These New Sleeper Trains Are Basically Luxury Hotels On Wheels

The title of this post, is the same as that of this article on Time Out.

French startup; Midnight Trains, aims to update sleeper trains for the twenty-first century.

What Routes Are Being Offered?

The Time Out article says this.

Centred around Paris’s Gare du Nord train station, routes will stretch as far as 800km in a star shape across Europe, encompassing major destinations such as Madrid, Lisbon, Porto, Milan, Venice, Florence, Rome, Vienna, Prague, Budapest, Berlin, Hamburg, Copenhagen and even Edinburgh.

A map on the Midnight Trains web site, shows these individual routes.

  • Paris and Barcelona
  • Paris and Edinburgh
  • Paris and Madrid
  • Paris and Porto
  • Paris, Brussels, Hamburg and Copenhagen
  • Paris, Brussels, Hamburg and Berlin
  • Paris, Milan and Venice
  • Paris, Florence and Rome

I’m sure this list will grow.

Some Detailed Looks At Routes

I shall give a few notes about some of the proposed routes.

Paris And Barcelona

Crows would fly 831 kilometres or 516 miles.

I have gone by train between Barcelona and Paris twice. One trip is described in From Barcelona To Paris.

It looks like it takes 06:40 in a TGV without a change.

The service leaves from Barcelona Sants and arrives at Paris Lyon.

Time Out says journeys are centred on Gare Nord, so could the train access that terminal from the South?

An eight or nine hour sleeper journey would probably be convenient for train operators and passengers.

But I suspect that this route may need trains that can take advantage of the high speed nature of much of the route.

Paris And Edinburgh

Crows would fly 873 kilometres or 543 miles.

  • I have gone by train between London and Edinburgh many times and four-and-a half hours would not be an unreasonable time.
  • I have also used  Eurostar between London and Paris many times and two-and-a-quarter-hours would not be an unreasonable time.

An eight or nine hour sleeper journey would probably be convenient for train operators and passengers.

The most efficient way could be for the Paris and Edinburgh service to operate would be with a reverse at St. Pancras.

  • It could be at between one and three in the morning, as sleeper trains run slower than high speed services.
  • It would take about ten-fifteen minutes for the driver to change ends.

Would they be allowed to pick up passengers on the way through London?

  • I doubt they would be able to do this universally, but there must be a market for passengers needing to get to Edinburgh or Paris early in the morning from London.
  • During the Glasgow Commonwealth Games, on one day, I used the Caledonian Sleeper to return to London. It was packed and a sleeper train leaving for Paris and Edinburgh might pick up a substantial number of passengers after sporting or cultural events or business that finished late in the evening.
  • Timings could be arranged, so that both the Edinburgh and Paris legs were sufficient for say four or five hours sleep.

Caledonian Sleeper would probably object. But competition of this nature is often mutually beneficial.

There is also an alternative fully-electrified route that avoids the reverse at St. Pancras.

It winds its way through East London between Barking and Holloway using the North London Line.

It is feasible, but wouldn’t have the commercial advantages of a reverse in St. Pancras.

Would the Paris and Edinburgh services call at other stations?

The Lowland Caledonian Sleeper to Edinburgh and Glasgow calls at the following other stations.

  • Watford Junction – Pick up Northbound – Set down Southbound
  • Carlisle – Pick up Southbound – Set down Northbound
  • Carstairs – Pick up Southbound – Set down Northbound
  • Motherwell – Pick up Southbound – Set down Northbound

Would the Midnight Trains do something similar. Perhaps they would call at the following stations.

  • Stevenage – Pick up Northbound – Set down Southbound
  • York – Pick up Southbound – Set down Northbound
  • Newcastle – Pick up Southbound – Set down Northbound

This would create three extra sleeper services.

  • Paris and Newcastle
  • Paris and York
  • Stevenage and Edinburgh

Commercially this must be attractive, as it would require no extra rolling stock.

I also suspect providing Customs and Immigration for outgoing passengers at York and Newcastle would not be an expense, that made the stops unviable.

Paris And Madrid

Crows would fly 1057 kilometres or 657 miles.

In 2014, I used trains from Madrid to Paris and on to London, which I wrote about in From Madrid To London.

That was a trip that I planned on the move, so it could have been done faster.

Looking at the timetables, I find the following.

  • Paris and Barcelona – 6:41
  • Barcelona and Madrid – 2:45

Note

  1. All times are given in hours:minutes.
  2. A direct service without a change at Barcelona must be possible.
  3. Would this service pick up and set down at Girona, Barcelona, Camp de Tarragona and Zaragoza?

A ten or eleven hour sleeper journey would probably be feasible and convenient for train operators and passengers.

But when I look at the route map on the Midnight Trains web site, their route between Paris and Madrid appears to go further to the West.

I have a strong feeling that they are proposing to use the currently closed route via the iconic Canfranc station.

But then Wikipedia says this about plans for the future of the route and the station.

The government of Aragon has long held various ambitions for the rehabilitation of the station. Plans have been mooted to redevelop the main station building into a hotel, which would involve the construction of a new station beside it to replace it. There have been explorations of options to reopen the through line as the “western trans-Pyrenean line”; this initiative would reportedly involve the assistance of the government of Aquitaine, the adjacent French region. In February 2020, it was announced that funding from the European Union had been made available for the purpose of reopening the through line and relaunching international services.

Note.

  1. A regular rail service between Pau in France and Zaragoza in Spain would tick a lot of boxes.
  2. On the French side the Pau-Canfranc railway is a fifty-eight mile electrified single-track, standard-gauge railway.
  3. On the Spanish side, the railway is Iberian gauge.
  4. It would probably be a useful freight route.
  5. If it could take a TGV, it would enable faster TGV links between France and the Iberian nations.

It looks to me, that if it was properly rebuilt, it could be a useful standard gauge line between the high speed networks of France and Spain.

Looking at the timetables, I find the following.

  • Paris and Pau – 4:24
  • Zaragoza and Madrid – 1:35

If Pau and Zaragoza could be achieved in three hours, times would be as good or better, than the Barcelona route.

Paris And Porto

Crows would fly 1213 kilometres or 753 miles.

This is a challenging one to find the route, but I did find a current time of just over fourteen hours with lots of changes.

But from Zaragoza, there does appear to be a route via Burgos and Vigo.

It could be up to sixteen hours, so would probably be the better part of a day.

Could the Madrid and Porto services, provide a service to and from Canfranc?

Consider.

  • Canfranc station is a spectacular station in the Pyrenees.
  • It has been blessed by St. Michael.
  • I suspect many people would like to visit.
  • The station might be converted into a hotel.

I wouldn’t be surprised to see innovative arrangements in the Madrid and Porto services, so that passengers could have a visit to Canfranc.

