Hitachi Trains For Avanti

The title of this post is the same as that of an article in the January 2020 Edition of Modern Railways.

The Bi-Mode Trains

Some more details of the thirteen bi-mode and ten electric Hitachi AT 300 trains are given.

Engine Size and Batteries

This is an extract from the article.

Hitachi told Modern Railways it was unable to confirm the rating of the diesel engines on the bi-modes, but said these would be replaceable by batteries in future if specified.

I do wonder if my speculation in Will Future Hitachi AT-300 Trains Have MTU Hybrid PowerPacks? is possible.

After all, why do all the hard work to develop a hybrid drive system, when your engine supplier has done it for you?

Would Avanti West Coast need a train that will do 125 mph on diesel?

The only place, they will be able to run at 125 mph or even higher will be on the West Coast Main Line, where they will be running under electric power from the pantograph.

If I were designing a bi-mode for 90 mph on diesel and 125 mph on electric, I would have batteries on the train for the following purposes.

  • Handle regenerative braking.
  • Provide hotel power in stations or when stationery.
  • Provide an acceleration boost, if required, when running on diesel.
  • Provide emergency power, if the wires go down in electric mode.

I’m sure MTU could work out a suitable size of diesel engine and batteries in an MTU PowerPack, that would meet the required performance.

Or maybe a smaller diesel could be used. An LNER Class 800 train has 1680 kW of installed power to maintain 125 mph. But the Great Western Railway versions have 2100 kW or twenty-five percent more, as their routes are more challenging with steeper gradients.

For the less challenging routes at a maximum of 90 mph between Crewe, Chester, Shrewsbury and North Wales, I wonder what level of power is needed.

A very rough estimate based on the speed required could put the power requirement as low as 1200-1500 kW.

As the diesel engines are only electrical generators, it would not effect the ability of the train to do 125 mph between Crewe and London.

There looks to be a virtuous circle at work here.

  • Lower maximum speed on diesel means smaller diesel engines.
  • Smaller diesel engines means lighter diesel engines and less fuel to carry.
  • Less weight to accelerate needs less installed power.
  • Less power probably means a more affordable train, that uses less diesel.

It looks to me, that Hitachi have designed a train, that will work Avanti West Coast’s routes efficiently.

The Asymmetric Bi-Mode Train

It looks to me that the bi-mode train  that Avanti West Coast are buying has very different performance depending on the power source and signalling

  • 90 mph or perhaps up to 100 mph on diesel.
  • 125 mph on electric power.with current signalling.
  • Up to 140 mph on electric power with in-cab digital signalling.

This compares with the current Class 221 trains, which can do 125 mph on all tracks, with a high enough operating speed.

The new trains’ different performance on diesel and electric power means they could be called asymmetric bi-modes.

Surely, creating an asymmetric bi-mode train, with on-board power; battery, diesel or hydrogen, sized to the route, means less weight, greater efficiency, less cost and in the case of diesel, higher carbon efficiency.

Carbon Emissions

Does the improvement in powertrain efficiency with smaller engines running the train at slower speeds help to explain this statement from the Modern Railways article?

Significant emissions reduction are promised from the elimination of diesel operation on electrified sections as currently seen with the Voyagers, with an expected reduction in CO2 emissions across the franchise of around two-thirds.

That is a large reduction, which is why I feel, that efficiency and batteries must play a part.

Battery-Electric Conversion

In my quote earlier from the Modern Railways article, I said this.

These (the diesel engines) would be replaceable by batteries in future if specified.

In Thoughts On The Next Generation Of Hitachi High Speed Trains, I looked at routes that could be run by a battery-electric version of Hitachi AT-300 trains.

I first estimated how far an AT-300 train could go on batteries.

How far will an AT-300 train go on battery power?

  • I don’t think it is unreasonable to be able to have 150 kWh of batteries per car, especially if the train only has one diesel engine, rather than the current three in a five-car train.
  • I feel with better aerodynamics and other improvements based on experience with the current trains, that an energy consumption of 2.5 kWh per vehicle mile is possible, as compared to the 3.5 kWh per vehicle mile of the current trains.

