Irlam Station To Go Step-Free

This document on the Government web site is entitled Access for All: 73 Stations Set To Benefit From Additional Funding.

Irlam station is on the list.

These pictures show the station and the current subway.

The station was a total surprise, with a large pub-cafe and a lot of visitors and/or travellers sitting in the sun.

I had an excellent coffee and a very welcoming gluten-free blueberry muffin!

This Google Map shows the station.

It is one of those stations where commuters have to cross the railway either on the way to work or coming home.

So a step-free method of crossing the railway is absolutely necessary.

The Current And Future Rail Service

As the station lies conveniently between Liverpool and Warrington to the West and Manchester and Manchester Airport to the East, it must be a station with tremendous potential for increasing the number of passengers.

At the moment the service is two trains per hour (tph) between Liverpool Lime Street and Manchester Oxford Road stations.

  • Oxford Road is probably not the best terminus, as it is not on the Metrolink network.
  • When I returned to Manchester, many passengers alighted at Deansgate for the Metrolink.
  • On the other hand, Liverpool Lime Street is a much better-connected station and it is backed up by Liverpool South Parkway station, which has a connection to Merseyrail’s Northern Line.
  • The current service doesn’t serve Manchester Piccadilly or Airport stations.

A guy in the cafe also told me that two tph are not enough and the trains are oqften too short.

Merseyrail work to the same principle as the London Overground and other cities of four tph at all times and the frequency certainly draws in passengers.

Whilst I was drinking my coffee, other trains past the station.

  • One tph – Liverpool Lime Street and Manchester Airport
  • One tph – Liverpool Lime Street and Norwich

Modern trains like Northern’s new Class 195 trains, should be able to execute stops at stations faster than the elderly diesel trains currently working the route.

So perhaps, after Irlam station becomes step-free, the Manchester Airport service should call as well.

As Liverpool Lime Street station has been remodelled, I can see a time in the not too distant future, when that station can support four tph, that all stop at Irlam station.

The Manchester end of the route could be a problem, as services terminating at Oxford Road have to cross the busy lines of the Castlefield Corridor.

So perhaps all services through Irlam, should go through Deansgate, Manchester Oxford Road and Manchester Piccadilly stations to terminate either at the Airport or perhaps Stockport or Hazel Grove stations.

But would this overload the Castlefield Corridor?

Battery/Electric Trains

If you look at the route between Liverpool Lime Street and Manchester Oxford Road stations, the following can be seen.

  • Only about thirty miles between Deansgate and Liverpool South Parkway stations is not electrified.
  • The section without electrification doesn’t appear to be particularly challenging, as it is along the River Mersey.

It is my view, that the route between Liverpool and Manchester via Irlam, would be an ideal route for a battery/electric train.

A train between Liverpool Lime Street and Manchester Airport stations would do the following.

  • Run from Liverpool Lime Street station to Liverpool South Parkway station using the installed 25 KVAC overhead electrification.
  • Drop the pantograph during the stop at Liverpool South Parkway station.
  • Run from Liverpool South Parkway station to Deansgate station using battery power.
  • Raise the pantograph during the stop at Deansgate station.
  • Run from Deansgate station to Manchester Airport station, using the installed 25 KVAC overhead electrification.

The exact distance between Deansgate and Liverpool South Parkway stations is 28.2 miles or 45.3 kilometres.

In 2015, I was told by the engineer riding shotgun on the battery/electric Class 379 train, that that experimental train was capable of doing fifty kilometres on battery power.

There are at least four possible trains, that could handle this route efficiently.

  • Porterbrook’s proposed batteryFLEX train based on a Class 350 train.
  • A battery/electric train based on the seemingly unwanted Class 379 train.
  • A battery/electric version of Stadler’s Class 755 train.
  • I believe that Bombardier’s Aventra has been designed so that a battery/electric version can be created.

There are probably others and I haven’t talked about hydrogen-powered trains.

Battery power between Liverpool and Manchester via Irlam, appears to be very feasible.

Tram-Trains

As my train ran between Manchster and Irlam it ran alongside the Metrolink between Cornbrook and Pomona tram stops.

Manchester is very serious about tram-trains, which I wrote about in Could A Class 399 Tram-Train With Batteries Go Between Manchester Victoria And Rochdale/Bury Bolton Street/Rawtenstall Stations?.

Tram-trains are often best employed to go right across a city, so could the Bury tram-trains go to Irlam after joining the route in the Cornbrook area?

  • Only about thirty miles between Deansgate and Liverpool South Parkway stations is not electrified.
  • The route between Liverpool and Manchester via Irlam doesn’t look to be a very challenging line to electrify.
  • The total distance bettween Liverpool Lime Street and Manchester Victoria station is only about forty miles, which is a short distance for a tram-train compared to some in Karlsruhe.
  • Merseyrail’s Northern Line terminates at Hunts Cross station, which is going to be made step-free.
  • There is an existing step-free interchange between the Liverpool and Manchester route via Irlam and Merseyrail’s Northern Line at Liverpool South Parkway station.
  • Class 399 tram-trains will have a battery capability in South Wales.
  • Class 399 tram-trains have an operating speed of 62 mph, which might be possible to increase.
  • Stadler make Class 399 tram-trains and are building the new Class 777 trains for Merseyrail.

I think that Stadler’s engineers will find a totally feasible and affordable way to link Manchester’s Metrolink with Liverpool Lime Street station and Merseyrail’s Northern and Wirral Lines.

I can envisage the following train service running between Liverpool and Manchester via Irlam.

  • An hourly service between Liverpool Lime Street and Nottingham, as has been proposed for the new East Midlands Franchise.
  • A four tph service between Liverpool Lime Street and Manchester Airport via Manchester Piccadilly.
  • A tram-train every ten minutes, linking Liverpool Central and Manchester’s St Peter’s Square.
  • Tram-trains would extend to the North and East of Manchester as required.
  • All services would stop much more comprehensively, than the current services.
  • Several new stations would be built.
  • In the future, the tram-trains could have an interchange with High Speed Two at Warrington.

Obviously, this is just my speculation, based on what I’ve seen of tram-train networks in Germany.

The possibilities for the use of tram trains are wide-ranging.

Installing Step-Free Access At Irlam Station

There would appear to be two ways of installing step-free access at Irlam station.

  • Add lifts to the existing subway.
  • Add a separate bridge with lifts.

These are my thoughts on each method.

Adding Lifts To The Existing Subway

Consider.

  • The engineering would not be difficult.
  • Installaton would probably take a number of weeks.
  • There is good contractor access on both sides of the railway.

There are similar successful step-free installations around the UK

The problem is all about, how you deal with passengers, whilst the subway is closed for the installation of the lifts.

Adding A Separate Bridge With Lifts

Consider.

  • There is a lot of space at both the Eastern and Western ends of the platform to install a new bridge.
  • Adding a separate bridge has the big advantage, that during the installation of the bridge, passengers can use the existing subway.
  • Once the bridge is installed, the subway can be refurbished to an appropriate standard.

Passengers will probably prefer the construction of a new bridge.

In Winner Announced In The Network Rail Footbridge Design Ideas Competition, I wrote how the competition was won by this bridge.

So could a factory-built bridge like this be installed at Irlam station?

There is certainly space at both ends of the platform to install such a bridge and the daily business of the station and its passengers would be able to continue unhindered, during the installation.

I’m also sure, that the cafe would be happy to provide the daily needs of the workforce.