Paris, Brussels, Hamburg And Copenhagen

Crows would fly 1027 kilometres or 638 miles.

Looking at the timetables, I find the following.

  • Paris and Brussels – 1:32
  • Brussels and Hamburg- 6:49
  • Hamburg and Copenhagen- 5:06

Note

  1. All times are given in hours:minutes.
  2. When I went between Hamburg and Copenhagen by train, I used the Bird Flight Line which involved a train ferry, where passengers had to get on the ship for the crossing. I described that trip in From Copenhagen To Hamburg By Train.
  3. The ferry is being replaced by a tunnel by 2028.
  4. It looks like it might be possible to go between Hamburg and Copenhagen by a longer route further to the North.

An eleven or twelve hour sleeper journey would probably be feasible and convenient for train operators and passengers.

I was initially surprised that the service didn’t call at Amsterdam.

  • But then there are a lot of big cities between Brussels and Amsterdam; Antwerp, Rotterdam, Schipol Airport and The Hague.
  • There is generally one train per hour (tph) between Brussels and Amsterdam.
  • Paris and Amsterdam are only 3:20 apart by Thalys, so perhaps there wouldn’t be many takers for a sleeper train.
  • It would appear that the best route between Paris and Hamburg is via Brussels and Cologne.

From friends in the area, I also get the impression, that it would take forever for the Belgians and the Dutch to decide on the calling pattern.

Paris, Brussels, Hamburg And Berlin

Crows would fly 876 kilometres or 545 miles.

Looking at the timetables, I find the following.

  • Paris and Brussels – 1:32
  • Brussels and Hamburg- 6:49
  • Hamburg and Berlin – 1:36

Note that all times are given in hours:minutes.

A ten or eleven hour sleeper journey would probably be feasible and convenient for train operators and passengers.

I was initially surprised that the service didn’t call at Cologne.

  • Thalys runs a high speed service between Paris and Cologne.
  • DB runs a high speed service between Cologne and Hamburg.
  • NightJet runs a sleeper service from Brussels and Cologne to Austria.

It could be that the demand isn’t thought to be there.

Paris, Milan And Venice

Crows would fly 845 kilometres or 525 miles.

I have done much of this route before and wrote about it in From Novara To Paris.

Looking at the timetables, I find the following.

  • Paris and Milan – 7:22
  • Milan and Venice – 2:29

Note

  1. All times are given in hours:minutes.
  2. Would this service pick up and set down at Turin and Verona?

A ten or eleven hour sleeper journey would probably be feasible and convenient for train operators and passengers.

Paris, Florence And Rome

Crows would fly 1106 kilometres or 687 miles.

Looking at the timetables, I find the following.

  • Paris and Turin – 5:42
  • Turin and Florence – 3:00
  • Florence and Rome – 1:36

Note

  1. All times are given in hours:minutes.
  2. Would this service pick up and set down at Turin and Verona?

A ten or eleven hour sleeper journey would probably be feasible and convenient for train operators and passengers.

What Rolling Stock Will Be Used?

In recent years sleeper train sets have been ordered as follows.

  • Austrian Railways from Siemens.
  • Caledonian Sleepers from CAF of Spain.

But as Midnight Trains is a French Company, I suspect the train order could go to Alstom.

On the other hand because of European procurement rules and quality, the order could go to CAF.

The CAF Mark 5 Coaches are capable of running at 100 mph and there are pictures in On The Caledonian Sleeper To Glasgow.

I do wonder, though if we’ll see a radical design, which is different to current locomotive-hauled sleeper trains.

  • Electrical multiple unit rather than locomotive hauled.
  • 125 mph capability, which could be useful on some routes.
  • A fleet of identical train sets.
  • Ability to use all the voltages on the routes.
  • Ability to work in pairs or singly dependent on the needs of the route.
  • Ability to split and join automatically in a station.
  • Ability to use the signalling on all routes, including high speed ones.
  • The trains would be built to be suitable for all loading gauges on the routes served.

Note.

  1. Given that French-designed Class 373 trains used by Eurostar, could trundle all over South London into Waterloo, I don’t think it will be difficult to design a train, that fitted the Edinburgh service.
  2. Get the design right and there could be other customers.

They would be true Pan-European trains.

When Will The Trains Start Running?

2024 is the date given by Time Out and the Midnight Trains web site.

Conclusion

I like the proposed service.

These are reasons why.

The Proposed Level Of Service

When travelling for between eight and twelve hours, you need a quality train.

Over the years, I must have used sleeper trains run by Caledonian Sleeper at least twenty times,

When they have been good, they have been very good.

The new trains from CAF don’t need for anything more.

If Midnight Trains can match Caledonian Sleeper for quality on trains, service and food, they’ll attract passengers.

The Service Is Easy To Expand And Extend

Consider, these extra services could surely be added to the  proposed network.

  • Paris and Munich
  • Paris and Switzerland.
  • Paris, Nice and Genoa

If some of the plans to connect the UK and Irish railways come to fruition, there could even be a Paris and Dublin service in the distant future.

Consider, these extensions to the proposed services.

  • Edinburgh and Glasgow 1:12
  • Rome and Naples – 1:10
  • Barcelona and Valencia – 2:40

Note that all times are given in hours:minutes.

The Service Is Very UK-Friendly

Because of Eurostar, with its two-and-a-quarter hour journey between two of Europe’s largest cities, London and Paris can almost be considered twin cities with respect to long-distance transport.

Suppose a resident of Paris wants to go for a weeks holiday birdwatching in the North of Scotland, a late afternoon Eurostar to London and the Caledonian sleeper to Inverness is a very-feasible way to travel.

Suppose, I wanted to go from London to Berlin, in the future, I will be able to get a Eurostar to Paris and a Midnight Train to Berlin.

A Good Food Offering

I would hope that the food is of a quality nature.

I am coeliac and must have gluten-free food, like probably up to one percent of people.

I have found that the higher the quality of the food, the more likely it is, that the chef knows their allergies.

Before the pandemic, the best train food in Europe on a regular service was Great Western Railway’s Pullman Dining. But because of the restrictions, I’ve not tried it lately.





June 30, 2021 Posted by | Transport | , , , , , , , , , , , , , , , , , , , , | 4 Comments

Northern Powerhouse Rail Progress As Recommendations Made To Government

The title of this post, is the same as that of this article on Transport for the North.

This is the introductory paragraph.

Northern leaders have agreed an initial preferred way forward for a new railway network that will transform the region’s economy.

And these are the rail improvements proposed.