Doing the calculation gives a range of sixty miles for an AT-300 train with batteries.

As train efficiency improves and batteries are able to store more energy for a given volume, this range can only get better.

I then said this about routes that will be part of Avanti West Coast’s network.

With a range of sixty miles on batteries, the following is possible.

  • Chester, Gobowen, Shrewsbury And Wrexham Central stations could be reached on battery power from the nearest electrification.
  • Charging would only be needed at Shrewsbury to ensure a return to Crewe.

Gobowen is probably at the limit of battery range, so was it chosen as a destination for this reason.

The original post was based on trains running faster than the 90 mph that is the maximum possible on the lines without electrification, so my sixty mile battery range could be an underestimate.

These distances should be noted.

  • Crewe and Chester – 21 miles
  • Chester and Shrewsbury – 42 miles
  • Chester and Llandudno – 47 miles
  • Chester and Holyhead – 84 miles

Could electrification between Crewe and Chester make it possible for Avanti West Coast’s new trains to go all the way between Chester and Holyhead on battery power in a few years?

I feel that trains with a sixty mile battery range would make operations easier for Avanti West Coast.

Eighty miles would almost get them all the way to Holyhead, where they could recharge!

Rlectrification Between Chester And Crewe

I feel that this twenty-odd miles of electrification could be key to enabling battery-electric trains for the routes to the West of Chester to Shrewsbury, Llandudno and Holyhead.

How difficult would it be to electrify between Chester and Crewe?

  • It is not a long distance to electrify.
  • There doesn’t appear to be difficult viaducts or cuttings.
  • It is electrified at Crewe, so power is not a problem.
  • There are no intermediate stations.

But there does seem to be a very large number of bridges. I counted forty-four overbridges and six underbridges. At least some of the bridges are new and appear to have been built with the correct clearance.

Perhaps it would be simpler to develop fast charging for the trains and install it at Chester station.

Conclusion On The Bi-Mode Trains

It appears to me that Avanti West Coast, Hitachi and Rock Rail, who are financing the trains have done a very good job in devising the specification for a fleet of trains that will offer a good service and gradually move towards being able to deliver that service in a carbon-free manner.

  • The initial bi-mode trains will give a big improvement in performance and reduction in emission on the current Voyagers, as they will be able to make use of the existing electrification between Crewe and London.
  • The trains could be designed for 125 mph on electric power and only 90-100 mph on diesel, as no route requires over 100 mph on diesel. This must save operating costs and reduce carbon emissions.
  • They could use MTU Hybrid PowerPacks instead of conventional diesel engines to further reduce emissions and save energy
  • It also appears that Hitachi might be able to convert the trains to battery operation in a few years.
  • The only new infrastructure would be a few charging stations for the batteries and possible electrification between Chester and Crewe.

I don’t think Avanti West Coast’s ambition of a two-thirds reduction in CO2 is unreasonable and feel it could even be exceeded.

Other Routes For Asymetric Bi-Mode Trains

I like the concept of an asymetric bi-mode train, where the train has the following performance.

  • Up to 100 mph on battery, diesel or hydrogen.
  • Up to 100 mph on electrified slower-speed lines.
  • 125 mph on electrified high-speed lines, with current signalling.
  • Up to 140 mph on electrified high-speed lines, with in-cab digital signalling.

I am very sure that Hitachi can now tailor an AT-300 train to a particular company’s needs. Certainly, in the case of Avanti West Coast, this seems to have happened, when Avanti West Coast, Hitachi, Network Rail and Rock Rail had some serious negotiation.

LNER At Leeds

As an example consider the rumoured splitting and joining of trains at Leeds to provide direct services between London and Bradford, Harrogate, Huddersfield, Ilkley, Skipton and other places, that I wrote about in Dancing Azumas At Leeds.

In the related post, I gave some possible destinations.