Conclusion

From a station and project management point-of-view, adding a new factory-built bridge to Irlam station is the easiest and quickest way to make the station step-free.

It also appears, that Network Rail have made a wise choice in deciding to put Irlam station on their list of stations to be made step-free, as the station could be a major part in creating a new high-capacity route between Liverpool and Manchester.

This could also be one of the first stations to use an example of the new bridge.

  • Installation would be quick and easy.
  • There is no site access problems.
  • There station can remain fully open during the installation.
  • All stakeholders would probably be in favour.

But above all, it would be a superb demonstration site to bring those from stations, where Network Rail are proposing to erect similar bridges.

July 6, 2019 Posted by | Transport | , , , , , , , , , , , | Leave a comment

A Trip Around The West Midlands

Today, I did a trip around the West Midlands, using five different trains.

Tain 1 – 19:10 – Chiltern – London Marylebone To Leamington Spa

This was one of Chiltern’s rakes of Mark 3 coaches hauled by a Class 68 locomotive.

I like these trains.

  • They are comfortable.
  • Everybody gets a table and half sit by a big window.
  • There is more space than Virgin Train’s Class 390 trains.
  • They may be slower, but they are fast enough for most journeys I make.

The train arrived seven minutes late at Leamington Spa at 11:32.

Train 2 – 12:02 – West Midlands Trains – Leamington Spa To Nuneaton

This is a new West Midlands Trains service, via the new station at Kenilworth and Coventry.

The trains are Class 172 trains, that used to run on the Gospel Oak to Barking Line.

Note.

  1. The have been repainted and refreshed.
  2. The seat cover on the driver’s seat is a relic of the London Overground.
  3. The train now has a toilet.

The train was about half-full and I got the impression, that the new service had been well-received.

The train arrived on time at Nuneaton at 12:38.

Train 3 – 12:54 – West Midlands Trains – Nuneaton to Rugeley Trent Valley

The train was a Class 350 train and it arrived eight minutes late at 13:29.

These pictures show Rugeley Trent Valley station.

It is very minimal with just a shelter, a basic footbridge and no information on how or where to buy a ticket.

Passengers deserve better than this!

Train 4 – 13:43 – West Midlands Trains – Rugeley Trent Valley to Birmingham New Street

This is a new West Midlands Trains electric service.

Compared to the Leamington Spa to Nuneaton service, passengers were spread rather thinly in the train.

The train was a Class 350 train and it arrived five minutes late at 14:44.

Train 5 – 15:55 – Chiltern – Birmingham Moor Street to London Marylebone

Another comfortable Chiltern Railways train back to London, which arrived four minutes late at 17:47.

Customer Service

Customer service and especially that from West Midlands Trains was rather patchy.

  • Leamington Spa station was rebuilding the entrance, but staff were around.
  • Nuneaton station was very quiet.
  • Rugeley Trent Valley station needs a lot of improvement.
  • The two Birmingham City Centre stations were much better.

I actually had to travel ticketless from Rugeley Trent Valley to Birmingham New Street, as the Conductor on the train didn’t check the tickets.

But Virgin Trains were very professional at Birmingham New Street.

Service Pattern

I have some observations on the service patterns.

  • For comfort reasons, I would prefer that Chiltern ran Mark 3 coaches and Class 68 locomotives on all Birmingham services.
  • In the future, it looks like Leamington Spa and Nuneaton needs at least a half-hourly service.
  • There definitely needs to be more services on the Chase Line.

There also is a serious need for staff and better facilities at Rugeley Trent Valley station.

No-one even a hardened member of the SAS would want to spend thirty minutes changing trains there on a blustery and cold winter’s day.

Conclusion

I tried two new services today, that started on the May 2019 timetable change.

  • A diesel service between Leamington Spa and Nuneaton via Kenilworth and Coventry.
  • An electrified service between Rugeley Trent Valley and Birmingham New Street.

The first would appear to be what passengers want, but the second needs a bit of promoting.



May 24, 2019 Posted by | Transport | , , , , , , , , | Leave a comment

Thoughts On A Battery/Electric Train With Batteries And Capacitors

I’m going to use a Class 350/2 train as the example.

In Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion, I calculated the kinetic energy of one of these trains at various speeds.

Wikipedia gives this information.

  • Maximum Speed – 100 mph
  • Train Weight – 175.5 tonnes
  • Capacity – Around 380 passengers

If I assume each passenger weighs 90 Kg with baggage, bikes and buggies, the train weight is 209.7 tonnes.

This weight could be a bit high, bnut then the train must perform even when crush-loaded.

Using Omni’s Kinetic Energy Calculator, I get the following kinetic energies at various speeds.

  • 80 mph – 37.2 kWh
  • 90 mph – 47.1 kWh
  • 100 mph – 58.2 kWh
  • 110 mph – 70.4 kWh

In the video shown in A Must-Watch Video About Skeleton Technologies And Ultracapacitors., Taavi Madiberk of Skeleton Technologies likens a capacitor/battery energy store with Usain Bolt paired with a marathon runner. Usain would handle the fast energy transfer of braking and acceleration, with the marathon runner doing the cruising.

This would seem to be a good plan, as the capacitors  could probably quickly store the regenerative braking energy and release it at a high rate to accelerate the train.

Once, up to operating speed, the lithium-ion batteries would take over and keep the train at the required speed.

Obviously, it would be more complicated than that and the sophisticated control system would move electricity about to keep the train running efficiently and to maximum range.

The capacitors should probably be sized to handle all the regenerative braking energy, so for a 100  mph train, which would have a kinetic energy of 58.2 kWh, a 100 kWh capacitor would probably be large enough.

In some ways the lithium-ion batteries can be considered to be a backup to the capacitors.

  • They provide extra power where needed.
  • If during deceleration, the capacitors become full, energy could be transferred to the lithium-ion batteries.
  • If after acceleration, the capacitors have got more energy than they need, it could be transferred to the lithium-ion batteries.
  • The lithium-ion batteries would probably power all the hotel services, like air-con, lights doors etc.  of the train.

Note that the energy transfer between the capacitors and the lithium-ion batteries should be very fast.

A good Control Engineer could have a lot of fun with sorting the trains control system.







November 11, 2018 Posted by | Transport | , , , | Leave a comment

How Do Porterbrook’s Battery/FLEX Trains Compare With Eversholt’s Hydrogen-Powered Trains?

In the two green corners of this ultra-heavyweight fight to provide electric trains for rail routes without electrification, there are two ROSCOs or rolling stock operating companies.

Eversholt Rail Group

Eversholt Rail Group‘s product is the Class 321 Hydrogen, which is an upgrade of a Class 321 train with batteries and hydrogen-power.

Porterbrook

Porterbrook‘s product is the Class 350 Battery/FLEX, which is an upgrade of a Class 350 train with batteries.

How Do The Two Trains Compare?

I will list various areas and features in alphabetical order.

Age

The Class 350 trains date from 2008-2009 and others were introduced to the UK rail network as early as 2004.

The Class 321 trains date from the 1990s, but that shouldn’t be too  much of a problem as they are based on the legendary Mark 3 Coach.

Scores: Porterbrook 4 – Eversholt 3

Batteries And Supercapacitors

This is an area, where the flow of development and innovation is very much in favour of both trains.

Currently, a 1000 kWh battery would weigh about a tonne. Expect the weight and volume to decrease substantially.

Scores: Porterbrook 5 – Eversholt 5

Battery Charging – From Electrification

No problem for either train.

