UK-German Energy Link Reaches Financial Close

The title of this post, is the same as that of this article on renews.biz.

These are the three introductory paragraphs.

A multibillion-euro 725 km interconnector between the UK and Germany has reached financial close, paving the way for construction works to begin in the coming months.

The £2.4bn (€2.8bn) NeuConnect interconnector will form an “invisible energy highway” with subsea cables allowing up to 1.4GW of electricity to flow in either direction between the UK and Germany and will help deliver a more secure and resilient energy supply, particularly as more renewable generation is added.

Independent analysis shows the project will create over £1.7bn in UK consumer benefits over 25 years.

Other points about NeuConnect include.

  • It has been privately funded by a consortium of over twenty national and international banks.
  • It will run between the Isle of Grain and a the new Fedderwarden substation in Wilhelmshaven.
  • It should be operational in 2028.

Although, it is bi-directional, it appears that one of its major uses will be to provide Germany with UK wind energy to compensate for the loss of Putin’s bloodstained gas.

July 21, 2022 Posted by | Energy | , , , , | Leave a comment

Boris Baldrick’s Cunning Plan

This written statement to Parliament on the UK Government web site, is entitled Transport Update: Transpennine Route Upgrade.

It has been published by Grant Shapps and this is the sub-title.

Additional funding has been made available for the Transpennine route upgrade.

This is the complete statement.

Today 19 July 2022, the government has made available £959 million of additional funding to continue to progress the delivery of the ambitious Transpennine route upgrade.

This funding is a significant milestone and another step towards upgrading the key east-west rail artery across the north of England, to further this government’s levelling up and decarbonisation objectives.

In addition to progressing the design of aspects of the upgrade, this funding will enable further on-the-ground delivery of electrification and journey time improvement works, mostly west of Leeds.

One of the first tangible benefits will be enabling electric trains to run between Manchester and Stalybridge by the middle of the decade. We are also developing scope that will enable the Transpennine route upgrade to become the first phase of Northern Powerhouse Rail, including plans to unlock freight flows and take thousands of lorries off our roads.

We are also more than trebling the investment in the Transpennine route upgrade from £2.9 billion to between £9.0 billion and £11.5 billion.

This additional investment will enable the roll out of digital signalling technology, electrification of the full route and the provision of additional tracks for commercial and freight services, giving rail users more reliable, more punctual, more comfortable and greener rail journeys.

I have some thoughts.

It’s Not A Wish List, But A Reality

The last paragraph reads like a wish list.

This additional investment will enable the roll out of digital signalling technology, electrification of the full route and the provision of additional tracks for commercial and freight services, giving rail users more reliable, more punctual, more comfortable and greener rail journeys.

But it’s not a wish list, it’s what is to be done.

Where Will The Government Get Between Nine and Eleven-And-A-Half Billion Pounds?

It’s not the sort of small change that you have in a sock draw.

This document on the UK government web site, is entitled PM Opening Remarks At Press Conference With German Chancellor Olaf Scholz: 8 April 2022, where this is these three paragraphs.

We will also agree on the importance of weaning ourselves off dependence on Russian gas and oil, and ensuring that our energy security cannot be threatened by a rogue state.

This is not easy for any of us, and I applaud the seismic decisions taken by Olaf’s government to move Germany away from Russian hydrocarbons.

Today we have agreed to maximise the potential of the North Sea and collaborate on energy security and on renewables, where Germany and the UK lead the way in new technology.

So did Boris and Olaf sign the world’s first Green Alliance based on zero-carbon energy?

  • They may not have signed an Alliance, but they have agreed on common actions.
  • Over the last year or so, German money and technology has started to be more visible in our offshore wind farms.
  • BP have been backed by German utility; enBW in some of their huge wind farms.
  • Siemens Gamesa are providing a lot of wind turbines.
  • Will German shipyards build the floats for floating wind farms?
  • An interconnector between the Isle of Grain and Wilhelmshaven is planned.
  • Rolls-Royce and its German subsidiary MTU are charging into battle against climate change.
  • The Germans have taken a liking to ITM Power’s electrolysers to produce hydrogen.

