Airport and Leeds.

Lets assume it is seventy kilometres or 43.5 miles.

So times, through the tunnel at various average speeds would be.

  • 125 mph – 21 minutes
  • 110 mph – 23.7 minutes
  • 100 mph – 26.1 minutes
  • 90 mph – 29 minutes
  • 80 mph – 32.6 minutes
  • 62 mph (Gotthard Base Tunnel speed for freight) – 42 minutes.

Could it be mandated that freight trains can use the tunnel, if they could maintain a particular speed?

Consider.

  • A 125 mph train with stops at Manchester Airport, Manchester, Huddersfield, Bradford and Leeds would probably take thirty minutes to transit the tunnel.
  • A freight train running at 90 mph would take more or less the same time.
  • Fifteen tph would mean a train every four minutes.
  • Automatic control of all trains in the tunnel would be a possibility. It appears to work on the much more complicated Thameslink.

I think with the following conditions, one or even two freight trains per hour, in addition to the passenger trains, can pass through the Big Bore in each direction.

  • The locomotives have the performance of at least the Class 93 locomotive, which is currently being built.
  • Freight trains can be hauled through at a minimum speed, which could be between 90 and 110 mph.
  • The passenger trains and train and platform staff work together to produce very short station dwell times.
  • All passenger trains are identical.
  • Station platforms are designed so that passengers can leave and enter the trains rapidly.

It will be a Big Bore with a capacity to match!

What About Sheffield?

I haven’t forgotten Sheffield, but I think it could be linked across the Penines by another route.

Under the upgrades for Northen Powerhouse Rail, it is proposed that services between Sheffield and Leeds become 4 ton in 25 minutes along the Dearne Valley Line.

Does Boris Know More Than He Lets On?

The headline on the front cover of Issue 885 of Rail Magazine is Boris Backs New Pennine Railway.

There is also a sub-heading of PM commits to Leeds-Machester line.

Boris didn’t apply any substance to the speech, except to say that it will be funded.

I believe that my naive analysis in this post shows that something is possible and I just wonder, if Boris has been briefed about a much better plan?

August 25, 2019 Posted by | Transport | , , , , , , , , , , , , | 5 Comments

ProRail And Arriva Launch Automation Trials

The title of this post, is the same as that of this article on Railway Gazette.

I have posted this article, because it lays out in a simple way, the benefits of digital signalling and Automatic Train Operation.

March 22, 2019 Posted by | Transport | , , , , | Leave a comment

Integration Of High-Speed And Commuter Services Out Of Kings Cross Station

The East Coast Main Line ECML) has the following services on the Southern section between Kings Cross and Peterborough.

  • Express services capable of at least 125 mph running from LNER , Grand Central, Hull Trains and other Open Access operators.
  • Great Northern services capable of 110 mph running between Kings Cross and Cambridge and Ely.
  • Great Northern services to Peterborough appear to have been discontinued.
  • Thameslink services capable of 100 mph running between Kings Cross and Cambridge and Peterborough.

It would appear that the slower  Great Northern and Thameslink services will get in the way of the faster trains, if they need to use the fast lines.

The Digswell Viaduct

A particular problem will be the double-track section of line through Welwyn North station and over the Digswell Viaduct.

There are two Great Northern and  six Thameslink services in each hour, that are not capable of operating at 125 mph on the double-track section.

Following the logic of Oxford and Bedwyn services out of Paddington, which are now run by 125 mph Class 802 trains, I feel that timetabling would be easier on the ECML, if there were 125 mph trains running Great Northern and Thameslink services to Cambridge, Ely and Peterborough.

I explored 125 mph services to Kings Lynn in Call For ETCS On King’s Lynn Route, after reading about a proposal in Rail Magazine. They certainly look like they’d give advantages.

Some idiot decided that Thameslink services were fine with a 100 mph top speed. They should have been 110 mph or even faster trains, so that they could cross the Digswell Viaduct without slowing high speed services.