Scores: Porterbrook 5 – Eversholt 5

Battery Charging – From Rapid Charging System

I believe that a third-rail based rapid charging system can be developed for battery/electric trains and I wrote about this in Charging Battery/Electric Trains En-Route.

No problem for either train.

Scores: Porterbrook 5 – Eversholt 5

Development And Engineering

Fitting batteries to rolling stock has now been done successfully several times and products are now appearing with 400 kWh and more energy storage either under the floor or on the roof of three and four-car electrical multiple units.

I feel that adding batteries, supercapacitors or a mixture of both to typical UK electric multiple units is now a well-defined process of engineering design and is likely to be achieved without too much heartache.

It should be noted, that the public test of the Class 379 BEMU train, was a rare rail project, where the serious issues found wouldn’t even fill a a thimble.

So I have no doubt that both trains will get their batteries sorted without too much trouble.

I do feel though, that adding hydrogen power to an existing UK train will be more difficult. It’s probably more a matter of space in the restricted UK loading gauge.

Scores: Porterbrook 5 – Eversholt 3

Electrification

Both types of train currently work on lines equipped with 25 KVAC overhead electrification, although other closely-related trains have the ability to work on 750 VDC third-rail electrification.

Both trains could be converted to work on both systems.

Scores: Porterbrook 5 – Eversholt 5

Interiors

The interior of both trains will need updating, as the interiors reflect the period, when the trains were designed and built.

Eversholt have already shown their hand with the Class 321 Renatus.

The interiors is a design and refurbishment issue, where train operating companies will order the trains and a complimentary interior they need, for the routes, where they intend to run the trains.

Scores: Porterbrook 5 – Eversholt 5

Operating Speed

Both trains in their current forms are 100 mph trains.

However some versions of the Class 350 trains have been upgraded to 110 mph, which allows them to work faster on busy main lines and not annoy 125 mph expresses.

I am pretty sure that all Class 350 trains can be 110 mph trains.

Scores: Porterbrook 5 – Eversholt 4

Public Perception

The public judge their trains mainly on the interiors and whether they are reliable and arrive on time.

I’ve talked to various people, who’ve used the two scheduled battery/electric services, that have run in the UK.

All reports were favourable and I heard no tales of difficulties.

In my two trips to Hamburg, I didn’t get a ride on the Coradia iLint hydrogen-powered train, but I did talk to passengers who had and their reactions were similar to those who travelled to and from Harwich in the UK.

I rode on the Harwich train myself and just like Vivarail’s Class 230 train, which I rode in Scotland, it was impressive.

I think we can say, that the concept and execution of battery/electric or hydrogen-powered trains in the UK, will be given a fair hearing by the general public.

Scores: Porterbrook 5 – Eversholt 5

Range Without Electrification

Alstom talk of ranges of hundreds of miles for hydrogen trains.and there is no reason to believe that the Class 321 Hydrogen trains will not be capable of this order of distance before refuelling.

Bombardier, Vivarail and others talk of battery ranges in the tens of miles before a recharge is needed.

The game-changer could be something like the technique for charging electric trains, I outlined in Charging Battery/Electric Trains En-Route.

This method could give battery trains a way of topping up the batteries at station stops.

Scores: Porterbrook 3 – Eversholt 5

Conclusion

The total scores are level at forty-seven.

All those, who say that I fiddled it, not to annoy anybody are wrong.

The level result surprised me!

I feel that it is going to be an interesting engineering, technical and commercial battle between the two ROSCOs, where the biggest winners could be the train operating companies and the general public.

I wouldn’t be surprised to see two fleets of superb trains.



November 4, 2018 Posted by | Transport | , , , , , , , , | 2 Comments

Could Electric Trains Run On Long Scenic And Rural Routes?

In the UK we have some spectacular scenic rail routes and several long rural lines.

Basingstoke And Exeter

The West of England Main Line is an important rail route.

The section without electrification between Basingstoke and Exeter St. Davids stations has the following characteristics.

  • It is just over one hundred and twenty miles long.
  • There are thirteen intermediate stations, where the expresses call.
  • The average distance between stations is around nine miles.
  • The longest stretch between stations is the sixteen miles between Basingstoke and Andover stations.
  • The average speed of trains on the line is around forty-four mph.

There is high quality 750 VDC third-rail electrification at the London end of the route.

Cumbrian Coast Line

The Cumbrian Coast Line  encircles the Lake District on the West.

The section without electrification between Carnforth and Carlisle stations has the following characteristics.

  • It is around a hundred and fourteen miles long.
  • There are twenty-nine intermediate stations.
  • The average distance between stations is around four miles.
  • The longest stretch between stations is the thirteen miles between Millom and Silecroft stations.
  • The average speed of trains on the line is around thirty-five mph.

There is also high standard 25 KVAC electrification at both ends of the line.

Far North Line

The Far North Line is one of the most iconic rail routes in the UK.

The line has the following characteristics.

  • It is one-hundred-and-seventy-four miles long.
  • There are twenty-three intermediate stations.
  • The average distance between stations is around seven miles.
  • The longest stretch between stations is the thirteen miles between Georgemas Junction and Wick stations.
  • The average speed of trains on the line is around forty mph.

The line is without electrification and there is none nearby.

Glasgow To Oban

The West Highland Line is one of the most iconic rail routes in the UK.

The line is without electrification from Craigendoran Junction, which is two miles South of Helensburgh Upper station  and the section to the North of the junction, has the following characteristics.

  • It is seventy-eight miles long.
  • There are ten intermediate stations.
  • The average distance between stations is around eight miles.
  • The longest stretch between stations is the twelve miles between Tyndrum Lower and Dalmally stations.
  • The average speed of trains on the line is around thirty-three mph.

From Glasgow Queen Street to Craigendoran Junction is electrified with 25 KVAC overhead wires.

Glasgow To Mallaig

This is a second branch of the West Highland Line, which runs between Crianlarich and Mallaig stations.

  • It is one hundred and five miles long.
  • There are eighteen intermediate stations.
  • The average distance between stations is around five miles.
  • The longest stretch between stations is the twelve miles between Bridge Of Orchy and Rannoch stations.
  • The average speed of trains on the line is around twenty-five mph.

Heart Of Wales Line

The Heart of Wales Line is one of the most iconic rail routes in the UK.

The line is without electrification and the section between Swansea and Shrewsbury stations, has the following characteristics.

  • It is just over one hundred and twenty miles long.
  • There are thirty-one intermediate stations.
  • The average distance between stations is around four miles.
  • The longest stretch between stations is the thirteen miles between Shrewsbury and Church Stretton stations.
  • The average speed of trains on the line is just under forty mph.

There is also no electrification at either end of the line.

Settle And Carlisle

The Settle and Carlisle Line is one of the most iconic rail routes in the UK.

The section without electrification between Skipton and Carlisle stations has the following characteristics.

  • It is just over eighty miles long.
  • There are thirteen intermediate stations.
  • The average distance between stations is around six miles.
  • The longest stretch between stations is the sixteen miles between Gargrave and Hellifield stations.
  • The average speed of trains on the line is around forty mph.

There is also high standard 25 KVAC electrification at both ends of the line.

Tyne Valley Line

The Tyne Valley Line is an important route between Carlisle and Newcastle stations.

The line is without electrification has the following characteristics.

  • It is just over sixty miles long.
  • There are ten intermediate stations.
  • The average distance between stations is around six miles.
  • The longest stretch between stations is the sixteen miles between Carlisle and Haltwhistle stations.
  • The average speed of trains on the line is around mph.