I can see the North Sea or the German Ocean becoming Europe’s power station, with by 2030, a large amount of the energy not needed by the UK, being exported to the Continent, either as electricity or hydrogen.

The Germans could become our magische Geldbäume.

But unlike gas and oil, wind power in the North Sea won’t run out, as it’s renewable.

In How Britannia With Help From Her Friends Can Rule The Waves And The Wind, this was my conclusion.

Boris’s vision of the UK becoming a Saudi Arabia of wind is no fantasy of a man with massive dreams.

Standard floating wind turbines, with the possibility of also harvesting wave power could be assembled in ports along the coasts, towed into position and then connected up.

Several GW of wind-power capacity could probably be added each year to what would become the largest zero-carbon power station in the world.

By harvesting the power of the winds and waves in the seas around the British Isles it is an engineering and mathematical possibility, that could have been developed by any of those great visionary Victorian engineers like Armstrong, Bazalgette, Brunel and Reynolds, if they had had access to our modern technology.

Up Yours! Putin!

This energy and the money it provides will finance our infrastructure and our tax cuts.



July 19, 2022 Posted by | Transport/Travel | , , , , , , , , , , | 2 Comments

UK Energy Exports To Europe At Record High

The title of this post, is the same as that of this article on The Times.

This is the first two paragraphs.

Britain has exported record amounts of gas to Europe so far this year as its liquefied natural gas terminals receive shipments destined for the Continent.

Electricity exports also have surged to unprecedented highs in recent weeks after an unexpected glut of gas pushed down short-term gas prices and resulted in gas-fired power plants generating more for export.

Who’d have thought it, that all those gas pipelines and electricity interconnectors between the UK and the Continent of Europe would be part of the replacementliqui for Russian gas.

According to Wikipedia, we have three liquified natural gas terminals; two at Milford Haven; South Hook and Dragon, and Grain on the Isle of Grain.

Note.

  1. South Hook is Europe’s largest liquified natural gas terminal and is owned by a partnership of the Qataris, ExxonMobil and Elf.
  2. South Hook and Dragon together can provide 25 % of the UK’s natural gas needs.
  3. Grain is owned by National Grid and according to Wikipedia, is in terms of storage capacity it is the largest LNG facility in Europe and the eighth largest in the world.
  4. Grain can supply 20 % of the UK’s natural gas needs.
  5. Grain has a reloading facility, so that gas can be exported.
  6. Grain seems to be continually expanding.
  7. Both Milford Haven and the Isle of Grain have large gas-fired power-stations.

Politicians say we don’t have enough gas storage, but we do seem to have world-class LNG terminals.

I have a couple of extra thoughts.

Blending Natural Gas With Hydrogen

HyDeploy is a project investigated blending hydrogen natural gas to cut carbon emissions. The project is described in this post called HyDeploy.

Surely, these terminals could be places, where hydrogen is blended with our natural gas supply.

  • The terminals are connected to the UK gas network.
  • Both Milford Haven and the Isle of Grain should have access to large amounts of offshore wind energy in the next few years, which could be used to generate green hydrogen.
  • The terminals would need electrolysers to generate the hydrogen.

The Isle of Grain already has a blending capability.

NeuConnect

NeuConnect is an under-development interconnector between the Isle of Grain in Kent and Wilhelmshaven in Germany.

  • It will have a capacity 1.4 GW.
  • All the planning permissions seem to be in place.
  • Prysmian have won a € 1.2 million contract to deliver the interconnector.
  • Arup and German engineering firm Fichtner have formed a joint venture to provide project services for the interconnector.
  • Construction could start this year.

It looks like the Germans will be replacing some of Putin’s bloodstained gas with clean zero-carbon energy from the UK.

Should We Develop More Gas Fields?

There are some gas fields in the seas around the UK, like Jackdaw, that could be developed.

Suppose, we extracted the gas and sent it to the reloading terminal on the Isle of Grain through the gas transmission network, where it could be exported by ship, to the Continent.

The UK would not be increasing its carbon emissions, as that would surely be the responsibility of the end-user.

Should We Develop More Gas Fired Power-Stations?

I believe it is possible to develop carbon-capture technology for gas-fired power stations.