  • Bradford – 13 miles – 25 minutes – Electrified
  • Harrogate – 18 miles – 30 minutes
  • Huddersfield – 17 miles – 35 minutes
  • Hull – 20 miles – 60 minutes
  • Ilkley – 16 miles – 26 minutes – Electrified
  • Skipton – 26 miles – 43 minutes – Electrified
  • York – 25 miles – 30 minutes

Note, that the extended services would have the following characteristics.

They would be run by one five-car train.

  1. Services to Bradford, Ilkley and Skipton would be electric
  2. Electrification is planned from Leeds to Huddersfield and York, so these services could be electric in a few years.
  3. All other services would need independent power; battery, diesel or hydrogen to and from Leeds.
  4. Two trains would join at Leeds and run fast to London on the electrified line.
  5. Services would probably have a frequency of six trains per day, which works out at a around a train every two hours and makes London and back very possible in a day.
  6. They would stop at most intermediate stations to boost services to and from Leeds and give a direct service to and from London.

As there are thirty trains per day between London and Leeds in each direction, there are a lot of possible services that could be provided.

Currently, LNER are only serving Harrogate via Leeds.

  • LNER are using either a nine-car train or a pair of five-car trains.
  • The trains reverse in Platforms 6 or 8 at Leeds, both of which can handle full-length trains.
  • LNER allow for a generous time for the reverse, which would allow the required splitting and joining.
  • All trains going to Harrogate are Class 800 bi-mode trains.

Note that the Class 800 trains are capable of 125 mph on diesel, whereas the average speed between Harrogate and Leeds is just 35 mph. Obviously, some of this slow speed is due to the route, but surely a train with a maximum speed of 90-100 mph, with an appropriate total amount of diesel power, would be the following.

  • Lighter in weight.
  • More efficient.
  • Emit less pollution.
  • Still capable of high speed on electrified lines.
  • Bi-mode and electric versions could run in pairs between Leeds and London.

LNER would probably save on track access charges and diesel fuel.

LNER To Other Places

Could LNER split and join in a similar way to other places?

  • Doncaster for Hull and Sheffield
  • Edinburgh for Aberdeen and Inverness
  • Newark for Lincoln and Nottingham
  • York for Middlesbrough and Scarborough.

It should be noted that many of the extended routes are quite short, so I suspect some train diagrams will be arranged, so that trains are only filled up with diesel overnight,

GWR

Great Western Railway are another First Group company and I’m sure some of their routes could benefit, from similar planning to that of Avanti West Coast.

Splitting and joining might take place at Reading, Swindon, Bristol and Swansea.

South Western Railway

South Western Railway will need to replace the three-car Class 159 trains to Exeter, that generally work in pairs with a total number of around 400 seats, in the next few years.

These could be replaced with a fleet of third-rail Hitachi trains of appropriate length.

  • Seven cars sating 420 passengers?
  • They would remove diesel trains from Waterloo station.
  • All South Western Railway Trains running between Waterloo and Basingstoke would be 100 mph trains.

I wonder, if in-cab digital signalling on the route, would increase the capacity? It is sorely needed!

Southeastern

Southeastern need bi-mode trains to run the promised service to Hastings.

  • Trains would need a third-rail capability.
  • Trains need to be capable of 140 mph for High Speed One.
  • Trains need to be able to travel the 25 miles between Ashford International and Ore stations.
  • Trains would preferably be battery-electric for working into St. Pancras International station.

Would the trains be made up from six twenty-metre cars, like the Class 395 trains?

The Simple All-Electric Train

The Modern Railways article, also says this about the ten all-electric AT-300 trains for Birmingham, Blackpool and Liverpool services.

The electric trains will be fully reliant on the overhead wire, with no diesel auxiliary engines or batteries.

It strikes me as strange, that Hitachi are throwing out one of their design criteria, which is the ability of the train to rescue itself, when the overhead wires fail.

In Do Class 800/801/802 Trains Use Batteries For Regenerative Braking?, I published this extract from this document on the Hitachi Rail web site.