There is also high standard 25 KVAC electrification at both ends of the line.

A Pattern Emerges

The routes seem to fit a pattern, with very similar characteristics.

Important Local Transport Links

All of these routes are probably important local transport links, that get children to school, many people to large towns for shopping and entertainment and passengers of all ages to see their friends and relatives.

Many would have been closed but for strong local opposition several decades ago.

Because of the overall rise in passengers in recent years, they are now relatively safe for a couple of decades.

Iconic Routes And Tourist Attractions

Several of these routes are some of the most iconic rail routes in the UK, Europe or even the world and are tourist attractions in their own right.

Some of these routes are also, very important in getting tourists to out-of-the-way-places.

Lots Of Stations Every Few Miles

The average distance between stations on all lines seems to be under ten miles in all cases.

This surprised me, but then all these lines were probably built over a hundred years ago to connect people to the expanding railway network.

The longest stretch between two stations appears to be sixteen miles.

Diesel Hauled

All trains seem to be powered by diesel.

This is surely very inappropriate considering that some of the routes go through some of our most peaceful and unspoilt countryside.

Inadequate Trains

Most services are run by trains, that are just too small.

I know to put a four-car train on, probably doubles the cost, but regularly as I explore these lines, I find that these two-car trains are crammed-full.

I once inadvertently took a two-car Class 150 train, that was on its way to Glastonbury for the Festival. There was no space for anything else and as I didn’t want to wait an hour for the next train, I just about got on.

Passengers need to be encouraged to take trains to rural events, rather than discouraged.

An Electric Train Service For Scenic And Rural Routes

What would be the characteristics of the ideal train for these routes?

A Four-Car Electric Train

Without doubt, the trains need to be four-car electric trains with the British Rail standard length of around eighty metres.

Dual Voltage

To broaden the applications, the trains should obviously be capable of running on both 25 KVAC overhead and 750 VDC third-rail electrification.

100 mph Capability

The trains should have at least a 100 mph capability, so they can run on main lines and not hold up other traffic.

No Large Scale Electrification

Unless there is another reason, like a freight terminal, quarry, mine or port, that needs the electrification, using these trains must be possible without any large scale electrification.

Battery, Diesel Or Hydrogen Power

Obviously, some form of power will be needed to power the trains.

Diesel is an obvious no-no but possibly could only be used in a small way as emergency power to get the trains to the next station, if the main power source failed.

I have not seen any calculations about the weight, size and power of hydrogen powered trains, although there have been some professional videos.

But what worries me about a hydrogen-powered train is that it still needs some sizeable batteries.

So do calculations indicate that a hydrogen-powered train is both a realisable train and that it can be produced at an acceptable cost?

Who knows? Until, I see the maths published in a respected publication, I will reserve my judgement.

Do Bombardier know anything?

In the July 2018 Edition of Modern Railways, there is an article entitled Bi-Mode Aventra Details Revealed.

A lot of the article takes the form of reporting an interview with Des McKeon, who is Bombardier’s Commercial Director and Global Head of Regional and Intercity.

This is a paragraph.

However, Mr McKeon said his view was that diesel engines ‘will be required for many years’ as other power sources do not yet have the required power or efficiency to support inter-city operation at high-speeds.

As Bombardier have recently launched the Talent 3 train with batteries that I wrote about in Bombardier Introduces Talent 3 Battery-Operated Train, I would suspect that if anybody knows the merits of hydrogen and battery power, it is Mr. McKeon.

So it looks like we’re left with battery power.

What could be a problem is that looking at all the example routes is that there is a need to be able to do station-to-station legs upwards of thirteen-sixteen miles.

So I will say that the train must be able to do twenty miles on battery power.

How Much Battery Capacity Should Be Provided On Each Train?

In Issue 864 of Rail Magazine, there is an article entitled Scotland High Among Vivarail’s Targets for Class 230 D-Trains, where this is said.

Vivarail’s two-car battery units contains four 100 kWh lithium-ion battery rafts, each weighing 1.2 tonnes.

If 200 kWh can be placed under the floor of each car of a rebuilt London Underground D78 Stock, then I think it is reasonable that up to 200 kWh can be placed under the floor of each car of the proposed train.

As it would be required that the train didn’t regularly run out of electricity, then I wouldn’t be surprised to see upwards of 800 kWh of battery installed in the train.

n an article in the October 2017 Edition of Modern Railways, which is entitled Celling England By The Pound, Ian Walmsley says this in relation to trains running on the Uckfield Branch, which is not very challenging.

A modern EMU needs between 3 and 5 kWh per vehicle mile for this sort of service.

So if we are aiming for a twenty mile range from a four-car train with an 800 kWh battery, this means that any energy consumption better than 10 kWh will achieve the required range.

Regular Charging At Each Station Stop

In the previous section, I showed that the proposed train with a full battery could handle a twenty mile leg between stations.

But surely, this means that at every stop, the electricity used on the previous leg must be replenished.

In Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion, I calculated the kinetic energy of a four-car Class 350 train, with a full load of passengers, travelling at ninety mph, as 47.1 kWh.

So if the train is travelling at a line speed of ninety mph and it is fitted with regenerative braking with an efficiency of eighty percent, 9.4 kWh of energy will be needed for the train to regain line speed.

There will also be an energy consumption of between 3 kWh and 5 kWh per vehicle per mile.

For the proposed four-car train on a twenty mile trip, this will be between 240 and 400 kWh.

This will mean that between 240 and 400 kWh will need to be transferred to the train during a station stop, which will take one minute at most.

I covered en-route charging fully in Charging Battery/Electric Trains En-Route.

I came to this conclusion.

I believe it is possible to design a charging system using proven third-rail technology and batteries or supercapacitors to transfer at least 200 kWh into a train’s batteries at each stop.

This means that a substantial top up can be given to the train’s batteries at stations equipped with a fast charging system.

New Or Refurbished Trains?

New trains designed to meet the specification, could obviously be used.

But there are a several fleets of modern trains, which are due to be replaced. These trains will be looking for new homes and could be updated to the required battery/electric specification.

  • Greater Anglia – 30 x Class 379 trains.
  • Greater Anglia – 26 x Class 360 trains.
  • London North Western Railway – 77 x Class 350 trains.
  • TransPennine Express – 10 x Class 350 trains

In Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion, I describe Porterbrook’s plans to convert a number of Class 350 trains to battery/electric trains.

These Class 350 Battery/FLEX trains should meet the specification needed to serve the scenic and rural routes.

Conclusion

I am led to the conclusion, that it will be possible to design a battery/electric train and charging system, that could introduce electric trains to scenic and rural routes all over the UK, with the exception of Northern Ireland.

But even on the island of Ireland, for use both North and South of the border, new trains could be designed and built, that would work on similar principles.

I should also say, that Porterbrook with their Class 350 Battery/FLEX train seem to have specfied a train that is needed. Pair it with the right charging system and there will be few no-go areas in mainland UK.

November 2, 2018 Posted by | Transport | , , , , , , , , , , | 2 Comments

Could A Class 450 Battery/FLEX Train Be Used Between Waterloo And Exeter?

When I wrote Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion, Issue 864 of Rail Magazine hadn’t been published. The magazine contained details of Vivarail’s proposed rapid charging facility, which I wrote about in Charging A Battery-Powered Class 230 Train.