The carbon dioxide would be either used in a beneficial way or stored in perhaps a worked-out gas field under the North Sea.

So long as no carbon dioxide is released into the atmosphere, I don’t see why more gas-fired power stations shouldn’t be developed.

What is happening at Keadby near Scunthorpe would appear to be one model for zero-carbon power generation.

Keadby Power Station



This is an existing

Conclusion

We will be exporting more energy to the Continent.

May 20, 2022 Posted by | Energy, Energy Storage, Hydrogen | , , , , , , , , , , , , | 1 Comment

NeuConnect Awards Two Major Contracts

This page on the NeuConnect web site is entitled NeuConnect Awards Over £1.5 billion Of Major Contracts As First Ever UK-German Energy Link Moves An Important Step Closer.

NeuConnect is a proposed interconnector between England and Germany.

  • It will have a capacity of 1.4 GW.
  • The interconnector will be around 450 miles long.
  • It will be HVDC, like many similar undersea power cables.
  • As the title says, it will be the first-ever UK-German energy link.

Wikipedia describes the route like this.

The cable will run between the Greystones substation on the Isle of Grain, in Kent in England to the new Fedderwarden substation in Wilhelmshaven in the Lower Saxony region of Germany. Landfall will be next to Grain Coastal Park, in Kent, and at Hooksiel, near Wilhemshaven in Germany.

Two contracts have been awarded.

  • The contract to design, manufacture, install, test and commission the 725km interconnector has been awarded to Prysmian Group.
  • The contract to design and build two converter stations in the UK and Germany has been awarded to Siemens Energy.

This sounds like a very simple plan to add an important interconnector between the UK and Germany.

I have some observations and thoughts.

The Isle Of Grain

The Isle of Grain is described in Wikipedia like this.

Isle of Grain (Old English Greon, meaning gravel) is a village and the easternmost point of the Hoo Peninsula within the district of Medway in Kent, south-east England. No longer an island and now forming part of the peninsula, the area is almost all marshland and is a major habitat for diverse wetland birds. The village constitutes a civil parish, which at the 2011 census had a population of 1,648, a net decrease of 83 people in 10 years.

Apart for the birds, over the last few decades it has been home to the following.

  • Until 1982, it was the location of a BP oil refinery.
  • In the 1990s, the isle was used to make the segments for the lining of the Channel Tunnel.
  • Following completion of the Channel Tunnel, the site is now part-occupied by Thamesport, the UK’s third largest container port.
  • Next to the former BP site is Grain Power Station, built in the 1970s, which previously burnt oil.
  • This power station was demolished in the 2015 and replaced with a 1.275 GW gas-fired power station.
  • Another major installation is a new Grain Liquefied Natural Gas (LNG) import facility, which takes heat from the gas-fired power station.
  • The Isle of Grain is the landing point for the BritNed undersea power cable between The Netherlands and the UK.

The Google Map shows the Isle of Grain.

Note.

  1. Thamesport is in the South-West corner
  2. To its North is the LNG import facility.
  3. To the North-East of Thamesport is the 735 MW Medway power station.
  4. There is a rail connection to Hoo Junction on the North Kent Line.

This second Google Map shows the Eastern side of the Isle.

Note.

  1. Grain Coastal Park, where NeuConnect will make landfall, is marked by the green arrow at the top of the map.
  2. Towards the South-Eastern corner of the map is the 1.275 GW Grain gas-fired power station.
  3. To the East of the power station, there is more switchgear than you see in a bad Frankenstein film.
  4. The smaller square at the bottom with the two white squares could be the converter station for the BritNed interconnector.

I am sure there is space on the island for a connection for NeuConnect.

There is also a total of 2.01 GW of gas-fired power stations on the Isle of Grain.

Wind Power In The Thames Estuary

This Google Map shows the Thames Estuary.

Note that the red arrow indicates the Isle of Grain.

This map from Wikipedia shows the wind farms in the area.

These are the ones that are operational.

  • 2 – East Anglia Array – 714 MW
  • 8 – Greater Gabbard – 504 MW
  • 9 – Gunfleet Sands – 184 MW
  • 13 – Kentish Flats – 140 MW
  • 15 – London Array – 630 MW
  • 27 – Thanet – 300 MW

Note.