  • A new line to be constructed from Liverpool to Manchester via the centre of Warrington, Read more…
  • A new line to be constructed from Manchester to Leeds via the centre of Bradford. Read more…
  • Significant upgrades and journey time improvements to the Hope Valley route between Manchester and Sheffield. Read more…
  • Connecting Sheffield to HS2 and on to Leeds. Read more…
  • Significant upgrades and electrification of the rail lines from Leeds and Sheffield to Hull. Read more…
  • Significant upgrades of the East Coast Mainline from Leeds to Newcastle (via York and Darlington) and restoration of the Leamside Line. Read more…

The Read more links point to my initial thoughts.

No more detail is given, but the list is followed by this paragraph.

The move comes ahead of the much-anticipated publication of a new report that will set out long-term investment plans for rail upgrades in the North. The Government’s Integrated Rail Plan – due to be published by the end of this year – is expected to recommend how investment in rail projects like Northern Powerhouse Rail, HS2 Phase 2b, and the TransPennine Route Upgrade (a separate project) will be delivered.

I am waiting for the Government’s Integrated Rail Plan with interest.

November 20, 2020 Posted by | Transport | , , , , , , , , , | 3 Comments

Why Is Manchester The Odd City Out?

I find the different reactions of the large Northern cities interesting.

I have seen no comment and moaning from Leeds, Newcastle and Sheffield, and Liverpool and the rest of Lancashire seems to have accepted their Tier 3. fate.

Only Manchester seems to have a serious objection.

I know Liverpool well, as I went to Liverpool University in the 1960s, met my late wife there and we lived together in the city for a couple of years.

I still visit the City regularly, as I like the city’s weather and outlook and do business with my old University.

I have visited Manchester many times, often for football (I support Ipswich, despite being a Londoner!) and I find the city very different to Liverpool.

But I don’t seem to warm to Manchester, as I do to Liverpool and the other large cities of the North.

Or is it Manchester doesn’t warm to me?

Andy Burnham is not a Mancunian and could it be, that his hard stand against the Government, is driven by wanting to be more Mancunian, than the Mancunians.

Manchester puzzles me, but it does seem to be out of step with the rest of the North.

October 16, 2020 Posted by | Health, World | , , , , , | 5 Comments

Northern Cities And COVID-19

If you look at the official Government statistics for the total number of cases of COVID-19, as of May 3rd, the number of cases in the two major cities in the North West as follows.

  • Leeds – 1463 out of a city population of 789,194 (0.18%) and a metro population of 2,638,127 (0.05%)
  • Liverpool – 1454 out of a city population of 494,814 (0.29%) and a metro population of 2,241,000 (0.06%)
  • Manchester – 1154 out of a city population of 547,627 (0.21%) and a metro population of 3,748,274 (0.03%)
  • Newcastle – 939 out of a city population of 300,196 (0.31%) and a metro population of 1,650,000 (0.06%)
  • Nottingham – 537 out of a city population of 321,500 (0.17%) and a metro population of 1,610,000 (0.03%)
  • Sheffield – 2191 out of a city population of 582,506 (0.38%) and a metro population of 1,569,000 (0.14%)

Note.

  1. All populations come from Wikipedia.
  2. Why is Liverpool 40% worse than Manchester?
  3. Why is Sheffield the worst?

I will add a few smaller towns andcities.

  • Blackpool – 465 out of an urban population of 139,720 (0.33%)
  • Caldervale – 252 out of an urban population of 200,100 (0.13%)
  • Hull – 469 out of a city population of 260,645 (0.18%)
  • Middlesbrough – 566 out of an urban population of 174,700 (0.32%)
  • Stoke-on-Trent – 509 out of a city population of 255,833 (0.20%)
  • York – 315 out of a city population of 209,893 (0.15%)

I’d like to see full statistics plotted on a map or a scatter diagram.

The latter is a very powerful way to plot data and often they highlight data points that lie outside the underlying pattern of the data.

May 4, 2020 Posted by | Health, World | , , , , , , , , , , , | 3 Comments

Trains Ordered For 2021 Launch Of ‘High-Quality, Low Fare’ London – Edinburgh Service

The title of this post, is the same as that of this article on Railway Gazette.

This is the first paragraph.

FirstGroup has finalised an order for five Hitachi AT300 electric trainsets which it will use to launch a London – Edinburgh open access service in autumn 2021.

The trains appear to be be similar to those used by FirstGroup companies; Hull Trains and Great Western Railway.

These are some points from the article.

  • FirstGroup is targeting the two-thirds of passengers, who fly between London and Edinburgh.
  • They are also targeting business passengers, as the first train arrives in Edinburgh at 10:00.
  • The trains are five-cars.
  • The trains are one class with onboard catering, air-conditioning, power sockets and free wi-fi.
  • Stops will be five trains per day with stops at Stevenage, Newcastle and Morpeth.
  • The trains will take around four hours.
  • The service will start in Autumn 2021.

These are my observations.

Earlier Start

I suspect that the service can’t start earlier, due to one of the following.

  • The lead time in building the trains.
  • Completion of the new Werrington Junction.
  • Completion of the sorting of Kings Cross.
  • Completion of the works at Stevenage station.

The track works will probably be needed to create the extra paths needed on the East Coast Main Line.

Electric-Only Trains

Most other AT300 trains are bi-mode trains, but will these be electric-only?

Capacity Issues

If the trains prove too small, they can just add extra carriages or two trains can run as a pair.

Timetables

Trains will probably take nine hours for a round-trip, allowing 30 minutes for turnround.

This would mean that two trains leaving London and Edinburgh at six, would arrive back at home after two round trips around midnight.

Conclusion

I think it will be a successful service.

March 22, 2019 Posted by | Transport | , , , , , , | 5 Comments

Boost For Borders In New Report

This report on the Scottish Government web site is entitled Borders Transport Corridors – Pre-Appraisal.

It is a comprehensive report with a helpful pag of recommendations.

Recommendations that apply to rail include.

Develop Forestry Route Network

Improve network of internal forestry tracks as well as its connections to roads and railway, including ‘low-tech’ timber
pickup facilities.

This seems sensible, as some of the forests on both sides of the Scottish order are mature and need to be cut down and replanted.

Increase Park and Ride Provision

Increase capacity of existing Park-and-Ride sites and implement new Park-and-Ride schemes for all modes at strategic locations [e.g. Interchanges and Key Employment Areas]

Every part of the UK seems to need more Park-and-Ride. The Borders is no exception.

Borders Railway Extension – South/West

Extend the Borders Railway to Hawick and/or Carlisle

Will it go all the way to Carlisle?

Consider.

  • The West Coast Main Line will need a capacity increase through Carlisle because of High Speed Two. These works could be combined with those on the Southern part of the Borders Railway.
  • Plans exist for a large freight interchange at Longtown on the former MoD site.
  • Linking the Tourist areas North and South of the Scottish Border by rail must be a good thing.
  • Extension to Carlisle would give those in the Scottish Borders access to High Speed Two at Carlisle, without a long trip via Glasgow.