Consequently, at the time, I came to the conclusion that a Class 450 train with a Battery/FLEX conversion, similar to Porterbrook’s one for a Class 350 train, couldn’t stretch between Waterloo and Exeter, as it was just too far.

But Vivarail’s proposed rapid charging facility could change everything!

The West of England Main Line is electrified as far as Basingstoke station, from where the route is worked excursively by diesel Class 159 trains.

Between Basingstoke and Exeter St. Davids stations, the trains make fourteen stops.

  • Most station stops,take up to a minute, but could take longer if say the train is busy or there’s a passenger in a wheelchair.
  • The train stops at Salisbury for four minutes, possibly to allow loading and unloading of catering trolleys.
  • The distances between stations range between a few and eighteen miles.
  • In Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion, I said that if a 400 kWh battery were to be fitted to a Class 350/2 train, that this would give a range between twenty and fifty miles.
  • The Class 350 and South Western Railway’s Class 450 trains are the same basic Siemens Desiro train, although the Class 350 train uses 25 KVAC overhead electrification and the Class 450 train uses 750 VDC third-rail electrification.

It would appear that if the train could be charged at each station, it should be able to hop all the way between Basingstoke and Exeter St. Davids stations.

Using a traditional charger, where the train would have to be physically plugged into the charger, wouldn’t be possible in the short station stops on the route.

Even raising a pantograph to connect to a 25 KVAC overhead line would be slow and could distract the driver, whilst they were doing more important things.

But Vivarail’s proposed rapid charging facility, which I am sure is automatic would give the battery a top-up without any driver intervention.



The charging system would have a third rail on the opposite side of the track to the platform, as in this picture of Kidbrooke station.

The third-rail would be.

  • Short enough to be shielded by a train stopping on top.
  • Long enough to connect to at least two contact shoes on the train.
  • Automatically earthed, when no train is present and connected.

This would be the sequence, as a train stopped in a station.

  • The driver would stop the train at the defined place in the platform, as thousands of train drivers do all over the world, millions of times every day.
  • Once stopped, the contact shoes on the train would be in contact with the third rail, as they would be permanently down, as they are when running on third-rail electrification.
  • The charging system would detect the stationary train and that the train was connected, and switch on the power supply. to the third-rail.
  • Electricity would flow from the track to the batteries, just as if the train was on a standard third-rail electrified track.
  • If the battery should become full, the train’s system could stop the charging.
  • When passengers had finished leaving and joining the train and it was safe to do so, the driver would start the train and drive it to the next station.
  • When the charging system determined that the train was moving or that the contact shoe was no longer connected to the third-rail, it would immediately cut the power to the rail and connect it to earth.

It is a brilliant system; simple, efficient and fail-safe.

  • Regenerative braking will mean that stopping in the station will help to top-up the batteries.
  • The battery on the train is being charged, as long as it is stationary in the station.
  • Delays in the station have no effect on the charging, except to allow it for longer if the battery can accept more charge.
  • The driver concentrates on driving the train and doesn’t have to do anything to start and stop the charging.
  • The charging system never exposes a live rail to passengers and staff.

The charging system may also help recovery after an incident.

Suppose a fallen tree or a herd of cows has blocked the line and the electricity used to power the train’s systems has used a lot of battery power, so that when the train eventually gets to the next station, the battery needs a long charge before continuing.

The driver would just wait in the station, charging the battery, until there is enough energy to safely proceed.

A Look At The Mathematics

I shall now look at the mathematics of a leg between Basingstoke and Andover stations.

I will assume the following.

  • The train will leave the electrification at Basingstoke with a full battery, containing 400 kWh of electricity, as it will have been charged on the way from Waterloo.
  • The train is running at an operating speed of up to 90 mph between stations where possible, which means it has a kinetic energy of 47.1 kWh.
  • For each mile, the train consumes 8 kWh of electricity, to power the trains services and maintain the required speed.
  • Regenerative braking is eighty percent efficient.

As Basingstoke to Andover is eighteen miles, this means that energy consumption in the leg and the stop at Andover is as follows.

  • 144 kWh is used to power the train and maintain speed.
  • 9.42 kWh is lost in the braking and acceleration back to operating speed..

So the train will lose about 154 kWh on the eighteen mile leg.

I have built an Excel spreadsheet of the route and it looks that if a minimum of 100 kWh can be transferred to the train’s battery at each stop and the train uses no more than 8 kWh per mile, that it should be possible for the train to go from Basingstoke to Exeter on battery power.

Obviously, there are ways to make this journey more certain.

  • Reduce the train’s energy consumption for items like lighting and air-conditioning..
  • Improve the efficiency of regenerative braking.
  • Improve the charging systems, so more electricity is transferred in the short stops.
  • Improve the track, so that it is as smooth as possible with gentle curves.
  • Fit a larger battery.

It requires different teams of engineers to optimise their own area, so all contribute to a more energy-efficient system.

Would Battery Power Work If The Line Speed Was Increased to 100 mph?

I have done this calculation assuming an operating speed of 100 mph, rather than the current 90 mph determined in part by the maximum speed of the Class 159 trains and it appears to be still possible.

Could 100 kWh Be Transferred To The Train In The Short Stops?

In Station Dwell Times On The London Overground, I showed that the London Overground regularly has station stops of under thirty seconds.

Even to me, as an trained Electrical Engineer, 100 kWh does seem a lot of power to transfer to the train in a stop that is that short.

In the related post, I postulated that a thirty-second dwell time, means that the only way to connect the train to the rapid charging system is to use third-rail electrification, as this connects and disconnects automatically.

This was said about Vivarail’s charging system in Issue 864 of Rail Magazine.

The rapid charging concept consists of a shipping container of batteries that are trickle charged from a mains supply. When a Class 230 sits over the short sections of third-rail, electricity can be quickly transferred to the train’s batteries. When the train is away, the power rails are earthed to ensure they pose no risk The concept provides for charging a Class 230 as it pauses at a terminus before making its return journey.

The key is the battery-to-battery transfer of electricity, as batteries have a low impedance and are designed to supply high electrical currents for a short time, as when starting a massive diesel engine in a truck.

This page shows a 12v 250Ah battery available for just over three hundred pounds.

  • This battery alone has a capacity of 3 kWh.
  • It is 518mm x 273mm x 240mm.
  • It weighs 61 Kg.

You’d get a lot of these in a twenty-foot shipping container, which according to Wikipedia has a volume of 33.2 m³.

I estimate that a hundred of these batteries would fit easily into the container with all their control gear and electronics, which would mean a total capacity of 300 kWh.

Running my Excel spreadsheet with a 200 kWh transfer at each station, shows that the train can leave many stations with a full battery.

I have also run a more difficult scenario.

  • For each mile, the train consumes 10 kWh of electricity instead of 8 kWh, to power the trains services and maintain the required speed.
  • The rapid charging system can only transfer 80 kWh in thirty seconds.

The train still appears to get to its destination.

Obviously, Porterbrook, Siemens and Vivarail have better data than I have and will know what the actual performance of their trains and systems are.

How Much Power Can The Third-Rail Handle?

It should also be noted that a Class 450 train has eight x 250 kW traction motors, so the third-rail system of the train, must be capable of handling all of these at full power, when running on lines with third-rail electrification.

Would One Charging System Handle Both Tracks?

The route is double-track, with often platforms on either side of the tracs.

This Google Map shows Gillingham station, which appears to have a typical layout.

Note the three-car Class 159 train in the station.