  1. The Isle of Grain is just above the second o in London.
  2. I have ignored the Ramplion wind farm (21!), as it is too far from the Isle of Grain.
  3. This is a total of nearly 2.5 GW.

Planned extensions in the area include.

  • East Anglia Array – 3.1 GW – Completion date of 2026

But the Wikipedia entry for the East Anglia Array says this about the wind farm.

The target capacity for the entire East Anglia Zone is 7200 MW which could require up to 1200 turbines.

Could we see one of the following?

  • A connector from the East Anglia Array to the Isle of Grain.
  • One or more new wind farms in the Thames Estuary connected to the Isle of Grain.
  • German investment in a wind farm or farms connected to the Isle of Grain.

The Isle of Grain could become an island of energy providing power for London, the South-East of England, Germany and The Netherlands.

An Electrolyser On The Isle Of Grain

Consider.

  • There will be plenty of renewable electricity.
  • As there is a liquified natural gas terminal, there is plenty of gas storage.
  • One or both of the gas-fired power stations can be converted to run on hydrogen.
  • As more and more trucks are converted to hydrogen, there will be a large demand for hydrogen for heavy transport.

This must surely make a large electrolyser on the Isle of Grain a possibility.

The BritNed Interconnector

The BritNed interconnector is described like this in Wikipedia.

BritNed is a 1,000 MW high-voltage direct-current (HVDC) submarine power cable between the Isle of Grain in Kent, the United Kingdom; and Maasvlakte in Rotterdam, the Netherlands.

The BritNed interconnector would serve as a link for the foreseeable European super grid project.

Up to now, most of the electricity flow has been to the UK.

But surely, as more wind farms are developed power will flow the other way.

Wilhelmshaven Will Be A German Hub For Green Hydrogen

In Uniper To Make Wilhelmshaven German Hub For Green Hydrogen; Green Ammonia Import Terminal, I described plans by the Germans for a hydrogen hub at Wilhelmshaven.

The original story came from an article with the same name on Green Car Congress.

This is the first two paragraphs.

Under the name “Green Wilhelmshaven,” Germany-based international energy company Uniper plans to establish a German national hub for hydrogen in Wilhelmshaven and is working on a corresponding feasibility study.

Plans include an import terminal for green ammonia. The terminal will be equipped with an ammonia cracker for producing green hydrogen and will also be connected to the planned hydrogen network. A 410-megawatt electrolysis plant is also planned, which—in combination with the import terminal—would be capable of supplying around 295,000 metric tons or 10% of the demand expected for the whole of Germany in 2030.

As I said in the original post, I’m not happy about green ammonia, but the 1.4 GW NeuConnect interconnector has more than enough power to run a 410 MW electrolyser plant at full capacity.

It could even run three electrolysers of this size.

Hooksiel And Wilhelmshaven

NeuConnect will make landfall at Hooksiel.

This Google Map shows Hooksiel and Wilhelmshaven.

Note.

  1. Hooksiel is the village outlined in red.
  2. The water to the right of the map is the Jade Bight.
  3. The square block sticking out into the bight appears to be a container port.
  4. There appears to be chemical works or oil refineries North of the port.
  5. Wilhelmshaven is the town to the South of the port.

There would appear to be plenty of space for Uniper to construct Green Wilhelmshaven.

German And UK Wind Power Production

According to this page on Wikipedia, which is entitled Wind Power By Country, in 2020, these were installed wind power in various countries.

  • Germany – 62,184 MW
  • Spain – 27,089 MW
  • UK – 24,665 MW
  • France – 17,382 MW
  • Italy – 10,389 MW
  • Netherlands – 6,600 MW

In 2020 we were 37.5 GW behind Germany.

It looks like we’ll commission 3.3 GW this year and 6.1 in 2023, with Wikipedia saying that 12.9 GW is under development, which should close the gap to a certain extent.

In ScotWind Offshore Wind Leasing Delivers Major Boost To Scotland’s Net Zero Aspirations, I described how Scotland will add 15.1 GW of floating and 9.7 GW of fixed foundation offshore wind.