For these reasons, I think that the Borders Railway will go to Carlisle.

Borders Railway Extension – South/East

Extend the Borders Railway towards East Coast Main Line (ECML) via Berwick-upon-Tweed

This surprised me, but it does complete the jigsaw.

Does it offer a freight route for moving the timber out of the area?

It woulde certainly offer a scenic route between Edinburgh and Newcastle.

New Rail Stations

New rail stations on the existing Borders Railway

This is surely building on the success of the current Borders Railway.

Extension of Borders Railway Services

Link Borders Railway and Fife Circle, providing interchange at Edinburgh Gateway; West Edinburgh; and potential future link to Glasgow.

Back-to-back services across a city are always a good idea, as they cut the need for terminal platforms

  • The Borders Railway and Fife Circle are both half-hourly services, so could be connected together, once suitable rolling stock is available.
  • This service would also connect the Borders to the Edinburgh Airport tram at Edinburgh Gateway.
  • With extra services, would the capacity of the Borders Railway will probably need to be increased?

Does the South East extension enable better services for the Borders beyond Edinburgh?

Conclusion

There are a lot of projects needing to be developed, but they will create a lot of economic activity in the Borders.

The two railway extensions to Hawick and/or Carlisle and Berwick-on-Tweed are the two most expensive projects, but both have English implications, so I don’t think Westminster will mind paying some of the cost.

March 12, 2019 Posted by | Transport | , , , , , , , , | Leave a comment

Could Hydrogen Replace Natural Gas In Domestic Properties?

This post was suggested by this article on the Chronicle Live, which is entitled Thousands of Tyneside Homes Could Be Fuelled By Hydrogen Under £22bn Plan.

This is the first three paragraphs.

Thousands of homes across Tyneside and the wider North East could be converted to run on hydrogen in an effort to hit climate change targets.

The H21 North of England report, published today, has called for more than 700,000 homes across Tyneside and Teesside to be converted to run on hydrogen by 2034.

The moves have been proposed by Northern Gas Networks, which supplies gas to the North East, and its North West and Midlands counterpart Cadent, in association with Norwegian energy company Equinor.

It would be feasible to convert houses from natural gas to hydrogen.

In fact, there is a small proportion of hydrogen in natural gas anyway.

But just because it is feasible, it doesn’t mean it is a good idea.

Who Pays?

Consumers would feel, that they shouldn’t pay any more.

Conversion

I remember being converted from town to natural gas in the 1970s.

We only had an ancient gas cooker and conversion was not a problem, but what will happen, if your boiler or cooker is not convertible?

New Technologies

I don’t like gas cookers, so in my current house, I only have a four-year-old modern boiler, so houses like mine wouldn’t be a problem.

Also according to various people, I’ve met, the trend in cookers is to go to induction appliances, which would take a variable out of the conversion equation.

I see lots of new housing and other construction, advertised as low energy, with high insulation levels and solar panels everywhere.

Add in innovative district heating systems and I can see new housing being built without the need of a gas supply.

This must surely be safer, as gas does seem to cause a lot of deaths in homes.

Just Say No!

So what happens, if you say no and your area is being converted to hydrogen?

Do you lose your gas supply?

Creation Of The Hydrogen

This article on the Internet is entitled Northern Gas Networks: One Company’s Ambitious Plan To Cut Carbon Emissions For An Entire Nation.

This is said about the creation of the hydrogen.

The first step is getting access to enough hydrogen. The most widely used method to produce hydrogen is steam-methane reforming, which involves reacting methane (CH4) with high-temperature steam (H2O), which creates carbon dioxide (CO2) and hydrogen (H2). But hydrogen isn’t a clean fuel if that carbon dioxide is put into the atmosphere. So the reactor which produces hydrogen will have to be paired with carbon capture and storage, a process where carbon dioxide is captured before it enters the air, and then pumped underground for safe, permanent storage.

Companies, politicians and academics have been waffling on about carbon capture and storage for decades and I believe at the present time, it is one of those technologies, which is akin to burning large numbers of fifty pound notes.

I do think that at some point in the future, a clever chemist will design a chemical plant, where carbon dioxide goes in one end and sheets, rods or components of carbon fibre, graphene or other carbon form come out the other end.

In my view it is much better to not create the carbon dioxide in the first place.

The obvious way is to use surplus wind power to electrolyse water and produce hydrogen. It is a clean process and the only by-product is oxygen, which no-one has yet flagged up as dangerous.

Conclusion

The objective of this project may be laudable, but there is a lot of development and thinking that needs to be done.



November 23, 2018 Posted by | World | , , , , | 5 Comments

Exploring The Tyne And Wear Metro

The Tyne and Wear Metro is unique in the UK, in that it is a regional electric railway system, that is powered by 1500 VDC overhead electrification.

But what is not unique about the system is the affection shown by regular users. You get similar feelings on other local systems like these.

As they mature, other systems including the Manchester Metrolink, Midland Metro and the London Overground will be felt of by their passengers in a similar way.

My four examples and the Tyne and Wear Metro, have a lot more in common than just affection from their users.

  • All were created in their own unique ways in an era not noted for railway innovation.
  • Merseyrail has an unrivalled tunnel layout for a railway under a city.
  • The Docklands Light Railway is automated with a Train Captain on each train.
  • Glasgow’s Blue Trains were very-un-British at the time.
  • Local interests were very much involved in creating the systems.
  • The Tyne and Wear Metro was created for  Driver Only Operation.

All of these lines are seeking to add more branches and replace, update and augment the rolling stock, much of which is forty years old.

Does the age of te trains show Central Government contempt for important local railway systems, which are the lifeblood of communities?

Manchester’s Missing Tunnel

The tunnels under Liverpool and Newcastle, were part of a three pronged plan by to improve local transport in the North.

  • I remember from the 1960s, when I was at the University, the electric railway under the Mersey to Birkenhead and the Wirral. Modern it was not, but the innovative Loop and Link Project made it a lot better. Although, that project was never completed.
  • Newcastle had had Tyneside Electrics from the 1900s. In the 1970s the old system became the core of the Metro, with the addition of a central tunnel.

The third plan was to bore the Picc-Vic tunnel under Manchester to link Manchester Piccadilly and Victoria stations.

According to Wikipedia, it would have had the following characteristics.

  • Full-size twin-bore tunnels.
  • 25 KVAC overhead electrification.
  • Low-level stations at Piccadilly and Victoria.
  • Three intermediate stations at Market Street, Albert Square and Princess Street
  • Trains would have been similar to the Class 315 trains, which are still common in London.

It would have joined the suburban rail services together across the city.