Digital Signalling

Digital signalling will be installed on the Southern section of the East Coast Main Line

This could ease the problem of the double-track section, as all trains should eventually be timed more precisely.

More Use Of The Hertford Loop

Perhaps some or all of the six 100 mph Thameslink services, could use an upgraded Hertford Loop Line, which will be fitted with digital signalling.

125 mph Trains

In a last resort, it would surely be more affordable to run 125 mph commuter trains to Cambridge, Ely and Peterborough, than put put two extra tracks on the Digswell Viaduct.

March 20, 2019 Posted by | Transport | , , , | 5 Comments

Porterbrook Awards £11m Contract To Modify New Digital Heathrow Express Fleet

The title of this post is the same as that of this article on Rail Technology Magazine.

These are the first two paragraphs.

Porterbrook has unveiled a £11m contract with Bombardier to modify 12 Class 387 trains in preparation for their use on the Heathrow Express rail link.

The 12 specially converted ‘Electrostar’ trains currently operate on London commuter services for GWR but will now form a dedicated Heathrow Express fleet of electric multiple-units.

As other Class 387 trains are used on Gatwick Express, I’m sure that the trains will end up as some of the best airport expresses in the world.

But I feel that this is the most significant paragraph in the article.

The deal will also see the company fit digital signalling equipment, called ETCS, to the Class 387s – the first-time digital signalling will have been fitted on an existing fleet of electric passenger trains and will result in ‘type approval’ from the ORR which will enable ETCS to be fitted on all Electrostar fleets.

Fitting ETCS to the Heathrow Express trains will have several benefits.

More Trains Between Paddington And Reading

With the refurbishment of the Class 387 trains for the Heathrow Express, there will only be three types of trains between Paddington and Reading stations.

  • Class 387 trains
  • Class 800/801/802 trains
  • Class 345 trains

Within a few years, all of these trains will be able to use ETCS and the benefits will be more trains between Paddington and Reading stations.

The trains would probably be a few minutes faster too!

All Electrostars Will Be Able To Be Updated With Digital Signalling

If the digital signalling works for the Class 387 trains, it would appear that it could be fitted to all the other Electrostars.

This could be very significant, as several busy lines have a high proportion of Electrostars.

These are my thoughts on some lines.

Brighton Main Line

The trains working the Brighton Main Line include.

  • Gatwick Express’s Class 387 trains.
  • Thameslink’s Class 700 trains, which are already using ETCS.
  • Southern’s Electrostars.

Could we see digital signalling increase the capacity of this line.

East London Line

The East London Line is an all-Electrostar line and in the next few years, with the coming of Crossrail, it will probably need more services.

I suspect it will be using digital signalling and ETCS in a few years time.

North And West London Lines

If the East London Line were to be successfully signalled to bring capacity benefits, I could see the North London and West London Lines following suit.

The Class 710 trains, that will be boosting passenger capacity are Aventras and will be compatible with digital signalling. The freight locomotives are also being upgraded to digital signalling.

c2c

In a few years time, c2c will be using only Electrostars and Aventras! So why not use digital signalling?

As more new trains arrive with digital signalling, more lines will be converted to digital signalling and ETCS.

Conclusion

The updating of twelve Class 387 trains for Heathrow Express is a big step in the creation of a digital railway.

January 22, 2019 Posted by | Transport | , , , | Leave a comment

Capacity Of Cross London Rail Routes

I shall start by looking at the current and future capacity of various rail routes across London.

Bakerloo

The Bakerloo Line has a frequency of twenty trains per hour (tph) between Queen’s Park and Elephant & Castle stations.

The current 1972 Stock trains have a capacity of 700 passengers.

This gives a capacity a 14,000 passengers per hour (pph) in each direction.

In the Wikipedia entry for the New Tube for London, this is said.

Bakerloo line capacity could be increased by 25% with 27 trains per hour at peak times by 2033.