If both tracks were to have a charging rail, I can’t see why one set of batteries shouldn’t be able to feed both tracks with separate control systems.

Although it does appear that several stations often use the same platforms for both directions.

Conclusion

This could be a very affordable way of electrifying a line with a lot of stations.



October 26, 2018 Posted by | Transport | , , , , , , , | 1 Comment

Flirt Akku Battery Multiple-Unit Unveiled

The title of this post is the same as that of this article in Railway Gazette International.

This is the first paragraph.

Stadler has officially unveiled the prototype Flirt Akku, a version of its Flirt family of electric multiple-units which is equipped with a battery to permit operation on non-electrified or partly-electrified routes.

So it looks like another train with batteries, that joins the following, that have been announced in recent months.

There are also several projects using MTU Hybrid Power Packs.

What new projects will emerge in the next couple of years?

October 26, 2018 Posted by | Transport | , , , , , , , , | 3 Comments

Porterbrook Makes Case For Battery/Electric Bi-Mode Conversion

The title of this post is the same as that of this article on Global Rail News.

This is the first paragraph.

Rolling stock leasing company Porterbrook is working on a prototype battery/electric bi-mode Class 350/2 to demonstrate the technology’s viability to train operators.

So why would you fit batteries to an electric train like a Class 350 train?

Range Extension

An appropriately-sized battery can be used to power the train on an extension or branch line without electrification.

The classic route in London is the Barking Riverside Extension of the Gospel Oak to Barking Line.

Until someone says otherwise, I believe this short route will be built without electrification and the Class 710 trains will run on this route using stored battery power.

In my article in Issue 856 of Rail Magazine, I said this.

London is also designing and building another rail line, which will be used only by Aventras – The Barking Riverside Extension of the Gospel Oak and Barking Line.

I have read all of the published Transport for London documents about this extension and although electric trains are mentioned, electrification is not!

The extension is only a mile of new track and trains could leave the electrified c2c line with full batteries.

It would not be difficult to go to Barking Riverside and back on stored power.

Benefits would include.

  • Less visual and audible intrusion of the new railway.
  • Simpler track and station design.
  • It might be easier to keep the railway at a safe distance from all the high voltage electricity lines in the area, that bring power to London.
  • A possibly safer and more reliable railway in extreme weather.
  • Costs would be saved.

No-one has told me, I’ve got it wrong.

Handling Regenerative Braking Energy

Normally, the energy generated by regenerative braking is returned through the overhead wires or third-rail  to power nearby trains.

This does save energy, but it does have drawbacks.

  • What happens if there are no nearby trains?
  • The transformers and systems that power the track are more complicated and more expensive.

As trains slow and accelerate continuously, would it not be better if regenerative energy could be used to accelerate the train back up to line speed?

The train would need an intelligent control system to decide whether to use power from the electrification or the batteries.

In my view, a battery on the train is the obvious way to  efficiently handle the energy from regenerative braking.

Handling Power Failures

Electrification failures do occur for a number of reasons.

If trains have an alternative power supply from a battery, then the driver can move the train to perhaps the next station, where the train can be safely evacuated.

I believe that Crossrail uses battery power for this purpose.

Electrically Dead Depots And Sidings

Depots and sidings can be dangerous places with electricity all over the place.

If trains can be moved using stored energy, then safer depots and sidings can be designed.

Remote Wake-Up

We’ve all got up early in the morning, to drive to work on a cold day.

One train driver told me, there was no worse start to the day, than picking up the first train from sidings in the snow.

I discuss, remote wake-up fully in Do Bombardier Aventras Have Remote Wake-Up?.

I suspect to do this reliably needs a battery of a certain size.

How Big Should The Batteries Be?

It is my belief, that the batteries on an electric train, must be big enough to handle the energy generated if a full-loaded train stops from maximum speed.

If we take the Class 350/2 train, as owned by Porterbrook, Wikipedia gives this information.

  • Maximum Speed – 100 mph
  • Train Weight – 175.5 tonnes
  • Capacity – Around 380 passengers

If I assume each passenger weighs 90 Kg with baggage, bikes and buggies, the train weight is 209.7 tonnes.

This could be a bit high, but if you’ve been on one of TransPennine’s Class 350 trains, you might think it a bit low.

Using Omni’s Kinetic Energy Calculator, I get the following kinetic energies at various speeds.

  • 60 mph – 20.9 kWh
  • 70 mph – 28.5 kWh
  • 80 mph – 37.2 kWh
  • 90 mph – 47.1 kWh
  • 100 mph – 58.2 kWh
  • 110 mph – 70.4 kWh
  • 120 mph  83.6 kWh

I have added the unrealistic 120 mph figure, to show how the amount of energy rises with the square of the speed.

As it would be advantageous for trains to run at 110 mph, the batteries must always have the capacity to handle at least 70.4 kWh, so perhaps 100 kWh would be a good minimum size.

How Much Battery Capacity Could Be Fitted Under A Train?

Wikipedia doesn’t give the formation of a Class 350 train, but it does give that of the similar third-rail version of the train; the Class 450 train.

  • DMSO(A)
  • TCO
  • TSO
  • DMSO(B)

Which is two identical Driver Motor Cars with two Trailer Cars in the middle. Looking at a Class 350 train in Euston, they appear to have a similar formation.

This page on the Vivarail web site is entitled Battery Train Update.

This is a paragraph.

Battery trains are not new but battery technology is – and Vivarail is leading the way in new and innovative ways to bring them into service. 230002 has a total of 4 battery rafts each with a capacity of 106 kWh and requires an 8 minute charge at each end of the journey. With a 10 minute charge this range is extended to 50 miles and battery technology is developing all the time so these distances will increase.

So it looks like Vivarail manage to put 212 kWh under each car of their two-car train.

This article on the Railway Gazette is entitled Battery-Powered Desiro ML Cityjet Eco Unveiled.

This is an edited version of the first two paragraphs.

An electric multiple-unit equipped with a prototype electric-battery hybrid drive system designed to enable through running onto non-electrified lines was unveiled by Siemens and Austrian Federal Railways in Wien on September 10.

The Desiro ML Cityjet Eco has been produced using a series-built version of the Desiro ML EMUs which Siemens is supplying to ÖBB. The middle car has been equipped with three battery containers with lithium-titanate batteries offering a total capacity of 528 kWh.

Although this train is designed for a different loading gauge, it is another Siemens product and they manage to fit 528 kWh in, on top or under one car.

I think, it would be reasonable to assume that around 400 kWh of batteries could be fitted under a Class 350 train.

These pictures show a Class 350 train at Euston.

Note that the trailer car with the pantograph has less free space underneath. I would assume that is because the transformer and other electrical gubbins are underneath the car to increase passenger space.

I’m certain there is space under a Class 350 train to fit an appropriate amount of storage.

What Battery Range Could Be Expected?

In an article in the October 2017 Edition of Modern Railways, which is entitled Celling England By The Pound, Ian Walmsley says this in relation to trains running on the Uckfield Branch, which is not very challenging.

A modern EMU needs between 3 and 5 kWh per vehicle mile for this sort of service.

So how far would a four-car Class 350 train go with a fully-charged 400 kWh battery?

  • 5 kWh per vehicle mile – 20 miles
  • 4 kWh per vehicle mile – 25 miles
  • 3 kWh per vehicle mile – 33.3 miles
  • 2 kWh per vehicle mile – 50 miles

Obviously, this is a very crude estimate, but it does show that the train could have a useful range on battery power.