How would Manchester have developed if this important tunnel had been built?

We will probably be able to partially answer this question, when the Ordsall Chord is fully operational, which will handle cross-Manchester long-distance and local trains.

It is my view that cancelling this tunnel was one of the great infrastructure mistakes of the period along with the cancellation of the Channel Tunnel and London’s Third Airport at Maplin. But then Harold Wilson believed everybody would have their own car and that railways were of the past and preferred to spend what little money the Government had on political projects, many of which were total failures.

We must protect ourselves from politicians, who have a political view that owes too much to the extreme left or right and be left to get on with our personal lives.

To my mind, it is no surprise that the cities in the UK with the best urban rail systems; London, Cardiff, Liverpool and Newcastle, have more local control. Now that Birmingham, Glasgow, Leeds and Manchester have greater local control, will we see improvement?

Exploring The Metro

There are several main assets and factors that make up a railway system.

  • Tracks
  • Tunnels and Bridges
  • Electrification
  • Stations
  • Accessibility
  • Trains
  • Signalling
  • Operating Method
  • Ticketing

I shall now give my thoughts on these in detail.

Tracks

The branches of the Metro were all built for heavy rail trains and the Sunderland Branch even shares the tracks with Class 142, Class 180 and heavy freight trains.

This principle of building tracks for full-size trains, has been used on Merseyrail’s Northern and WirralLines, London’s Trameslink, Crossrail and East London Line and innumerable railways across the world.

Build a system for small-size trains and you paint yourself into a dead end. I doubt for instance, London will ever build another new Tube-size line across London.

As I explored the Matro, the tracks also seemed to be in generally good condition.

This picture taken at South Hylton station shows typical track in apparently good condition.

Tunnels And Bridges

Wikipedia has a section on the tunnels of the Metro. This is said.

The tunnels were constructed in the late 1970s, using mining techniques, and were constructed as single-track tubes with a diameter of 4.75 metres. The tunnels under Newcastle were mechanically bored through boulder clay and lined with cast iron or concrete segments. The tunnel under Gateshead, was bored through sandstone and excavated coal seams. Old coal mine workings, some of which dated from the Middle Ages had to be filled in before the tunnelling began.

This description of the Crossrail tunnels is on this page of their web site.

A network of new rail tunnels have been built by eight giant tunnel boring machines, to carry Crossrail’s trains eastbound and westbound. Each tunnel is 21 kilometres/13 miles long, 6.2 metres in diameter and up to 40 metres below ground.

The Crossrail tunnels have a walkway on either side, but they are only 1.25 metres larger in diameter than those of the Metro. So it would appear that there is not much difference in size of the important section in the middle, where the trains run.

It is worthwhile looking at the widths of various trains.

The last three figures are from Wikipedia.

Look at these pictures of some of the tunnels and bridges on the Metro.

The weather could have been betterfor photography.

I rode on all the branches of the Metro and, I get the impression that all the bridges and tunnels seem to have been built with a generous clearance in both width and height.

I very much feel that when the Metro was built that unlike some other lines, it was well-built to a heavy rail standard.

I wouldn’t be surprised to be told, that a battery-powered train based on say an Electrostar like the Class 379 BEMU demonstrator, could pass through all of the Metro.

Electrification

The electrification is a unique 1500 VDC overhead system, which is the same as was used on the Woodhead Line, which closed to passenger trains in 1970 and to goods in 1981.

Could it be that the Metro got this voltage, rather than the 25 KVAC used on similar systems in London and Glasgow suburban routes, as British Rail and their contractors had 1500 VDC expertise available in the North and all their 25 KVAC expertise was employed elsewhere?

The bridges and tunnels seem to have been built with the ability to handle the higher and more common voltage.

1500 VDC may have also saved on the cost of the installation, as they had a lot of gantries and brackets from the Woodhead Line.

These pictures show the simplistic nature of some of the electrification.

However, on the South Hylton Branch, which was built in the 2000s, it appears that better methods were used, as these pictures show.

The gantries and supports are certainly better than many you see on the Lea Valley Lines.

This picture shows 25 KVAC electrification at Walthamstow Central station.

Note the extra insulators to deal with the higher voltage.

Would it be possible and worthwhile to convert all of the Metro lines to 25 KVAC?

In theory this must be possible, but I think it is probably more important to first beef up the electrification gantries to the higher standard of the South Hylton Branch.

Consider.

  • A driver told me, that electrification failures are not unknown.
  • Trains running on 25 KVAC are more energy-efficient.
  • Trains could be built that would be able to run on both 1500 VDC and 25 KVAC, that use the same pantograph for current collection and automatically adjust to the voltage received.
  • Trains with batteries can be used on sections without electrification.
  • Mixed voltage systems are possible, that would have 25 KVAC electrification on some sections of track and 1500 VDC on others.
  • The passenger Health and Safety case would need to be established for the higher voltage.

The electrification could be designed holistically with any future trains to maximise reliability, electrical efficiency and operational flexibility, and minimise costs.

Obviously, during the changeover to new trains, all lines would need to be at 1500 VDC, so that the current rolling stock could be used as required.

Stations

These pictures show a selection of Metro stations.

The stations appear to be in generally good condition and vary from the the basic to well-preserved Victorian stations like Tynemouth and Whitley Bay.

The platforms are generally of an adequate length, which except for some stations in tunnels seem to have been built to accept three of the current trains working together, which would be a formation 83.4 metres long.

This would be long enough to accept one of any number of four-car trains running on the UK rail network, which are usually eighty metres long. London Overground’s, new Class 710 trains will be this length.

Sunderland Station

Sunderland station, is an important station on the Metro.

I describe the station and its operation in The Rather Ordinary Sunderland Station.





Accessibility

Stations are step-free, but this is often by the use of ramps and a few more lifts woulds be welcome.

Access from platform to train is generally good, as these pictures show.

Note the picture of the access to a Grand Central Class 180 train.

I suspect that when Northern replace their Class 142 trains, with brand new Class 195 trains on the services between Middlesbrough and Newcastle, that the step-free access will be good.

I think a lot of credit is due to the original designers of the Metro, who thought about what they were doing and seem to have created a system that fitted heavy rail trains, Metro trains and users requiring step-free access.

Trains

There are several sets of electric trains in the country, that continue to defy their age and are a tribute to their builders, refurbishers and operating companies, by providing a quality service to passengers and other stakeholders

  • Merseyrail’s Class 507 and Class 508 trains.
  • The Class 315 trains of TfL Rail and the London Overground.
  • The Piccadilly Line’s 1973 Stock trains.
  • South Western Railway’s Class 455 trains.
  • The trains of the Tyne and Wear Metro.

|These pictures show the trains for the Metro.

Note.