This gives a future capacity of 17,500 pph in each direction.

Central

The Central Line has a frequency of thirty-five tph between White City and Leytonstone stations.

The current 1992 Stock trains have a capacity of 930 passengers.

This gives a capacity a 32,550 pph in each direction.

In the Wikipedia entry for the New Tube for London, this is said.

Central line capacity increased by 25% with 33 trains per hour at peak times by 2030.

This gives a future capacity of 40,687 pph in each direction.

Crossrail

Crossrail is planned at present to have twenty-four tph between Paddington and Whitechapel stations.

Each of Crossrail’s Class 345 trains can hold 1,500 passengers.

This gives a capacity a 36,000 pph in each direction.

It has been said in several places that Crossrail has a future frequency of thirty tph.

If this could be achieved this would increase capacity to 45,000 pph in each direction.

District

The District Line has a combined frequency with the Circle Line of  twenty-four tph between Gloucester Road and Tower Hill stations.

The current S7 Stock trains have a capacity of 865 passengers.

This gives a combined capacity a 20,760 pph in each direction.

The Wikipedia entry for the District Line talks about a future frequency of thirty-two tph.

This could increase the future capacity to 27,680 pph in each direction.

East London

The East London Line has a frequency of sixteen tph between Dalston Junction and Surrey Quays stations.

The current Class 378 trains have a capacity of 840 passengers.

This gives a capacity of 13,440 pph in each direction.

London Overground are planning to increase the frequency to twenty tph in the next couple of years.

This would give an increased capacity if 16,800 pph in each direction.

Gospel Oak To Barking

The Gospel Oak To Barking Line has a frequency of four tph across North London,

The current Class 172 trains have a capacity of 120 seats, with perhaps a total capacity of 300.

This would give a capacity of 1,200 pph in each direction.

The new Class 710 trains have a capacity around 700, according to various reports.

This would give a future capacity if 2,800 pph in each direction.

Hammersmith & City

The Hammersmith & City Line has a combined frequency with the Circle Line of twelve tph between Paddington and Liverpool Street stations.

The current S7 Stock trains have a capacity of 865.

This gives a combined capacity of 10,380 pph in each direction.

Jubilee

The Jubilee Line has a frequency of thirty tph between North Greenwich and Willesden Green stations.

The current 1996 Stock trains have a capacity of 875 passengers.

This gives a capacity of 26,250 pph in each direction.

With Siemens new trains, I suspect that this value could be increased by perhaps fifteen percent to 30,187 pph in each direction.

Metropolitan

The Metropolitan Line has an Off Peak frequency of sixteen tph between Baker Street and Liverpool Street stations.

The current S8 Stock trains have a capacity of 1003.

This gives a combined capacity a 16.048 pph in each direction.

With the Metropolitan Line Upgrade, we can probably see some more capacity.

A not unreasonable twenty percent would raise the future capacity to 19,257 pph in each direction.

Northern

In the Peak both branches of the Northern Line have a frequency of twenty-four tph between Camden Town and Kennington stations.

This is reduced to twenty tph in the Off Peak.

With the addition of the Extension to Battersea, these figures are unlikely to get lower.

The current 1195 Stock trains have a capacity of 662 passengers.

This gives a capacity of 31,776 pph in each direction.

With Siemens new trains, I suspect that this value could be increased by perhaps fifteen percent to 36,542 pph in each direction.

North London

The North London Line has a frequency of eight tph between Willesden Junction and Stratford stations.

The current Class 378 trains have a capacity of 840 passengers.

This gives a capacity a 6,720 pph in each direction.

London Overground are possibly planning to increase the frequency to twelve tph in the next couple of years.

This would give an increased capacity if 10,080 pph in each direction.

Piccadilly

As we don’t know the capacity of the new Siemens trains, this is a best estimate, for when they are in service around 2023-2025.

Currently, the Piccadilly Line is running at a frequency of twenty-four tph between Barons Court and Arnos Grove stations.