It looks like initially, we’ll be buying German wind-generated electricity, but in the future the direction could easily change around.

Boris And Olaf

There were mumblings from Boris, that energy was talked about in their meeting in Downing Street last week.

It does appear there is a lot of ways that the UK and Germany can co-operate in the future with respect to energy.

  • German finance can be used to build wind farms in UK waters.
  • German companies can build the turbines and the interconnectors we need to develop vast offshore wind farms.
  • We can supply surplus energy to Germany through the NeuConnect interconnector.

I wouldn’t be surprised if Boris and Olaf had signed a very comprehensive energy co-operation agreement.



April 11, 2022 Posted by | Energy, Hydrogen | , , , , , , , , , , , , , , , | 1 Comment

Aberdeen City Council And BP Sign Joint Venture Agreement To Develop City Hydrogen Hub

The title of this post, is the same as this article on Renewable Energy Magazine.

The title is a good description of the project and these are a few details.

  • Production will start in 2024.
  • The hub will produce 800 kilograms of green hydrogen per day.
  • That will be enough for 25 buses and 25 other vehicles.
  • Further investment would provide hydrogen for rail, freight and marine uses.

I don’t think this is a small project, as they are talking about potentially exporting the hydrogen.

These are a few thoughts.

Electricity Supply

In Can The UK Have A Capacity To Create Five GW Of Green Hydrogen?, I said the following.

Ryze Hydrogen are building the Herne Bay electrolyser.

  • It will consume 23 MW of solar and wind power.
  • It will produce ten tonnes of hydrogen per day.

The electrolyser will consume 552 MWh to produce ten tonnes of hydrogen, so creating one tonne of hydrogen needs 55.2 MWh of electricity.

Scaling those figures mean that to create 800 kilograms of hydrogen will need 44.16 MWh of electricity or if it is a 24/7 operation, the electrolyser will need a feed of 1.84 MW.

Currently, there are two offshore wind farms close to Aberdeen.

That would provide enough electricity to provide a starter of under 2 MW.

I can see a lot more wind farms off the coasts around Aberdeen, as on all my visits to the city it has been windy and there is a lot of empty sea.

I don’t think providing enough renewable electricity for a very large electrolyser in Aberdeen will be a problem.

Hydrogen Exports

I would expect, that the hydrogen would go to Germany, as the Germans are backing BP in their wind farm ambitions and they are building a large hydrogen import terminal at Wilhelmshaven on the North-West German coast. The distance for a ship is under 500 miles.

BP’s Future Hydrogen Plans

This is a quote from Louise Kingham CBE, BP’s UK head of country and senior vice president for Europe.

Partnering with cities and corporates as they shape their paths to net zero is a core part of BP’s strategy. BP expects to partner with 10-15 cities globally by 2030 to provide innovative, integrated, ‎and decarbonized energy solutions at scale to help them achieve their goals of net zero emissions. BP also aims to capture 10% of the low carbon hydrogen market in key geographies by 2030.

BP is investing across all the energy transition growth areas in the UK. In fact, we have committed to spend £2 in the UK for every £1 generated here out to the middle of this decade.

“Today’s announcement is evidence of that commitment in action and is supported by other ambitious plans to produce clean energy from UK offshore wind, develop carbon capture in Teesside and grow the country’s electric vehicle charging network.

BP would be in part using their expertise in providing oil and gas to the production and delivery of hydrogen to end users, be they large or small.

I can also see BP repurposing a few gas and oil production platforms into offshore hydrogen production hubs, as this could be a better financial route, rather than demolishing the platforms.

Conclusion

Birmingham is building a hydrogen hub at Tyseley Energy Park to fuel hydrogen buses and other vehicles.

Where is the plan for London’s hydrogen hubs?





March 12, 2022 Posted by | Hydrogen, Transport/Travel | , , , , , , , | 5 Comments

Uniper To Make Wilhelmshaven German Hub For Green Hydrogen; Green Ammonia Import Terminal

The title of this post, is the same as that of this article on Green Car Congress.

This is the first two paragraphs.