  1. The quality is not bad for nearly forty years of service.
  2. The lady in the last picture, sitting in the front of the train, watching the world go by.
  3. Standing is not difficult in the rush hour for this seventy-year-old stroke survivor.
  4. Information could be better.
  5. The Metro needs a new train wash.

Wikipedia says this about the Proposed New Fleet.

The proposed new fleet would consist of 84 trains to replace the existing 90 train fleet, as Nexus believe that the improved reliability of the newer trains would allow them to operate the same service levels with fewer trains. These are proposed to have longitudinal seating instead of the 2+2 bench seating arrangement of the present fleet, and a full width drivers cab instead of the small driving booth of the existing trains. The proposed new fleet is planned to have dual voltage capability, able to operate on the Metro’s existing 1.5 kV DC electrification system and also the 25 kV AC used on the national rail network, to allow greater flexibility. Battery technology is also being considered.

I’ll put my ideas at the end of this note.

Signalling

The Metro is unique in the UK, in that it uses the Karlsruhe model to mix Metro trains with heavy rail trains on the Southern branch to Sunderland and South Hylton.

If in the future modern signalling and trains are used on the Metro, an increasingly intricate set of routes could be designed.

Add in dual-voltage trains able to run on both the Metro’s 1500 VDC and the National network’s 25 KVAC and the possibilities will be even greater.

Operating Method

The trains are run in the same way as London Underground, with only a driver on the train, who does the driving and controls the doors.

Ticketing

As I always find outside London, ticketing is still in the Victorian era.

Will the Tyne and Wear Metro embrace a contactless card based on bank and credit cards?

Possible Future Expansion

Wikipedia gives a list of possible extensions under Proposed Extensions And Suggested Improvements.

These include.

Tyne Dock To East Boldon

Wikipedia says this.

Tyne Dock to East Boldon along a dismantled railway alignment through Whiteleas could easily be added, because two Metro lines are separated by only a short distance (1.61 miles). This would provide a service from South Shields to Sunderland via the Whiteleas area of South Shields.

If ever there was a route for a battery-powered train, this must be it.

Consider.

  • The route is less than two miles.
  • The route connects two electrified lines.
  • You can see the disused track-bed on a Google Map.
  • No electrification would be required.
  • The battery would be charged between South Shields and Tyne Dock and East Boldon and Sunderland.
  • Modern signalling would allow the route to be built as a single track if required, handling up to ten tph in both directions.
  • Single platform stations could be built as required.

I can certainly understand, why Wikipedia mentioned battery trains.

Washington

Wikipedia says this.

Washington either via the disused Leamside line or a new route. Present planning may lead to the Leamside line being opened at least as far as Washington as a conventional rail line for passengers as well as freight, although this could be shared with Metro trains in the same way as the line from Pelaw Junction to Sunderland.

Washington station would only be a short run of less than ten miles along a reopened Leamside Line.

  • If somebody else paid for 25 KVAC electrification of the Leamside Line, then dual-voltage trains could run the service.
  • If not, they could use battery-power.

Either way, Washington would get a Metro service.

If as I believe, the new trains on the Metro will be main line trains, then what is the point of running heavy rail services to the town, as the Metro would be able to serve more places and with a change at Newcastle station, you could get a train virtually anywhere.

The possibility must also exist if the Leamside Line is developed as a diversion of the East Coast Main Line, then the Metro could go as far South as Durham.

Blyth And Ashington

Wikipedia says this about trains to Blyth and Ashington, on what is now regularly referred to as the Northumberland Line.

Blyth and Ashington, running on existing little-used freight lines. Northumberland Park station has been built to provide a link to a potential new rail service to these communities; if opened, it will not be a part of the Metro system.

Ashington is around fourteen miles from Northumberland Park station, which means that an return journey might be possible on battery-power.

In an article in the October 2017 Edition of Modern Railways, which is entitled Celling England By The Pound, Ian Walmsley says this in relation to trains running on the Uckfield Branch, which probably has a terrain not much different to the lines to Blyth and Ashington.

A modern EMU needs between 3 and 5 kWh per vehicle mile for this sort of service.

If the Metro trains could have a high energy efficiency, I think it would be reasonable to assume that 4 kWh per vehicle mile is attainable.

So a three car train, would need a battery of 14 x 2 x 3 x 4 = 336 kWh. That is not an unattainable figure for battery size.

Killingworth And Cramlington

Wikipedia says this.

A northward extension to Killingworth and Cramlington has been planned since the Metro was on the drawing board, but would require widening of the busy East Coast Main Line to four tracks, which would be expensive, and a new alignment involving street running.

Suppose the new Metro trains were modern trains, such as the latest offerings from Bombardier, CAF, Hitachi, Siemens, Stadler and others, that were able to do the following in addition to running on the Metro.

  • Use 25 KVAC electrification.
  • Operate at around or even over 100 mph.
  • Execute fast stops at a station.

Would they be able to perhaps run a four tph Metro service along the East Coast Main Line to Cramlington station?

I suspect with modern signalling and a couple of passing loops on the East Coast Main Line, the answer is yes!

This may eliminate the need for street-running.

West End Of Newcastle

Wikipedia says this.

Extending the Metro to the West End of Newcastle would require new track, involving tunnelling and bridging in rough terrain; this would be very costly and is perhaps least likely to receive funding, though would probably have the highest potential ridership.

In this article in the Newcastle Chronicle, which is entitled What Could Happen To The Metro, this is said.

A rail extension out of Central Station along the original Newcastle to Carlisle line could head along Scotswood Road to serve Newcastle’s west, while a bridge could then connect the city to the Metrocentre. This would be integrated with the Metro system. Building developments in Gallowgate have greatly reduced any chance of extending the Metro west from St James’ Park.

The railway alignment still seems to be there in places.

It would be another extension that would use battery-powered trains on sections, that don’t have electrification.

Ryhope And Seaham

Wikipedia says this.

Ryhope and Seaham, a proposal drawn up by Tyne and Wear Passenger Authority to use the existing Durham coast line south of Sunderland.

Sunderland to Seaham is about six miles, so is definitely in range of battery trains.

But that is being timid!

Sunderland to Middlesbrough is probably about thirty miles and I believe it will be possible to do those sort of distances on battery power alone, in a few years. Provided that the train could be recharged at Middlesbrough.

What would a four or six tph service between Middlesbrough and Newcastle Airport via Hartlepool, Seaham, Sunderland, Gateshead and Newcastle, do for the area?

Conclusion About Possible Future Expansion

In this section on expanding the Metro network, it has surprised me how many of the extensions could be done with dual-voltage or battery-powered trains.