The current 1973 Stock trains, each have a capacity of 684 passengers.

This gives a current capacity of 15,416 pph in each direction.

In the Wikipedia entry for the New Tube for London, this is said.

Piccadilly line capacity could be increased by 60% with 33 trains per hour at peak times by 2025.

This gives a 2025 capacity of 24,666 pph in each direction.

Dividing  the 24,666 by 33 gives a train capacity of 750 passengers for a New Tube for London.

Thameslink

Thameslink will have a frequency of twenty-four tph between St. Pancras and Blackfriars stations.

Half of these will be twelve-car Class 700 trains with a capacity of 1754 and the other half will be eight-car trains with a capacity of 1146.

This gives a capacity of 34,800 pph in each direction.

It has been stated that Thameslink will be able to handle thirty tph in the future, which would raise the capacity to 43,500 pph in each direction.

Victoria

The Victoria Line is currently running at a frequency of thirty-six tph.

The current 2009 Stock trains, each have a capacity of 876 passengers.

This gives a capacity of 31,536 pph in each direction.

I think it is reasonable to assume that the Victoria Line is at capacity.

But I wouldn’t be surprised, that with station improvements, which would include a double-ended Walthamstow Central station, engineers on Dear Old Vicky managed to squeeze forty tph out of the old girl.

This would give a capacity of 35,040 pph in each direction.

I also wouldn’t rule out replacing the current trains with the New Tube for London, if the new trains have proved an outstanding success on all the other lines. But that probably wouldn’t be to well into the 2030s.

Current And Future Summary And Total Capacity

The current figures in passengers per hour can be summarised as follows.

  • Bakerloo – 14,000
  • Central – 32,550
  • Crossrail – 36,000
  • District – 20,760
  • East London – 13,440
  • Gospel Oak To Barking – 1,200
  • Hammersmith & City – 10,380
  • Jubilee – 26,250
  • Metropolitan – 16,048
  • Northern – 31,776
  • North London – 6,720
  • Piccadilly – 15,416
  • Thameslink – 34,800
  • Victoria – 31,536

This gives a total current capacity of 290,876

Reasonable projections for future figures can be summarised as follows.

  • Bakerloo – 17,500 (25% Increase) – New Tube for London/New Signalling
  • Central – 40,687 (25% Increase) – New Tube for London/New Signalling
  • Crossrail – 45,000 (25% Increase) – 30 tph from 24 tph
  • District – 27,680 (33% Increase) – New Signalling
  • East London – 16,800 (25% Increase) – 20 tph from 16 tph
  • Gospel Oak To Barking – 2,800 (133% Increase) – New larger trains
  • Hammersmith & City – 10,380
  • Jubilee – 30,187 (15% Increase) – New Tube for London
  • Metropolitan – 19257 (20% Increase) – New Signalling
  • Northern – 36,542 (15% Increase) – New Tube for London
  • North London – 10,080 (50% Increase)
  • Piccadilly – 24666 (60% Increase) – New Tube for London/New Signalling
  • Thameslink – 43,500(25% Increase) – 30 tph from 24 tph
  • Victoria – 31,536

This gives a total future capacity of 356615

Or a capacity increase of around twenty-three percent.

What Do These Figures Show?

My figures are very much rough estimates, based on what is proposed to happen.

New Tube for London

Five of the improvements in capacity require the replacement of the current trains with the New Tube for London. Three of these replacements will need new signalling and only the Piccadilly Line trains have actually been given the go-ahead.

If these train replacements and signalling are done sequentially, they would show these overall capacity improvements.

  • Piccadilly – 3.2%
  • Central – 2.6%
  • Bakerloo – 1.1%
  • Jubilee – 1.3%
  • Northern – 1.5%

Overall, these five projects will increase capacity by 10.2%

Some of these figures may appear small, compared to the Piccadilly and Central, but then with the exception of the Bakerloo, the other lines already have Automatic Train Control and high-frequency services.