Under the name “Green Wilhelmshaven,” Germany-based international energy company Uniper plans to establish a German national hub for hydrogen in Wilhelmshaven and is working on a corresponding feasibility study.

Plans include an import terminal for green ammonia. The terminal will be equipped with an ammonia cracker for producing green hydrogen and will also be connected to the planned hydrogen network. A 410-megawatt electrolysis plant is also planned, which—in combination with the import terminal—would be capable of supplying around 295,000 metric tons or 10% of the demand expected for the whole of Germany in 2030.

I can’t help feeling that there is some bad thinking here.

The Wikipedia entry for ammonia, says this about green ammonia.

Even though ammonia production currently creates 1.8% of global CO2 emissions, a 2020 Royal Society report claims that “green” ammonia can be produced by using low-carbon hydrogen (blue hydrogen and green hydrogen). Total decarbonization of ammonia production and the accomplishment of net-zero targets are possible by 2050.

So why is green ammonia imported rather than green hydrogen, which may have been used to manufacture the ammonia?

Green ammonia would appear to have two main uses in its own right.

  • As a feedstock to make fertiliser and other chemicals.
  • As a possible fuel for large ships, which could also be powered by hydrogen.

The only thing, I can think of, is that as liquid hydrogen boils at -253 ° C and liquid ammonia at -33 ° C, ammonia may be easier to transport by ship.

It may make a better fuel for large ships for the same reason.

This policy briefing from The Royal Society is entitled Ammonia: Zero-Carbon Fertiliser, Fuel And Energy Store.

This is the introductory paragraph.

This policy briefing considers the opportunities and challenges associated with the manufacture and future use of zero-carbon or green ammonia.

It is an excellent explanation of green ammonia and a must read.

Hydrogen for Wilhelmshaven

On the other hand, Wilhelmshaven, which is situated on Germany’s North West Coast would be in a good position to be a terminal for a hydrogen pipeline or electrical interconnector from the Dogger Bank, where both the Netherlands and the UK have plans for some of the largest windfarms in the world.

The UK’s Dogger Bank Wind Farm, which is being developed by SSE, looks to have an initial capacity of 4.8 MW, whereas the North Sea Wind Power Hub, being developed by the Danes, Dutch and Germans on their side of the Dogger Bank could be rated at up to 110 GW.

Wikipedia says this about how the two huge projects could be connected.

The power hub would interconnect the three national power grids with each other and with the Dogger Bank Wind Farm.

We could be seeing a 200 GW power station in an area of the sea, generally only known to those who listen to the shipping forecasts and fans like Marti Caine.

Under a section in the Wikipedia entry for the North Sea Wind Power Hub, which is entitled the North Sea Wind Power Hub Consortium, these points are made.

  • It is hoped that Norway, the United Kingdom, and Belgium will join the consortium.
  • Dutch gas-grid operator Gasunie has joined the consortium, suggesting converting wind power to gas and using near offshore gas infrastructure for storage and transport.
  • The Port of Rotterdam became the fifth member of the consortium.

This looks like a party, where some of our North Sea gas fields and infrastructure, lying in the triangle of the Humber, Teesside and the Dogger Bank could add a lot of value.

We could even see hydrogen generated in the European Eastern part of the Dogger Bank, stored in a worked-out gas field in the UK sector of the North Sea and then when needed, it could be pumped to Germany.

A 410 Megawatt Electrolyser

Ryze Hydrogen are building the Herne Bay electrolyser.

  • It will consume 23 MW of solar and wind power.
  • It will produce ten tonnes of hydrogen per day.

This would produce just 5.6 percent of the hydrogen of the Wilhelmshaven electrolyser

In H2 Green Steel Plans 800 MW Hydrogen Plant In Sweden, I wrote about a 800 MW electrolyser, that would produce 380 tonnes of hydrogen per day.

It looks like the Wilhelmshaven  electrolyser is very much a middle-sized one and would produce around 65,000 tonnes per year.

Conclusion

It looks like the Germans will be importing lots of green ammonia and green hydrogen from the North Sea.

April 18, 2021 Posted by | Energy, Hydrogen | , , , , , , , , , , , | 3 Comments