The system can select the appropriate power source from either the main transformer or the GUs. Also, the size and weight of the system were minimized by designing the power supply converter to be able to work with both power sources. To ensure that the Class 800 and 801 are able to adapt to future changes in operating practices, they both have the same traction system and the rolling stock can be operated as either class by simply adding or removing GUs. On the Class 800, which is intended to run on both electrified and non-electrified track, each traction system has its own GU. On the other hand, the Class 801 is designed only for electrified lines and has one or two GUs depending on the length of the trainset (one GU for trainsets of five to nine cars, two GUs for trainsets of 10 to 12 cars). These GUs supply emergency traction power and auxiliary power in the event of a power outage on the catenary, and as an auxiliary power supply on non-electrified lines where the Class 801 is in service and pulled by a locomotive. This allows the Class 801 to operate on lines it would otherwise not be able to use and provides a backup in the event of a catenary power outage or other problem on the ground systems as well as non-electrified routes in loco-hauled mode.

This is a very comprehensive power system, with a backup in case of power or catenary failure.

So why does it look like Hitachi are throwing that capability out on the trains for Avanti West Coast.

There are several possibilities.

  • The reliability of the trains and the overhead wire is such, that the ability of a train to rescue itself is not needed.
  • The auxiliary generator has never been used for rescuing the train.
  • The West Coast Main Line is well-provided with Thunderbird locomotives for rescuing Pendelinos, as these trains have no auxiliary generator or batteries.
  • Removal of the excess weight of the auxiliary engine and batteries, enables the Hitachi AT-300 trains to match the performance of the Pendelinos, when they are using tilt.

Obviously, Hitachi have a lot of train performance statistics, from the what must be around a hundred trains in service.

It looks like Hitachi are creating a lightweight all-electric train, that has the performance or better of a Pendelino, that it achieves without using tilt.

  • No tilt means less weight and more interior space.
  • No auxiliary generator or batteries means less weight.
  • Wikipedia indicates, that Hitachi coaches are around 41 tonnes and Pendelino coaches are perhaps up to ten tonnes heavier.
  • Less weight means fast acceleration and deceleration.
  • Less weight means less electricity generated under regenerative braking.
  • Pendelinos use regenerative braking, through the catenary.
  • Will the new Hitachi trains do the same instead of the complex system they now use?

If the train fails and needs to be rescued, it uses the same Thunderbird system, that the Pendelinos use when they fail.

Will The New Hitachi Trains Be Less Costly To Run?

These trains will be lighter in weight than the Pendelinos and will not require the track to allow tilting.

Does this mean, that Avanti West Coast will pay lower track access charges for their new trains?

They should also pay less on a particular trip for the electricity, as the lighter trains will need less electricity to accelerate them to line speed.

Are Avanti West Coast Going To Keep The Fleets Apart?

Under a heading of Only South Of Preston, the Modern Railways article says this.

Unlike the current West Coast fleet, the Hitachi trains will not be able to tilt. Bid Director Caroline Donaldson told Modern Railways this will be compensated for by their improved acceleration and deceleration characteristics and that the operator is also working with Network Rail to look at opportunities to improve the linespeed for non-tilting trains.

The routes on which the Hitachi trains will operate have been chosen with the lack of tilt capability in mind, with this having the greatest impact north of Preston, where only Class 390 Pendelinos, which continue to make use of their tilting capability will be used.

Avanti West Coast have said that the Hitachi trains will run from London to Birmingham, Blackpool and Liverpool.

All of these places are on fully-electrified branches running West from the West Coast Main Line, so it looks like there will be separation.

Will The New Hitachi Trains Be Faster To Birmingham, Blackpool And Liverpool?

Using data from Real Time Trains, I find the following data about the current services.

  • Birmingham and Coventry is 19 miles and takes 20 minutes at an average speed of 57 mph
  • Blackpool and Preston is 16.5 miles and takes 21 minutes at an average speed of 47 mph
  • Liverpool and Runcorn is 3.15 miles and takes 15 minutes at an average speed of 52 mph

All the final legs when approaching the terminus seem to be at similar speeds, so I doubt there are much savings to be made away from the West Coast Main Line.