The great thing about the effects of the New Tube for London on capacity, is that it is a rolling program and as each line is converted, more capacity will continue to be added, benefiting many parts of London.

Digital Signalling

Increasingly, lines in London are digitally-signalled with a degree of Automatic Train Control.

In a few years time, these lines will be controlled this way in Central London.

  • Central
  • Circle
  • Crossrail
  • District
  • Hamersmith & City
  • Jubilee
  • Metropolitan
  • Northern
  • Piccadilly
  • Thameslink
  • Victoria

All these lines are or will be carriers of high numbers of passengers.

In A North London Line With Digital Signalling, I looked at the benefits of installing digital signalling on the North London Line. This was my conclusion.

It looks to me, that they’ll come a time, when digital signalling to squeeze the required number of trains along the North London Line.

Digital signalling will have to be applied to all the other lines in my list to make the most of the train lines we have in London.

Bakerloo

These lines will be given new signalling

  • Bakerloo – 17,500 (25% Increase)
  • Central – 40,687 (25% Increase)
  • District – 27,680 (33% Increase)
  • Hammersmith & City – 10,380
  • Metropolitan – 19257 (20% Increase)
  • Piccadilly – 24666 (60% Increase)

Of the deep level Underground lines, the Bakerloo Line is well below the capacity in passengers per hour (pph) of the other lines, through Central London.

The easiest way to increase the capacity would be to increase the frequency of the trains, by the application of digital signalling.

Earlier in the section on the Piccadilly Line, I calculated the capacity of each New Tube for London on that line as 750.

So if the Bakerloo Line could handle the thirty-six tph currently running on the Victoria Line, this would give a capacity of 23,333 pph in each direction.

Like the Victoria Line, the Bakerloo is a simple double-track without junctions through Central London.

At the Southern end the line terminates in the two platforms at Elephant & Castle station. If Brixton and Walthamstow Central stations can handle thirty-six tph, then surely with modern trains and digital signalling, this number of trains can be handled at Elephant & Castle station.

But at Queen’s Park station, it’s more difficult.

This map from carto.metro.free.fr shows the track layou at Queens Park station.

Note.

  1. The Watford DC Line of the Overground is shown in orange and runs through Kilburn High Road and Queens Park stations.
  2. The Bakerloo Line is shown in brown and runs through Kilburn Park and Queens Park stations.
  3. There are reversing sidings to the West of Queens Park station for the Bakerloo Line.

The following services go through or terminate at Queens Park station.

  • Three tph between Euston and Watford Junction on the London Overground.
  • Six tph between Harrow & Wealdstone and Elephant & Castle on the Bakerloo Line.
  • Three tph between Stonebridge Park and Elephant & Castle on the Bakerloo Line.
  • Eleven tph between qQueens Park and Elephant & Castle on the Bakerloo Line.

It is also likely that the Overground service will go to four tph.

So this means that services will be as follows.

  • Four tph on the Watford DC Line run through Kilburn High Road station.
  • Twenty tph on the Bakerloo Line run through Kilburn Park station.
  • Nine tph on the Bakerloo Line run through Queens Park station.
  • Four tph on the Watford DC Line run through Queens Park station.
  • Eleven tph on the Bakerloo Line terminate at Queens Park station.

Thirteen tph will continue to various destinations towards Watford.

So how many trains could the double-track line between Queens Park and Wartford Junction stations handle?

Consider.

  • All services on the line are london Overground or London Underground.
  • There are no junctions, where services divide and join.
  • There is a turnback facility at Harrow & Wealdstone station, that can handle six tph.
  • The Overground trains are being replaced with Class 710 trains, which must be able to be made compatible with digital signalling.
  • Watford Junction station has four platforms connected to the Watford DC Line.
  • Good design should be able to make the stations step-free for both Class 710 trains and New Tube for London.
  • The Watford DC Line service, always seems to terminate in platform 9 at Euston.
  • London Underground have run thirty-six tph on the Victoria Line for about a year now.