But the following would increase the range of the train.

  • A low energy interior.
  • An increased battery capacity.
  • Two cars in the four-car train are trailers, so should have more space underneath.
  • Routes for battery trains could be reprofiled with gentle curves and gradients.
  • Terminal platforms could be fitted with charging stations.

In Did Adrian Shooter Let The Cat Out Of The Bag?, Mr Shooter talked about a range of forty miles at sixty mph for the battery version of a Class 230 train.

That distance, would open up a surprising number of routes for battery trains.

Should A Small Diesel Generator Be Fitted?

It is worth noting that Transport for Wales has ordered two battery trains.

  • Vivarail Class 230 trains for North Wales.
  • Stadler Flirts for South Wales

Both trains have diesel engines, that can be used to back-up battery power.

In addition the Class 801 train has a diesel generator to rescue the electric train, when the power fails.

Are Hitachi, Stadler and Vivarail just being safe or do their figures show that a diesel engine is absolutely necessary? After all, the diesel generator can be easily removed, if it’s never used.

I think if it was easy, whilst the new battery-powered train was being tested and on probation, I’d fit a small diesel generator.

Remote Battery Charging

Most of the charging would be done, whilst running on electrified lines, which could be either 25 KVAC overhead or 750 VDC third-rail.

But the trains would be ideal for the sort of charging system, that I wrote about in Is This The Solution To A Charging Station For Battery Trains?.

To use this Opbrid system, all the train needs is the ability to connect through a 25 KVAC pantograph, which the train already has.

As there is a lot of interest in battery trains throughout Europe, I suspect that a charging station will be a standard piece of equipment, that can be easily installed in a terminal platform or a turnback siding.

We could see important towns and cities like Barrow-in-Furness, Blackburn, Chester, Dundee, Harrogate, Huddersfield, Hull, Middlesbrough, Perth and Sheffield, which are within battery range of the electrified network, being served by electric trains , without the disruption of installing electrification.

An Updated Interior

The Class 350 trains were ordered around 2000 and don’t have the features that passengers expect, as these pictures show.

An update would probably include.

  • LED lighting.
  • Low-energy air-conditioning.
  • Wi-fi
  • Power sockets
  • USB sockets.

Other features would be cosmetic like new seat covers and flooring.

But overall, a better interior will surely reduce the energy needs of a train.

What Would Be The Maximum Speed?

The current maximum speed of Porterbrook’s Class 350/2 trains is 100 mph, but all other variants of the train are capable of 110 mph.

Under Description in the Wikipedia entry for the Class 350 train, this is said.

The top speed of the fleet was originally 100 mph (160 km/h), but all 350/1s were modified to allow 110 mph (180 km/h) running from December 2012, in order to make better use of paths on the busy West Coast Main Line.

So would the conversion to battery power, also include an uprating to 110 mph?

It would definitely be a prudent move, so as to make better use of paths on busy main lines.

Where Would These Trains Run?

I feel that Porterbrook will produce a four-car train with these characteristics.

  • 110 mph operating speed.
  • Forty or perhaps a fifty mile range on batteries.
  • Quality interior.
  • The ability to use a charging station in a terminal platform.

The Global Rail News article says this about possible use of the trains.

Engineers at Porterbrook have run models on a variety of routes, including the Windermere branch line and the West Coast main line, and believe a battery/electric bi-mode, known as a 350/2 Battery/FLEX, could offer various performance benefits.

The Windermere to Manchester Airport service would seem to be an ideal route  for the Class 350/2 Battery/FLEX trains.

  • Only ten miles are not electrified.
  • The trains could easily work the return trip on the Windermere Branch Line on battery power.
  • There would be no need for any charging station at Windermere station.
  • Much of the route is on the West Coast Main Line, where a 110 mph electric train would fit in better than a 100 mph diesel train.
  • As the trains would need a refurbishment, some could be fitted with an interior, suitable for airport travellers.
  • The trains would fit the ethos and environment of the Lake District.

As the route will soon be run by Class 769 trains, I suspect there would need to be no modifications to the tracks, stations and signalling, as both trains are bi-modes, based on four-car electric trains.

I have other thoughts about, where Class 350/2 Battery/FLEX trains could be used.

Interchangability With Class 769 Trains

Both the Class 350/2 Battery/FLEX and Class 769 trains are trains owned by Porterbrook.

They are also surprisingly similar in their size, performance and capabilities.

  • Both are four-car trains around eighty metres long.
  • Both can work on 25 KVAC overhead electrification and both could be modified to work on 750 VDC third-rail electrification.
  • Both are 100 mph trains, although it may be possible to uprate the Class 350/2 Battery/FLEX to 110 mph working.
  • Both trains can be fitted with modern interiors giving operators, passengers and staff what they need or want.
  • Many routes for bi-mode trains could be worked by either train.

There will be a few differences.

  • The Class 350/2 Battery/FLEX train is a pure electric train and more environmentally-friendly.
  • The Class 350/2 Battery/FLEX train could fit in better on a busy main line.
  • The Class 769 train will probably have a longer range away from electrification.
  • The Class 350/2 Battery/FLEX train is twenty years younger.

I think that this similarity will be used to advantage by Porterbrook and the train operating companies.

  • A Class 350/2 Battery/FLEX train would be an ideal replacement for a Class 769 train, when the latter needs replacing.
  • A Class 769 train could replace a Class 350/2 Battery/FLEX train, if say the latter was being serviced or repaired or perhaps the charging station at one terminus was out of action.
  • A Class 769 train could be used for route-proving for both trains.

Porterbrook wins every way, as they own both trains.

But I can also see a time, when the Class 769 trains become a reserve fleet to be used, when a train operating company is in urgent need of more capacity.

Around Electrified Conurbations

The UK has several conurbations with a lot of electrification.

  • Birmingham-Coventry-Wolverhampton
  • Edinburgh-Glasgow-Stirling
  • Leeds-Bradford-Doncaster-York
  • Liverpool-Manchester-Preston-Blackpool
  • London

Cambridge, Cardiff, Reading and Newcastle could also become major electrified hubs.

I suspect there will be a lot of routes for which these trains would be eminently suitable.

This is a selection of the easy routes, where there is electrification at one end of the route and a charging station could be added at the other, if required.

  • Doncaster to Hull
  • Dunblane to Perth
  • Glasgow Central To East Kilbride
  • Leeds to York
  • London Bridge to Uckfield
  • Manchester to Buxton
  • Manchester to Chester
  • Manchester to Clitheroe
  • Preston to Barrow-in-Furness
  • Preston to Blackpool South
  • Preston to Colne

In total, there must be at least twenty of these routes in the UK.

Trains Across The North Of England

It should be noted that Leeds to Stalybridge is about thirty-five miles by rail and both ends of the route are electrified.

So could these trains have sufficient battery capacity to enable Northern to run fast electric services between Blackpool, Chester, Liverpool, Manchester, Manchester Airport and Preston in the West to Hull, Leeds and York in the East?

If the Class 350/2 Battery/FLEX train has sufficient battery capacity and the speed limits on various sections of the East West routes are increased from some of their miserable levels, I believe that a much better service could be provided.

At over seventy miles long, the Settle-Carlisle Line, is probably too long for battery operation, especially as the route is not electrified between Skipton and Carlisle, which is nearly ninety miles.

The same probably applies to the Tyne Valley Line, which has just over sixty miles without electrification.

But it is called the Tyne Valley Line for a good reason, it runs alongside the River Tyne for a long way and looks to be not very challenging.