Most savings will be on the West Coast Main Line, where hopefully modern in-cab digital signalling will allow faster running at up to the design speed of both the Hitachi and Pendelino trains of 140 mph.

As an illustration of what might be possible, London to Liverpool takes two hours and thirteen minutes.

The distance is 203 miles, which means that including stops the average speed is 91.6 mph.

If the average speed could be raised to 100 mph, this would mean a journey time of two hours and two minutes.

As much of the journey between London and Liverpool is spent at 125 mph, which is the limit set by the signalling, raising that to 135 mph could bring substantial benefits.

To achieve the journey in two hours would require an overall average speed of 101.5 mph.

As the proportion of track on which faster speeds, than the current 125 mph increase over the next few years, I can see Hitachi’s lightweight all-electric expresses breaking the two hour barrier between London and Liverpool.

What About The Pendelinos And Digital Signalling?

The January 2020 Edition of Modern Railways also has an article entitled Pendolino Refurb Planned.

These improvements are mentioned.

  • Better standard class seats! (Hallelujah!)
  • Refreshed First Class.
  • Revamped shop.

Nothing is mentioned about any preparation for the installation of the equipment to enable faster running using digital in-cab signalling, when it is installed on the West Coast Main Line.

Surely, the trains will be updated to be ready to use digital signalling, as soon as they can.

Just as the new Hitachi trains will be able to take advantage of the digital signalling, when it is installed, the Pendellinos will be able to as well.

Looking at London and Glasgow, the distance is 400 miles and it takes four hours and thirty minutes.

This is an average speed of 89 mph, which compares well with the 91.6 mph between London and Liverpool.

Raise the average speed to 100 mph with the installation of digital in-cab signalling on the route, that will allow running at over 125 mph for long sections and the journey time will be around four hours.

This is a table of average speeds and journey times.

  • 100 mph – four hours
  • 105 mph – three hours and forty-eight minutes
  • 110 mph – three hours and thirty-eight minutes
  • 115 mph – three hours and twenty-eight minutes
  • 120 mph – three hours and twenty minutes
  • 125 mph – three hours and twelve minutes
  • 130 mph – three hours and four minutes

I think that I’m still young enough at 72 to be able to see Pendelinos running regularly between London and Glasgow in three hours twenty minutes.

The paragraph is from the Wikipedia entry for the Advanced Passenger Train.

The APT is acknowledged as a milestone in the development of the current generation of tilting high speed trains. 25 years later on an upgraded infrastructure the Class 390 Pendolinos now match the APT’s scheduled timings. The London to Glasgow route by APT (1980/81 timetable) was 4hrs 10min, the same time as the fastest Pendolino timing (December 2008 timetable). In 2006, on a one off non-stop run for charity, a Pendolino completed the Glasgow to London journey in 3hrs 55min, whereas the APT completed the opposite London to Glasgow journey in 3hrs 52min in 1984.

I think it’s a case of give the Pendelinos the modern digital in-cab signalling they need and let them see what they can do.

It is also possible to give an estimate for a possible time to and from Manchester.

An average speed of 120 mph on the route would deliver a time of under one hour and forty minutes.

Is it possible? I suspect someone is working on it!

Conclusion

I certainly think, that Avanti West Coast, Hitachi and Network Rail, have been seriously thinking how to maximise capacity and speed on the West Coast Main Line.

I also think, that they have an ultimate objective to make Avanti West Coast an operator, that only uses diesel fuel in an emergency.





January 1, 2020 Posted by | Transport | , , , , , , , , , , , , , , , , | 3 Comments

Abellio’s Plans For Nottingham And Crewe Via Derby

This page on the Department for Transport web site is an interactive map of the Abellio’s promises for East Midlands Railway.

These are mentioned for services between Nottingham and Crewe via Derby.. This is an extension of the current service which is two separate services, that need a change at Derby.