I suspect that if the trains are digitally signalled, with a degree of Automatic Train Control, that there could be as many as thirty-six tph between Queens Park and Watford Junction stations.

I also think it is significant that the New Tube for London, specifies that the Bakerloo Line will run at twenty-seven tph. Why not more, if the theoretical capacity North of Queens Park is thirty-six tph?

But a single platform at Euston can probably handle six tph, so add 27 and 6 and you get 33 tph, which is the proposed core frequency of the Piccadilly Line.

Suppose too, that all Bakerloo services ran all the way to Watford Junction.

  • This would simplify operation at Queens Park, Stonebridge Park and Harrow & Waldstone.
  • Digital signalling would easily handle the frequency.
  • The platform arrangement at Queens Park would be unchanged, with Euston services on the outside and Bakerloo services in the middle.

Suppose too, that the Watford DC Line service were to be run by New Tube for London trains.

  • All platform heights could be the same.
  • All services would be step-free between train and platform.
  • Digital signalling could easily handle 33 tph along the route.

This last section has very much been speculation on my part, but it shows how it may be possible to create a service on the Bakerloo Line with the following characteristics.

  • Twenty-seven tph between Watford Junction and Elephant & Castle stations.
  • Six tph between Watford Junction and Euston stations.
  • All stations would be step-free between platform and train.
  • All trains would be identical New Tube for London trains.
  • All trains would run under Automatic Train Control, as does the Victoria Line.

Note, that I have said nothing about the Bakerloo Extension to Lewisham.

In my view, that extension does what it says on the tin and creates a new twenty-seven tph service between Elephant & Castle and Lewisham, which brings new services to an area of South-East London, where they are much needed.

Effectively, the Bakerloo Line could become two twenty-seven tph lines, that happen to connect back-to-back at Elephant & Castle station to enable cross-London journeys.

If we look at the Victoria Line, where the frequency has increased over the last few years by the addition of various improvements, I would not be surprised to see the frequency of twenty-seven tph increased.

After all London Underground’s engineers have been squeezing Dear Old Vicky for half a century, so they must know more tricks, than Paul Daniels knew at the peak of his success.

Crossrail

Taking the figures in the current table, Crossrail will add 36,000 pph in both directions across London, to a current capacity of 254,876.

This is a increase of fourteen percent on the current total capacity.

Increasing the frequency from twenty-four to thirty tph, adds another 9,000 pph in each direction, which is an increase of seventeen percent on the current total capacity.

It is very likely, that Crossrail has been designed, so that the train length can be changed as required.

The initial trains have been supplied as seven-car trains and when the line opens nine-car trains will be used.

I have read somewhere that the trains could be extended to ten cars, but eleven might be a bit difficult.

So what would be the effect on capacity of ten-car trains.

I will assume each ten-car train has a capacity of 1500 *10 / 9 = 1667.

This means that Crossrail capacity is increased as follows with ten-car trains.

  • 24 tph gives a capacity of 40,000 pph in each direction. Or sixteen percent on the total current capacity!
  • 30 tph gives a capacity of 50,000 pph in each direction. Or twenty percent on the total current capacity!

It looks like Crossrail might have been built to be expanded.

East London Line

It is my view that the East London Line will eventually be digitally signalled and there could be an increase in frequency from the proposed twenty tph.

It has been stated in the past, that the East London Line will eventually have a service based on six-car trains, running at a frequency of twenty-four tph.

Six-car trains could be a problem, as some of the stations like Canada Water, Shadwell, Wapping and Rotherhithe are a bit short for five-car trains and use selective door opening.

The hopefully high-capacity connection to Crossrail at Whitechapel station will surely drive more passengers to use the East London Line.

So increasing the frequency to twenty-four tph using digital signalling would be an option to increase the capacity.

There are four separate services on the East London Line.