  • Tyne Dock To East Boldon – Battery
  • Washington – Battery
  • Blyth And Ashington – Battery
  • Killingworth And Cramlington – Dual-Voltage
  • West End Of Newcastle – Battery
  • Ryhope And Seaham – Battery
  • Middlesbrough – Battery and Dual-Voltage

I think it shows how we must be careful not to underestimate tyhe power of battery trains. But then I’m one of the few people in the UK, outside of the residents of Harwich, who’s ridden a battery-powered four-car heavy rail train in normal service! Mickey Mouse, they are not!

New Trains

I’ll repeat what Wikipedia says this about the Proposed New Fleet.

The proposed new fleet would consist of 84 trains to replace the existing 90 train fleet, as Nexus believe that the improved reliability of the newer trains would allow them to operate the same service levels with fewer trains. These are proposed to have longitudinal seating instead of the 2+2 bench seating arrangement of the present fleet, and a full width drivers cab instead of the small driving booth of the existing trains. The proposed new fleet is planned to have dual voltage capability, able to operate on the Metro’s existing 1.5 kV DC electrification system and also the 25 kV AC used on the national rail network, to allow greater flexibility. Battery technology is also being considered.

I’ll now give my views on various topics.

Heavy Rail Train Or Lightweight Metro?

Will the trains be lightweight metro trains or variants of heavy rail trains like Aventras, Desiro Cities or A-trains to name just three of several?

The advantages of the heavy rail train are.

  • It could run at 90 or even 100 mph on an electrified main line.
  • It will meet crashworthiness standards for a main line.
  • It would likely be a design with a lot in common with other UK train fleets.
  • It could run into most railway stations.
  • If it was shorter than about sixty metres it could use all current Metro stations without station rebuilding.

On the other hand the lightweight metro train would be lighter in weight and possibly more energy-efficient.

Walk-Through Design

Wikipedia says this about the seating layout.

These are proposed to have longitudinal seating instead of the 2+2 bench seating arrangement of the present fleet.

Longitudinal seating has been successfully used on London Overground’s Class 378 trains.

  • This layout increases capacity at busy times.
  • It allows passengers to distribute themselves along the train and get to the right position for a quick exit.

But the biggest advantage, is that when linked to selective door opening, it enables a longer train to be used successfully in stations with short platforms.

London Overground use this facility on their Class 378 trains to overcome platform length problems at a few stations on the East London Line.

But train design is evolving.

Bombardier have shown with the Class 345 train, that you can have both in the same train. So in a three-car train, you might have two identical driver cars with longitudinal seating and a middle car with 2+2 bench seating.

Bombardier are able to get away with this, as they are maximising the space inside the train. I wrote about it in Big On The Inside And The Same Size On The Outside.

These pictures show the inside of one of Crossrail’s Class 345 trains.

Whoever builds the new Metro trains, they’ll probably have similar interiors.

Train Length

A trend seems to be emerging, where new fleets of trains are the same length as the ones they replace, although they may have more carriages.

This has happened on Greater Anglia, Merseyrail and West Midlands Trains.

It probably makes sense, as it avoids expensive and disrupting platform lengthening.

Currently, the Metro trains work in pairs, which means a train length of 55.6 metres. As the standard UK train carriage size for suburban multiple units is often twenty metres, then if the platforms can accept them, three-car trains would be possible for the new trains.

Longer trains would be possible in most stations, except for some in the central tunnel, which appear to have platforms around sixty to seventy metres long.

So perhaps four-car trains would be possible for the new trains, that would use selective door opening at the short platforms of the stations in the central tunnels.

Because the trains are walk-through, passengers can position themselves accordingly, for the station, where they will leave the train.

London Overground have also shown that selective door opening and walk-through trains can be used to advantage, when trains are lengthened to increase capacity.

Dual-Voltage

Obviously, the trains will have the capability of running on both 1500 VDC and 25 KVAC overhead wires, as the extension to Killingworth And Cramlington would need the latter, for a start.

The interchange between the two different voltages can be very simple, due to some technology developed for the
German cousins of the Class 399 tram-train. A ceramic rod separates the two voltages and the pantograph just rides over. The train or tram-train, then determines the voltage and configures the electrical systems accordingly.

Batteries

These would appear to be key to several of the proposed extensions.

Batteries also enable other features.

  • Movement in depots and sidings without electrification.
  • Emergency power, when the main power fails.
  • Handling regenerative braking.
  • Remote train warm-up.

In a few years time, all trains with electric drive will have batteries, that are probably around 75-100 kWh.

Operating Speed

To work efficiently on the East Coast Main Line, 90 mph or even a  100 mph operating speed will be needed.

Note that Crossrail’s Class 345 trains, which will generally work routes very similar to the Metro, have a 90 mph operating speed.

These faster trains will result in an increased service.

Currently, trains between Newcastle Airport and South Hylton take 65 minutes with sixteen stops.

Modern trains have the following features.

  • Minimised dwell times at stations.
  • Smooth regenerative braking and fast acceleration.
  • Driver Advisory Systems to improve train efficiency.
  • Higher safe speeds in selected sections.
  • Trains are designed for quick turnrounds at each end of the route.

In addition, train operators are organising station staff to minimise train delays.

Put it all together and I’m pretty certain, that this route could be done comfortably in under an hour.

So the same number of trains are able to do more trips in every hour.

Handling Tight Curves

Under Electrics, Wikipedia says this about the ability of the trains to handle tight curves.

Metro has a maximum speed of 80 km/h (50 mph), which it attains on rural stretches of line. The vehicles have a minimum curve radius of 50 m (55 yd), although there are no curves this tight except for the non-passenger chord between Manors and West Jesmond.

Could this chord be avoided by different operating procedures?

Serving Newcastle Station

Northern’s services from Newcastle station are.

  • 1 tph – Northbound on the East Coast Main Line to Cramlington and Morpeth with services extended to Chathill at peak hours.
  • 1 tph – Southbound along the Durham Coast Line to Middlesbrough calling at Heworth, Sunderland, Seaham, Hartlepool, Seaton Carew, Billingham, Stockton andThornaby, with an extension to James Cook University Hospital and Nunthorpe.
  • 1 tph – Westbound on the Tyne Valley Line to Carlisle calling at MetroCentre, Prudhoe, Hexham, Haydon Bridge, Haltwhistle, Brampton and others at alternate hours.
  • Westbound slow service on the Tyne Valley Line to Hexham calling at Dunston, MetroCentre, Blaydon, Wylam, Prudhoe, Stocksfield, Riding Mill, Corbridge and terminating at Hexham, with an extension to Carlisle at peak hours.
  • 1 tph – Newcastle to Metro Centre calling at Dunston only during the day.

Pathetic is probably a suitable word.