Crewe-Derby Services Will Operate With Increased Capacity Compared To Today

Consider.

  • Currently, the service between Derby and Crewe takes 43 minutes with another 30 minutes for Derby And Nottingham.
  • It is run by a Sprinter with one or two cars.
  • The service is hourly.
  • I suspect that a well-driven train will be able to do a round trip from Nottingham to Crewe and back in under three hours.

This would mean that three trains are needed to provide the hourly service.

But put four- or five-car Class 222 trains on the route and this would mean.

  • Much greater capacity.
  • Faster journeys.
  • More comfort and facilities.

If a train could do the round trip in under two hours, then just two trains would be needed for the hourly service.

Most Services Will Be Extended To And From Nottingham

I assumed this in the previous section and it appears sensible.

, Later Evening Service Is To Be Provided In Both Directions

Trains can never be too late.

Enhanced Sunday Service With A Regular Hourly service Starting Early In The Morning

You can’t fault that!

Increased Community Rail Partnership Funding

Or that one!

Refurbished Modern Trains

As with their plans for Nottingham to Norwich, they use the same words about the trains.

Read Abellio’s Plans For Norwich And Liverpool, to see what I said.

Wikipedia’s View

The Wikipedia entry for the Crewe-Derby Line says this about services on the route.

The line sees a basic hourly service in each direction with trains calling at all stations on the route however Peartree which is served by 2 Derby bound trains and 3 Crewe bound trains per weekday.

The majority of services on the route since December 2008 have been provided by Class 153 “Super Sprinter” Diesel Multiple Units however Class 158 “Express Sprinter” and Class 156 “Super Sprinter” units are occasionally used. Overcrowding remains a major issue on the route, particularly in the morning and evening peak and a weekends. Passengers are occasionally left behind.

A Class 222 train on this line with a 70 mph operating speed, must provide a better service.

Collateral Benefits

I see these as collateral benefits.

Extra Services Between Derby and Nottingham

If you take this plan with Abellio’s Plans For Norwich And Liverpool, they both have added an hourly service between Derby and Nottingham.

Better Connections To High Speed Two

\Will these extra services connect to High Speed Two at the East Midlands Hub station?

Remember that Abellio’s is an eight year franchise and High Speed Two will arrive in the area, at the time of the end of the franchise.

April 14, 2019 Posted by | Transport | , , , , , | Leave a comment

Did Adrian Shooter Let The Cat Out Of The Bag?

This article with a video in the Scotsman is entitled Video: Battery Trains On Track To Cut Emissions and gives a lot of information about the Class 230 train. This is a paragraph.

The train is restricted to a 25mph speed on this week’s test trips, but Vivarail Chief Executive Adrian Shooter says it can sustain speeds of “60 mph for 40 miles” when new batteries become available next year.

Moreover, the batteries need just four minutes to recharge.

So what does this mean for the various routes?

Borderlands Line

Transport for Wales have ordered Class 230 trains for the Borderlands Line.

The line runs between Bidston and Wrexham Central stations is around twenty-seven miles and takes an hour. There is a generous turnround time at both ends in the current schedule.

This Google Map shows the layout of the two-platform station at Bidston.

This picture shows the red-roofed shed in the middle of the island platform, with the tracks on either side.

Would it be sensible to add a dedicated bay platform at Bidston for charging the battery trains?

The train will certainly be able to start with a full battery after a long charge at Wrexham Central and then do the following.

  • Run to Bidston on battery power.
  • Turnround at Bidston, where four minutes could be used to charge the batteries.
  • Run back to Wrexham Central on battery power.
  • Regenerative braking would be used at the thirteen intermediate stations.

If necessary during the long runs the diesel engines could be used to provide more power or top up the batteries.

Chester To Crewe Line

Transport for Wales have ordered Class 230 trains for the Chester to Crewe Line.

It runs between Chester and Crewe stations, is around twenty miles long and services take about twenty minutes.

As there are no stations between Chester and Crewe and the maximum speed of the Class 230 train is sixty mph, it looks like the train will be almost at maximum speed  along this route.