  • Dalston Junction and New Cross
  • Dalston Junction and Clapham Junction
  • Highbury & Islington and Crystal Palace
  • Highbury & Islington and West Croydon

Each currently has a srvice of four tph, but it is planned that six tph will run to Crystal Palace and Clapham Junction before 2020.

Note that all services terminate in a dedicated platform, that is not shared with other services.

With modern signalling and good driving, these platforms should be able to handle six tph.

If all services went to six tph, that would mean twenty-four tph, through the core of the East London Line.

This would mean that the capacity of the line would be 20,160 pph in each direction, which would be a fifty percent increase on current capacity.

There may even be space for more trains through the core, as thirty tph is certainly possible with digital signalling. But where would the trains terminate?

Extra tunnel-capable Class 378 trains to run the extra services shouldn’t be a problem, as new Class 710 trains, will displace the older units from the Watford DC and the North London Lines.

North London Line

It is my view that the North London Line will eventually be digitally signalled to allow a more intensive passenger service than eight tph, amongst all the freight trains.

I have said that twelve tph between Willesden Junction and Stratford will be possible, within a few years.

But this could be the limit for the following reasons.

  • Terminating twelve tph in the two platforms at Stratford is probably possible but difficult.
  • Clapham Junction with one platform can probably handle six tph but no more.

Only Richmond has enough capacity for extra trains.



Conclusion

It looks to me that digital signalling and well-designed new trains can improve the capacity across London. Or Liverpool, Newcastle or Berlin to name just three major cities.







October 4, 2018 Posted by | Transport | , , , , , , , , | Leave a comment

A North London Line With Digital Signalling

In Digital Signalling Implications For North London, I indicated that there may be benefits in equipping the North London Line with digital signalling.

  • It would ease co-ordination of services between Gunnersbury and Richmond stations, where track, stations and signalling are shared with the District Line.
  • All freight trains are being fitted with digital signalling capabilities.

Obviously, the other benefits of digital signalling like closer running of trains would apply.

Current Service Levels

The Service Levels section of the Wikipedia entry for the North London Line, gives the following details..

Services run seven days a week and since the December 2018 timetable change are the same all day.

  • Four trains per hour (tph) – Richmond and Stratford
  • Four tph – Clapham Junction and Stratford

Which gives eight tph between Willesden Junction and Stratford

Compared to the service I remember from the 1980s, it is a great improvement.

Possible Future Service Levels

London Reconnections is a web site, that usually gets things right.

In this article, which is entitled More Trains for London Overground: A Bargain Never to be Repeated, this is said.

London Overground have a long-held desire to increase the frequency on the WLL from 4tph to 6tph. They also aspire to another 2tph (at least) from Clapham Junction continuing to Stratford, to further increase the frequency on the North London Line (NLL). This would enable 10tph on eastern end of the North London line. This is due to be implemented with the main order of the new Class 710 stock.

What, it is suspected, London Overground would really like is to have 6tph from Richmond to Stratford and 6tph from Clapham Junction all the way to Stratford. Unfortunately, the additional trains to Stratford would appear to rely on freight, travelling between East London and the West Coast Main Line, using the route via Gospel Oak instead of via the NLL. Until that actually happens, sometime after the electrification of the GOBLIN, such an intensive service on the NLL can only be a dream.

Would this mean this service?

  • Six tph – Richmond and Stratford
  • Six tph – Clapham Junction and Stratford

Which gives twelve tph between Willesden Junction and Stratford

I can’t say I’d complain living equidistant from Dalston Kingsland and Canonbury stations.

Richmond Station

The current service between Richmond and Gunnersbury station is as follows.

  • Four tph – London Overground to Stratford
  • Six tph – District Line to Upminster

Digital signalling on the District Line is likely to add 33% capacity to Peak Hour services, so this would mean another two trains to Upminster.

So a future service could be as follows.