When Greater Anglia have their new trains, services between Ipswich, Norwich, Colchester, Bury St. Edmunds, Lowestoft and Yarmouth, will be at least two tph and sometimes three and four on most routes.

Newcastle To Sunderland Via Sunderland

Newcastle, Sunderland and Middlesbrough surely need a four tph rail connection along the Durham Coast Line.

I believe that dual-voltage Metro trains with a battery capability could run between Middlesbrough and Newcastle at a frequency of four tph.

If they can’t, I’m certain that a suitable train could be procured.

If the new Metro trains are correctly-configured heavy-rail trains, then surely a go-anywhere express version can be built.

  • Identical train bodies, cabs and traction systems to new Metro trains
  • An interior geared to the needs of passengers.
  • Four or five cars with selective door opening.
  • Ability to run on Metro tracks using 1500 VDC overhead wires.
  • Ability to run on 25 KVAC overhead wires.
  • Batteries for regenerative braking, emergency power and distances up to two miles.
  • Diesel or preferably hydrogen power pack.
  • Sufficient range to keep going all day.
  • 90-100 mph capability.

As the trains would have an identical cross-section to the new Metro trains, they could do any of the following at Newcastle.

  • Terminate at Newcastle station.
  • Go through Newcastle station to Metrocentre, Hexham, Carlisle, Morpeth or some other destination.
  • Go through the tunnel of the Metro to Newcsastle Airport.
  • Go through the tunnel of the Northumberland Park station to link to the North-East.

I believe that such a train could run as an express to link the whole conurbation from Middlesbrough to Morpeth together.

Newcastle To Carlisle Via Metrocentre and Hexham

The train that i just proposed would be ideal for this route.

I also believe that Metrocentre needs at least six tph connecting it to the centre of Newcastle and the Metro.

The proposed West End of Newcastle branch of the Metro looks to be a necessity, to provide some of this frequency.

What Is The Point Of Northern?

With the right trains, all of the local services in the Tyne-Wear-Tees area can be satisfied by a Metro running modern trains making the maximum use of modern technology.

This model already works in Merseyside, so why not in the North-East? And Manchester, Leeds and South Yorkshire!

A Tees Valley Metro

I have always been keen on the creation of a Tees Valley Metro. I wrote about it in The Creation Of The Tees Valley Metro.

Get the design of the trains on the Tyne and Wear Metro right and they could work any proposed Tees Valley Metro.

Conclusion

I think that Nexus will get some very interesting proposals for their new trains, which will open up a lot of possibilities to extend the network.























February 5, 2018 Posted by | Energy Storage, Transport | , , , , | Leave a comment

Have Train, Will Travel

This article in the underland Echo is entitled Metro bosses unveil plans to extend network, including direct link between Sunderland and South Tyneside.

This is the opening couple of paragraphs.

Ambitious plans to extend and expand the region’s rail and Metro networks have been drawn up by public transport bosses.

The scheme – to be presented to the North East Combined Authority (NECA) – could see a direct link between Sunderland and South Tyneside and the network extended as far as Washington and Peterlee.

It is a comprehensive plan, that takes note and advantage of the best practice and technology from around the world.

The Proposed New Routes

Plans for the Tyne and Wear Metro include.

  1. Sunderland City Centre to Doxford Park using the route of the former Hetton Colliery Railway.
  2. New Routes From South Tyneside by linking the South Shields and Sunderland routes, using an existing single-track railway in the region of Tyne Dock.
  3. A Wearside Loop can be created to serve Washington using existing rail routes.
  4. The Leamside Line could be used as a new Metro route.
  5. Re-electrification of Sunderland to 25 KVAC would give advantages to Network Rail and allow Metro services to go South.
  6. Dualling of the track through South Tyneside.

Every plan seems to have serious element of using former and existing routes in a creative manner.

This map shows how the network could look in a few years.

metro-futures-map-july-2016

The Metro Has A Touch Of The Karlsruhes

What many forget about the Metro, is that it some of its operation on the Sunderland route is based on a modified form of the Karlsruhe model, where heavy rail passenger and freight trains, share tracks with the Metro.

I was surprised once on a station on the Metro to see a Grand Central High Speed Train come through.

The last two improvements listed above; 5 and 6, use this capability.

The Durham Coast Line runs from Newcastle to Middlesborough and the East Coast Main Line, via Sunderland and Hartlepool. The only electrified section of this line is that which is used by Metro trains.

If new Metro trains could run on their current 1500 VDC and 25 KVAC, then if the line was fully electrified, the following benefits, would be realised.

  • Metro trains could go as far South as Middlesbrough.
  • Grand Central could run electric trains to Middlesbrough, Hartlepool and Sunderland.
  • There would be a second electrified route South from Newcastle, for use as a diversion.
  • Network Rail would get maintenance advantages, as the electrification is network standard.

So we would see Metro trains sharing the route with high speed passenger trains like Class 800s and electrified freight.

The South Tyneside Dualling would incorporate the freight line to the Jarrow Oil Terminal into the Metro. I think that the line would be arranged, so that if freight ever needed to use the line, the Karlsruhe model would apply.

It looks to me that this dualling and the upgraded electrification through Sunderland would be done together.

New Trains

New trains are also mentioned and in this article on Global Rail News. This is said.

Nexus, the Tyne and Wear region’s Passenger Transport Executive (PTE), said it would look to procure a new fleet of multi-system trains capable of operating on the Metro’s 1.5 kV DC electrification system and the 25 kV AC used on the national rail network. Battery technology is also being considered for short sections of non-electrified line.

Looking at the map, there are a couple of short new lines, that might be ideal for IPEMUs.

Conclusion

Taken as a whole, it is good well-thought out plan.













July 16, 2016 Posted by | Transport | , , , | Leave a comment

The Updating Of Newcastle Station

Newcastle station is one of the most important stations on the East Coast Main Line. I took these pictures of the station redevelopment as I passed through.

My memories of the station usually involve how blustery it can be. The glazing of the front of the station, may not be as dramatic as that at Strasbourg, but it did seem to make the station entrance a lot more civilised. The position of the ticket machines and information screens under the portico, is an idea that could have been borrowed from the French station, with which it shares a lot of operational characteristics, like fast trains to the capital, an extensive regional network and a below-ground metro or tram.

Newcastle has now joined Kings Cross and Liverpool Lime Street, where you can walk straight outside the station and be in a partly-pedestrianised area, where you can get your bearings of the city, that might be unknown to you. As the pictures show work is still continuing in this area.

Newcastle is one of six operational stations in the UK, that is a Grade One Listed Building. The others are Bristol Temple Meads, Huddersfield, Kings Cross, Paddington and St. Pancras. I can see Manchester Victoria joining this elite group, when it is completed.

March 13, 2015 Posted by | Transport | , | Leave a comment