So will the four diesel engines be working hard?

When these trains were built in the 1980s, I doubt that anybody thought they’d be running services on a section of the North Wales Coast Line.

Conwy Valley Line

Transport for Wales have ordered Class 230 trains for the Conwy Valley Line.

It runs between Llandudno and Blaenau Ffestiniog stations, is around thirty miles long and services take eighty minutes to ascend and seventy to come down.

The train will certainly be able to start with a full battery after a long charge at Llandudno and then do the following.

  • Ascend to Blaenau Ffestiniog on battery power, with help from the diesel engines.
  • Turnround at Blaenau Ffestiniog, where four minutes could be used to charge the batteries.
  • Descend to Llandudno on battery power, with help from gravity.
  • The descent would be controlled by regenerative braking.
  • Regenerative braking would be used at the eleven intermediate stations.

If necessary during the long ascent the diesel engines could be used to provide more power or top up the batteries.

Greenford Branch

What do you do with a problem like the Greenford Branch?

In Could Class 165 HyDrive Trains Be The Solution To The Greenford Branch?, I looked at the possibility of using the proposed Class 165 Hydrive trains to provide a four trains per hour (tph) service on the Greenford Branch.

This was my conclusion.

Four tph is possible on the Greenford Branch, but it will need an extra crossover just outside West Ealing station.

Class 165 HyDrive trains with their extra performance would make the four tph timetable more reliable.

The lower noise and emissions of the trains would also please the local residents.

I also feel that a well-designed battery-powered two-car train, with perhaps a charging station at either end could also provide the improved service.

That well-designed battery-train has arrived in the shape of the Class 230 train.

Island Line

It appears likely, that Class 230 trains will be ordered for the Island Line.

It runs between Ryde Pier Head and Shanklin stations, is under nine miles long and a typical round trip is as follows.

  • Shanklin to Ryde Pier Head – 24 minutes
  • Turnround at Ryde Pier Head – 20 minutes
  • Ryde Pier Head to Shanklin – 24 minutes
  • Turnround at Shanklin – 5 minutes

The Island Line has an operating speed of just 45 mph.

Adding all that up, I would estimate that a train doing a round trip would do under twenty miles at a maximum speed of 45 mph.

Adrian Shooter said that the trains will be able to store 2,400 miles² /hour, whereas the Island Line would use only 900 miles² /hour in a round trip. They may be weird units, you won’t find in any text book, but I want to prove if something is possible or not.

It looks like it most definitely is possible for a battery-powered Class 230 train to perform a round trip on one charge of of the batteries.

Suppose though, the line was reinstated to Ventnor station, as a  line without electrification. A quick estimate gives the round-trip as thirty miles, which would need  1350 miles² /hour.

There could even be a second charging station at Ventnor.

Could we see a future Island Line like this?

  • No electrification.
  • Extension to a new Ventnor station.
  • A passing loop at Brading station.
  • Battery trains.
  • Relaid track for very gentle curves and high efficiency.
  • Charging stations at Ryde Pier Head and Ventnor stations.

I suspect with some faster running, where it is possible and perhaps one diesel power pack per train, three-car Class 230 trains could run a two tph service.

This type of service would not be unique for long, as other places would quickly copy.

Marston Vale Line

West Midlands Trains have ordered Class 230 trains for the Marston Vale Line.

It runs between Bedford and Bletchley stations, is around twenty-four miles long and services appear to take about forty-five minutes, with a turn-round time of well over four minutes.

So it would seem that each leg of a return journey would be less than forty miles and there would be sufficient time for a full four-minute charge at either end.

The regenerative braking would be useful in handling the eleven stops.

Conclusion

It isn’t one cat!

It’s a whole destruction, glorying or nuisance of felines!







October 16, 2018 Posted by | Transport | , , , , , , , | 6 Comments

Crewe Hub To Be First ‘All-Digital’ Station, Says Transport Chief

The title of this post is the same as that of this article in the Warrington Guardian.