  • Six tph – London Overground to Stratford
  • Eight tph – District Line to Upminster

This level of service could be easily handled by conventional signalling and good driving or by digital signalling.

Piccadilly Line To Ealing Broadway Station

This article on Chiswick W4, is entitled Major Reorganisation Of Local Tube Services Planned.

This is said.

The decision appears to have been made by Transport for London (TfL) to press ahead with a major restructuring of local underground services. This would see the District line service to Ealing Broadway ended and services switched to the Piccadilly line. The rolling stock would transfer to the Richmond and Wimbledon branches of the District line allowing an increase in regularity for these services.

Currently, Ealing Broadway station has a six tph service to Upminster on the District Line.

This map from carto.metro.free.fr shows the lines at Ealing Broadway station.

Note that after the changeover, the following would apply.

  • The Piccadilly Line would have three platforms.
  • In a few years time, the Central and Piccadilly Lines will have similar trains.
  • Passengers for Turnham Green, Stamford Brook and Ravensbrook Park, would use the Piccadilly Line, which would probably have a higher frequency.
  • Passengers for Victoria and other stations in the East on the District Line, would probably have a step-free cross-platform interchange at a number of stations.

But I think, that probably the main reason for the change, is that it will make the proposed frequency of well upwards of twenty tph of the Piccadilly Line easier to operate.

Consider.

  • The platforms would help with service recovery,
  • I suspect that TfL would like to see a Victoria Line frequency of thirty-six tph.
  • Currently, twenty-four tph run between Arnos Grove and Acton Town in the Peak.
  • Twenty-one tph run in the Off Peak.

If thirty-six tph is the intended frequency, then two terminal platforms in a rebuilt step-free Ealing Broadway station,  could turn a lot of trains.

A Side Effect Of Changing The District Line Terminus

If the District Line service of six tph to Ealing Broadway, were to be reallocated between Richmond and Wimbledon, this would add three tph to the section between Gunnersbury and Richmond.

So now we could be looking at seventeen tph between Gunnersbury and Richmond stations.

Will that mean that North London Line trains to Richmond will need digital signalling and automatic train control?

The West London Orbital Railway

The proposed West London Orbital Railway will use the Dudding Hill Line to create the following services.

  • West Hampstead to Hounslow
  • Hendon to Kew Bridge

If both routes run at four tph, then it will add eight tph to the North London Line between Acton Wells and South Acton junctions.

Added to the six tph between Richmond and Stratford, this would be fourteen tph through Acton Central and South Acton stations.

Digital signalling on the North London Line and the West London Orbital Railway would probably ease the merging of trains for the joint section.

Freight

It appears that there are up to four freight trains per hour in both directions on the line.

The Level Crossing At Acton Central Station

I doubt the users of the level crossing at Acton Central would like the levels of traffic, that digital signalling would enable.

A Summary Of Passenger Services

I can summarise the passenger train frequencies as follows.

  • Stratford to Willesden Junction – 12 tph
  • Willesden Junction to Acton Wells Junction – 6 tph
  • Acton Wells Junction to South Acton Junction – 14 tph
  • South Acton Junction to Gunnersbury – 6 tph
  • Gunnersbury to Richmond – 16 tph

I have assumed all developments mentioned earlier take place.

The Effect Of High Speed Two And Crossrail

When High Speed Two and Crossrail open at Old Oak Common station, this must surely increase the number of passengers using the North London Line, by a significant amount.

There will be two new stations.

Will the proposed six tph, each of five cars have sufficient capacity?

Conclusion

It looks to me, that they’ll come a time, when digital signalling will be needed to squeeze the required number of trains along the North London Line.

As I said in the previous section, traffic will continue to grow on the North and West London Lines because of High Speed 2 and Crossrail, as it has done since the route’s reopening with new trains in 2010.

I feel there will come a time, when trains will have to be lengthened from their current length of five cars.

Can all the stations on the route be extended if necessary?



September 30, 2018 Posted by | Transport | , , , , | 1 Comment