I wouldn’t rule out, that in a few years time, the route is run by a battery hybrid train, like the Class 350 Battery/FLEX.

The secondary route between Leeds and Lancashire is the Calder Valley Line via Hebden Bridge, which is not electrified between Preston and Bradford, which is a distance of fifty-three miles.

Electrification of this route and especially between Burnley and Bradford would be extremely challenging due to mthe numerous bridges and the terrain, with the added complication of the Grade II Listed Hebden Bridge station.

It would be pushing it, but I believe the Class 350 Battery/Flex train could handle it.

There is a plan to reconnect Skipton in Yorkshire to Colne in Lancashire to create another route across the Pennines.

The trains would need to travel the forty-two miles between Preston and Skipton using battery power, but it would create a valuable route at an affordable cost, if no electrification was used.

What would improve the running of the routes via Hebden Bridge and Colne, would be to electrify the route between Preston and Blackburn, which would reduce the distance to be run on battery power by twelve miles.

The Hope Valley Line runs between Sheffield and Manchester Piccadilly and is forty-two miles long without electrification.

This route certainly needs a modern four-car train and I believe that the Class 350 Battery/FLEX train could handle it.

But it would need a charging station at Sheffield.

On this rough and ready analysis, it looks like the three Southern routes and a new one via Colne could be handled successfully by a Class 350 Battery/FLEX.

Summing up the gaps West of Leeds we get.

  • Bradford and Manchester Victoria via Hebden Bridge – 40 miles
  • Sheffield and Manchester Piccadilly via Hope Valley Line – 42 miles
  • Stalybridge and Leeds via Hudderfield – 35 miles
  • Preston and Skipton via Colne – 42 miles

If the Class 350 Battery/FLEX train can do around fifty miles on battery power, which I suspect is a feasible distance, then these trains could give Northern an electric stopping service on all their routes across the Pennines.

In my view the system could be improved by the following projects.

  • Electrify between Preston and Blackburn and possibly Burnley Manchester Road.
  • Electrify between Manchester Victoria and Todmorden.
  • Renew the crap electrification between Manchester Piccadilly and Glossop, with an extension for a few miles along the Hope Valley Line to perhaps New Mills Central and Rose Hill Marple.
  • Tidy up the electrification between Leeds and Bradford and extend it to the Northbound East Coast Main Line.

But the most important thing to do, is to increase the line speed on the routes across the Pennines.

Greater Anglia and Network Rail are talking about ninety minutes for the 114 miles between London and Norwich, which is an average speed of 76 mph.

Liverpool Lime Street to York is about the same distance and TransPennine take around 110 minutes for the journey, which is an average speed of around 60 mph.

  • Both journeys have a few stops.
  • Both routes are or will be run by 100 mph trains.
  • The East Anglian route is electrified, but trans-Pennine is not.

The big difference between the routes, is that large sections of the East Anglian route can be run at 100 mph, whereas much of the Trans-Pennine route is restricted to far lower speeds, by the challenging route

Sort it!

Electric traction will make a difference to the acceleration, but it doesn’t matter if they get their power from overhead wires or batteries!

Putting up overhead wires on the current route will be throwing good money after bad, unless the track is fixed first.

Liverpool Lime Street to York should be ninety minutes in a Class 350 Battery/FLEX.

The Scottish Breakout

Finally, the electrification in the Scottish Central Belt is on track and the Scots are seeing the benefit of modern electric trains.

Trains like the Class 350 Battery/FLEX could be the key to extending Scotland’s growing network of electric trains.

In A Railway That Needs Electric Trains But Doesn’t Need Full Electrification, I described how the 11.5 mile service between Glasgow Central and East Kilbride station could be run by an electric train using batteries, which would be charged using the 25 KVAC overhead wires at the Glasgow end of the route.

If the Class 350 Bettery/FLEX train existed, they could work this route, as soon as drivers and other staff had been trained.

With a forty mile range on batteries, trains could reach from the electric core to many places, like Dumbarton, Perth and possibly Dundee.

It should be noted that Dundee is just under fifty miles from Dunblane, where the current electrification will end, so with a charging station in one of the bay platforms at Dundee, a Class 350 Battery/FLEX should be able to bridge the gap.

They could even probably handle the current Borders Railway, with a charging station at Tweedbank.

Scotland would not need to acquire a fleet of Class 350 Battery/FLEX, as they already have a fleet of Class 380 trains, which I am certain could be re-engineered in the same way to become battery/electric trains.

ScotRail may need a few more electric trains, but they could always keep the Class 365 trains, that have been used as cover for the much-delayed Class 385 trains.

South Western Railway

South Western Railway don’t have any obvious needs for a train like a Class 350 Battery/FLEX train.

But consider.

  • They do have 127 Class 450 trains, which are the third-rail version of the Class 350 train, so could probably be converted into a Class 450 Battery/FLEX.
  • They have ten Class 158 and thirty Class 159 diesel trains, some of which work partially-electrified routes.
  • British Rail-era third-rail systems have their deficiencies in places.
  • There are proposals and some plans to reopen branch lines to the West of Basingstoke and Southampton.
  • The Class 450 trains could be converted to dual-voltage operation, as they have a pantograph well.

So perhaps a few Class 450 Battery/FLEX trains could be a useful possibility.

  • Basingstoke to Salisbury is thirty-six miles and with a charging station at Salisbury, an electric service between Waterloo and Salisbury could be run.
  • Salisbury to Southampton Central is twenty-five miles.
  • Waterloo to Corfe Castle and Swanage, if it was decided to run this Saturday service, more frequently.

I also suspect that a Class 450 Battery/FLEX would give South Western Railway several operational and energy-efficiency advantages, which could lead to financial advantages.

I doubt though that the trains would have the capability to reach Exeter, as that is just too far.

These trains would also be ideal for the for the following services, run by other operators.

  • London Bridge to Uckfield.
  • The Marshlink Line.
  • Reading to Gatwick, where they would replace the proposed Class 769 trains.

Converting these three lines to electric traction, would remove the final diesel passenger services from Kent and Sussex.

Other Routes

Use your imagination!

Conclusion

Porterbrook have just dropped an enormous flower-smelling bomb, into the electrification and train replacement plans of UK railways.





























October 18, 2018 Posted by | Transport | , , , , , | 9 Comments

Aventras Have Underfloor Heating

I have underfloor heating in my house, so why shouldn’t trains.

In this article on Global Rail News, which is entitled First look around Greater Anglia’s Bombardier Aventra mock-up, this is said.

Instead of body-side heaters encroaching on leg room, under-floor heating has been used, seats are cantilevered too to save on space and there will be no doors separating vehicles.

These pictures show the heating in various trains.

Note.

Can this be why the Class 345 trains give an impression of width?

September 14, 2017 Posted by | Transport | , , | 7 Comments

From Glasgow To Carlisle In A Class 350 Train

TransPennine Express are replacing their Class 350 trains with new Class 397 trains.

So coming down from Glasgow to Carlisle, I took one of the Class 350 trains to see why they are being replaced.

The train that I rode, had been spruced up with the new livery.

The new Class 397 train has the following advantages over the Class 350 train.

  • It will be a 125 mph train rather than a 110 mph train.
  • It will have power sockets, wi-fi and possibly 4G connectivity
  • It will be five-cars instead of four-cars.

Will there be any other passenger features like a buffet?



September 12, 2017 Posted by | Transport | , , , | Leave a comment