This is the first three paragraphs

Delays caused by signalling faults could eventually be a thing of the past on trains running to and from Crewe.

At a meeting on Friday Pete Waterman, chairman of the Cheshire and Warrington Local Transport Body (LTB), revealed that Network Rail, the Department for Transport and HS2 Ltd have agreed that the town will become home to Britain’s first all-digital station.

It means that all trains running from Crewe to Warrington, Chester and other destinations across Cheshire would benefit from the same technology which will be used by HS2 services – meaning lines could run more efficiently with trains travelling in a tighter sequence.

I feel that increasingly, digital signalling will be used to improve capacity on UK railways.

April 9, 2018 Posted by | Transport | , | 1 Comment

New Readers

I was given a write-up in the Ipswich Town program today and some people who visit, may have been directed from the program.

Don’t take anything I say too seriously, as underneath it all I try to amuse and inform.  Remember too, I have other interests outside Ipswich Town, like art, architecture, engineering and trains.  I also feel that one of the ways we’re going to get this country out of the mess it’s in, is by appreciating what we’ve got here in these Isles and enjoying it. Who would have thought that a visit to Middlesbrough or Crewe could be so enjoyable.  But they genuinely were and I shall be visiting other places in the next few months, that might be equally unpromising.  Hopefully, they’ll be equally enjoyable, even if Town don’t win or the trip has nothing to do with football.

The next trips will be Portsmouth and Scunthorpe.

Feel free to post comments.  I reserve the right to remove those that are not constructive!

August 28, 2010 Posted by | Sport, Transport | , , , , , , , | 1 Comment

A Good Trip to Crewe and Chester

It was a good trip, not only because Ipswich won and I was able to renew old memories in Chester, but also because of the little things that happened and that I discovered.

  • Virgin’s First Class lounges made travel in my condition a bit easier.
  • The Crewe Arms offered a comfortable bed and good coffee in the morning close to the station and the football.
  • I had a very good curry in Passage to India in Crewe.
  • The staff and stewards at Crewe Alexandra were pleasant and welcoming.
  • Real pubs still exist in the most unlikely places.
  • I got a nice complimentary gluten-free salad on the way back.  So Virgin can do gluten-free, despite what I said earlier

I shall definitely go to Crewe again, if Ipswich play there!

August 26, 2010 Posted by | Food, Sport, Transport | , , , , | Leave a comment

On To Chester

After a good night’s sleep and some nice coffee in the Crewe Arms hotel, I took a short walk to the station and bought a return ticket to Chester, which would get me back in time for my 15:57 train back to London.

I actually could have boarded my return train at Chester, as it had come from Holyhead, but I wan’t too sure of my plans in Chester.  And I was a bit wary of missing the train home!

August 26, 2010 Posted by | Transport | , , | Leave a comment

Crewe Heritage Centre

One of the few places that are worth seeing in Crewe is the Crewe Heritage Centre, which is a railway museum.

Unfortunately it was closed, despite it being the school holidays.  But as it is within walking distance of the station and the football ground, it would be an ideal place to waste a few hours before an away match with Crewe Alexandra.

August 26, 2010 Posted by | Sport, Transport | , , , | Leave a comment

Ipswich Win at Crewe

I really enjoyed the game at Crewe last night.

I know Ipswich won, but the football was good and it could easily have gone to penalties.

I should also say, that Crewe’s stewards knew how to make visiting fans appear welcome.  Something that some clubs could learn how to do!

I also had a problem in that I needed to take my medicine.  That was no problem, as I asked one of the helpful staff in the refreshment hut, if I could have a glass of water. I got it without question.

That was typical of the attitude on the club.

Alexandra Stadium, Crewe

August 25, 2010 Posted by | Sport | , | Leave a comment

D & G Buses in Crewe

I noticed that some of the buservices in Crewe are run by a company call D & G Bus

Obviously as Crewe is in Cheshire, these buses must be the first choice of the many footballers wives who live in the area.

August 25, 2010 Posted by | Sport, Transport | , , | Leave a comment
